Summary of Contents for Stadt GLACIER
- Page 1 ~ The future in heating and cooling ~ GLACIER EVAPORATIVE COOLERS OPERATING GUIDE Rev1/Nov ‘98...
-
Page 2: Electronic Control
How do they work? Fresh outside air is drawn into the unit through a series of wet filter pads. This causes evaporation to take place and the resulting air being blown through the duct work is filtered and cooled. The resulting cool air is then dispersed into each room (to be cooled) through an outlet at a rate pre- determined by your contractor at the time of sale. - Page 3 Operation This section explains how to operate your Stadt Glacier evaporative cooler, and the functions of each of the buttons featured on the evaporative cooling wall controller. Figure 1 shows the controller for your evaporative cooler. It features four buttons which are used to control the operation of the unit, and an array of lights which are used to display the operation of the unit.
- Page 4 8. At each press of the “STEP” button the lower flashing light will move in a clockwise direction. If the mains power to the unit has not been interrupted the next time the “ON/OFF COOL” button is activated the comfort level setting will be as last programmed. If the mains power has been interrupted the comfort level setting will revert back to the lowest setting when automatic cooling is next activated.
- Page 5 Figure 3. Wall controller showing changes to fan operation. Run Time Button This button allows you to preset the time at which your cooler turns on or off. If the unit is operating and you press the “RUN TIME” button all the light indicators will go blank.
- Page 6 Figure 4. Wall controller showing changes in run time. Figure 5. Wall controller showing countdown to "on time". Rev1/Nov ‘98...
- Page 7 Maintenance Regular maintenance is essential for ensuring that your evaporative cooler operates at maximum efficiency and comfort levels. To ensure that your evaporative cooler remains in good working condition for many years it should be thoroughly serviced every year. This service should be performed at the beginning and end of each cooling season.
