Two or three light reciprocal movements are enough for testing, do not make excessive
efforts when move the banknote to-and –fro.
Avoid touching magnetic sensor with fingers and metallic objects during test procedure.
Cell phones in calling mode can cause electromagnetic interference.
Figure 6
Remote 10x mouse is used to examine external features, allows to see extremely small
details and accurately control print structure.
Tested features:
absence of mechanical erasures,
accuracy of the pattern, anti scanner net, continuity of lines, presence of visible fibers,
microprinting, watermarks, fibers with microprinting. Connect power cord of the remote
mouse to the mains.
Place the mouse on the examined patter of a banknote. Switch on lightning. (Fig. 1-7).
To see the maximum size of the image lean to the mouse with your eye right at the lens
One can also use the mouse with batteries (AAх2), autonomously from the mains.
14
Attention: imitation of magnetic ink on
counterfeit banknotes produced by spread-
ing magnetic substances on a pattern is
possible.
Such banknotes can cause sensor snap
into action at a location where should be no
ink and on the contrary, where it is present.
Attention: some types of copiers, laser
printers and other devices also contain
magnetic substances which snap sensor
into action.

Remote mouse operation
