LG Electronics Monterrey, México S.A. de C.V.
PART NUMBER: MFL67851401
DESCRIPTION: OWNER'S MANUAL
Product: Bottom Freezer Refrigerator
Brand: LG
1. Trim Size (mm): 182±1 (W), 257±1 (H)
2. Printing Color: Black
3. Paper Type:
- Cover: Bond 63 gr
- Content : Bond 63 gr
1. The part should not contain prohibited substances (Pb, Cd, Hg, Cr+6, PBB, PBDE) and should comply
with standard LG (61)-A-9101.
2. Blank sheets should be distributed as follows: 1st Blank sheet after cover.
3. For Owner's Manuals with less than 100 pages the bindery type will be Saddle Stitch, those with more
than 100 pages can use Perfect Bind. CONSIDERING NO VARIATION ON PRICE BETWEEN SADDLE
STITCH AND PERFECT BIND.
DESCRIPCIÓN: MANUAL DE USUARIO
Producto: Refrigerador con Congelador Inferior
Marca: LG
1. Dimensiones (mm): 182±1 (A), 257±1 (L)
2. Color de Impresión: Negro
3. Tipo de Papel:
- Portada: Papel Bond 63 gr
- Contenido: Papel Bond 63 gr
1. Esta pieza no debe contener sustancias prohibidas (Pb, Cd, Hg, Cr+6, PBB, PBDE) y los detalles deben
de cumplir con el estándar LG (61)-A-9101.
2. Las páginas en blanco deben distribuirse de la siguiente manera: 1ra página en blanco después de la
portada.
3. Para Manuales de Usuario con menos de 100 páginas el método de unión será de Engrapado, aquellos
con más de 100 páginas pueden usar Engomado. CONSIDERANDO QUE NO HAY VARIACIÓN EN EL
PRECIO ENTRE ENGRAPADO Y ENGOMADO.
EGVD900286 28/OCT/13: Change some text and language marks orientation.
1
Part No.
MODEL DESCRIPTION:
Project: QUANTUM-B DRAWER/SWING
Customer: LGEUS
PRINTING SPECIFICATION:
4. Printing Method: Off Set
5. Bindery Type: Saddle Stitch
6. Language: English
7. Number of Pages: 60
8. Number of Sheets: 15
NOTES:
Número de Parte:
DESCRIPCIÓN DEL MODELO:
Proyecto: QUANTUM-B DRAWER/SWING
Cliente: LGEUS
ESPECIFICACIONES DE IMPRESIÓN:
4. Método de Impresión: Off Set
5. Modo de Unión: Engrapado
6. Idioma: Inglés
7. Número de Páginas: 60
8. Número de Pliegos: 15
NOTAS:
DATE: AUG 17th, 2013
MFL67851401
MFL67851401

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LDC24370 series and is the answer not in the manual?

Questions and answers

Related Manuals for LG LDC24370 series

Summary of Contents for LG LDC24370 series

  • Page 1 LG Electronics Monterrey, México S.A. de C.V. PART NUMBER: MFL67851401 DATE: AUG 17th, 2013 DESCRIPTION: OWNER’S MANUAL Part No. MFL67851401 MODEL DESCRIPTION: Product: Bottom Freezer Refrigerator Project: QUANTUM-B DRAWER/SWING Brand: LG Customer: LGEUS PRINTING SPECIFICATION: 1. Trim Size (mm): 182±1 (W), 257±1 (H) 4.
  • Page 2 OWNER’S MANUAL BOTTOM FREEZER REFRIGERATOR Please read this owner’s manual thoroughly before operating and keep it handy for reference at all times. LDC24370** LDC22370** LBC24360** LDN22470** LBN22370** www.lg.com P/No. : MFL67851401-1...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS PRODUCT FEATURES HOW TO USE Before Use Control Pad IMPORTANT SAFETY - Control Pad Features INSTRUCTIONS Automatic Icemaker - Turning the Automatic Icemaker On or O - When You Should Turn the Icemaker O COMPONENTS - Normal Sounds You May Hear Refrigerator Exterior...

  • Page 5: Product Features

    PRODUCT FEATURES PRODUCT FEATURES * Depending on the model, some of the following functions may not be available. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer drawer remains open. If a refrigerator door or freezer drawer is left open for more than 60 seconds, a warning alarm sounds at 30 second intervals.

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of re, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following : This product is not to be used for special purposes such as the storage of medicine or test materials or for use on ships, etc.
  • Page 8 If the refrigerator is disconnected from the power supply, wait for at least ve minutes before plugging it back in. If you notice a chemical or burning plastic smell or see smoke, unplug the refrigerator immediately and contact your LG Electronics Service Center. SAVE THESE INSTRUCTIONS...

  • Page 9: Components

    COMPONENTS COMPONENTS Use this page to become more familiar with the parts and features of your refrigerator. Page references are included for your convenience. *The appearance and speci cations of the actual product may di er depending on the model. Refrigerator Exterior <Freezer Drawer model>...

  • Page 10: Refrigerator Interior

    COMPONENTS Refrigerator Interior (Freezer Drawer Model) Dairy Product Bin Used to preserve dairy products. LED interior lamps Fold-Up Bin The interior lamps light up the inside of the refrigerator. Can be folded up when tall storage is needed in the Door Bin. Adjustable Refrigerator Shelf The shelves in your...
  • Page 11 1_MFL67855701_Eng.indd 101 2013.7.30 8:28:16 AM COMPONENTS Refrigerator Interior (Freezer Swing Model) Dairy Product Bin Used to preserve dairy products. LED interior lamps Fold-Up Bin The interior lamps light up the inside of the refrigerator. Can be folded up when tall storage is needed in the Door Bin.

  • Page 12: Installation

    INSTALLATION INSTALLATION Installation Overview Please read the following installation instructions rst after purchasing this product or transporting it to another location. Unpacking your 2 Choosing the proper 3 Disassembling/Assembling refrigerator location 4 Connecting the water 5 Leveling and Door supply and water line Alignment...

  • Page 13: Speci Cations

    1_MFL67855701_Eng.indd 2 2013.7.24 11:44:56 AM INSTALLATION Specifications The appearance and speci cations listed in this manual may vary due to constant product improvements. 32 ¾’’ (W) X 34 7/8’’ (D) X 69 7/8’’ (H), 62 ¾’’ (D w/ door open) 24 cu.

  • Page 14: Unpacking Your Refrigerator

    1_MFL67855701_Eng.indd 3 2013.7.24 11:44:58 AM INSTALLATION Unpacking Your Refrigerator Choosing the Proper Location Select a place where a water supply can WARNING be easily connected for the automatic icemaker. Use two or more people to move and install the refrigerator. Failure to do so NOTE can result in back or other injury.

  • Page 15: Ambient Temperature

    1_MFL67855701_Eng.indd 4 2013.7.24 11:44:58 AM INSTALLATION Removing/Assembling the Ambient Temperature Refrigerator Door Handles Install this appliance in an area where the temperature is between 55°F (13°C) and 110°F NOTE (43°C). If the temperature around the appliance is too low or high, cooling ability may be When it is necessary to move the adversely a ected.

  • Page 16: Removing/Assembling The Freezer

    1_MFL67855701_Eng.indd 5 2013.7.24 11:44:59 AM INSTALLATION Removing/Assembling the Removing/Assembling the Freezer Drawer Handle Doors and Drawers (On Freezer Drawer Models) When it is necessary to move the refrigerator through a narrow opening, removing the doors Removing the Handle is the recommended procedure. Loosen the set screws located on the WARNING...
  • Page 17 1_MFL67855701_Eng.indd 6 2013.7.24 11:44:59 AM INSTALLATION Removing the Refrigerator Door Assembling the Refrigerator Door Remove the top hinge cover screws Mak e sure that the plastic sleeve is inserted in the bottom of the door. Lower Lift the hook (not visible), located at the the door onto the middle hinge pin as bottom of the front side of the cover shown in the gure.

  • Page 18: Removing The Freezer Drawers

    1_MFL67855701_Eng.indd 7 2013.7.24 11:44:59 AM INSTALLATION Removing the Freezer Drawers Slide out the bar. (On Freezer Drawer Models) The top and bottom drawers are all removed in the same way. In the following gures, the Pullout Drawer located above the freezer drawer is not shown for clarity.

  • Page 19: Assembling The Freezer Drawers

    1_MFL67855701_Eng.indd 8 2013.7.24 11:45:0 AM INSTALLATION Assembling the Freezer Drawers Reinstall the bar in the drawer supports. (On Freezer Drawer Models) The top and bottom drawers are all assembled in the same way. Using two hands, pull out both rails simultaneously until they are fully extended.

  • Page 20: Removing The Freezer Door

    1_MFL67855701_Eng.indd 9 2013.7.24 11:45:2 AM INSTALLATION Removing the Freezer Door Assembling the Freezer Door (On Freezer Swing Models) (On Freezer Swing Models) Before beginning, make sure you completely remove the refrigerator door. hinge pin. See Removing the Refrigerator Door (p.15) CAUTION Bottom Use two or more people to remove and...

  • Page 21: Reversing Door Opening Direction

    1_MFL67855701_Eng.indd 10 2013.7.24 11:45:2 AM INSTALLATION Reversing Door Opening Direction Assemble the mounting fasteners NOTE both ends of the handle using a To assist in the installation of the handle Allen wrench. on the right side, place a piece of masking tape near the top of the handle Place the handle on the door by tting before removing it.

  • Page 22: Reversing The Doors

    1_MFL67855701_Eng.indd 11 2013.7.24 11:45:3 AM INSTALLATION Reversing the Doors Remo ve the four screws , the hinge (On Freezer Drawer Models) pin insert and the hinge pin brackets from the bottom right side of the door. Remove the top hinge cover screws Lift the hook (not visible), located at the bottom of the front side of the cover with a at-head screwdriver.
  • Page 23 1_MFL67855701_Eng.indd 12 2013.7.24 11:45:4 AM INSTALLATION With a a t-head screwdriver, carefully pry Insert th e decorative screw into the outer o and remove the cover over the bolt hole on the right side of the ange. Attach holes on the left side of the refrigerator. the cover on the right side.
  • Page 24 1_MFL67855701_Eng.indd 13 2013.7.24 11:45:5 AM INSTALLATION Reversing the Doors NOTE (On Freezer Swing Models) The left top hinge, right hinge cap and left hinge cover are provided for Remove the top hinge cover screws reversing doors. Lift the hook (not visible), located at the bottom of the front side of the cover Line up the left top hinge with the holes in with a at-head screwdriver.
  • Page 25 1_MFL67855701_Eng.indd 14 2013.7.24 11:45:6 AM INSTALLATION Re move the four screws , the hinge NOTE pin insert and the hinge pin brackets Before removing the freezer door, from the bottom right side of the door. make sure you completely remove the refrigerator door.
  • Page 26 1_MFL67855701_Eng.indd 15 2013.7.24 11:45:9 AM INSTALLATION Usin g a 13/32-inch or 10mm socket On th e top part of the door, you will nd a wrench with a 2 inch extension and a and a pivot . Remove them with screwdriver, loosen the two bolts and the a at head screwdriver and install them screw, and remove the bottom hinge from...
  • Page 27 1_MFL67855701_Eng.indd 16 2013.7.24 11:45:11 AM INSTALLATION Using a 1 3/32 in. socket wrench with a 2 Flip the mi ddle hinge bracket and position in. extension and a screwdriver, tighten the it on the left side of the refrigerator and two bolts and the screw, and assemble reattach it with two bolts and a screw.
  • Page 28 1_MFL67855701_Eng.indd 17 2013.7.24 11:45:13 AM INSTALLATION Insert the decorative screw into the outer NOTE hole on the right side of the ange. Attach The left top hinge, right hinge cap the cover on the right side. Cover is force- and left hinge cover are provided for tted.

  • Page 29: Connecting The Water Line

    1_MFL67855701_Eng.indd 18 2013.7.24 11:45:14 AM INSTALLATION Connecting the Water Line Before You Begin CAUTION This water line installation is not covered by the Wear eye protection during installation refrigerator warranty. Follow these instructions to prevent injury. carefully to minimize the risk of expensive water damage.

  • Page 30: Water Line Installation Instructions

    1_MFL67855701_Eng.indd 19 2013.7.24 11:45:15 AM INSTALLATION If your existing copper water line has a CHOOSE THE VALVE LOCATION ared tting at the end, you will need Choose a location for an adapter (available at plumbing supply the valve that is easily stores) to connect the water line to the accessible.
  • Page 31 1_MFL67855701_Eng.indd 20 2013.7.24 11:45:16 AM INSTALLATION TIGHTEN THE PIPE CLAMP FLUSH OUT THE TUBING Tighten the clamp screws until the sealing Turn the main water washer begins to swell. supply on and ush out the tubing until the water NOTE: Do not overtighten the clamp or is clear.

  • Page 32: Turning On The Power

    1_MFL67855701_Eng.indd 21 2013.7.24 11:45:19 AM INSTALLATION Turning On The Power TURN THE WATER ON AT THE SHUTOFF VALVE Tighten any connections that leak. Plug in the refrigerator. CAUTION CAUTION Check to see if leaks occur at the water Connect to a rated power outlet. line connections.

  • Page 33: Leveling And Door Alignment

    1_MFL67855701_Eng.indd 22 2013.7.24 11:45:20 AM INSTALLATION Leveling and Door Alignment Leveling Door Alignment After installing, plug the refrigerator’s power If the space between your doors is uneven, cord into a 3-prong grounded outlet and push follow the instructions below to align the the refrigerator into the nal position.

  • Page 34: How To Use

    1_MFL67855701_Eng.indd 23 2013.7.24 11:45:21 AM HOW TO USE HOW TO USE Before use Clean the refrigerator. Clean your refrigerator thoroughly and wipe o all dust that accumulated during shipping. CAUTION Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a ammable liquid or an abrasive when removing any tape or adhesive from the refrigerator.

  • Page 35: Control Pad

    1_MFL67855701_Eng.indd 24 2013.7.24 11:45:23 AM HOW TO USE Control Pad * Depending on the model, some of the following functions may not be available. Control Pad Features LED Display Indicator Control Button Door Alarm Refrigerator Temperature Indicates the set temperature of the refrigerator When power is connected to the refrigerator, the door alarm is initially set to ON.

  • Page 36: Automatic Icemaker

    1_MFL67855701_Eng.indd 25 2013.7.24 11:45:25 AM HOW TO USE Automatic Icemaker (Freezer Room) * Depending on the model, some of the following functions may not be available. Ice is made in the automatic icemaker and sent to the dispenser. The icemaker will produce 12 cubes per cycle—approximately 100 cubes in a 24-hour period, depending on freezer compartment temperature, room temperature,...

  • Page 37: When You Should Turn The Icemaker O

    1_MFL67855701_Eng.indd 26 2013.7.24 11:45:26 AM HOW TO USE Automatic Icemaker (continued) Normal Sounds You May Hear CAUTION The icemaker water valve will buzz as The rst ice produced may include particles the icemaker lls with water. If the or odor from the water supply line or the power switch is in the ON (I) position, water tank.

  • Page 38: Storing Food

    1_MFL67855701_Eng.indd 27 2013.7.24 11:45:26 AM HOW TO USE Storing Food Food Preservation Location (On Freezer Drawer Models) Each compartment inside the refrigerator is designed to store di erent types of food. Store your food in the optimal space to enjoy the freshest taste. Dairy product bin Adjustable refrigerator shelf Adjustable shelves to meet your...
  • Page 39 1_MFL67855701_Eng.indd 28 2013.7.24 11:45:27 AM HOW TO USE Food Preservation Location (On Freezer Swing Models) Each compartment inside the refrigerator is designed to store di erent types of food. Store your food in the optimal space to enjoy the freshest taste. Dairy product bin Adjustable refrigerator shelf Adjustable shelves to meet your...

  • Page 40: Food Storage Tips

    1_MFL67855701_Eng.indd 29 2013.7.24 11:45:28 AM HOW TO USE Storing Frozen Food Food Storage Tips * The following tips may not be applicable NOTE depending on the model. Check a freezer guide or a reliable cookbook for further information about preparing food Wrap or store food in the refrigerator in airtight for freezing or food storage times.

  • Page 41: Humidity Controlled Crisper And Glide'n'serve

    1_MFL67855701_Eng.indd 30 2013.7.24 11:45:29 AM HOW TO USE Storing Frozen Food (continued) Humidity Controlled Crisper and Glide’N’Serve Packaging Humidity Controlled Crisper Successful freezing depends on correct packaging. When you close and seal the package, it must not allow air or moisture in or * Depending on the model, some of the out.

  • Page 42: Detaching And Assembling The Storage Bins

    1_MFL67855701_Eng.indd 31 2013.7.24 11:45:30 AM HOW TO USE Detaching and Assembling the To Remove the Glass Storage Bins (Glide’N’Serve not shown for clarity.) Lift up the glass under the crisper cover, and Glide’N’Serve and Humidity pull up and out. Controlled Crisper To remove the Humidity Controlled Crisper and the Glide’N’Serve, pull out the Crisper Glide’N’Serve...

  • Page 43: Adjusting The Refrigerator Shelves

    1_MFL67855701_Eng.indd 32 2013.7.24 11:45:32 AM HOW TO USE Adjusting the Refrigerator Assembling the Split Shelf Shelves Tilt the front of the shelf up and guide the shelf hooks into the slots at a desired height. Then, The shelves in your refrigerator are adjustable lower the front of the shelf so that the hooks to meet your individual storage needs.

  • Page 44: Maintenance

    1_MFL67855701_Eng.indd 33 2013.7.24 11:45:32 AM MAINTENANCE MAINTENANCE Cleaning Both the refrigerator and freezer sections defrost automatically; however, clean both sections about once a month to prevent odors. Wipe up spills immediately. Always unplug the refrigerator before cleaning. General Cleaning Tips Inside Walls (allow freezer to warm up so the cloth will not stick) Unplug refrigerator or disconnect the...

  • Page 45: Smart Diagnosis

    After you hear three beeps, release the in Canada). Only use the Smart Diagnosis feature Freezer button. when instructed to do so by the LG call center agent. The transmission sounds that you will hear Keep the phone in place until the tone are normal and sound similar to a fax machine.

  • Page 46: Troubleshooting

    1_MFL67855701_Eng.indd 35 2013.7.24 11:45:33 AM TROUBLESHOOTING TROUBLESHOOTING Review the Troubleshooting section before calling for service; doing so will save you both time and money. Problem Possible Causes Solutions Refrigerator and The refrigerator control is set to Turn the control ON. Refer to the Setting the Freezer section OFF (some models).
  • Page 47 1_MFL67855701_Eng.indd 36 2013.7.24 11:45:36 AM TROUBLESHOOTING Problem Possible Causes Solutions Refrigerator or The refrigerator was recently It may take up to 24 hours for each compartment Freezer section is installed. to reach the desired temperature. too warm. The air vents are blocked. Rearrange items to allow air to ow throughout the compartment.
  • Page 48 1_MFL67855701_Eng.indd 37 2013.7.24 11:45:37 AM TROUBLESHOOTING Problem Possible Causes Solutions Interior moisture The doors are opened often or When the doors are opened often or for long buildup. for long periods of time. periods of time, warm, humid air enters the compartment.
  • Page 49 1_MFL67855701_Eng.indd 38 2013.7.24 11:45:37 AM TROUBLESHOOTING Problem Possible Causes Solutions Refrigerator or Incorrect temperature control If the temperature is too cold, adjust the control Freezer section is settings. one increment at a time and wait for the too cold. temperature to stabilize. Refer to the Setting the Controls section for more information.
  • Page 50 1_MFL67855701_Eng.indd 39 2013.7.24 11:45:38 AM TROUBLESHOOTING Problem Possible Causes Solutions Icemaker is not The doors are opened often or If the doors of the unit are opened often, ambient making enough for long periods of time. air will warm the refrigerator which will prevent ice (continued).
  • Page 51 1_MFL67855701_Eng.indd 40 2013.7.24 11:45:40 AM TROUBLESHOOTING Problem Possible Causes Solutions Ice has a bad The water supply contains A water lter may need to be installed to taste or odor. minerals such as sulfur. eliminate taste and odor problems. NOTE: In some cases, a lter may not help. It may not be possible to remove all minerals / odor / taste in all water supplies.
  • Page 52 1_MFL67855701_Eng.indd 41 2013.7.24 11:45:41 AM TROUBLESHOOTING Problem Possible Causes Solutions Rattling Rattling noises may come from Normal Operation the ow of refrigerant, the water line on the back of the unit, or items stored on top of or around the refrigerator. The refrigerator is not resting The oor is weak or uneven or the leveling legs solidly on the oor.
  • Page 53 1_MFL67855701_Eng.indd 42 2013.7.24 11:45:42 AM TROUBLESHOOTING Problem Possible Causes Solutions Doors will not Food packages are keeping the Rearrange food containers to clear the door and close correctly or door open. door shelves. pop open. The ice bin, crisper cover, pans, Push bins all the way in and put the crisper cover, shelves, door bins, or baskets pans, shelves and baskets into their correct...

  • Page 54: Warranty

    Should your LG Refrigerator (“Product”) fail due to a defect in materials or workmanship under normal home use, during the warranty period set forth below, LG will at its option repair or replace the product. This limited warranty is valid only to the original retail purchaser of the product and applies only when purchased and used within the United States including U.S.
  • Page 55 Damage resulting from misuse, abuse, improper installation, repair, or maintenance. Improper repair includes use of parts not approved or speci ed by LG. Damage or failure caused by unauthorized modi cation or alteration, or if it is used for other than the intended purpose, or any water leakage where the unit was not properly installed.
  • Page 56 WARRANTY : Should your LG Refrigerator (“Product”) fail due to a defect in material or workmanship under normal home use during the warranty period set forth below, LG Canada will at its option repair or replace the Product upon receipt of proof of original retail purchase. This warranty is valid only to the original retail purchaser of the product and applies only to a Product distributed in Canada by LG Canada or an authorized Canadian distributor thereof.
  • Page 57 Damage resulting from the misuse, abuse, improper installation, repair, or maintenance of the Product. Improper repair includes use of parts not approved or speci ed by LG Canada. Damage or product failure caused by unauthorized modi cation or alteration, or use for other than its intended purpose, or resulting from any water leakage due to improper installation.
  • Page 58 1_MFL67855701_Eng.indd 48 2013.7.24 11:45:44 AM NOTES...
  • Page 59 1_MFL67855701_Eng.indd 49 2013.7.24 11:45:44 AM NOTES...
  • Page 60 1_MFL67855701_Eng.indd 50 2013.7.24 11:45:44 AM...
  • Page 61 1_MFL67855701_Eng.indd 51 2013.7.24 11:45:45 AM LG Customer Information Center For inquires or comments, visit www.lg.com or call; 1-800-243-0000 USA, Consumer User 1-888-865-3026 USA, Commercial User 1-888-542-2623 CANADA Register your product Online! www.lg.com...
