WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE. DO NOT REMOVE COVER.
PILOT LAMPS SOLDERED IN PLACE. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
R I S K O F E L E C T R I C
SHOCK DO NOT OPEN
The lighting flash with arrowhead
symbol, within an equilateral triangle,
CAUTION: TO REDUCE THE RISK OF
is intended to alert user to the
ELECTRIC SHOCK, DO NOT REMOVE
presence of uninsulated "dangerous
COVER (OR BACK). NO USER –
voltage" within the product's
SERVICEABLE PARTS INSIDE. REFER
enclosure that may be of sufficient
SERVICING TO QUALIFIED SERVICE
magnitude to constitute risk of electric
PERSONNEL.
shock to persons.
* The appliance is not intended to be operated by means of an external timer or separate remote-
control system.
* This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance. Cleaning and user maintenance shall
not be made by children unless they are older than 8 and supervised.

Specifications

FREQUENCY
: FM 88 -108 MHz
USB 2.0 PORT
: Full Speed 512MB - 4GB
SD CARD SLOT
: 512MB – 4GB
POWER SOURCE
: AC 230V-50Hz
ANTENNA
: External antenna for FM
POWER CONSUMPTION
: 18W
SPEAKER SIZE
: 2 x 4" x 4" 8 ohm Dynamic type
REMOTE CONTROL
: A Cell battery is fitted -
Replacement Lithium Battery required : 1 x 3V CR2025
*DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
Coopers of Stortford, 11 Bridge Street, Bishop's Stortford,
Hertfordshire, CM232JU. Tel 0844 482 4400.
IMPORTANT SAFEGUARDS FOR AUDIO PRODUCTS
The exclamation point within an
equilateral triangle is intended to alert
user to the presence of important
operating and maintenance (servicing)
instruction in the literature
accompanying the appliance.
AM 530 - 1600 KHz
(Support FAT16, FAT32)
Built-in ferrite bar for AM
INSTRUCTION MANUAL
910-294700-0020-100
MODEL: 8714

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8714 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stortford 8714

  • Page 1: Specifications

    : A Cell battery is fitted - Replacement Lithium Battery required : 1 x 3V CR2025 *DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE. Coopers of Stortford, 11 Bridge Street, Bishop's Stortford, Hertfordshire, CM232JU. Tel 0844 482 4400. MODEL: 8714...

  • Page 2: Control Locators

    RE-ATTACHING THE TURNTABLE DRIVE-BELT CONTROL LOCATORS The turntable drive belt is factory fitted - use these instructions only if the turntable fails to revolve. Speakers STEP 1 STEP 3 Use a screwdriver to remove the black iron To fix the turntable back onto the phonograph mechanism, C-clipand lift the turntable off the DIAL SCALE PLATE make sure the column point is positioned over the correct...

  • Page 3: Radio Operation

    PROGRAMMING TRACKS UNPACKING Up to 20 tracks can be programmed to play tracks on an Audio or MP3-CD, USB Device or SD Card in the desired sequence. 1. Remove packing materials from unit. NOTE: Save all packing materials until you are completely satisfied all parts of the unit are operating satisfactorily. 1.

  • Page 4: Important Safeguards For Audio Products

    Dispose of the item at the end of its lifespan at your local authorised household waste recycling centre. 17. Damage Requiring Service - The appliance should be serviced by qualified service This item is supplied by: personnel only. Coopers of Stortford 11 Bridge Street, Bishop’s Stortford. Hertfordshire.
  • Page 5 CONTROL LOCATORS Recording from Phono to SD / USB The system is capable of converting an audio signal from PHONO input (record player) into MP3 format and store it on a USB mass storage device or SD card (the default is USB if both devices are detected). Prepare for playing a record, as SPINDLE ADAPTOR FOR 45 RPM RECORDS described previously.

  • Page 6: Playing A Record

    PLAYING A RECORD USB & SD CARD OPERATION 1. Place record on turntable. Switch the unit ON by turning the power ON-OFF SWITCH/VOLUME CONTROL switch to SD Card Operation: the ON position. Note there is a gap at the rear of the wooden casing to allow for larger 33 or 78rpm records to fit the 1.
