Page 2: Safety Instructions
Safety Instructions Do not disassemble, or drop the camera from high altitude. Do not expose the camera to high temperatures and avoid contact with water and other liquid substances. After long time using, the camera body may become warm. This is a normal situation. Use only accessories provided by the manufacturer. -
Page 3: Table Of Contents
Catalogue Quick start guide ............................................ 1 1 Device Construction.......................................... 3 2 Buttons Designing .......................................... 4 3 Install the battery .......................................... 5 4 Battery charging ............................................ 5 5 AC power supply ............................................ 6 6 Insert the memory card ........................................ 6 7 Power on/power off .......................................... 7 8 Preview mode ............................................ 7 ... - Page 4 17 LCD screen auto shut-off ....................................... 17 18 Auto shut-off function after power supply cut ............................... 17 19 Cameras connected to a computer .................................... 17 20 Connected to TV .......................................... 18 21 Connected with car bracket (optional) .................................. 18 22 Remote Control Operation (optional) .................................. 19 Appendix I Packing list ...
-
Page 5: Quick Start Guide
Quick start guide ● Power on/power off Long press [Power] key to turn on the camera. Press and hold the [Power] key for 3 seconds to turn off the camcorder. ● Camera /photo / Continuous shooting In preview status, short press [Power] button to convert between different working mode: photo/ video/continuous shooting. In preview status, short press [Video/Photo] button to begin the recording / stop recording function. - Page 6 Watermark will be superimposed on photographs and videos. ● Night mode In night or low light environment, this mode is suggested for better photo and video performance. In preview mode, press [Menu/Back] button to enter main menu, select [ ] to enter the next menu. Press [Up]/[Down] button to select corresponding options and press [OK] button to confirm the setting.
-
Page 7: Device Construction
Device Construction 1) Video recording LED 2) USB port 3) Connector cover 4) HDMI port 5) Support micro SD card up to 32GB 6) MIC 7) Speaker 8) Video recording(up) / charging(down) LED 9) Power buttons / mode conversion 10) Ultra wide angle aspherical lens 11) Video/photo button 12) Menu/OK button Rechargeable Li-ion Battery... -
Page 8: Buttons Designing
Buttons Designing Video/Photo ● start & stop video recording ● take photos/continuous shooting button ● return to preview mode Up button ● select up & right towards ● zoom out ● long press for fast forward Down button ● select down & left towards ● zoom in ● long press for fast backward ●... -
Page 9: Install The Battery
Install the battery 1) Open the battery cover switch, take out the battery cover. 2) As shown in the illustration, put battery into the battery compartment, pay attention to the battery mounting direction. 3) After installing the batteries, close the battery cover and fasten the battery cover switch. Battery charging 1) Turn off the camera, with one end of the supplied USB cable connected with power adapter or computer, the other end connected to the camera, after a successful connection charge indicator turns red, charging starts. -
Page 10: Ac Power Supply
AC power supply The camera is switched on, with one end of the supplied USB cable to connect the power adapter or a computer and the other end connected to the camera, the LCD screen on the selected power supply options [ ], the camcorder using AC power supply, the battery icon changes to the Power icon. -
Page 11: Power On/Power Off
Power on/power off 1) Press [Power] key or connect a USB power cable to turn on the camera. 2) Press [Power] key for 3 seconds or unplug the USB power cable to turn off the camcorder. Note: ：You can set auto shut-off time in setting menus. Preview mode 1) preview mode icons illustration... - Page 12 present mode video mode photo mode continuous shooting mode 2 Hour: available recording time; Recording time 436/3999 : photo quantity/memory capacity 00:00:41: recording time Night mode Night mode open Motion detection motion detection opened & started motion detection opened but not started GPS status GPS connected GPS not connected...
- Page 13 Video resolution (1920x1080 30fps) (1280x720 60fps) (848x480 120fps) (video mode） Photo resolution (4608x3456) (2592x1944) (2048x1536) (photo mode) 2) Video recording Boot directly into the video preview status, short press [photo/video] button to start video recording. During video recording, short press [Power] key to protect current or adjacent video files, short press [photo/video] button again to stop recording. 3) Photo shootings In video preview state short press [Power] key to convert to photo mode, press [photo/video] key to take photos.
-
Page 14: Main Menu
Main menu In preview mode, press [Menu/Back] button to access the main menu. Press [Up]/[Down] keys to select the option to enter, press the [OK] key to enter the option, press the [Menu/Back] key to exit the main menu. Playback 1) playback preview mode In the main menu, select [ ] / [... - Page 15 In playback preview mode, press [Up]/[Down] button to select the file to be replayed, press [OK] button to open the video / photo, press [Menu/Return] key to pop up the playback menu.
- Page 16 2) Video playback In video playback mode, short press [UP]/[Down] key to select the previous / next video, press OK button to play / pause the video file. During video playback, long press [Up] key to fast forward play video files, long press [Down] key to rewind play video files.
- Page 17 3) Photo playback In Photo Playback mode, short press [UP]/[Down] button to browse previous / next photo, press [Up]/[Down] keys to zoom in / out the photo files, press [OK] key to restore normal size. Press the [Menu/Back] button to pop up the playback menu, press [Up]/[Down] keys to select an action to perform, select "Back" option, press [OK] key to return to the playback preview mode.
-
Page 18: Vehicle Use ( Mode ) And Sport Use ( Mode )
Vehicle use ( mode ) and sport use ( mode ) The default setting is vehicle use when connected with the car bracket, otherwise it is sport use ( mode ) . In two modes, different file names are applied to distinguish video files. Vehicle use ( mode ) named prefix CARM, sport use ( mode ) named prefix SPTM. The loop recording function under vehicle use ( mode ) is disabled for sport mode. -
Page 19: Emergency Video Protection
Emergency video protection When the camcorder is connected to car bracket, it will automatically open the gravity sensor. When the machine is subject to certain acceleration, the camera automatically triggers the emergency recording protection. Camcorder automatically protect the corresponding files. In the recording process, you can press the power button to manually protect current video file or an adjacent note. -
Page 20: Motion Defection
reaches 1GB, automatic segmentation is operated. While the card is full, recording stops. Motion defection When motion detection function is started, the camera will automatically detect whether an object is moving ahead. Recording will starts automatically when movement begins, and will stop in 10 seconds when the object quit moving. In setting menu under video recording, select [ ], press [Up]/[Down] to select the options, press “OK”... -
Page 21: Lcd Screen Auto Shut-Off
LCD screen auto shut-off In sport use, when there is no operation, LCD screen LED will automatically be shut off in 3seconds (except for situations during video& photo replay). Short press any button to recover it. In vehicle use, LCD screen is always on. When LCD screen is on, long press OK button to shut off the LED;... -
Page 22: Connected To Tv
removable disk drive, in this mode, you can copy files from the camera to your computer. Connected to TV Using a dedicated high-definition (HDMI) cable to connect the camcorder and HDTV. The TV source is adjusted to HDMI, turn on the camcorder, the camera image can be displayed on your HDTV. Note: TV display and LCD display are different, the LCD screen operation. -
Page 23: Remote Control Operation (Optional)
Remote Control Operation (optional) Using the remote control to take photos, make recordings. Remote control panel structure as shown below: 1) Video recording key: Press the remote control [video recording] key to make video recordings . 2) Stop button: Press the remote control [Stop] button to stop recording. 3) Photo button: Press the remote control [Photo] key to take photos. -
Page 24: Appendix I Packing List
Appendix I Packing list Please open the package and check it according to below accessories table. Item description Gotop: silver edition camera 197'/ 60m Waterproof Housing* Rechargeable Li-ion Battery QR Buckle J-Hook Buckle 3-Way Pivot Arm 1 Curved Adhesive Mount... -
Page 25: Appendix Ii Warranty
Appendix II warranty Dear Customer: Thank you for purchasing cameras. We will provide you high quality after-sales service in the future to facilitate your using. For any questions please do not hesitate to contact us. Our commitment: From the date of purchase, for defects occurred in normal using of the product, we will provide you sales service according to our warrantee. - Page 26 Client stub The "Warranty Card" is valid only by dealer or manufacturer stamp. Please keep "Warranty Card" and purchase invoice properly and safely, if unable to present the warranty card or purchase invoice, the warranty will be deemed a waiver of the right. User Information Name: Phone:...
- Page 27 Sales stub The "Warranty Card" is valid by dealer or manufacturer stamp. Please keep "Warranty Card" and purchase invoice properly and safely, if unable to present the warranty card or purchase invoice, the warranty will be deemed a waiver of the right. User Information Name: Phone:...
- Page 28 Manufacturers stub The "Warranty Card" is valid by dealer or manufacturer stamp. Please keep "Warranty Card" and purchase invoice properly and safely, if unable to present the warranty card or purchase invoice, the warranty will be deemed a waiver of the right. User Information Name: Phone:...
