Mesa I-Video PRO XVR1648 User Manual

Stand alone type

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Stand Alone Type

DVR SYSTEM

USER MANUAL

XVR1648

Table of Contents

Need help?

Do you have a question about the I-Video PRO XVR1648 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mesa I-Video PRO XVR1648

Page 1: User Manual
Stand Alone Type DVR SYSTEM USER MANUAL XVR1648...
Page 2: Table Of Contents
IMPORTANT SAFETY INSTRUCTIONS -------------------------------------------- 4 Specification & Organization -------------------------------------------------- 5 Specifications --------------------------------------------------------- 5 Product Contents List --------------------------------------------------- 7 System Organization ---------------------------------------------------- 8 Product Description -------------------------------------------------------- 9 Front panel description --------------------------------------------------- 9 Rear panel description --------------------------------------------------- 10 Remote Controller description --------------------------------------------- 11 HDD , CD/DVD-RW Connect -------------------------------------------------- 12 Power On ---------------------------------------------------------------- 13 Live Display --------------------------------------------------------------- 14...
Page 3 Archiving -------------------------------------------------------- 47 Archiving --------------------------------------------------- 47 Reserved Data Management ---------------------------------------------- 48 Ch Selection -------------------------------------------------- 49 SEQ Start / Stop ---------------------- ------------------------------------ 50 PTZ --------------------------------------------------------------- 51 Digital Zoom ------------------------------------------------------ 52 Key Lock ------------------------------------------------------ 53 Panic Rec ------------------------------------------------------ 54 Shutdown ------------------------------------------------------ 55 Remote SW installation ------------------------------------------------------ 56 System Requirement ---------------------------------------------------- 56 Introduction ----------------------------------------------------------- 57...
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
Page 5: Specifications
SPECIFICATION&ORIGANIZATION Specifications MODEL XVR1648 Operation PENTAPLEX PENTAPLEX performance (Doing Simultaneous Live Display/Recording/Playback/Archiving/ Networking effectively without interfering each other operations) Video in Channels Connection BNC, 1.0Vpp composite 75ohm balanced Loop through BNC,1.0Vpp composite 75ohm unbalanced, auto termination Audio in Channels Connection line level unbalanced Main Displays 1.0Vpp composite 75ohm unbalanced...
Page 6 SPECIFICATION&ORIGANIZATION Model XVR1648 Playback Speed Forward / reverse. 1x, 2x, 3x, 4x, 8x, 16x, 32x, 64x, 128x Control Front panel buttons and Jog / Shuttle ring/USB Mouse Search method Calendar / timeline, event log, Panorama Search 1,2, Smart Search Split screen display modes 1,4,16 Audio synchronization Yes, any frame rate...
Page 7: Product Contents List
SPECIFICATION&ORIGANIZATION Product Contents List Please confirm that all product contents are present when open the package. ① Basic Contents AC Power Cable Instruction Manual Remote Controller Remote Agent AAA Battery x 2 Installation CD ② Optional Contents Internal Hard Disk Drive Internal CD-RW/DVD-RW Drive USB Thumb Drive...
Page 8: System Organization
SPECIFICATION&ORIGANIZATION System Organization Remote Client PC(RA & CMS) Alarm Sensor #1-16 Alarm Out #1-16 Image Printer Camera #1-16 Alarm Input/Out NETWORK AVI Backup TCP/IP Video In WEB Client Backup Video Out Remote Controller A/V Monitor USB Mouse Monitor DVD-...
Page 9: Product Description
PRODUCT DESCRIPTION Front Panel Increases the speed for reverse playback Reverses playback Pauses / resumes playback CHANNEL SELECTION BUTTONS Selects forward playback Used to display individual channels in live display and playback ,And also used to enter numeric Increases the speed for POWER BUTTON passwords for login screens forward playback...
Page 10: Rear Panel Description
PRODUCT DESCRIPTION Rear Panel ① Video IN / Loop : BNC Video Input Port, BNC Video Loop Output ② Monitor out : BNC Main Monitor Output SVHS : Output Video by Connected SVHS. ③ Spot #1 ~ #4 : 4 x BNC Output to Individually-Sequenced Spot Monitors ④...
Page 11: Remote Controller Description
REMOTE CONTROLLER POWER MENU : Open System Setup Menu System ON/OFF Channel Selection Buttons ID Button Select DVR ID ENTER : Mouse Right Click RETURN Mouse Left click Navigation Buttons : Used for Playback Control, Menu Navigation, and PTZ/Focus Control ※...
Page 12: Hdd , Cd/Dvd-Rw Connect
HDD, CD/DVD-RW CONNECTION Above is the main board picture when open the top cover. The connection board (IDE subboard) is positioned in red box (1) (2) (1) is the port for the system disk (master drive), so you should install the first HDD at this port certainly. (HDD jumper location should be “Master”).
Page 13: Power On
POWER ON Press the power button. When the system completes to start up, the LOGON Box appears and then asking to input a password. DVR startup screen: detects and checks The HDD and CD-RW/DVD-RW. (Default password is none. Click the LOGON button.) DVR starts on normal operation mode and then show display with 16channels by default.
Page 14: Live Display
LIVE DISPLAY Configuring the Live Display Press mouse left button on DISP icon. It will change the display mode. • The operator can select the display mode between 5 different display type(1,4,8,9,16 split view). • Right click of mouse will allow user to change the channel of camera at the position.
Page 15: Setup-System
SETUP - SYSTEM Click the MENU icon on the Live Display mode and then Click the SYSTEM SETUP menu. Display -> Main Display Sequence • Main Display Sequence: Channel sequence on the main monitor. User can configure the display mode and with ordering for sequence - Press the ADD button.
Page 16 SETUP - SYSTEM Display -> Spot#1-4 Display Sequence In case of advance spot, setup method is almost same as main display sequence. - Press the ADD button. - Select Screen templates(1,4) - Press the screen template button for changing camera number. - Press the ADD button for inserting another screen templates.
Page 17: Camera
SETUP - SYSTEM Camera -> Title • Camera Title: Input camera title and description by virtual keyboard. Only English and Numeric are supported. Camera -> Color • Camera color setup: Select the Brightness, Contrast, Tint, Color. The operator can configure details of color on live display when clicking the button.
Page 18 SETUP - SYSTEM Camera -> PTZ • Select the address, protocol and Baud rate on each camera. The operator can configure detailed PTZ setup when click the button. Camera -> OSD / COVERT • Select channels for covert channel, Configure options for main display’s OSD and spot monitor’s OSD.
Page 19: Audio
SETUP - SYSTEM ※ How to use virtual keyboard Double click Mouse left button from the location that operator want to input character. It shows virtual keyboard. Select each characters on virtual keyboard. For using the small characters. Click the button.
Page 20: Network
SETUP - SYSTEM Network -> Configuration DHCP: In case of using ‘Dynamic IP’, Check the ‘DHCP’ When click ‘APPLY’ button, DVR get the IP address automatically. In case of using ‘Static IP’, input the IP address and other information manually. DDNS (Dynamic DNS): This is for user who has Dynamic IP address for DVR.
Page 21 SETUP - SYSTEM Network -> E-Mail Server USER Account : Enter username for sending mail server. PASSWORD : Enter password for sending mail server. SMTP SERVER : Name of SMTP server that will be used for email notifications. SMTP SERVER PORT : Port number for SMTP, well know port is 25.
Page 22: User
SETUP - SYSTEM User -> USER MANAGEMENT Default ID as ADMINISTRATOR is not allowed to delete for future maintenance. Press ADD icon for creating new user. Input ID and Password for new user. Input E-mail address for receiving email notification. Select group properly for accessing DVR.
Page 23 SETUP - SYSTEM User -> Group Management Default user group (administrator, manager, user) can not be deleted. After selecting “ADD” button, the operator can make the new user group with new authority. When press “ ADD” button, it shows “GROUP ADD” screen. It shows virtual keyboard with mouse double click in order to input characters.
Page 24: System
SETUP - SYSTEM System -> Date/Time - Date/ Time: Current DVR’s Date and Time. The operator can edit time setting manually. - Timezone: Select the Time zone for synchronization with NTP server. - Date and Time format: The operator can change the format of date and time. - Network Time server: Input the network time server’s domain name for getting the time automatically.
Page 25 SETUP - SYSTEM System -> System management - Firmware Upgrade Operator can update the F/W by USB device or CD/DVD. After copying the F/W into USB or CD/DVD, connect it into the DVR. Press the F/W upgrade button then they will show above screen. After selecting proper F/W from list, select the “OK”...
Page 26 SETUP - SYSTEM System -> Controller Controller connecting - Setup for keyboard joystick controller. - Select the System ID, Protocol and Baud rate. - Controller must be connected by RS485 port - Controller works same as mouse operation (control mouse pointer)
Page 27: Event
SETUP - SYSTEM Event -> Storage • File system Event - Disk Full - Alarm activation On/Off, when disk is full for recording. • Smart Event - Smart Warning- Alarm activation On/Off, when the system detects bad sector of HDD. - Smart Check Period - Select from 1 hour to 24 hour for bad sector check up period time.
Page 28 SETUP - SYSTEM Event -> Motion Detection Select the Motion Detection Activation,Sensitivity(1~10) and Motion Area. Operator can select motion areas from above screen when click the button. After selecting the motion areas with mouse drag, click the mouse right button, Then it shows pop-up menu that relates with selection type.
Page 29 SETUP - SYSTEM Event -> User Defined Operator can create User Defined Event as a combination of events. Operator can setup how it works when more than two events occur at the same time (Mixing condition is “AND” not “OR”) To setup detail configuration, press “EDIT”...
Page 30 SETUP - SYSTEM Event -> Alarm Out -Linked Event: Select an event that want to assign alarm out channel for action. (Alarm, Motion, Videoloss and User defined) - Select Activation on/off. - Normal status: Select the operation type. (High / Low) - Dwell Type: Latched/Transparent Time: 5- 300 second for Latched mode or until key strike...
Page 31 SETUP - SYSTEM Event -> Video Popup : When happen the selected event, screen pop-up at the designated monitor. - Press ADD button. - Select the event (Alarm, motion, User Defined Event) that want to pop-up, select the activation on/off. - Assign the camera’s channel that want to pop-up on each Monitor.
Page 32 SETUP - SYSTEM Event -> Remote Client Notification : When the selected event happen, it notify the event to Remote client. - Press ADD buttons. - Select User ID. - Select the Activation on/off. - Select Sensor, Videoloss, Motion, Storage(Smart alarm, HDD full) and user defined event). - Input the memo.
Page 33: Disk Management
SETUP - SYSTEM Disk Management - Operation mode: Select overwrite / write once mode (no overwrite) for recording. - Internal recording: It shows the internal HDD recording information that installed into system. - Format : When click the “START” button, all data will be formatted - Internal archiving: It shows the internal archiving information that installed...
Page 34: Setup-Record
SETUP - RECORD Click the Menu icon on the Live Display screen and then Click the Record setup Pre / Post Recording -Pre-Event Recording Time: When the DVR is not in continuous recording mode, this setting determines the amount of footage that is always recorded before an event occurs. (motion detection, alarm input etc.) - Post- Event Recording Time : When the DVR is not in continuous recording mode, this setting determines the amount of footage that is always recorded after an event occurs.
Page 35: Normal Record
SETUP - RECORD Normal Record DAY OF WEEK : Select ALL to apply the same recording parameter for everyday, otherwise select each date. -Drag the time that want to setup by mouse. In case of different setup by times, the color will be different.
Page 36 SETUP - RECORD Schedule The operator can select the recording type (Timer, Motion, Alarm, Alarm or Motion and Record off) Drag the section that want to select and then click the mouse right button. Then recording option will be appeared. The operator can select the recording option each time and channel.
Page 37: Intensive Record
SETUP - RECORD Intensive Record In case of this record, record will be centralized at a channel that event is happened as event priority. Parameter -Drag the time line that want to setup by mouse. In case of setup differently each time, the color will be different.
Page 38 SETUP - RECORD Schedule The operator can select the record on/ off each time, channel. Drag the section that want to select and then click the mouse right button. Then the recording option will be appeared. The operator can select the recording on/off each time and channel.
Page 39: Panic
SETUP - RECORD Panic Record When user press the panic button or system detects the panic alarm, recording condition will be changed as panic record setup. In case of recording setup, the operator should setup as 3 divided parts. The default setup is CIF, 30FPS. Setup method is same with normal record setup.
Page 40: Search
SEARCH The operator can search the recorded data as normal, panorama1, panorama2 and smart search mode Normal Search Click the MENU icon on the Live Display screen and Click the SEARCH button. Select the MENU icon and press the SEARCH button. Logon window will be display and input a password.
Page 41 SEARCH During the playback, the operator can save the image that want to save. Input the snapshot tag. Select the channel. Select the screen. Input the Memo. For saving the image, click the “reserve” button. (The operator can check the saved image from backup Date Management of backup menu).
Page 42 SEARCH It shows as left screen with backup data information. How to burning and reserve is same with how to save the snapshot. (The operator can check the saved image from backup Date Management of backup menu). Full Screen : Click the button for full screen from (D). Then it shows as below screen. For returning, move the mouse icon to the bottom of screen.
Page 43 SEARCH : Click the button for changing the playback display from (D). The operator can select the playback display mode. • Playback -> Live View Select the LIVE VIEW mode. Then it shows current live display instead of calendar. You can see the live display and playback display at the same time.
Page 44 SEARCH • Playback-> Log Click the LOG tap. Then it shows as left screen. Select the date that want to see the log from calendar. Select the event section that want to see. Click to start. Click the button for viewing timeline. The option that want to search each channel can be selected.
Page 45: Panorama1 Search
SEARCH Panorama1 Search - The operator can search the data as frame by frame. • Select the channel. • Select the date. • Select the time. • The operator can select the time from timer or by drag the timeline bar.
Page 46: Panorama2 Search
SEARCH Panorama2 Search - The operator can search with divided screens in time ranges. Snapshot backup Channel selection Start time selection Selection of Total time range The operator can select the playback starting point by Drag and drop Timeline bar.
Page 47: Smart Search
SEARCH Smart Search -The operator can search by Museum search or Motion search. - Select the camera. - Select the area that want to search by mouse drag. - Select the search method. (Museum or Motion) - Museum search This search indicates or generates event (consistent/inconsistency) when search is compare with the starting image and the image continuous to occur more than Designated Time on the Designated Accuracy of the Selected Area.
Page 48: Archiving
ARCHIVING Archiving Click the right mouse button on the Live Display screen and Click the ARCHIVING menu. • Select the MENU icon and press the ARCHIVING menu. • Logon window shows and input a password. It shows the backup menu. •...
Page 49: Reserved Data Management
ARCHIVING Reserved Data Management • The operator can see the saved snapshot images and AVI files which are from backup and search menu. Select the INFORMATION. It shows the AVI ARCIVING DATA INFORMATION window.
Page 50: Ch Selection
CH SELECTION CH SELECTION Right click mouse button on the Live Display screen and Click the Channel at the position. The operator can select the 16 CAM mode with clicking above icon.
Page 51: Ptz
Click the MENU icon on the Live Display screen and Click the menu. • PTZ control panel appears like above. 1) Select the camera. 2) Control the camera direction. Press this button. The operator can control the PTZ detailed configuration with pop-up screen. 4) Control the Zoom, Focus, Iris.
Page 52: Digital Zoom
DIGITAL ZOOM DIGITAL ZOOM Click MENU icon on the Live Display screen and Click the DIGITIAL ZOOM. Click button for returning to the live display. Right click of mouse button for changing the channel. Then it shows the channel list. Select the channel that want to change.
Page 53: Key Lock
KEY LOCK KEY LOCK Click the MENU icon on the Live Display screen and Click the KEY LOCK menu. Click the MENU icon on the Live Display screen and Click the LOCK menu. An operator with ADMIN rights can choose to lock the DVR front panel to prevent any un authorized control. Press the KEY LOCK button, All buttons are now disabled.
Page 54: Panic Rec
PANIC REC PANIC REC Click PANIC icon on the Live Display screen. Panic recording will override all standard recording settings to provide, by default, continuous recording on all channels. Press the PANIC icon. The right top of the display shows a red square with P to indicate that the DVR is in panic recording mode.
Page 55: Shutdown
SHUTDOWN SHUT DOWN Click the SHUTDOWN menu. To shutdown, user should enter the ID and password.
Page 56: Remote Sw Installation
REMOTE SW INSTALLATION System Requirement ① Main Board (CPU): Pentium-500(Minimum), Pentium 4 recommend ② OS: Higher than Windows 2000,DirectX 7.0A ③ Memory (RAM): More than 128 M ④ VGA: Graphic card that support the DIRECT-X ※IMM4 Codec (When Playback Backup File) ①...
Page 57: Introduction
REMOTE SW INSTALLATION Introduction ③ ① ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑭ ⑬ ① Main Display : Shows single or multi-channel view of cameras connected to the DVR. ② Camera Selection Buttons : Indicates Camera #; click button to display a selected camera. ③...
Page 58: Remote Sw Local Setup
REMOTE SW LOCAL SETUP Local Setup ② ① ① Group & DVR list. ② DVR Information. ③ Camera Assign : Setup camera. ③ ④ Option Check.(Event-system, alarm, video, record & In/Out) ⑤ Add, modify, delete group. ④ ⑤ Add Group ①...
Page 59 REMOTE SW LOCAL SETUP ③ Input DVR information.(name, IP, port, ID, PW) ④ Set camera position, check option and press ‘ADD’. ⑤ New DVR list is shown on the left upper side. Configuration ① Video OSD : Select screen information. (title, name, date, time) ②...
Page 60: Screen Division Selection
REMOTE SW LOCAL SETUP Selection Network ID • Select I/D to Connect Server. • I/D can be Add, Change, and Delete at Setup. TIP ※ Multi DVR Client 4EA DVRs can be control the live view, search the data, backup data and setup about each channel at the same time.
Page 61: Avi File Conversion
REMOTE SW LOCAL SETUP AVI File Conversion • Click AVI Conversion Button to Start AVI File Conversion. • During AVI Conversion Showing a Message and before Click ‘Stop” Save AVI File continuously . • ‘Press ‘Stop’ to Open Designate File Name & Saving Location, and Save AVI File.
Page 62: Remote Sw Search
REMOTE SW SEARCH Search Function Introduce ① ③ ④ ⑤ ⑥ ⑦ ② ⑧ ① Search Screen Playing Selected Video. ② Search Bar Search & Indicate Camera Recording Situation by Time Bar . ③ LIVE Return to Watch Mode. SETUP Open Setup to Change Network Setup or Option. ④...
Page 63: Search Method
REMOTE SW SEARCH Search Method ⑥ ⑤ ④ ③ ② ⑦ ① Indicates the Time of Day (0 ~ 24 hours) on Search Timeline. ② Indicates Recording Mode (Blue : No Recording, Red: Recorded Images Present) ③ Search Bar : Drag bar with the mouse to search through recorded video on the timeline. ④...
Page 64: Search Option
REMOTE SW SEARCH Search Option ③Save Image ①Archive ⑤Log Viewer ②Backup ⑥Event Play Viewer ④Print - Archive – Backup Image from Server to Remote PC. • Time Range - Enter the Starting and Ending Date/Time. • Channel : Check each channel to include in the Archive. •...
Page 65 REMOTE SW SEARCH - Backup Play (DVR Player) – Transfer to DVR Player ① ② ④ ③ ⑤ ① Showing Image (Possible to Only 1*1View Mode). ② Backup File Open to Play First Video. Ex. : ch02_04131730_04131735.rec ( Backup File for # 2 ch. Apr.13, 17H30M ~17H35M ) ③...
Page 66 REMOTE SW SEARCH - Save Image – Capture Image and Save to Local PC • Click ‘Save Image’ Icon During Playing Video. • Designate File name, File Type (JPG,BMP), and Location and Press Saving. • Conversion and Saving Image from Remote Viewer. - Print Image –...
Page 67 REMOTE SW SEARCH - Log Viewer – Find Video from the DVR Event Log. ② ① ③ ④ ⑤ ⑥ ⑧ ⑨ ⑩ ⑪ ⑦ ① Select Starting Date/Time and Ending Date/Time from which to search for Event Log events. - Press Search Button to Search and View Search Results.
Page 68 REMOTE SW SEARCH - Event Viewer - Showing Present Event in Server & Find Image ① Indicates the order in which events occurred. ② Indicates the DVR # on which an event occurred. ③ Indicates the Camera # on which an event occurred. ④...
Page 69: Remote Sw Dvr System Setup
REMOTE SW DVR SYSTEM SETUP Press button and it shows left screen. Select the System setup or Record setup. Click the “System” icon. Input the Password. ( Current default password is none. So click the “OK” w/o inputting the password )
Page 70: Camera
REMOTE SW DVR SYSTEM SETUP Camera Title: Input the name and description after Color: Select the Brightness, Contrast, Tint, Color selecting the channel with mouse. each channel. PTZ: Select the address, protocol, Baud rate Covert/OSD: Select the covert and main display, each channel.
Page 71: Alarm/Event
REMOTE SW DVR SYSTEM SETUP Alarm/Event VideoLoss Event: Select the video loss Sensor Event: Select the Activation, Active Activation. State (N/C, N/O-It is related with sensor type) and input the description. Motion Detection Event: Select the Motion Select the “AREA” icon. It shows above screen. Detection Activation and Select the motion area by Mouse drag then choose Sensitivity(1~10) and...
Page 72 REMOTE SW DVR SYSTEM SETUP Storage Event - User Event Disk Full: When disk full, Activation On/Off. Select the user event Activation Click the “Edit” then it shows above screen. The operator can make the User Defined Event with current event’s mixing. When happen the over two events at the same time, the operator can setup how it work.
Page 73 REMOTE SW DVR SYSTEM SETUP - Event Action * Relay out - Select the event that want to assign the action. - Select the Activation on/off. - Active state: Select the operation type(High / Low) - Dwell: Select the type and Action Time. Transparent : It work from Event start time to Event end time.
Page 74: Display
REMOTE SW DVR SYSTEM SETUP * Buzzer - When happen the selected event, select buzzer on/off. - After selecting the event(Alarm, motion, video loss,User Defined Event) that want to buzzer, select the activation on/off. - Select the buzzer type (Latched, Transparent) DISPLAY - Screen Template Select the screen division(typeA,B,C,D,E)
Page 75 REMOTE SW DVR SYSTEM SETUP - Main Display Setup - Press the ADD button or select the current list. - Select the name and dwell time. - Select the new list. - Select the screen template that want to do the sequence each channel.
Page 76: Audio
REMOTE SW DVR SYSTEM SETUP AUDIO - Live Audio Select the Live audio channel. - Network Audio Select the audio transmitter and receiver USER - User group Default user group(ADMINISTRATOR, MANAGER, USER) can not be deleted. After selecting “ADD” button, the operator can make the new user group with new authority.
Page 77: Remote Sw Dvr Record Setup
REMOTE SW DVR RECORD SETUP Input the Password. (Current default password is non. So click the “OK” w/o inputting the password) Record Mode - Select the “record mode” and “weekly/daily”. In case of selecting the “Normal Record” from record mode, The operator can not enter “Intensive Record”...
Page 78 REMOTE SW DVR RECORD SETUP - Weekly/Daily The operator can select the ‘Weekly” and “Daily” record setup from ‘Normal Record” and ‘Intensive Record” setup. So the DVR will record as daily and weekly setup configuration of “Normal and Intensive record” setup mode. Pre-Event Recording Time: When the DVR is not in continuous recording mode, this setting determines the amount of footage that is always recorded before an event occurs.
Page 79: Normal Record
REMOTE SW DVR RECORD SETUP Normal Record - Select the Daily/Weekly. - Select the Parameter/Schedule - Parameter - Drag the time that want to setup by mouse. In case of setup differently each time, the color is different - Click the “SET” icon. Then it shows above screen. In case of recording setup, the operator should setup as 4 divided parts.
Page 80 REMOTE SW DVR RECORD SETUP - Schedule The operator can select recording type (Timer, Motion, Alarm, User Defined, Alarm or Motion and Record off) each time, channel. Drag the section that want to select and then click the mouse right button. Then recording option will be appeared.
Page 81: Intensive Record
REMOTE SW DVR RECORD SETUP Intensive Record - In case of this record, record will be centralized at channel that event is happened as event priority. - Parameter - Drag the time that want to setup by mouse. In case of setup differently each time, the color is different The setup is same with normal recording setup.
Page 82: Panic Record
REMOTE SW DVR RECORD SETUP - Schedule The operator can select the record on/ off each time, channel. Drag the section that want to select and then click the mouse right button. Then recording option will be appeared. The operator can select the recording on/off each time and channel.
Page 83 WEB CLIENT SETUP • WEB Client Connection Input the IP Address or URL of the DVR in the Internet Explorer Address Bar. If when user use the DDNS, input the URL with default port number (8080) like below. http://00115FA1A4.dvrlink.net:8080 Then a dialog will appear to confirm download of an ActiveX control. Please click ‘Confirm’ or ‘Continue’. Then click the SETUP button.
Page 84 WEB CLIENT SETUP • WEB Client Connection Click the right button of mouse on the Site in Group and click the Add Group menu like below. Input the Group Name.
Page 85 WEB CLIENT SETUP • WEB Client Connection Click the Grout name and input the DVR information. * Input the default Port and User ID correctly. (6400, ADMINISTRATOR with NO PASSWORD) Then click the ADD button and OK button. Select the site name and click the connection button then input the password. (Default : No password)
Page 86 WEB CLIENT SETUP • WEB Client Connection If the DVR information is correct, can see the connected screen like below.
