Puget V752i User Manual

Table of Contents

Quick Links

Download this manual

V12.3.00(W8)

Table of Contents

Summary of Contents for Puget V752i

Page 1 V12.3.00(W8)
Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Eup-Standby And Off Mode Power Consumption Statement
Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5 Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.
Page 6: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 7: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 8: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 9: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 10 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 11: Power Safety
Preface Power Safety The computer has specific power requirements:  • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.
Page 12: Polymer Battery Precautions
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Page 13: General Battery Precautions
Preface General Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 14: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 15: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 16 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 17 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 18: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 19: Table Of Contents
Preface Contents Notice ................................I EuP-Standby and Off Mode Power Consumption Statement: ..............II FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Power Safety ...............................IX Polymer Battery Precautions ........................X General Battery Precautions ........................XI Cleaning ..............................
Page 20 Preface System Map: LCD Panel Open - Model A ....................1-7 System Map: LCD Panel Open - Model B ....................1-8 LED Indicators ............................1-9 Hot Key Buttons (Model B) ........................1-11 Keyboard ..............................1-12 Function Keys & Visual Indicators ......................1-13 Control Center ............................1-14 System Map: Front & Left Views ......................1-15 System Map: Right &...
Page 21 Preface DVD Regional Codes ..........................2-5 Multi-in-1 Card Reader ..........................2-6 Audio Features ............................2-7 Setup for Audio Recording ........................2-8 TouchPad and Buttons/Mouse ........................2-9 One-Finger ...............................2-13 Multi-Finger .............................2-15 Additional ..............................2-18 Power Management Overview ..............................3-1 The Power Sources ............................3-2 AC/DC Adapter ............................3-2 Battery ................................3-2 Turning On the Computer ..........................3-3 Power Plans ...............................3-4 Power-Saving States ..........................3-6...
Page 22 Preface Power Conservation Modes ........................3-10 Battery Information ..........................3-11 Conserving Battery Power ........................3-12 Battery Life ..............................3-13 New Battery .............................3-13 Recharging the Battery with the AC/DC Adapter ...................3-13 Proper handling of the Battery Pack ......................3-14 Battery FAQ .............................3-15 Drivers & Utilities What to Install ............................4-1 Module Driver Installation ........................4-1 Driver Installation ............................4-2 Manual Driver Installation .........................4-4...
Page 23 Preface LAN ................................4-6 Card Reader ...............................4-7 TouchPad ..............................4-7 Hot Key ..............................4-7 USB 3.0 (Win 7 Only) ..........................4-7 MEI Driver ..............................4-7 Audio .................................4-7 Windows Experience Index ........................4-8 Optional Drivers ............................4-9 BIOS Utilities Overview ..............................5-1 The Power-On Self Test (POST) .......................5-2 Failing the POST ............................5-3 Fatal Errors ..............................5-3 Non-Fatal Errors ............................5-3 The Setup Utility ............................5-4...
Page 24 Preface System/Extended Memory (Main Menu) ....................5-7 MB Series / BIOS Revision / KBC/EC Firmware Revision (Main Menu) ..........5-7 Advanced Menu ............................5-8 Intel Anti-Theft Technology (Advanced Menu) ..................5-9 SATA Mode (Advanced Menu) ........................5-9 Boot Logo (Advanced Menu) ........................5-9 Power On Boot Beep (Advanced Menu) ....................5-9 Battery Low Alarm Beep (Advanced Menu) .....................5-9 Security Menu ............................5-10 Set Supervisor Password (Security Menu) ....................5-10...
Page 25 Preface Removing the Component Bay Cover .......................6-5 Replacing the Component Bay Cover .......................6-7 Upgrading the Hard Disk Drive(s) ......................6-8 Upgrading the Optical (CD/DVD) Device ....................6-13 Removing the Optical Device Drive for Model A Computers ..............6-14 Removing the Optical Device Drive for Model B Computers ..............6-15 Upgrading the System Memory (RAM) ....................6-16 Modules Overview ..............................7-1...
Page 26 Preface PC Camera Driver Installation .........................7-16 PC Camera Audio Setup ..........................7-17 Wireless LAN Module ..........................7-23 3rd Party WLAN Driver Installation (for WLAN Module) ..............7-24 3rd Party WLAN Driver Installation (for Combo Module) ..............7-25 Intel® WLAN Driver Installation ......................7-26 Connecting to a Wireless Network in Windows 7 ...................7-29 Connecting to a Wireless Network Using Intel®...
Page 27 Preface Wireless Manager ............................7-71 Wireless Manager Installation .........................7-71 Wireless Manager Application ........................7-72 Profiles ..............................7-75 Settings ..............................7-79 Text Messaging Service (SMS) .......................7-82 SMS Utility ..............................7-82 Sending a Text Message ..........................7-84 Phonebook ...............................7-87 SMS Settings ............................7-90 Sierra Wireless AirCard Watcher ......................7-93 Sierra Wireless AirCard Watcher Installation ..................7-93 AirCard Watcher Application ........................7-94 Air Card Watcher Menu ..........................7-98 Selecting a Network Operator/Service Provider ..................7-99...
Page 28 Preface THX TruStudio AP Installation ......................7-107 THX TruStudio Pro Activation ......................7-108 THX TruStudio Pro Application ......................7-108 Intel® Rapid Storage Technology Driver ....................7-112 Intel® Smart Response Technology ......................7-113 Enabling Intel Smart Response Technology ..................7-114 Intel® Rapid Start Technology Driver ....................7-117 Intel® Rapid Start Technology Configuration ..................7-118 Intel®...
Page 29 Preface Ports and Jacks ............................A-2 Card Reader ..............................A-2 DC-In Jack ..............................A-2 DVI-Out Port ............................A-2 e-SATA / USB 3.0 Combo Port .......................A-2 HDMI-Out Port ............................A-3 Headphone-Out Jack ..........................A-3 Microphone-In Jack ..........................A-3 RJ-45 LAN Jack ............................A-3 S/PDIF-Out Jack ............................A-3 Security Lock Slot ............................A-3 USB 2.0/1.1 Ports .............................A-4 USB 3.0 Port .............................A-4 Control Center...
Page 30 Preface Display Devices & Options ........................C-7 Attaching Other Displays .........................C-8 Configuring an External Display in Windows 7 ..................C-11 NVIDIA Control Panel ...........................C-14 Optimus™ Customization Options ......................C-16 Set PhysX® Configuration ........................C-20 Video Settings ............................C-21 HDMI Audio Configuration ........................C-22 Specifications Processor ..............................D-2 Core Logic ..............................D-3 Memory ..............................D-3 Display ..............................D-3...
Page 31 Preface Communication ............................D-5 Security ..............................D-5 Features ..............................D-5 Operating System ............................D-6 Power Management ..........................D-6 Power ................................D-6 Environmental Spec ..........................D-6 Physical Dimensions & Weight ........................D-6 Windows 8 Overview ..............................E-1 Windows 8 Start Screen & Desktop ......................E-2 Apps & Tiles ............................. E-3 Desktop Application ..........................
Page 32 Preface Power Options ............................E-18 Running Metro UI Apps ......................... E-21 Drivers & Utilities ..........................E-23 Driver Installation (Windows 8) ......................E-24 PC Camera (Windows 8) ........................E-26 Metro UI Camera App ..........................E-27 Taking Pictures/Capturing Video ......................E-29 Wireless LAN Settings (Windows 8) ..................... E-31 WLAN Configuration in Windows 8 .....................
Page 33: Quick Start Guide Overview
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 34: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 35: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.
Page 36: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 7 (with Service Pack 1 in- stalled) and Windows 8 operating systems are supported.
Page 37: Model Differences
Quick Start Guide Model Differences This notebook series includes two different model types that mainly differ as indicated in the table below. Note that your model may appear slightly different from those pictured in this manual. Feature Model A Model B 15.6”...
Page 38: System Startup
Quick Start Guide System Startup Remove all packing materials and place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 39: System Map: Lcd Panel Open - Model A
Quick Start Guide System Map: LCD Panel Open - Model A Figure 1 - 2 LCD Panel Open - Model A Built-In PC Camera (Optional) PC Camera LED Power Button Top Case LED Indicators WLAN Hot Key Button GPU Button Speakers Keyboard Note that the Touchpad and...
Page 40: System Map: Lcd Panel Open - Model B
Quick Start Guide System Map: LCD Panel Open - Model B Figure 1 - 3 LCD Panel Open - Model B Built-In PC Camera (Optional) PC Camera LED Power Button GPU Button Speakers Top Case LED Indicators) Hot Key Buttons Keyboard 10.
Page 41: Led Indicators
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Number Lock is Activated (press Num Lk) Orange AC/DC Power is Plugged In Green Caps Lock is Activated (press Caps Lock) Green...
Page 42 Quick Start Guide Icon Color Description Green UMA Mode Activated (GPU Button)  Orange Optimus Mode Activated (GPU Button) Wireless Device Operation Orange NVIDIA Discrete GPU (dGPU) Activated Aboard Aircraft The use of any portable electronic transmis- Green Intel Integrated GPU (iGPU) Activated sion devices aboard aircraft is usually prohib- ited.
Page 43: Hot Key Buttons (Model B)
Quick Start Guide Hot Key Buttons (Model B) Press the hot key buttons on the computer to toggle the appropriate function on/off. Icon Color Description Green UMA Mode Activated (GPU Button) Orange Optimus Mode Activated (GPU Button) Power On/Off the (optional) PC Camera Mute On/Off Power On/Off the (optional) Wireless LAN Module...
Page 44: Keyboard
Quick Start Guide Keyboard  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See If your keyboard is dam- Table 1 - 5, on page 1 - 13 for full function key combination details and Appendix E aged or you just want to...
Page 45: Function Keys & Visual Indicators
Quick Start Guide Function Keys & Visual Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Visual in- dicators (see the table below) are available when the Hot Key driver is installed. Keys Function/Visual Indicators Keys...
Page 46: Control Center
Quick Start Guide Control Center Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and en- ables you to quickly turn modules on/off (see Appendix B for full details).
Page 47: System Map: Front & Left Views
Quick Start Guide System Map: Front & Left Views Figure 1 - 6 Front & Left Views 1. LED Indicators 2. Security Lock Slot 3. USB 2.0 Port 4. S/PDIF-Out Jack 5. Microphone-In Jack 6. Headphone-Out Jack 7. Optical Device ...
Page 48: System Map: Right & Rear Views
Quick Start Guide System Map: Right & Rear Views Figure 1 - 7 Right & Rear Views 1. Multi-In-1 Card Reader 2. 2 * USB 3.0 Ports 3. Combined eSATA/ USB 3.0 Port 4. HDMI-Out Port 5. RJ-45 LAN Jack 6.
Page 49: System Map: Bottom View - Model A
Quick Start Guide System Map: Bottom View - Model A Figure 1 - 8 Bottom View Model A Component Bay Cover Battery Primary HDD Bay Fan Outlet/Intake  Battery Information Always completely dis- charge, then fully charge, a new battery before using it.
Page 50: System Map: Bottom View - Model B
Quick Start Guide System Map: Bottom View - Model B Figure 1 - 9 Bottom View Component Bay Cover Battery Primary HDD Bay Fan Outlet/Intake  Battery Information Always completely dis- charge, then fully charge, a new battery before using it. Com- pletely discharge and ...
Page 51: Windows 7 Start Menu & Control Panel
Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 are accessed from the Start menu (see pendix E for information on the Windows 8 OS). When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 52: Video Features
Quick Start Guide Video Features ® NVIDIA Optimus Technology ™ NVIDIA Optimus technology is a seamless technology designed to get best performance from the graphics ® ™ system while allowing longer battery life, without having to manually change settings. When the computer is in Optimus Mode it will automatically switch between the integrated UMA (Unified Memory Architecture) GPU (iGPU) and the discrete GPU (dGPU) when required by the applications in use.
Page 53 Quick Start Guide To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel. Click Display (icon) - In the Appearances and Personalization category. Click Adjust Screen Resolution/Adjust resolution. Alternatively you can right-click the desktop and select Screen resolution. Use the dropbox to select the screen Resolution (Figure 1 - 11).
Page 54 Quick Start Guide To access the Intel(R) Graphics and Media Control Panel: Click Advanced settings (Figure 1 - 11 on page 1 - 21) in the Display Settings control panel in Windows. Click Graphics Properties (button) (Figure 1 - 12) in the Intel Graphics & Media Control Panel tab. Right-click the desktop and select Graphics Properties from the menu.
Page 55 Quick Start Guide To access the NVIDIA Control Panel: Right-click the desktop and select NVIDIA Control Panel (Figure 1 - 13). Double-click the icon (Figure 1 - 13) in the Windows control panel. Figure 1 - 13 - NVIDIA Control Panel Video Features 1 - 23...
Page 56: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 19 or see pendix E for information on the Windows 8 OS) allows you to configure power management features for your computer.
Page 57: Storage Devices, Audio & Mouse Overview
Storage Devices, Audio & Mouse Chapter 2: Storage Devices, Audio & Mouse Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • Multi-in-1 Card Reader •...
Page 58: Hard Disk Drive
Storage Devices, Audio & Mouse Hard Disk Drive  The hard disk drive(s) is(are) used to store your data in the computer. The hard Power Safety disk(s) can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 59: Optical Device
Storage Devices, Audio & Mouse Optical Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page D - 4). The Adjustment optical device is usually labeled “Drive D:”...
Page 60: Handling Cds Or Dvds
Storage Devices, Audio & Mouse Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 61: Dvd Regional Codes
Storage Devices, Audio & Mouse DVD Regional Codes  To change the DVD regional codes: DVD Region Note Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD region detection is DVD/CD-ROM drives. device dependent, not Double-click on the DVD-ROM device to bring up the Properties dialog box, and OS-dependent.
Page 62: Multi-In-1 Card Reader
Storage Devices, Audio & Mouse Multi-in-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 63: Audio Features
Storage Devices, Audio & Mouse Audio Features  You can configure the audio options on your computer from the Sound control THX TruStudio Audio panel in Windows, or from the Realtek HD Audio Manager icon in the notifi- Note that you will need to cation area/control panel (right-click the taskbar notification area icon to bring up install the THX TruStudio...
Page 64: Setup For Audio Recording
Storage Devices, Audio & Mouse Setup for Audio Recording To record audio sources on your computer at optimum quality follow the instruc- tions below: Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View. Click Realtek HD Audio Manager (or right-click the taskbar icon and select Sound Manager).
Page 65: Touchpad And Buttons/Mouse
Storage Devices, Audio & Mouse TouchPad and Buttons/Mouse  The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 66 Storage Devices, Audio & Mouse Elan TouchPad  Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 7) you can configure the functions by double-clicking the TouchPad driver icon in the Mouse Driver notification area of the taskbar (or from Options in the ELAN tab in the Mouse If you are using an ex- control panel in Windows).
Page 67 Storage Devices, Audio & Mouse The Elan Smart-Pad control panel allows you to use a specific gesture (action) on the surface of the TouchPad to perform specific actions to manipulate documents, objects and applications. Click the menu tabs (One-finger, Multi-finger or Additional) and then the function button on the left to access the Configuration controls in the right panel.
Page 68 Storage Devices, Audio & Mouse Click the Function Description button to get a detailed description of any func- tion. Click the Default button to set any of the functions to the default setting. Figure 2 - 9 Smart-Pad Control Panel with Function Description 2 - 12 TouchPad and Buttons/Mouse...
Page 69: One-Finger
Storage Devices, Audio & Mouse One-Finger Tapping The Smart-Pad supports one, two and three finger tapping, all configured from the Tapping control panel in the One-finger tab. You can configure two or three finger tapping to perform a number of different functions by selecting them from the drop- down menus provided.
Page 70 Storage Devices, Audio & Mouse Drag and Drop You can select the different drag and drop methods from the menu provided. The ob- ject can be released when you lift the finger off the TouchPad, when you tap again or after a set time delay. Figure 2 - 12 Drag and Drop Edge Scroll...
Page 71: Multi-Finger
Storage Devices, Audio & Mouse Multi-Finger Zooming Place two fingers on the TouchPad (for best results use the tips of the fingers) and slide them apart to zoom in, or closer together to zoom out. Figure 2 - 14 Zooming Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically.
Page 72 Storage Devices, Audio & Mouse Rotation You can rotate objects by using a two-finger gesture. Touch and rotate using two fin- gers on the pad in the direction required. Alternatively place a finger down on the pad and rotate the other finger around it in a circular motion (clockwise or counter- clockwise).
Page 73 Storage Devices, Audio & Mouse Fast Keys The Fast Keys gesture allows you to switch windows or open My Computer. Figure 2 - 18 Fast Keys My Computer (Fast Keys) Tap three fingers simultaneously on the pad and then move them up until you get to the My Computer window, you can then release the fingers from the pad.
Page 74: Additional
Storage Devices, Audio & Mouse Additional Palm Tracking This feature helps guard against accidental contact such as palms resting on the pad. Use the slider to adjust the sensitivity of the feature as appropriate. Figure 2 - 19 Palm Tracking Smart Motion Smart Motion makes it easier to drag objects across the screen or move the pointer across long distances.
Page 75 Storage Devices, Audio & Mouse Slow Motion Slow Motion allows you to slow down the cursor movement for more precise con- trol. Pressing and holding key (configured from the drop-down menu) will enable this feature. Figure 2 - 21 Slow Motion TouchPad and Buttons/Mouse 2 - 19...
Page 76 Storage Devices, Audio & Mouse 2 - 20...
Page 77: Power Management Overview
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 78: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-In jack on the left of the computer.
Page 79: Turning On The Computer
Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 80: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 81 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 82: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Page 83: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 84: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Page 85: Resuming Operation
Power Management Resuming Operation  You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status Icon Color To Resume...
Page 86: Power Conservation Modes
Power Management Power Conservation Modes  This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Power Conservation of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Energy Star setting Press the Fn + Esc key combination to toggle the Control Center on/off.
Page 87: Battery Information
Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Page 88: Conserving Battery Power
Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD The Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 89: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 90: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances. • DO NOT expose the battery to fire or high temperatures, it may explode. Caution • DO NOT connect the metal terminals (+, -) to each other. Danger of explosion if battery is incorrectly re- ...
Page 91: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 92 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 93 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 94 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 95: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities  Driver Installation & This chapter deals with installing the drivers and utilities essential to the operation or Power improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.
Page 96: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
Page 97 Drivers & Utilities Win 7 SP1/Win 8 Driver Page # Win 7 SP1/Win 8 Driver Page # Chipset Page 4 - 6 Setting Up SATA RAID or AHCI Mode Page 7 - 2 PC Camera Module Video (VGA) Page 4 - 6 Page 7 - 15 (Not required for Windows 8) NVIDIA Video (VGA)
Page 98: Manual Driver Installation
Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click the Browse CD/DVD button in the Drivers In- If you wish to update/reinstall individual drivers it staller application and browse to the executable file in may be necessary to uninstall the original driver.To do the appropriate driver folder.
Page 99: User Account Control
Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue/Al- ing the installation procedure (other than when out- low, and follow the installation procedure as directed.
Page 100: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Video (VGA) Insert the Device Drivers & Utilities + User’s Manual 1. Click 2.Install VGA Driver > Yes. disc and click Install Drivers (button), or Option Driv- 2. Click Next > Yes > Next > Next. ers (button) to access the Optional driver menu.
Page 101: Card Reader
Drivers & Utilities Card Reader MEI Driver 1. Click 5.Install Cardreader Driver > Yes. 1. Click 9.Install MEI Driver > Yes. 2. Click Finish. 2. Click Next > Yes > Next. 3. Click Finish. TouchPad Audio 1. Click 6.Install Touchpad Driver > Yes. 2.
Page 102: Windows Experience Index
Drivers & Utilities Windows Experience Index  After Video (VGA) driver has been installed, and the system restarted, the OS will automatically run the Windows Update "Winsat.exe" to rate the performance. If you have re- After installing all the drivers make sure you enable Win- started the system during this time then follow the in- dows Update in order to get all the latest security up- structions below to update the information.
Page 103: Optional Drivers
Drivers & Utilities Optional Drivers See the pages indicated in Table 4 - 1, on page 4 - 3 for the driver installation procedures for any modules in- cluded in your purchase option. Models A & B Figure 4 - 3 - Optional Drivers Installer Screen Note that you need to install both the WLAN &...
Page 104 Drivers & Utilities 4 - 10...
Page 105: Bios Utilities Overview
BIOS Utilities Chapter 5: BIOS Utilities  BIOS Screens Overview Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s BIOS.
Page 106: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) If you enable the Boot-time Diagnostic Screen in the Setup Utility, each time you turn on the computer the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). As the POST proceeds, the computer will tell you if there is anything wrong.
Page 107: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized distributor/supplier as soon as possible.
Page 108: The Setup Utility
BIOS Utilities The Setup Utility  The Aptio Setup Utility tells the system how to configure itself and manage basic BIOS Settings features and subsystems (e.g. port configuration). Warning Entering Setup Incorrect settings can cause your system to To enter Setup, turn on the computer and press F2 (give the system a few seconds malfunction.
Page 109: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.
Page 110: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 111: Sata Port # (Main Menu)
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.
Page 112: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu 5 - 8 Advanced Menu...
Page 113: Intel Anti-Theft Technology (Advanced Menu)
BIOS Utilities Intel Anti-Theft Technology (Advanced Menu)  Anti-Theft Technology, which is built-in to the processor of the computer, allows system administrators to render your computer useless to thieves by sending a poi- SATA Mode son pillencrypted SMS message over a 3G network etc. Administrators can also re- Selection motely unlock a recovered computer quickly, or direct the system to send location If you have installed the...
Page 114: Security Menu
BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...
Page 115: Password On Boot: (Security Menu)
BIOS Utilities Note: To clear existing passwords press Enter and type the existing password, then  press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance. Password Warning Note: You can only set the user password after you have set the supervisor pass- If you set a boot pass- word.
Page 116: Boot Menu
BIOS Utilities Boot Menu Figure 5 - 5 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
Page 117: Boot Option Priorities (Boot Menu)
BIOS Utilities Boot Option Priorities (Boot Menu) Use the arrow keys to move up and down the menu, and press enter to select a device from the menu (the selected device will be highlighted in white). You can go to ei- ther Network Device BBS Priorities, CD/DVD ROM Drive BBS Priorities or Hard Drive BBS Priorities and use the keys to move any device’s boot...
Page 118: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 119: Upgrading The Computer Overview
Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.
Page 120: When Not To Upgrade
Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 121 Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a fast- er/new one you will need to contact your customer service representative. We rec- ommend that you do not do this yourself, since if it is done incorrectly you may damage the processor or mainboard.
Page 122: Removing The Battery
Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Before removing the battery disconnect the AC/ Please check with your DC adapter from the computer first. service representative Turn the computer off, remove the AC/DC adapter and turn it over.
Page 123: Removing The Component Bay Cover
Upgrading The Computer Removing the Component Bay Cover Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws Figure 6 - 2 Component Bay Cover Screws Model A Model B Removing the Component Bay Cover 6 - 5...
Page 124 Upgrading The Computer Slide the cover in the direction of arrow , until the case markers line up. Remove the component bay cover Figure 6 - 3 Component Bay Cover Removal Model A Model B 6 - 6 Removing the Component Bay Cover...
Page 125: Replacing The Component Bay Cover
Upgrading The Computer Replacing the Component Bay Cover Reinsert the component bay cover by placing it on the bottom case assembly and sliding it on to the case in the direction of arrow Make sure the case markers line up. Replace screws (Figure 6 - 2 on page 6 - Figure 6 - 4...
Page 126: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s)  The hard disk Drive(s) can be taken out to accommodate up to two other 2.5" serial HDD System Warning (SATA) hard disk drives with a height of 9.5mm (h) (see “Storage” on page D - Follow your operating system’s installation instructions, and install all necessary New HDD’s are blank.
Page 127 Upgrading The Computer Removing the Hard Disk from the Primary HDD Bay Turn off the computer, and turn it over and remove the battery (see page Remove screw Slide the HDD cover in the direction of arrow until the case markers line up.
Page 128 Upgrading The Computer Slide the hard disk assembly forward, and remove the assembly from the  computer. Remove screws & and the primary HDD insulation plate HDD Insulation Plates Reverse the process to install a new disk and do not forget to reinstall the insulation plate.
Page 129 Upgrading The Computer Removing the Hard Disk from the Secondary HDD Bay  Turn off the computer, and turn it over and remove the battery and component bay cover (see pages 6 - 4 & HDD Insulation Plates Remove screws &...
Page 130 Upgrading The Computer Remove screws & and separate the case bracket and the insulation plate Figure 6 - 8 Secondary Hard Disk Case Bracket & Insulation Plate Removal Reverse the process to install a new disk (pay careful attention to the orientation of the hard disk in the case bracket before tightening the screws).
Page 131: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device The procedure for removing the optical device will depend upon your particular computer model: • See “Removing the Optical Device Drive for Model A Computers” on page 6 - • See “Removing the Optical Device Drive for Model B Computers” on page 6 - Upgrading the Optical (CD/DVD) Device 6 - 13...
Page 132: Removing The Optical Device Drive For Model A Computers
Upgrading The Computer Removing the Optical Device Drive for Model A Computers Turn off the computer, and turn it over and remove the battery and primary hard disk bay cover (see pages 6 - 9 & Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Figure 6 - 9...
Page 133: Removing The Optical Device Drive For Model B Computers
Upgrading The Computer Removing the Optical Device Drive for Model B Computers Turn off the computer, and turn it over and remove the battery and component bay cover (see pages 6 - 4 & Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Figure 6 - 10 Removing the...
Page 134: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDR III (DDR3) type memory modules (see “Memory” on page D - The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 135 Upgrading The Computer Turn off the computer, and turn it over and remove the battery and component bay cover (see pages 6 - 4 & The memory sockets will be visible at point on the mainboard. Figure 6 - 11 RAM Module Location ...
Page 136 Upgrading The Computer The RAM module will pop-up, and you can remove it.  Figure 6 - 13 Single Memory Module RAM Module Installation Removal If your computer has a single memory module, then insert the module into the  Channel 0 (JDIMM1) socket.
Page 137: Modules Overview
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 138: Setting Up Sata Raid Or Ahci Mode
Modules Setting Up SATA RAID or AHCI Mode  AHCI Mode RAID Hard Disks Advanced Host Controller Interface (AHCI) is an interface specification that allows All hard disks in a RAID the storage driver to enable advanced serial ATA features such as Native Command should be identical (the Queuing (for maximum hard disk efficiency and performance).
Page 139 Modules RAID Level Description Table 7 - 1 RAID Levels Identical drives reading and writing data in parallel to increase performance. RAID 0 RAID 0 implements a striped disk array and the data is broken into blocks and each block is written to a separate disk drive.
Page 140 Modules Prepare the following before setting up your serial ATA hard disks in RAID mode: The Microsoft Windows 7 OS DVD. A hard disk installed in the Primary HDD bay. A second (identical) hard disk installed in the Secondary HDD bay. The Device Drivers &...
Page 141: Sata Raid Setup Procedure (Bios)
Modules SATA RAID Setup Procedure (BIOS) Start-up your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu, select "SATA Mode" and press Enter (see page 10). • Select “RAID Mode”. Press Esc and go to the Boot menu. Set the DVD-ROM Drive (make sure the Microsoft Windows 7 OS DVD is inserted) as the first device in the boot order from the Boot menu (see “Boot...
Page 142: Raid Setup (Intel Matrix)
Modules RAID Setup (Intel Matrix) As the computer starts up press Ctrl + i to enter RAID configuration menu. Figure 7 - 1 Intel(R) Rapid Storage Technology Option ROM  Recovery Level When selecting disks for the Recovery RAID level you will need to use the Tab key to select a Mas- ter disk, and the Space...
Page 143 Modules Press Enter and the system will select the physical disks to use (see sidebar for  Recovery Level). Press Enter and select (if applicable) the Strip Size (best set to default). Recovery Level Press Enter and select the Capacity size (best set to default). Press Enter to select Create Volume.
Page 144 Modules 12. Make sure the Windows 7 OS DVD is in the DVD drive. and as the computer  starts up it will automatically boot from the Windows 7 OS DVD (you will be prompted to press a key to boot from the DVD). Win7 (pre SP1) &...
Page 145: Intel Rapid Storage Technology
Modules Intel Rapid Storage Technology The Intel Rapid Storage Technology application provides high-performance SATA and SATA RAID capabilities. Install the Intel Rapid Storage Technology application (after installing all necessary drivers in the correct order) to support your RAID system or SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)”...
Page 146: Intel® Rapid Storage Technology For Raid Systems
Modules Intel® Rapid Storage Technology for RAID Systems Intel® Rapid Storage Technology application displays status information on your RAID configuration. Run the Intel® Rapid Storage Technology application from the Intel item in the All Programs menu. When the Intel® Rapid Storage Technology application is launched the system will open the Status window.
Page 147 Modules Intel® Rapid Storage Technology Help  If a hard drive member of a RAID volume is reported as “Degraded” or “Failed” it may be possible to recover the volume. If the volume cannot be restored then you Help will need to recreate the RAID volume and restore the data from a back up. Click the Help menu (or press F1) for instructions on how to recover or recreate RAID Vol- Click the Help (or press F1) menu button at the...
Page 148: Raid Volume Data Verification And Repair
Modules RAID Volume Data Verification and Repair The RAID volume data verification process identifies any inconsistencies or bad data on a RAID 0 or RAID 1 volume. The table outlines what occurs for each RAID level: RAID Verify Verify & Repair Level Table 7 - 2 RAID 0...
Page 149 Modules Verifying and Repairing RAID Volume Data Before verifying the volume data you will need to initialize the volume. Run the Intel® Rapid Storage Technology application from the Intel item in the Programs/All Programs menu. Click Manage and click Advanced. Click Initialize and click Yes (button) to begin the process.
Page 150 Modules Click Advanced and click Verify, then click Verify (button) to begin the process. The completion percentage will be listed under Status (verifying and repairing). Figure 7 - 6 ® Intel Rapid Storage Technology Verify 7 - 14 Intel Rapid Storage Technology...
Page 151: Pc Camera Module
Modules PC Camera Module  Before installing the driver, make sure the PC Camera is on. Use the Fn + F10 key Latest PC Camera combination, or Control Center button, to toggle power to the to the PC Camera mod- Driver Information ule.
Page 152: Pc Camera Driver Installation
Modules PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install Webcam Driver > Yes. 4. Click Finish to restart the computer. 5.
Page 153: Pc Camera Audio Setup
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 154 Modules Figure 7 - 7 Audio Setup for PC Camera Right-click 7 - 18 PC Camera Module...
Page 155 Modules Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see below). Go to the Capture menu heading (if you wish to capture audio check “PC Camera Audio Setup”...
Page 156 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 157 Modules Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 158 Modules Taking Still Pictures  The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.
Page 159: Wireless Lan Module
Modules Wireless LAN Module  If you have included an Intel® or 3rd Party Wireless LAN (or WLAN & Bluetooth Wireless Device combo) module in your purchase option, make sure that the WLAN module is on be- Operation Aboard fore installing the driver. Aircraft The use of any portable Use the Fn + F11 key combination, Control Center button or WLAN hot key button...
Page 160: 3Rd Party Wlan Driver Installation (For Wlan Module)
Modules 3rd Party WLAN Driver Installation (for WLAN Module) This information applies to 3rd party WLAN modules only. See over for informa- tion on installing the drivers for the 3rd party WLAN & Bluetooth combo modules. If you see the message “Found New Hardware” click Cancel to close the window. 1.
Page 161: 3Rd Party Wlan Driver Installation (For Combo Module)
Modules 3rd Party WLAN Driver Installation (for Combo Module) This information applies to 3rd party WLAN & Bluetooth combo modules only. If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, and then insert the Device Drivers &...
Page 162: Intel® Wlan Driver Installation
Modules Intel® WLAN Driver Installation For a standard Intel® WLAN driver installation and configuration choose the Typ- ical Installation below and use the Windows OS for Wireless LAN control (see overleaf). If you want to use Intel® PROSet/Wireless WiFi Connection Utility as your WLAN interface, and/or add Intel®...
Page 163 Modules Custom Installation (for Intel® ProSet and/or Intel® MyWiFi Technology): Note that if you wish to install Intel® MyWiFi you will need to install Micro- soft.net Framework 4.0 (or later version) before installing the driver as per the procedure below. To get the Microsoft.net Framework file go to the Microsoft website, search for the file, Download it and then install it.
Page 164 Modules Figure 7 - 9 Install Intel® MyWiFi Technology & Intel® PROSet/Wireless WiFi Connection Utility 7 - 28 Wireless LAN Module...
Page 165: Connecting To A Wireless Network In Windows 7
Modules Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then double-click an access point to con- Network and nect to or click to Open Network and Sharing Center if you do not see a network Sharing Center you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net-...
Page 166 Modules You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 167 Modules Click the taskbar icon to see any currently connected networks.  To disconnect from the wireless network you can click the taskbar wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se- cure network.
Page 168: Connecting To A Wireless Network Using Intel® Proset Wireless
Modules Intel Connecting to a Wireless Network Using ® PROSet Wireless (For Intel® WLAN Modules Only) Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > WiFi Connection Utility). Click to select a network from the found list WiFi network access points, or click Refresh to update the list.
Page 169 Modules Click Connect to connect to the select WiFi network access point. If the access point is encrypted then you will need to enter the password and click Figure 7 - 14 Intel® PROSet/ Wireless WiFi Connection Utility (Connecting & Connected) You can turn WiFi On/WiFi Off from the button at the bottom of the Utility.
Page 170: Intel® My Wifi Configuration
Modules Intel My WiFi Configuration ®  (For Intel® WLAN Modules Only) Intel® My WiFi Technology (Intel® MWT) uses your WLAN to transform your Intel® My WiFi Help system into a WiFi Personal Area Network, and enables you wirelessly share your To get help on Intel®...
Page 171 Modules Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > Intel(R) My WiFi Dashboard), or click the icon in the notification area of the taskbar (or right-click and select Open Dashboard).
Page 172 Modules Intel® My WiFi Interface Help Wireless ON/OFF Configuration Options & Preferences Figure 7 - 16 Intel® My WiFi Utility - Interface Your Computer 7 - 36 Wireless LAN Module...
Page 173 Modules Intel® My WiFi Help Click the Help icon in the dashboard to bring up the Help menu and select and item from the Contents menu to obtain the help information. Help Figure 7 - 17 Intel® My WiFi Utility - Help Your Wireless LAN Module 7 - 37...
Page 174 Modules Preferences Click the Options icon and select Preferences to configure the options. Help Figure 7 - 18 Intel® My WiFi Utility - Preferences Your Computer 7 - 38 Wireless LAN Module...
Page 175 Modules Hotspot You can turn the computer into a hotspot to allow other devices to connect to it (and any locally connected devices), and also (if available) the internet. Click the Hotspot icon to turn the Hotspot on. The Hotspot settings tab shows the SSID and password (you will need to enter this information when accessing the hotspot from the client computer/device).
Page 176 Modules Finding Devices You can find any Nearby Devices by clicking the Refresh button in the main window. Click again at any time to update the list. If a lot of devices are found they will be listed on multiple pages and you can use the left or right buttons to turn the pages.
Page 177 Modules Favorite Devices The Favorite Devices tab is where you keep devices to which you connect most of- ten, and this is particularly useful in environments where many devices are listed nearby. A favorite device will display the icon To make any device a favorite just click to select it and select Add Favorite. Figure 7 - 20 Intel®...
Page 178 Modules Connect to a Device Click the device you want to connect to, and click the connect icon An invitation will be sent to the target device. The user must then accept the invitation. After the invitation is accepted the connection will be made. Use the Windows Network and Sharing Center to set permissions for viewing and sharing the resources on your computer with another connected computer.
Page 179: Windows Mobility Center
Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 180: Intel® Wireless Display Application
Modules Intel Wireless Display Application ®  The Intel ® Wireless Display Application (requires Intel® Centrino WLAN/ Compatible Combo module), in conjunction with a compatible video adapter (purchased sep- Adapters arately), allows you to display the contents of the notebook display on another dis- play (e.g.
Page 181: Intel® Widi Application Installation
Modules Intel WiDi Application Installation ® 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 3.Install WiDi AP > Yes. 4. Click Next. 5. Click the button to accept the license and click Next. 6.
Page 182: Intel® Widi Application Configuration
Modules Intel WiDi Application Configuration ® Click Start > All Programs > Intel Corporation > Intel(R) Wireless Display > Intel(R) Wireless Display, or double click the icon on the desktop. Click I agree to the terms of this license (button). The application will scan for any connected compatible adapters (or you can click the Scan for available adapters button to enable Intel My WiFi Technology).
Page 183 Modules Click to select any detected adapters, and click Connect. The system will then prompt you to enter the 4-digit security code which will be displayed on the external TV Screen (or press the connect button on the wireless speaker adapter). Enter the code for the video adapter and click Continue.
Page 184 Modules You will then be prompted to enter a name for the video adapter and click  Continue. Click Finished to complete the setup. Test Audio Adapter To verify a successful audio connection (for In- tel® Wireless Music), select the “Test your audio connection”...
Page 185: Fingerprint Reader Module
Modules Fingerprint Reader Module  (For Model A Computers Only) Password Warning The fingerprint reader Protector Suite Software provides a high level of security for your computer. Make sure you have administrator’s rights to your computer, and If you set passwords for have a Windows password enabled for full security protection.
Page 186: Fingerprint Reader Driver Installation
Modules Fingerprint Reader Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers. 3. Click 4.Install Finger Print Driver > Yes. 4. Click Next. 5. Click the button to accept the license and click Next. 6.
Page 187: Authentec Truesuite Application
Modules AuthenTec TrueSuite Application  The AuthenTec TrueSuite application is used in conjunction with your fingerprint reader to enroll fingerprints and manage settings etc. Fingerprint Enrollment User Enrollment Note that it is strongly rec- Click Start > All Programs > AuthenTec TrueSuite. ommended that you enroll Click Yes when you have identified your fingerprint sensor ( Fingerprint...
Page 188 Modules You will be prompted to select another finger for enrollment (it is recommended  that you enroll a number of fingers - see sidebar). Click the button to continue once you have enrolled a number of fingerprints. Help Enter the required information and click the button to register your software, or click to register later.
Page 189 Modules Settings Click the Settings button on the menu bar to access the personalization settings for AuthenTec TrueSuite. Here you can choose to enable/disable Website Log On, QuickLaunch, Fast User Switching and the desktop icon. You can also select the Theme and export/import identities.
Page 190 Modules Windows Log On Windows log on allows you to gain access to your computer by swiping your finger across the fingerprint reader sensor. Use the Biometric Devices control panel (in the Hardware & Sound category) in Windows to turn Biometrics on/off when re- quired.
Page 191 Modules Website Log On Use a fingerprint swipe to log on to websites to help you avoid having to remember user names and passwords across multiple websites (browsers supported are Internet Explorer, Firefox and Chrome). Registering a Website Use your web browser to navigate to the website required. Enter your user name and password and sign in to the website.
Page 192 Modules QuickLaunch QuickLaunch allows you to drag and drop icons (which represent websites, folders, applications and/or computer actions) to any enrolled finger and then swipe your fin- ger to launch the icons assigned to that finger. Click Start > All Programs > AuthenTec TrueSuite. Click Select Category (button) to group icons if required.
Page 193 Modules Adding a Website to QuickLaunch Click Start > All Programs > AuthenTec TrueSuite. Click the Add Website button on the menu bar and the dialog box will be displayed. Enter the website URL, name, icon and category as required. Click Save and an icon will be associated with the selected website.
Page 194 Modules Dock View Dock View displays the website icons across the bottom of the screen. Each icon wiLl have an associated web card which displays the website information, user name and password etc. This information may be edited or deleted as required. Figure 7 - 33 Dock View Editing a Web Card...
Page 195 Modules Exporting and Importing Your Identity You can export your identity to backup your information, or to move it to another computer. Exporting Your Identity Click Start > All Programs > AuthenTec TrueSuite. Click the Settings button on the menu bar. Click Export My Identity.
Page 196 Modules AuthenTec KeepSafe The KeepSafe folder is an encrypted area assigned on your hard drive that allows you to store files and folders to be protected by fingerprint protection. The folder will appear on your desktop (if selected in the Personalization Settings) and in My Computer, but will not be visible to other users of your computer.
Page 197: Bluetooth Module
Modules Bluetooth Module  If your purchase option includes the Combination Wireless LAN & Bluetooth Wireless Device module (either Intel® or 3rd Party) then install the driver as instructed (see “Blue- Operation Aboard tooth Settings (Windows 8)” on page E - 38 for instructions on Bluetooth settings Aircraft for Windows 8).
Page 198: 3Rd Party Bluetooth (V4.0) Combo Driver Installation
Modules 3rd Party Bluetooth (V4.0) Combo Driver Installation Note this driver is only required for the 3rd Party combo Bluetooth and WLAN module version 2 (Bluetooth V4.0). 1. Before installing the driver make sure the Bluetooth module is powered on (use Fn + F12 key combination), then insert the Device Drivers & Utili- ties + User’s Manual disc into the CD/DVD drive.
Page 199: Intel Bluetooth Combo Driver Installation
Modules Intel Bluetooth Combo Driver Installation  Note this driver is required only for the Intel combo Bluetooth and WLAN module only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...
Page 200: Standard Bluetooth Configuration In Windows 7
Modules Standard Bluetooth Configuration in Windows 7  For Intel and 3rd Party Driver Version 2 (Bluetooth V4.0) modules only. Setup your Bluetooth Device so the Computer Can Find it Add a Device Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Click Start, and click Con- Make the device discoverable (to do this check your device documentation).
Page 201 Modules To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con- nections.
Page 202 Modules Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 37 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 203 Modules To Change Settings for the Bluetooth Device  Click the notification area icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Page 204: 3G Module
Modules 3G Module  (For Model A Only) 3G Module Options If you have included an optional (for Model A Only) UMTS/HSPDA OR UMTS/ HSPDA+ based 3G Module (Universal Mobile Telecommunications System or There are two optional High Speed Packet Access) module (see “Communication”...
Page 205 Modules 3G Module USIM Card Installation  Follow the instructions below to install the USIM card (which will be provided by your service provider). Power Safety Warning Turn off the computer, and turn it over. Before you undertake any Remove the battery (see “Removing the Battery”...
Page 206 Modules Before installing the application, make sure that the 3G module is ON (installing  the driver with the module off will not allow the software to detect the module hard- ware correctly). Use the Fn + key combination (see Table 1 - 4, on page 1 - 3G Modules &...
Page 207: Wireless Manager
Modules Wireless Manager  With the 3G module and USIM card (supplied by your service provider) installed you may then install the Wireless Manager application. The Wireless Manager Wireless Device Operation Aboard application allows you to directly access your HSPA internet service from the com- Aircraft puter.
Page 208: Wireless Manager Application
Modules Wireless Manager Application  The connection information is stored on the USIM card supplied by the service pro- vider (where this is not the case you may need to create a profile - see “Creating a PIN Number Profile” on page 7 - 78).
Page 209 Modules The system will connect to your network.  Connected will appear above the timer icon (the timer will indicate your connected time for the current session) You can then access the internet, download e-mail etc. as per any internet Wireless Manager connection.
Page 210 Modules Click the Wireless Manager notification area icon to view the connection status, or wireless icon to view the Mobile Broadband Connection status Figure 7 - 43 Notification Area Icons (Connected)  Notification Area The indicator will display the signal strength and radio access Icon technology.
Page 211: Profiles
Modules Profiles Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click the Settings > Advanced. Click the Profiles (tab). Figure 7 - 44 Advanced Settings - Profiles 3G Module 7 - 75...
Page 212 Modules Multiple profiles may be available from the USIM card and the first time the application starts it may require you to select a profile (Set Profile) to use for your connection. Figure 7 - 45 Multiple Profiles Found Automatic Profile Selection If Automatic selection is chosen, then the application will search the operator pro- file database for a profile that matches the details on your USIM card.
Page 213 Modules Selecting a Profile Click Manual selection (button). Click the Filter to view the drop-down list. Select the Profile you wish to use and click Apply to confirm the selection. Figure 7 - 46 Profile - Manual Selection (Filter) 3G Module 7 - 77...
Page 214 Modules Creating a Profile  Click Manual selection (button). Click the New. Deleting a Profile Enter a name you prefer for the profile. Enter the Access Point Name (APN). To delete a profile click Enter the User Name and Password if required (some service providers may not to select Manual selec- require this information and the fields may then be left blank).
Page 215: Settings
Modules Settings The Settings tab allows you at adjust the application features. Click to put a tick in Launch Wireless Manager at Windows startup to launch the application at Win- dows Startup. Figure 7 - 48 Settings The Advanced settings allows more detailed configuration. To access the Ad- vanced settings: Access the Wireless Manager program from the Start menu (Start >...
Page 216 Modules  Most USIM cards are protected by a Personal Identity Number (PIN). You may turn on or off the Request PIN at startup (click Apply to save any changes). You can PIN Notes also Change PIN (you will need to enter the new PIN in the two fields provided and click Apply to save any changes).
Page 217 Modules Networks  The mobile network list lists available networks at your location, and allows you to select a network which to connect. You must disconnect before being able to select Warning a network. Note that some applica- tions automatically Connection transmit data when con- You can set the Wireless Manager to automatically connect at Windows startup...
Page 218: Text Messaging Service (Sms)
Modules Text Messaging Service (SMS) In addition to standard internet services you may also send and receive SMS text messages using the Wireless Manager, if your service supports SMS. SMS Utility Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 219 Modules Messages Click the Messages tab to access the tabs displaying text messages. The tabs at the top of the menu display the Inbox, Drafts, Outbox, Sent and Trash menus. Inbox Drafts Outbox Sent Trash Figure 7 - 52 SMS Utility Messages Text messages are automatically saved to your computer and may be sorted in as- cending or descending order by name or date.
Page 220: Sending A Text Message
Modules Sending a Text Message Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click SMS and the SMS Utility will then start. Click the New Message tab. Enter the phone number in the To field (multiple numbers may be entered separated by a semicolon (;), or click the phonebook icon to select a name from...
Page 221 Modules Click Send to send the message or Save to save the message in the Drafts folder. Clicking the Clear icon clears both the Message and To fields. If radio is on then the message will be sent, however if the radio is off the message will be stored in the Outbox.
Page 222 Modules Messages • Opening a text message: Double-click the message and the message will open in a new window (to close it click the close icon in the top right of the message). Figure 7 - 55 Click to close the message Close Message •...
Page 223: Phonebook
Modules Phonebook The Phonebook allows you to view and edit all your frequently used contacts, and is divided into Contacts and Groups . To access the Phonebook: Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 224 Modules Contacts  • New Contact: Click the New contact button to create a contact. Add the name and at least one phone number (Mobile, Work, Home and Other Import/Export Contacts fields are available) for the contact. Click the icon to expand the number details.
Page 225 Modules Groups You can organize existing contacts into groups from the Groups tab. • New Group: Click the New group button to create a group. Click icon to expand the group details, and click a check box to add at least one phone number from the contacts for the group.
Page 226: Sms Settings
Modules SMS Settings The SMS Utility Settings tab allows you at adjust the SMS features. Figure 7 - 59 SMS Utility Settings  SMS Settings Message Length: You can set the number of blocks that can be sent (up to a length of 10 blocks).
Page 227 Modules Send Click Delivery Report to automatically request a reply from a recipient. If you click to Send messages in Outbox automatically upon connection then messages writ- ten when the radio is off, will then be sent automatically the next time radio is turned on.
Page 228 Modules Number You can choose to Use default service center number or you can uncheck the box and add your number manually if your service provider supplies a different number (click Apply to save the change or Default to return to the default number). Memory Phonebook memory status displays the number of contacts displayed on the USIM card.
Page 229: Sierra Wireless Aircard Watcher
Modules Sierra Wireless AirCard Watcher  With the 3G module and USIM card (supplied by your service provider) installed you may then install the Sierra Wireless AirCard Watcher application. AirCard Wireless Device Operation Aboard Watcher allows you to directly access your internet service from the computer. Aircraft Sierra Wireless AirCard Watcher Installation The use of any portable...
Page 230: Aircard Watcher Application
Modules AirCard Watcher Application  The connection information is stored on the USIM card supplied by the service pro- vider (where this is not the case you may need to create a profile - see “Profiles” on PIN Number page 7 - 100).
Page 231 Modules The system will connect to your network.  The icon will turn green (and the upload/download speeds will be indicated). You can then access the internet, download e-mail etc. as per any internet connection. AirCard Watcher Help Topics To get help on AirCard Watcher configuration and settings, click the...
Page 232 Modules When connected the uplink/downlink speeds will be indicated.  You can also click the Speed Graph icon to get a visual display of the uplink/ downlink speeds. Roaming 10. While connected you can also click the icon in the notification area of the Notification taskbar to display the Windows 7 Mobile Broadband connection status.
Page 233 Modules 11. To disconnect from the service provider, click the Disconnect button  (note that if you click the close icon at the top right of the screen the application will close however the connection will still be maintained). 12. You can also click the icon in the notification area of the taskbar to display the Online Help connection status, click Connected, and then click the Disconnect button.
Page 234: Air Card Watcher Menu
Modules Air Card Watcher Menu  Right-click the menu button at the top of the AirCard Watcher screen to bring up the menu, and click to select any item required. Airplane Mode Click on the Airplane Mode icon to turn the ra- dio power off (e.g.
Page 235: Selecting A Network Operator/Service Provider
Modules Selecting a Network Operator/Service Provider  In most cases all your network operator/service provider details will be stored on your USIM card, and will not need to be edited/modified. If you do need to set up a Network Operator network operator/service provider follow these instructions.
Page 236: Profiles
Modules Profiles A profile contains information used to establish a data connection, and this informa- tion is usually stored on the USIM card supplied by your service provider. However you can create, edit or delete profiles if required. Creating a Profile Access the AirCard Watcher application from the Start menu (Start >...
Page 237 Modules You will need to complete the fields for Profile name, Username, Password and  Access Point Name (you will need to get the username and password details from your service provider). Edit or Delete Once you have added the details above you can click the Profiles heading menu Profiles and click to select the profile from the Selected Profile dropdown menu and then click OK to set the profile as the default connection.
Page 238: User Options
Modules User Options You can configure User Options as follows. Access the AirCard Watcher application from the Start menu (Start > All Pro- grams > Sierra Wireless > AirCard Watcher) or the desktop shortcut Either click the menu button and select Options, or click the Options button from the main program window.
Page 239 Modules • General - This item allows you to set options for Startup/Shutdown, Warning Messages, Display and Windows support. • Messaging - Set options here for SMS settings. • Network - Configure the network settings from this menu though your fre- quency band information is usually stored on the USIM card.
Page 240: Text Messaging Service (Sms)
Modules Text Messaging Service (SMS) In addition to standard internet services you may also send and receive SMS text messages using AirCard Watcher, if your service supports SMS. SMS Express Access the AirCard Watcher application from the Start menu (Start > All Pro- grams >...
Page 241: Sending A Text Message
Modules Sending a Text Message  Access the AirCard Watcher application from the Start menu (Start > All Pro- grams > Sierra Wireless > AirCard Watcher) or the desktop shortcut Sent Messages Either click the menu button and select SMS Express, or click the SMS Express button from the main program window.
Page 242: Inbox
Modules Inbox Any received text messages will be displayed in the Inbox. The number of total mes- sages and unread messages will be displayed in the inbox folder title. Messages • Opening a text message: Click on any message in the Inbox to read it in the bottom panel of the window.
Page 243: Thx Trustudio Pro Audio
Modules THX TruStudio Pro Audio  Note that you will need to install the THX TruStudio audio application in order to THX TruStudio & get maximum audio performance. The THX TruStudio AP to allows you to config- Speaker ure the audio settings to your requirements for the best performance in games, music Configuration and movies.
Page 244: Thx Trustudio Pro Activation
Modules THX TruStudio Pro Activation  On the first run of THX TruStudio Pro you will need to activate the application. THX Audio & HDMI To activate the application you will need to be connected to the internet. Double-click the THX Activate icon on the desktop and click the Activate Note that the THX audio effects do not apply to...
Page 245 Modules THX Control Panel Each control has an On/Off button to allow you to enable/disable the control, and most controls feature a slider to adjust the levels (the subwoofer may be turned on/ off). Figure 7 - 74 Menu THX TruStudio Pro Controls •...
Page 246 Modules THX TruStudio Pro Headphone Settings THX TruStudio selects the built-in speakers by default and this setting may cause some sound quality issues when using headphones. To adjust the settings for head- phones do the following: Run the THX TruStudio Pro application. Select Settings from the menu.
Page 247 Modules THX TruStudio Pro & HDMI When you connect an HDMI display to the HDMI-Out port, the THX Tru Studio Pro controls will be disabled. A warning box will pop-up and will prompt “Do you want to select another audio device now?”.
Page 248: Intel® Rapid Storage Technology Driver
Modules Intel Rapid Storage Technology Driver ® Install the Intel® Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - or if you have set up your hard disks in a RAID configuration (see“Setting Up SATA RAID or AHCI Mode”...
Page 249: Intel® Smart Response Technology
Modules Intel® Smart Response Technology Intel® Smart Response Technology is an Intel® Rapid Storage Technology (RST) caching feature that accelerates computer system performance by using the SSD as cache memory between the hard disk drive and system memory. System Requirements to support Intel® Smart Response Technology: •...
Page 250: Enabling Intel Smart Response Technology
Modules Enabling Intel Smart Response Technology Run the Intel® Rapid Storage Technology application from the All Programs menu. Click Enable acceleration either under Status or Accelerate. Figure 7 - 78 Enable Acceleration Select the SSD to be used as a cache device. Select the size from the SSD to be allocated for the cache memory (any remaining space on the SSD can be used for data storage using the simple data single-disk RAID 0 volume that is automatically created).
Page 251 Modules Select the HDD (or RAID volume) to be accelerated (it is highly recommended that you accelerate the system volume or system disk for maximum performance). Select the acceleration mode, and then click OK (Enhanced mode is selected by default). Note: Enhanced mode (default): Acceleration optimized for data protection.
Page 252 Modules The page will refresh and report the new configuration in Acceleration. Figure 7 - 80 Intel® Rapid Storage Technology Accelerate 7 - 116 Intel® Rapid Storage Technology Driver...
Page 253: Intel® Rapid Start Technology Driver
Modules Intel Rapid Start Technology Driver ® Intel(R) Rapid Start Technology can resume power from Hibernation within 5 to 6 seconds and can remember your computer's previous state with zero power. System Requirements to support Intel® Rapid Start Technology: • Rapid Start Technology should be enabled in the BIOS (see ““Intel(R) Rapid Start Technology (Advanced Menu)”...
Page 254: Intel® Rapid Start Technology Configuration
Modules Intel® Rapid Start Technology Configuration Enable/disable Intel(R) Rapid Start Technology from the BIOS (see “Intel(R) Rapid Start Technology (Advanced Menu)” on page 5 - Go the Windows control panel and double-click Administrative Tools (System and Security)> Computer Management > Storage > Disk Management Right-click the SSD and select Shrink Volume from the menu.
Page 255 Modules Enter the figure, which should be equal to amount of system memory (RAM) in your computer, in “Enter the amount of space to shrink in MB”. Figure 7 - 82 Shrink Volume Size Click Shrink (any unallocated file space may be formatted for storage use). ...
Page 256 Modules Click the Start menu and type “CMD” in the search box. Click CMD from the found list. Figure 7 - 83 Search for CMD Prompt Type “DISKPART”. At the DISKPART command type “list disk”. Figure 7 - 84 Diskpart - List Disk 7 - 120 Intel®...
Page 257 Modules 10. Type “select disk #” (# is disk number where you want to create the store partition, so refer to the results obtained from "list disk" for exact disk number). 11. The message “Disk # is now the selected disk.” will appear. Figure 7 - 85 Diskpart - Select Disk #...
Page 258 Modules 14. Type “detail disk”. Figure 7 - 87 Diskpart - Detail Disk 15. Type “select Volume #” (# is volume of your storage partition so refer to results obtained from "detail disk" for the exact volume number). 16. The message “Volume # is now the selected volume.” will appear. Figure 7 - 88 Diskpart - Select Volume #...
Page 259 Modules 17. Type “set id=84 override” (the id must be set to 84). Figure 7 - 89 Diskpart - Set id=84 Override 18. The message “DiskPart successfully set the partition ID.” will appear. 19. Close the CMD window. 20. Go the Windows control panel and double-click Administrative Tools (System and Security)>...
Page 260: Intel® Rapid Start Technology Driver Installation
Modules Intel® Rapid Start Technology Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 9.Install Rapid Start Driver > Yes. 4. Click Next > Next > Yes > Next > Next. 5.
Page 261 Modules Intel® Rapid Start Technology Driver 7 - 125...
Page 262 Modules 7 - 126 Intel® Rapid Start Technology Driver...
Page 263: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 264: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 265: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 266: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 267: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 268 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 269: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 270 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 271 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 272 Troubleshooting Problem Possible Cause - Solution The TouchPad doesn’t The Touchpad has been disabled. Press the Touchpad toggle (Fn + F1) key combination (make work. sure you have installed the Touchpad driver. I am sliding my finger up There are different TouchPad versions available on this computer, and this version requires and down on the right tapping/holding to scroll.
Page 273 Troubleshooting Problem Possible Cause - Solution When a DVD is played in This is an issue with Windows Media Player/Media Center and audio output through the S/PDIF- Windows Media Player/ Out Jack. We recommend that you use the Power DVD application to play DVDs. Media Center, the audio track in other languages (commentaries etc.) is...
Page 274 Troubleshooting Problem Possible Cause - Solution The Bluetooth module is The Bluetooth module’s default state will be off after resuming from the Sleep power-saving state. off after resuming from Use the key combination (Fn + F12) to power on the Bluetooth module after the computer Sleep.
Page 275 Troubleshooting Problem Possible Cause - Solution The Bluetooth module experiencing problems/ 2 Bluetooth adapters appear in the Device Manager under Bluetooth Radios. There is a conflict between an existing Bluetooth module and a Bluetooth & WLAN combination module. You should have only one Bluetooth module installed in order to prevent any conflicts (this includes the Bluetooth element of any combination WLAN &...
Page 276 Troubleshooting Problem Possible Cause - Solution cannot obtain high To obtain high speed Bluetooth data transfer take into account the following: speed Bluetooth data transfer. • Only the combination Wireless LAN & Bluetooth module supports high speed (data transfer. • To achieve high speed transfer speeds, both devices must support high speed data transfer (i.e both the computer and the Bluetooth compatible device you are connecting to).
Page 277: Bluetooth Connection Problems
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 278 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 279 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 280 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio 8 - 18 Bluetooth Connection Problems...
Page 281: Intel® Wlan & Bluetooth Combo Modules
Troubleshooting Intel® WLAN & Bluetooth Combo Modules Note that, at the time of going to press, Intel® Centrino® Wireless-N 2230 and Intel® Centrino Advanced 6235 WLAN & Bluetooth combo modules use the standard Bluetooth configuration in Windows 7 (see “Intel Bluetooth Combo Driver Installation”...
Page 282: Installing Windows 7 (Pre Service Pack 1) For Raid Systems With Advanced Format Disks
Troubleshooting Installing Windows 7 (pre Service Pack 1) for RAID Systems with Advanced Format Disks The following information is only applicable under the following conditions: • You are configuring your SATA hard disks in a RAID. • You are using Advanced Format hard disks that have a 4KB physical sector size. •...
Page 283 Troubleshooting Press a key at system startup to begin installing Windows from your Microsoft Windows 7 disc (make sure the DVD device is set at the top of the Boot Sequence in the BIOS - see “Boot Menu” on page 5 - 12).
Page 284 Troubleshooting 8 - 22...
Page 285: Interface (Ports & Jacks) Overview
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 286: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) / RSMMC SD (Secure Digital) / Mini SD / SDHC / SDXC MS (Memory Stick) / MS Pro / MS Duo Push the card into the slot and it will appear as a removable device.
Page 287: Microphone-In Jack
Interface (Ports & Jacks) Item Description HDMI-Out Port The HDMI-Out (High-Definition Multimedia Interface) port is an audio/video connector interface for transmitting uncompressed digital streams. This allows you to connect an external monitor, TV or Flat Panel Display etc. as a display device (see “Attaching Other Displays”...
Page 288: Usb 2.0/1.1 Ports
Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB (Universal Serial Bus) 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be USB 3.0 Port plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power...
Page 289: Control Center Overview
Control Center Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center. The Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn mod- ules on/off.
Page 290 Control Center Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the power status of modules (e.g. WLAN, Bluetooth, 3G or Camera), screen brightness, TouchPad power and Silent Mode.
Page 291 Control Center User Flight Modes Power Saving Entertainment Quiet Performance (Win 7 Only) Defined Icon Power Plan Power Saver Balanced Power Saving Power Saving High Performance Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance Brightness WLAN (Win 7 Only) Bluetooth BIOS Default...
Page 292 Control Center Power Status The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness The Brightness icon will show the current screen brightness level.
Page 293 Control Center Sleep Click the Sleep button to bring up the Hibernate or Sleep buttons, and click either button to have the computer enter the appropriate power-saving mode (see “Power-Saving States” on page 3 - Display Switch Click the Display Switch button to access the menu (or use the + P key combination) and select the appro- priate attached display mode (see page 13).
Page 294 Control Center B - 6...
Page 295: Video Driver Controls
Video Driver Controls Appendix C: Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on  page 1 - Video Driver Installation Video Card Options Note that card types, Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - specifications and driv- Insert the Device Drivers &...
Page 296: Nvidia Optimus ™ Technology
Video Driver Controls NVIDIA Optimus Technology ® ™  Most notebook computers come with either a discrete or integrated graphics solu- iGPU or dGPU tion. Note the NVIDIA control Discrete graphics solutions feature a dedicated Graphics Processing Unit (GPU) panel refers to High- performance NVIDIA which are capable of playing games, watching HD video or running GPU-based ap-...
Page 297 Video Driver Controls How Optimus Technology works  When the system is powered up and is displaying just the desktop, the dGPU will be powered off. In this case the system is running in the same way as a system without Customization a discrete graphics solution.
Page 298 Video Driver Controls GPU Button This computer also features a button that allows the user to switch between Op- timus Mode and UMA Mode (Unified Memory Architecture). UMA Mode will use only the integrated GPU; Optimus Mode will allow the system to automatically de- termine whether the dGPU or iGPU is used.
Page 299: Intel® Graphics & Media Control Panel
Video Driver Controls Intel Graphics & Media Control Panel ®  Advanced video configuration options are provided by the Intel Graphics and ® Application Mode Media Control Panel. To access the control panel: Note that all figures pic- Click Advanced settings in the Screen Resolution control panel in Windows. tured, and instructions Click the Intel(R)...
Page 300 Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and...
Page 301: Display Devices & Options
Video Driver Controls Display Devices & Options  Note that you can use an external display connected to the HDMI-Out port or exter- nal monitor port. See your display device manual to see which formats are support- Function Key Combination You can use the Fn + F7 ...
Page 302: Attaching Other Displays
Video Driver Controls Attaching Other Displays  If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port or HDMI-Out port. At least one other dis- To Clone Displays: play must be attached in Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 303 Video Driver Controls To Enable Extended Desktop:  Attach your display to the external monitor port or HDMI-Out port, and turn it on. Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Display Settings Click Operating Mode and select Extended Desktop from the menu. Extended Desktop Click Apply, and OK to confirm the settings change.
Page 304 Video Driver Controls Display Profiles You can save display settings to be loaded at any time. Go to the Intel(R) G&M control panel and click Display. Configure the General Settings, Multiple Displays, Color Enhancement, Custom Resolution & Monitor/TV Settings to your preferences. Click Apply, and OK to confirm the settings change.
Page 305: Configuring An External Display In Windows 7
Video Driver Controls Configuring an External Display in Windows 7  You can also use the Screen Resolution control panel in Windows 7 to configure an Function Key external display. Combination Attach your display to the external monitor port or HDMI-Out port, and turn it on. You can use the Fn + Go to the Screen resolution control panel (see page 21).
Page 306 Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 307 Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 308: Nvidia Control Panel
Video Driver Controls NVIDIA Control Panel  More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Click Start, and click Control Panel (or point to Settings and click Control Panel). To access the Ge- Double-click NVIDIA Control Panel (click "Classic View"...
Page 309 Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and  tools which allow quick access to features such as image settings, 3D Settings and video configuration. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 310: Optimus™ Customization Options
Video Driver Controls Optimus Customization Options ™  One of the most important aspects of Nvidia Optimus technology is that it will ® ™ Display GPU switch between the integrated GPU and discrete GPU seamlessly and automatically, Activity Icon and does not require any input from the user. However customization options are of- fered for users who prefer to set their own parameters for GPU usage.
Page 311 Video Driver Controls Close the NVIDIA Control Panel.  Find the executable file icon of the application you want to run. Right-click the icon and select Run with graphics processor from the context iGPU or dGPU menu. Select either High-performance NVIDIA processor (dGPU) or Integrated Note the NVIDIA con- graphics (iGPU) to run the program with the selected GPU.
Page 312 Video Driver Controls Global Settings Global settings allows you to set the preferred graphics processor for overall use. Ideally this would be the iGPU for battery life, but this can be set to the dGPU if pre- ferred. Run the NVIDIA Control Panel (see page 14).
Page 313 Video Driver Controls Program Settings Program settings allows you to make specific adjustments for installed applications. Run the NVIDIA Control Panel (see page 14). Click Manage 3D Settings (3D Settings) and select Program Settings (tab). Select a program to customize from the drop-down menu, or click Add to add any program that does not appear in the menu.
Page 314: Set Physx Configuration
Video Driver Controls Set PhysX Configuration ® NVIDIA PhysX is a physics engine that can use the GPU to accelerate game and ® ® 3D application performance. You can select the GeForce video card or CPU as a PhysX processor, or configure the computer to auto-select a PhysX processor ®...
Page 315: Video Settings
Video Driver Controls Video Settings Click the sub-menus under Video to adjust the video color or image settings. Figure C - 16 Video Settings Video Settings C - 21...
Page 316: Hdmi Audio Configuration
Video Driver Controls HDMI Audio Configuration  HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Volume Indicator In some cases it will be necessary to go to the Sound control panel and manually configure the HDMI audio output as per the instructions below. Click the taskbar volume indicator when an...
Page 317 Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure C - 18 HDMI Device Properties HDMI Audio Configuration C - 23...
Page 318 Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
Page 319: Specifications
Specifications Appendix D: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your distributor/supplier for details.
Page 320: Processor
Specifications Processor Intel® Core i5-3320M (2.6GHz) Intel® Core i7-2760QM (2.4GHz) Mobile Processor Quad-Core Mobile Processor Intel® Core i7-3820QM (2.7GHz) 3M L3 Cache, 22nm (22 Nanometer), 6M L3 Cache, 32nm (32 Nanometer), Quad-Core Mobile Processor DDR3-1600MHz, TDP 35W DDR3-1600MHz, TDP 45W 8M L3 Cache, 22nm (22 Nanometer), DDR3-1600MHz, TDP 45W Intel®...
Page 321: Memory
Specifications Intel® Core i7-2640M (2.8GHz) Intel® Core i5-2430M (2.4GHz) Core Logic Mobile Processor Mobile Processor Mobile Intel® HM77 Express Chipset 4M L3 Cache, 32nm (32 Nanometer), 3M L3 Cache, 32nm (32 Nanometer), DDR3-1333MHz, TDP 35W DDR3-1333MHz, TDP 35W Memory Intel® Core i5-2410M (2.3GHz) Intel®...
Page 322: Video Adapter Options
Specifications Video Adapter Options Storage Keyboard & Pointing Device Intel® Integrated GPU and NVIDIA® One 12.7 mm Super Multi/Blu-Ray Full Size Isolated Winkey Keyboard with GeForce Video: Combo/Blu-Ray Writer SATA Optical Numeric Keypad Device Drive (Factory Option) Supports NVIDIA® Optimus Built-In TouchPad (with Multi Gesture Switchable GPU Technology between Functionality)
Page 323: Slots
Specifications Slots Communication For Model A Only: UMTS/HSPDA OR UMTS/HSPDA+ 1st Mini-Card Slot: Built-In 10/100/1000Mb Base-TX Ethernet based 3G Module with Mini-Card Mini-Card Slot for WLAN & Bluetooth Interface (Factory Option) Combo Half Mini-Card Module with PCIe Quad-band GSM/GPRS (850 MHz, 900 Intel®...
Page 324: Power
Specifications Operating System Physical Dimensions & Weight Windows® 7 with Service Pack 1 Model A Windows® 8 374mm (w) * 250mm (d) * 16.3 - 42.7mm (h) 2.7kg with ODD and Battery Power Management Model B: Supports Wake on LAN 413mm (w) * 277.5mm (d) * 17.1 - 41.5mm (h) Supports Wake on USB 3.2kg with ODD and Battery...
Page 325: Windows 8
Windows 8 Appendix E: Windows 8 Overview This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows 8 OS. You can refer to the main manual for details of drivers required, audio & video information, BIOS, modules etc. However any information specific to Windows 8 will be included in this Appendix, as well as details on how to navigate the Windows 8 Metro User Interface to access the applications, control panels, taskbar etc.
Page 326: Windows 8 Start Screen & Desktop
Windows 8 Windows 8 Start Screen & Desktop The apps, control panels, utilities and programs within Windows 8 are accessed from the Metro user interface’s Start screen and/or Windows Desktop. The Desktop (which runs as an app within the Start screen) can be ac- cessed from the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination).
Page 327: Apps & Tiles
Windows 8 Apps & Tiles The Windows 8 Start screen will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen in order to view all the necessary apps.
Page 328: Desktop Application
Windows 8 Desktop Application When the Desktop app is running (click the app in the Start screen or use the Windows Logo Key + D key combination) you can use lower left hot corner to switch between the Start screen and the Windows Desktop. To do so move your mouse to hover over the bottom left corner of the screen and click the pop-up.
Page 329 Windows 8 When the Desktop app is running you can right-click the lower left hot corner (or use the Windows Logo Key + X key combination) to bring up an advanced context  menu of useful features such as Control Panel, Programs and Features, Power Op- Display Most tions, Task Manager, Search, Windows Explorer, Command Prompt, Device Man- Recently Used...
Page 330: Windows 8 Charms Bar
Windows 8 Windows 8 Charms Bar The right side of the screen displays the Windows 8 Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower right corners of the screen, and then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the Windows Logo Key + C key combination.
Page 331 Windows 8 Charms Bar Items • Search : You can search for any file, application, apps and control panel settings with instantaneous results. • Share : This button is used to share information with people via mail or social networks. •...
Page 332: Windows 8 Control Panel
Windows 8 Windows 8 Control Panel In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel is much the same as that in Windows 7, however it can be accessed in a number of ways in Windows 8. •...
Page 333 Windows 8 • When in the Desktop app (this does not apply to the Start screen) click on Settings in the Windows Charms Bar and select Control Panel from the menu. Figure E - 9 - Settings Charms Bar (Desktop App Only) •...
Page 334 Windows 8 • Right-click the lower left hot corner to bring up the menu and select Control Panel (see Figure E - 4 on page E -  Keyboard Shortcut to Control Panel You can also use keyboard shortcuts to access the Control Panel. Press the Windows logo key and X to bring up the context menu, and then press P to bring up the Control Panel.
Page 335: Windows 8 Taskbar
Windows 8 Windows 8 Taskbar In many instances throughout this manual you will see an instruction to access the notification area of the task- bar. In Windows 8 the taskbar is accessed from the Desktop application. If you are in the Start screen you will need to click the Desktop app to switch to the Desktop.
Page 336: E - 12 Led Indicators
Windows 8 LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Number Lock is Activated (press Num Lk) Orange AC/DC Power is Plugged In Green Caps Lock is Activated (press Caps Lock) Green The Computer is On...
Page 337 Windows 8 Icon Color Description Green UMA Mode Activated (GPU Button) Orange Optimus Mode Activated (GPU Button) Orange NVIDIA Discrete GPU (dGPU) Activated Green Intel Integrated GPU (iGPU) Activated White Hard Disk Activity Green The (optional) WLAN Module is Powered On Win 7 - The (optional) Bluetooth Module is Powered On Orange Win 8 - The (optional) Bluetooth Module is Installed (this...
Page 338: E - 14 Keyboard - Windows 8
Windows 8 Keyboard - Windows 8  The main difference between the Windows 7 & Windows 8 keyboards is in the func- Windows Logo tion of the Windows Logo Key & Menu/Application Key (in the Start screen), oth- Keyboard Shortcut erwise the keyboard functions are identical (see “Keyboard”...
Page 339: Keyboard Shortcuts
Windows 8 Keyboard Shortcuts The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navigation/operation in Windows 8. Description Windows Logo Key + Tap Winkey Toggle between the Start screen and the foremost running app or the Windows Desktop Display Charms menu Switch to the Windows Desktop and toggle show Desktop Switch to the Windows desktop and launch Windows Explorer with Computer displayed...
Page 340: Function/Hot Key Indicators & Control Center
Windows 8 Function/Hot Key Indicators & Control Center The function/hot key indicators and Control Center function in the same manner as outlined for Windows 7 (ex- cept for the Mute, Volume and Brightness indicators which use the standard Windows 8 indicators) in “Func- tion Keys &...
Page 341: Video Features
Windows 8 Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows 8 in the same manner as Windows 7 running the Desktop app (see “Desktop Application” on page E - 4 Appendix C).
Page 342: Power Options
Windows 8 Power Options Power Options can be accessed from the Control Panel in the same manner as Windows 7 from the Desktop app. The Power item in Settings in the Charms Bar in Windows 8 may be used to Shut down, Restart or send the computer to Sleep.
Page 343 Windows 8 Ctrl + Alt + Delete Key Combination You can use the CTRL + ALT + DEL key combination from almost any of the Windows 8 interfaces/apps to bring up a full-screen displaying Lock, Switch User, Log off, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu appears to display Sleep, Shut down, and Restart.
Page 344 Windows 8 Wake On LAN Settings  If you require your computer to wake up from network activity in Windows 8 then make sure that the computer is either in Sleep or Hibernate. The power/sleep button Wake On LAN (Fn + F4 key combo) and closed lid may be set to send the computer in to a power- Support (Windows 8) saving state.
Page 345: Running Metro Ui Apps
Windows 8 Running Metro UI Apps  To run apps in the Metro UI in Windows 8 you will need to check that the Screen Screen Resolution Resolution and User Account Control Settings are compatible with the system re- for Metro Style Apps quirements: (Windows 8) Screen Resolution Settings...
Page 346 Windows 8 User Account Control Settings If your computer meets the minimum screen resolution requirements, and still you can't run Metro apps, then that you have to check the status of User Account Control (UAC). Metro apps may fail to open when the UAC is turned off.
Page 347 Windows 8 Drivers & Utilities Make sure you install all the drivers and uti lites for your system. Follow the instructions in Chapter 4 “Drivers & Utilities” on page 4 - “Modules” on page 7 - 1 for installing all the basic system drivers and module drivers for Windows 7 &...
Page 348: Driver Installation (Windows 8
Windows 8 Driver Installation (Windows 8) Insert the Device Drivers & Utilities + User’s Manual disc into the computer’s DVD drive. Click the message “Tap to choose what happens with this disc.” Click Run autorun.exe.  Driver Installation If you miss the message above you can eject the De- vice Drivers &...
Page 349 Windows 8 Win 7 SP1/Win 8 Driver Page # Win 7 SP1/Win 8 Driver Page # Chipset Page 4 - 6 Setting Up SATA RAID or AHCI Mode (see page Video (VGA) Page 4 - 6 The PC Camera driver is not required for Windows 8 (see page NVIDIA Video (VGA) Page 4 - 6 Wireless LAN Module...
Page 350: Pc Camera (Windows 8
Windows 8 PC Camera (Windows 8) Use the Fn + F10 key combination (see “Function Keys & Visual Indicators” on page 1 - 13) or Control Cen- ter button to toggle power to the PC Camera module. When the PC Camera is in use the LED indicator to the left of the camera will be illuminated in (see Figure 1 - 2 on page 1 - 7/Figure 1 - 3 on page 1 - Note that you need to use the Camera app in Windows 8 to take pictures and capture video (the camera appli-...
Page 351: Metro Ui Camera App
Windows 8 Metro UI Camera App Make sure the PC Camera is turned on by using the Fn + F10 key combination (or Control Center button). Run the Camera app from the Metro UI by clicking on the Camera app icon The camera interface is a translucent app bar with three buttons.
Page 352 Windows 8 You can also click on More to adjust Brightness, Contrast and Flicker (if you find that the video screen in the camera program is flickering, you can try to adjust the setting here), Figure E - 23 -More Camera Options •...
Page 353: Taking Pictures/Capturing Video
Windows 8 Taking Pictures/Capturing Video Make sure the PC Camera is turned on by using the Fn + F10 key combination (or Control Center button). Run the Camera app from the Metro UI by clicking on the Camera app icon Click to select the timer if you require a countdown before capture.
Page 354 Windows 8 A scroll arrow will appear on the left side of the screen after any pictures/videos have been captured. Click the arrows (on either side of the screen) to browse through the captured photos/video, and back to the Camera app. 10.
Page 355: Wireless Lan Settings (Windows 8
Windows 8 Wireless LAN Settings (Windows 8) If you have included an Intel® or 3rd Party Wireless LAN (or WLAN & Bluetooth combo) module in your pur- chase option, make sure that the WLAN module is on before installing the driver. Use the Fn + F11 key combination (see “Function Keys &...
Page 356: Wlan Configuration In Windows 8
Windows 8 WLAN Configuration in Windows 8 You can configure a wireless connection using one of the following options, however make sure the Wireless LAN module is turned on (and not in Airplane Mode) before configuration begins. Charms Bar Go to the Charms Bar. Select Settings and then click the WiFi icon (it should read Available under the icon and Airplane mode should be Off).
Page 357 Windows 8 Double-click an access point to connect to it (or click it and click Connect). Enter a network security key (password) if required, and click Next. You can choose to share or connect to devices or not. When you are connected to the network access point it will display the Connected icon Select any connected network and click Disconnect to disconnect from a connected access point.
Page 358 Windows 8 11. You need to either use Airplane Mode, or to turn the WLAN module off aboard aircraft.  Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module is either OFF or in Air- plane Mode (for Win- dows 8 only) if you are...
Page 359 Windows 8 Desktop Mode Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination). Click the wireless icon in the notification area of the taskbar. A list of available access points will appear. Double-click an access point to connect to it (or click it and click Connect).
Page 360 Windows 8 Control Panel If you are in Category View do the following (see over for Icon View): Open the Control Panel (see “Windows 8 Control Panel” on page E - Click the Network and Internet control panel. Click Connect to a network. Figure E - 31 - Network and Internet Control Panel A list of available access points will appear.
Page 361 Windows 8 If you are in Icon View do the following: Open the Control Panel (see “Windows 8 Control Panel” on page E - Click Network and Sharing Center. Click Change Adapter Settings. Double-click Wi-Fi. Figure E - 32 - Network and Sharing Center Control Panel A list of available access points will appear.
Page 362: Bluetooth Settings (Windows 8
Windows 8 Bluetooth Settings (Windows 8) If your purchase option includes the Combination Wireless LAN & Bluetooth module (either Intel® or 3rd Party) then install the driver as instructed in Chapter 7 (see links below). Use the Fn + F12 key combination to toggle power to the Bluetooth module. ...
Page 363: Bluetooth Configuration In Windows 8
Windows 8 Bluetooth Configuration in Windows 8 You can configure a Bluetooth connection as below, however make sure the Bluetooth module is turned on (and not in Airplane Mode) before configuration begins. Desktop Mode Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination).
Page 364 Windows 8 Click Add a Device. Double-click the device you want to pair with the computer. Figure E - 34 - PC Settings (Devices) - Add A Device On first connection the computer will provide you with a pairing code to be entered onto the device. Figure E - 35 - Enter the Passcode Enter the code into your Bluetooth enabled device and click Yes on the computer to complete the pairing.
Page 365 Windows 8 You need to either use Airplane Mode, or to turn the Bluetooth module off aboard aircraft.  Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module is either OFF or in Air- plane Mode (for Win- dows 8 only) if you are...
Page 366 Windows 8 To Make your Computer Discoverable to Bluetooth Devices Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination). Click the notification area of the taskbar, click the Bluetooth icon and click Open Settings. Click Options, and make sure that Allow Bluetooth devices to find this computer check box (Discovery) has a tick inside it.
Page 367: Settings (Windows 8
Windows 8 3G Settings (Windows 8) (For Model A Only) If you have included an optional UMTS/HSPDA OR UMTS/HSPDA+ based 3G Module (Universal Mobile Telecommunications System or High Speed Packet Access) module in your purchase option, you do not require a driver/application installation for Windows 8.
Page 368: 3G Configuration In Windows 8
Windows 8 3G Configuration in Windows 8 You can configure a 3G connection as below, however make sure the 3G module is turned on by pressing the Fn + key combination (give the module about 10 seconds to power on) before configuration begins. Charms Bar Go to the Charms Bar.
Page 369 Windows 8 Any 3G service provider (connection information is usually stored on the USIM card) will appear under Mobile Broadband. Double-click any connection icon under Mobile Broadband (or click and click Connect). Figure E - 39 - Mobile Broadband (Connect) The system will connect to your network.
Page 370 Windows 8 You can then access the internet, download e-mail etc. as per any internet connection. To disconnect you can select the connection and click Disconnect 10. You need to either use Airplane Mode, or to turn the Mobile Broadband module off aboard aircraft. ...
Page 371: Raid Setup (Windows 8
Windows 8 RAID Setup (Windows 8) To configure your RAID (Redundant Array of Independent Disks) system in Striping (RAID 0) or Mirroring (RAID 1) modes (see Table E - 5, on page E - 48) you will require at least two identical (see sidebar) hard disks.
Page 372 Windows 8 RAID Level Description Identical drives reading and writing data in parallel to increase performance. RAID 0 RAID 0 implements a striped disk array and the data is broken into blocks and each block is written to a separate disk drive. Identical drives in a mirrored configuration used to protect data.
Page 373: Sata Raid Setup Procedure (Windows 8
Windows 8 SATA RAID Setup Procedure (Windows 8) Before setting up the system you will need to copy three files to a USB flash drive or external USB hard disk. These drivers are included on the Device Drivers & Utilities + User’s Manual disc but you will need to go to an operable computer and copy the files to a USB Flash drive or external USB hard disk.
Page 374 Windows 8 12. The computer will then restart, as it does so press <F2> to re-enter the BIOS. 13. Go to the Exit menu (see page 14). 14. Select “Launch EFI Shell from filesystem device” (see page 14). 15. The system will restart and will look for the EFI shell application on your attached USB flash drive or external USB hard disk.
Page 375 Windows 8 18. Type “FS1:” 19. Type “rcfgsata /c YOURRAIDNAME /L:1” (note that YOURRAIDNAME can be any name you choose for your RAID, and that L:* denotes the RAID level e.g. /L:0 for RAID level 0 or /L:1 for RAID level 1). (Note if you need to delete an existing RAID see “Deleting an Existing RAID Volume”...
Page 376 Windows 8 25. Click Next. 26. Click Install Now. 27. A prompt will appear to ask you to Load Driver. 28. Click Browse and browse to the location you copied the files to on your USB Flash drive or external USB hard disk (X: denotes your USB Flash drive or external USB hard disk): •...
Page 377 Windows 8  Deleting an Existing RAID Volume If you have already created a RAID volume, and wish to delete it to create a new volume then follow the steps outlined in the previous pages until step 19. “rcfgsata /x” To delete an existing RAID volume type: You will be prompted to select y/n if you want to reset the disks (Note that deleting a RAID causes all the data on the disk to be lost).
Page 378 Windows 8 E - 54...

Puget V752i User Manual

Quick Start Guide Overview

Storage Devices, Audio & Mouse Overview

Power Management Overview

Drivers & Utilities

BIOS Utilities Overview

Upgrading the Computer Overview

Modules Overview

Troubleshooting

Interface (Ports & Jacks) Overview

Control Center Overview

Video Driver Controls

Specifications

Windows 8

Quick Links

Related Manuals for Puget V752i

Summary of Contents for Puget V752i
