- Page 1 Workshop Manual for MesCom © Dycon Ltd 2012 Tel: +44 (0)1443 471 060 Fax: +44 (0)1443 479 374 Cwm Cynon Business Park – Mountain Ash – CF45 4ER - UK www.dyconsecurity.eu sales.en@dyconsecurity.eu...
-
Page 2: Table Of Contents
.......................... 36 EFAULT OINT ABELS ........................ 37 EFAULT OINT VARIABLES ........................ 37 EFAULT OINT ONTROL LAGS USE WITH A PRE‐PAY SIM CARD ...................... 38 EXPANSION............................ 38 APPENDIX 1 ‐ SPECIFICATION ...................... 39 APPENDIX 2 ‐ GLOSSARY OF TERMS .................... 40 MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 3: Description
The board temperature sensor has an accuracy ±2°C. All ports with the exception of the antenna and battery are 30v tolerant. All input and output can be configured to suit the user’s application. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 4: Connections
LED2 Power supply Status Indication Antenna connector 9-30Vdc 500mA* Open collector Ground Inputs; Voltage or volt-free contact OP & IP 3V max (30V overvoltage protected) outputs 100mA 30V max common MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... - Page 5 4-20mA sensors. R = 3/max current The MesCom can be configured Device to monitor for volt-free contacts. Allowing Input relay contact to be connected to the inputs. Volt-free contact MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 6 MesCom output is protected again back EMF and therefore the protection diode shown is optional but recommended. Output Relay coil Relay coil 60mA max Supply 30V max Optional reverse EMF protection diode MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
-
Page 7: Commissioning
The MesCom is not fitted with fuse or overvoltage/polarity protection incorrectly connecting a PSU with damage the device. Connect a suitable supply to the power terminals being careful to observe polarity. And switch the supply on. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 8: Configure
#nnnnn to be ADC count HYST Threshold hysteresis 0.0 to 3.0 (volts) or in format #nnnnn to be ADC count PNAME The point identifying name a string (no spaces) of up-to 24 characters MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 9: Configure Outputs
(max 4) a fail message will be returned. If the number is omitted then the sender’s number will be added to the user list. Adding a number that is already on the user list will not create a duplicate. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 10: Normal Operation
3 delay before changing to final value, 4 final value to set point to. Attempting to PULSE a point that isn’t an output will have no effect. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 11: Disable Faulty Input
This command will stop you receiving any more notifications REMOVE Note name password or arguments are required or permitted in the special case. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 12: Advanced
Name of level Name of level Name of level Analogue when below when between when between when between when above Input Bottom Bottom and Low and High High and Top 9876 POINT Input2 LEVELS Empty Low Normal High Full MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... - Page 13 Digital Input Input High/low 9876 POINT Input2 THRES 1.0 3.0 3.0 3.0 HYST 0.0 Or 9876 POINT Input2 THRES 0.5 3.0 3.0 3.0 HYST 2.0 LEVELS Level 1 Level 2 Level 3 Level 4 Level 5 Digital Input Name given Name given to low signal to High signal 9876 POINT Input2 LEVELS Off On na na na MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 14 Name given Name given to overflow to threshold crossed 9876 POINT Input2 LEVELS overflow threshold na na na Counters can be configured to record the number of changes from high to low and low to High state. 9876 POINT Input4 TYPE 2 COUNT POS MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 15 Level 3 Level 4 Level 5 Timer Name given Name given to overflow to threshold crossed 9876 POINT Input2 LEVELS overflow threshold na na na Timers can be configured to record time in either High or Low state. 9876 POINT Input4 TYPE 1 COUNT POS MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 16 LEVELS Level 1 Level 2 Level 3 Level 4 Level 5 Digital Name given Name given Output to off to on 9876 POINT Input2 LEVELS Off On na na na Hysteresis setting has no effect in Digital Outputs MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
-
Page 17: Debounce And Averaging
The input signal has a modified moving average applied to it. New Value = current value x (samples-1) + new reading samples 3.0v Full Threshold High Input Signal High Threshold Normal Point Value Threshold Bottom Threshold Empty Hysteresis MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 18: Point Scaling
Label for out-of-range (over) reading a string (no spaces) of up to 16 characters 9876 POINT Input2 READMIN 0.6 READMAX 2.6 DISPMIN 12 DISPMAX 42 9876 POINT Input2 SUFFIX psi UNLIM short OVLIM open DISPMAX Over Range DISPMIN Under Range Input Voltage 0.0v 3.0v READMIN READMAX Input ADC count 65535 MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 19: Point Action Flags
The input will report it disables/enables itself. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... - Page 20 : 0-65535 number of transitions : 0-65535 decay constant : 0-65535 suspend time SUSPEND Time after an point change to ignore 0-65535 suspend time further changes on that point MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
-
Page 21: Option Command
CKINT Clock update interval Number of minutes Min 0 (0 disables) 32767 CKSRC Default clock source 0 – manual only 1 – GSM if available. 2-255 reserved for future use MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... - Page 22 INI1 First radio module init string String max 60 characters INI2 Final radio module init string String max 60 characters BEARER Cell bearer select type string String max 10 characters MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 23 Primary communication device and how it is attached COMMMODE Answer incoming, reply to sms, ringback etc. MSGTIME Message timeout within a call CMDEXP maximum age of an incoming email/sms command that should actioned MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
-
Page 24: View Command
Reinstate a blank password to ‘newWord’, if more than one password is blank then the high level password in reinstated first. Passwords are case sensitive If 2 password levels have the same password the higher level access will be assumed. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 25: Commands
Input3: Clear Input4: Clear Op1: On Op2: Off 04/04/12,16:15:25 5566 READ 6 7 8 MesCom: Status: Input1: Clear Input2: Clear Input3: Clear 04/04/12,16:15:25 Notes ALL keyword will list all enabled points MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... - Page 26 5566 PULSE Op1 Off 1500 MesCom: Status: Op1: Off 04/04/12,16:15:25 5566 PULSE 10 0 1500 1 MesCom: Status: Op1: Off 04/04/12,16:15:25 Notes Attempting to pulse an input will have no effect MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 27 ADDNUM Add the sender’s number to the user list Access level required password Arguments Min 0 Max 0 Examples ADDNUM MesCom: ADDNUM Successful 04/04/12,16:15:25 Notes Any arguments will be ignored MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 28 MesCom: DISABLE 2 POINT Battery 04/04/12,16:15:25 5566 DISABLE ALL MesCom: DISABLE 11 POINT 04/04/12,16:15:25 5566 DISABLE 6 7 8 MesCom: DISABLE 3 POINT 04/04/12,16:15:25 Notes ALL keyword will disable all points MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 29 MesCom: ENABLE 2 POINT Battery 04/04/12,16:15:25 5566 ENABLE ALL MesCom: ENABLE 11 POINT 04/04/12,16:15:25 5566 ENABLE 6 7 8 MesCom: ENABLE 3 POINT 04/04/12,16:15:25 Notes ALL keyword will enable all points MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 30 MesCom: MODE LANGUAGE DEBUG ENCRYPT SAMPLE LOGINT HEALTH SYNC BAUD SERFOR FLWCTRL XOFF PSAVE WAKE SLEEP REBOOT REGINT INP REGFAIL REGBOOT IDLE MAXLEN IDENT TIME PIN INI1 INI2 BEARER ICCID IMEI 04/04/12,16:15:25 MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 31 MesCom: REMOVE Successful 04/04/12,16:15:25 Notes This command will not be recognised if a password is prefixed Any arguments will be ignored This command will stop you receiving any more notifications MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 32 5566 VIEW OPTION ALL MesCom: OPTION: 04/04/12,16:15:25 Notes ALL keyword will list all user, options and settings for a specific point ALL is not a valid argument for the point number MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 33 ALL keyword allows user to change all settings in a list format as per order given by HELP POINT command ALL is not a valid argument for the point number Please Note All labels Must contain No spaces, we suggest underscore is used instead MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
- Page 34 HELP OPTION command, an incomplete list is permitted. ALL is not a valid argument for the point number Please Note All labels Must contain No spaces, we suggest underscore is used instead MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
-
Page 35: Factory Defaults
The read only access level is the same as the control level but does not allow the use of SWITCH and PULSE commands, for typical installation this access level is redundant and should be ignored. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 36: Default Point Configuration
Clear Press Power UnderV OverV Battery Fail Good High Temperature vLow Cold Norm Fire Alarm Normal Intruder Alarm Normal P.A. Alarm Normal Status Unset Use the POINT command to change. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 37: Default Point Variables
These control what actions should be taken by the point Point Name Enabled Count Alarm Logs Email Unsol Call Modem Button Power Battery Temperature Input1 Input2 Input3 Input4 Use the POINT command to change MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 38: Use With A Pre-Pay Sim Card
The MesCom is designed with an expansion port which could allow additional inputs and outputs or an interface to another control system or meter. Please contact us to discuss your requirements. MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 39: Appendix 1 - Specification
Typically 50mA at 12v International Radio Approval The D6000 MesCom incorporates an independently tested and approved GSM/GPRS radio module that meets the requirements of European radio communication standards. Approval Authority: CE0889 MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013... -
Page 40: Appendix 2 - Glossary Of Terms
Semiconductor device used to isolate a signal, for either safety or electrical reasons. Back EMF Reverse voltage (Electro Motive Force) generated when an inductive load is switched off For additional explanation please refer to the internet http://encyclopedia.thefreedictionary.com/ http://www.acronymfinder.com/ MesCom – Operation Manual – D6000OP-EU/j13/V5 © Dycon Ltd 2013...
