Whirlpool Europe
Customer Services
Service Manual
Washing machine
ACCESS
AWM 8000-CENTR.EU
AWM 8000-CENTR.EU
8570 079 10000
Family
This documentation is only intended for qualified technicians who are aware of the respec-
tive safety regulations.
Date: 23.08.2002
Document-No.: 4812 712 17818
AWM 8000-CENTR.EU
Page
2 - 4
5 - 6
7 - 8
9
10
11 - 16
17 - 19
OMEGA
Access EU
Subject to modification
