  • Page 1 P R O G R A M M I N G M A N UAL KLA-110 Launch Amplifier/Power Supply PA G E 1 P R O G R A M M I N G M A N U A L...

  • Page 2: Table Of Contents

    Now that you have installed the rack, launch amplifier and • A window will appear for you to enter the User name and modules, it is now time to program the system via the KLA-110 Password. Enter the default user name ‘admin’ and default Launch Amplifier, following these steps;...
  • Page 3 NOTE: If the headend has already been installed and the username and password is not known, use a thin blunt object (such as a paper clip) to activate the reset (for 3 seconds) on the front of the KLA-110, as shown in the adjacent image. This will reset the username and password back to default.

  • Page 4: Programming The System Via Ethernetconnection

    KLA- appropriate module as displayed 110 (The KLA-110 will be on the far right hand side). . on your computer screen. The In the headend software, click on following window will appear.

  • Page 5: Kvm-110 Parameters

    2.2 KVM-110 PARAMETERS 2.3 KLA-110 PARAMETERS In the KVM-110 settings, you can change the In the KLA-110 settings, you can change the Module Name, the Module Name, Module Position, Channel Name, Output Level via the gain, and switch the external power supply Output Frequency, RF Level, RF Output, and on or off.

  • Page 6: Programming The System Via Usb Connection

    4) Select the folder you wish to save the programme in and if 3.0 PROGRAMMING THE SYSTEM you want anybody else to have access to the software, then VIA USB CONNECTION click ‘next’. When only one module is being installed, use the USB software to access and change the settings.

  • Page 7: Operating The Software

    7) Once the installation programme is complete, click ‘close’. 10) Now double click on the file ‘CP210xVCPInstaller.exe’ to install the software 11) The following window will now appear. Choose your location and click ‘Install’. 8) Now you must install the device driver. Download or copy the software across to C drive on the computer being used to program the module.

  • Page 8: Kcc-110 Parameters

    From the target dropdown menu, choose module. either KCC-110 Channel Converter, KVM-110 VSB Modulator, or Channel Name Text can be added to name the KLA-110 Launch Amplifier. channel. System Mode Analogue or Digital signal to convert. System Bandwidth Choose the channel bandwidth applicable to your country e.g.

  • Page 9: Kla-110 Parameters

    Output level set by Gain Settings’ to save the new information. (max 10 channels at 110 dBuV -60 dB IMR). 3.4 KLA-110 PARAMETERS External Power: ON/OFF Allows 18 volts @ 100mA to be feed out of the antenna input When choosing the Launch Amplifier, the following window will connection.

  • Page 10: Save Settings

    4.1 SAVE SETTINGS The system will allow you to save the parameters of the system. This is particularly useful to clone a system when installing several headends that are the same or just for record keeping. To save the settings, in system configuration menu, click on ‘save settings’...

  • Page 11: Network

    (such as a paperclip), to push into the small hole on the front of This is important if any remote monitoring or controlling is the KLA-110. Hold this in whilst switching the system on for 3 required when connecting to a network. You may find that the seconds.

  • Page 12: Trouble Shooting

    I have connected the system as above but still no Check that you have connected to a channel Converter module. connection. I noticed the communication LED’s do not flash on the KLA-110 when plugging in the ethernet lead. Solution If the computer you are using is old, (i.e. over 5 years old), you may need to use a cross over cable.
  • Page 13 Double click local area connection. automatically then you won’t be able to connect directly to the Kingray Professional Series. You must make sure you have a static IP address set up as below to connect to the system. Under the ‘General’ tab, enter in the following IP settings (other IP addresses can be used providing it is in the same range as the KLA110 eg 192.168.xx.xx).
  • Page 14 USING WINDOWS 7 In the left hand column, click on CHANGE ADAPTER SETTINGS. Go to START, then click on CONTROL PANEL. Double click the icon, LOCAL AREA CONNECTION. Click on NETWORK AND SHARING CENTER. Click on PROPERTIES. Network and Sharing Center PA G E 1 4 P R O G R A M M I N G M A N U A L K L A - 1 1 0...
  • Page 15 NOTE: If your computer is set up to obtain an IP address automatically then you won’t be able to connect directly to the Kingray Professional Series. You must make sure you have a static IP address set up as below to connect to the system.
  • Page 16 A division of Standard Communications Pty Ltd. www.kingray.net.au Head Office: PO Box 96, Winston Hills, NSW 2153. T: (02) 8867 6000 F: (02) 8867 6199 Enquiries/tech support: 1300 463 463 Sydney Melbourne Brisbane Adelaide Perth Auckland (02) 8867 6000 (03) 9558 9999...
