The White Mountain Log Collection:
STONE RIVER
WARNINGS
If the information in this manual is not fol-
lowed exactly, a fire or explosion may result
causing property damage, personal injury
or loss of life.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier
from neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
– Installation and service must be per-
formed by a qualified installer, service
agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
LSU24SF-2 Shown
LOG SET FOR
VENTED AND UNVENTED
MULTI-SIDED GAS LOG HEATER
MODELS
LSU18SF-2
LSU24SF-2
LSU30SF-2
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
Log sets comply with ANSI Z21.11.2 Unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may
only allow operation of log sets in a vented
configuration. Check your state or local codes.
WARNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
Page 1
Advertisement
Table of Contents
Related Manuals for White Mountain LSU18SF-2
Summary of Contents for White Mountain LSU18SF-2
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL LOG SET FOR The White Mountain Log Collection: VENTED AND UNVENTED STONE RIVER MULTI-SIDED GAS LOG HEATER MODELS LSU18SF-2 LSU24SF-2 LSU30SF-2 LSU24SF-2 Shown WARNINGS If the information in this manual is not fol- lowed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 2: Table Of Contents
Page Important Installation Guidelines ..............3 General Information ..................3 Requirements for Canada ................4 LSU18SF-2 Log Identification ................5 LSU18SF-2 Log Placement ............... 6-12 LSU(24,30)SF-2 Log Identification..............13 LSU(24,30)SF-2 Log Placement...............14-21 Ember Placement LSU18SF-2 Photos ............22 Ember Placement LSU24SF-2 Photos ............23 Ember Placement LSU30SF-2 Photos ............24 Parts List and Parts View ................25... -
Page 3: Important Installation Guidelines
IMPORTANT INSTALLATION GUIDELINES Proper Log Placement WARNING Log placement is critical to proper burner performance. Logs must be correctly positioned onto the burner. The photos in this manual Do not use a blower insert, heat exchanger insert or other show the proper pinned position for logs on this set. Owners need to accessory not approved for use with this heater. -
Page 4: Requirements For Canada
REQUIREMENTS FOR CANADA This unit cannot be installed in a UNVENTED application, this WARNING unit can only be installed as a VENTED application with these requirements. DO NOT OPERATE THIS GAS LOG SET WITH GLASS DOORS CLOSED IMPORTANT SAFETY INFORMATION •... -
Page 5: Lsu18Sf-2 Log Identification
LSU18SF-2 LOG IDENTIFICATION Part Front View Top View Description Number Log A R9297 Log B R9298 Log C R9299 Log D R9300 Log E R9301 25743-1-1015 Page 5... -
Page 6: Lsu18Sf-2 Log Placement
LSU18SF-2 LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. - Page 7 LSU18SF-2 LOG PLACEMENT 1. Place Log A onto the two left front burner pins and two left middle row burner pins. See image below. 25743-1-1015 Page 7...
- Page 8 LSU18SF-2 LOG PLACEMENT 2. Place Log B onto the two right front burner pins as shown below. Page 25743-1-1015...
- Page 9 LSU18SF-2 LOG PLACEMENT 3. Place Log C onto the two right middle row burner pins as shown below. 25743-1-1015 Page 9...
- Page 10 LSU18SF-2 LOG PLACEMENT 4. Place Log D onto the two left rear burner pins. See image below. Page 25743-1-1015...
- Page 11 LSU18SF-2 LOG PLACEMENT 5. Place Log E onto the two right rear burner pins as shown below. 25743-1-1015 Page 11...
-
Page 12: Lsu18Sf-2 Log Placement
LSU18SF-2 LOG PLACEMENT 6. LSU18SF-2 log set is complete. Page 25743-1-1015... -
Page 13: Lsu(24,30)Sf-2 Log Identification
LSU(24,30)SF-2 LOG IDENTIFICATION Part Number Front View Top View Description LSU24SF-2 LSU30SF-2 Log A R9909 R9915 Log B R9910 R9916 Log C R9912 R9918 Log D R9913 R9919 Log E R9914 R9920 Log F R9911 R9917 25743-1-1015 Page 13... -
Page 14: Lsu(24,30)Sf-2 Log Placement
LSU(24,30)SF-2 LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. - Page 15 LSU(24,30)SF-2 LOG PLACEMENT 1. Place Log A onto the two front left burner pins as shown below. 25743-1-1015 Page 15...
- Page 16 LSU(24,30)SF-2 LOG PLACEMENT 2. Place Log F onto the two left middle row burner pins. See image below. Page 25743-1-1015...
- Page 17 LSU(24,30)SF-2 LOG PLACEMENT 3. Place Log B onto the two front right burner pins as shown below. 25743-1-1015 Page 17...
- Page 18 LSU(24,30)SF-2 LOG PLACEMENT 4. Place Log C onto the two right middle row burner pins. See image below. Page 25743-1-1015...
- Page 19 LSU(24,30)SF-2 LOG PLACEMENT 5. Place Log D onto the two left rear burner pins as shown below. 25743-1-1015 Page 19...
- Page 20 LSU(24,30)SF-2 LOG PLACEMENT 6. Place Log E onto the two right rear burner pins as shown below. Page 25743-1-1015...
- Page 21 LSU(24,30)SF-2 LOG PLACEMENT 7. LSU(24,30)SF-2 log set is complete. 25743-1-1015 Page 21...
-
Page 22: Ember Placement Lsu18Sf-2 Photos
EMBER PLACEMENT LSU18SF-2 PHOTOS REAR FRONT (VALVE SIDE) Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) Page 25743-1-1015... -
Page 23: Ember Placement Lsu24Sf-2 Photos
EMBER PLACEMENT LSU24SF-2 PHOTOS FRONT (VALVE SIDE) REAR Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) 25743-1-1015 Page 23... -
Page 24: Ember Placement Lsu30Sf-2 Photos
EMBER PLACEMENT LSU30SF-2 PHOTOS FRONT (VALVE SIDE) REAR Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) Page 25743-1-1015... -
Page 25: Parts List And Parts View
LOGS PARTS LIST & PARTS VIEW Attention: When ordering parts, it is very important that part number and description of part coincide. Index No. Part Number Description LSU18SF-2 R9297 Left Front Log R9298 Right Front Log R9299 Center Log R9300... -
Page 26: Master Parts Distributor List
MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort. com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit. -
Page 27: Service Notes
SERVICE NOTES 25743-1-1015 Page 27... - Page 28 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 25743-1-1015...
