EnGenius EP-801-OUT-LLC400-10 Quick Installation Manual

External antenna packet for the EnGenius EP Series (EP801, EP802 & EP800)
The EP-801-OUT-LLC400-10 content consist:
– 1 x Outdoor CX840 rugged antenna (30cm) with N-Female connector
– 1 x set of mounting U-Bolts & fasteners
– 1 x 10 meters of LLC400, Low Loss Coaxial cable with N-Male connector & TNC-Male connector
Mounting instructions
UHF antenna for base station service made of high quality materials to get the best performance and the maximum e ciency. It is
completely manufactured with aluminum tubes and nylon for its great robustness and it is supplied with a solid steel bracket for an easy
and safe installation. Its Gamma Match feed makes it earthed for a perfect protection against the discharges. In the mentioned range of
frequency, adjustments are not required. Simple and strong it is particularly recommended for a professional use.
