4358-3775B Scenera OHB
5/30/06
Replacement Parts List
NOTE: If requested color is not available, similar color will be
substituted.
Part
Cost
Quantity Total Cost
Crotch Strap/Buckle $4.99 X______= $ ______________
Seat Pad . . . . . . . . .$42.00 X______= $ ______________
Harness Retainer . . .$1.50 X______= $ ______________
Cup Holder . . . . . . .$4.99 X______= $ ______________
Locking Clip . . . . . . .$2.50 X______= $ ______________
Tether Kit . . . . . . . .$9.99 X______= $ ______________
Latch Kit . . . . . . . .$24.99 X______= $ ______________
Instructions . . . . . . .$0.00 X______= $ ______________
Merchandise Total
Shipping and handling:
Up to $25.00 . . . . . . . . . .$5.95
$25.01 to $50.00 . . . . . . .$6.95
$50.01 to $75.00 . . . . . . .$8.95
$75.01 to $100.00 . . . . . .$9.95
Sales Tax
(Indiana, California, Arkansas, and Massachusetts residents add applicable
sales tax.
Grand Total
No shipping and handling on instructions for quantities under 6. Add $.50 for
each instruction over 6, then add applicable shipping and handling.
Fill Out For Credit Card
K Visa
K Mastercard
Card Exp. Date: ______________________________
Cardholder's Name: __________________________
Card Number: ______________________________
Signature____________________________________
2:09 PM
Page 1
$______________
$ ______________
$100.01 to $150.00 . . . . .$10.95
$150.01 to $200.00 . . . . .$11.95
$200.01 and up . . . . . . . .$13.95
Outside Continental USA $10.00
$ ____________
$ ______________
50
S S c c e e n n e e r r a a V V e e r r s s a a - - F F i i t t
O O v v e e r r h h e e a a d d B B a a r r r r i i e e r r
I I n n s s t t r r u u c c t t i i o o n n M M a a n n u u a a l l
www.djgusa.com
This child
restraint is
designed for
use by children
whose:
Weight:
5-40 pounds
(2.3-18 kg)
Height:
19-43 inches
(48-110 cm)
Read all instructions
BEFORE USING
this child restraint.
KEEP INSTRUCTIONS FOR FUTURE USE.
IMPORTANT!
Failure to follow the warnings on the labels
and in the instruction manual can result in
the death or serious injury of your child.
Para recibir las instrucciones en español, llame al
1-800-544-1108 o solicitarse por escrito al dirección por arriba.
Eng. 4358-3775B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scenera Versa-Fit Overhead Barrier and is the answer not in the manual?

Questions and answers

Related Manuals for DJG Scenera Versa-Fit Overhead Barrier

Summary of Contents for DJG Scenera Versa-Fit Overhead Barrier

  • Page 1 4358-3775B Scenera OHB 5/30/06 2:09 PM Page 1 Eng. 4358-3775B Replacement Parts List S S c c e e n n e e r r a a V V e e r r s s a a - - F F i i t t NOTE: If requested color is not available, similar color will be substituted.

  • Page 2: Table Of Contents

    Table of Contents Thank you for choosing this car seat, referred to Warnings..................2-4 throughout this manual as a child restraint.The DJG General and Warm Weather Use..........4 family is committed to creating a child restraint with the Registration and Recall ..............5 most comfort and convenience available today.

  • Page 3: Warnings

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 5 WARNING WARNING Failure to follow these warnings can result in The vehicle or LATCH belt must stay the serious injury or death of your child. To tight at the belt path.When you switch from help you recognize those instructions which one mode to the next, review the sections of this instruction manual that apply to that...

  • Page 4: General And Warm Weather Use

    Dorel Juvenile Group does not recommend Dorel Juvenile Group, Inc. the use of any child restraint accessories PO Box 2609, Columbus, IN 47202-2609 except those provided by DJG. Attn: Consumer Relations or visit www.djgusa.com or call 1-800-544-1108 Never allow any child to play with this child restraint;...

  • Page 5: Understanding Your Vehicle

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 9 Understanding Your Vehicle Your vehicle’s features may be considerably different than those pictured here. Consult your vehicle owner’s manual to help identify your vehicle’s specific features. A.Anchor Bracket D.Air Bag For Top Anchorage Strap (Consult your vehicle (Forward-Facing Only) owner’s manual for all air...

  • Page 6: Child Restraint Parts

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 11 Child Restraint Parts Front Back Pillow (on select models) Buckle Infant Insert Top Anchorage Recline Stand Harness Release (on select models) (Tether) Strap & Lever LATCH Belt Hook Harness Covers Harness (on select models) Locking Clip Adjustment Strap Harness Retainer...

  • Page 7: Choosing Restraint And Position

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 13 Preparing Child Restraint to Fit Choosing Restraint and Position Your Child Your child’s height, weight and age determine how your You MUST make these adjustments with your child restraint should be placed in the vehicle and which child before you install the child restraint in the restraint should be used.

  • Page 8: Harness Height

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 15 Press red button on Determine which set of buckle to release the harness slots works best buckle plate. Raise barrier for your child. Adjust if above child restraint. needed. To change harness Place the child’s bottom location: and back flat against the...

  • Page 9: Accessories (On Select Models)

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 17 Accessories (on select models) Securing Your Child in the Child Restraint Pillow (on select models): The pillow provides extra comfort for Lower overhead barrier your toddler. and position harness straps To remove pillow: Pull over the child’s shoulders.

  • Page 10: Removing Your Child From The Child Restraint

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 19 Pull on harness adjustment Removing Your Child From the strap to tighten harness snugly. Child Restraint Loosen harness by pushing NOTE: A snug strap down on the harness should not allow any slack. release lever while pulling It lies in a relatively out on the harness.

  • Page 11: Reclining The Child Restraint

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 21 Choosing LATCH or Vehicle Belts Reclining the Child Restraint The LATCH System This child restraint has 2 recline positions: Upright (forward-facing only) and LATCH means Lower Anchor bars Reclined. Anchors and Tethers for CHildren.

  • Page 12: Knowing Your Vehicle Belts

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 23 Manual Belts Knowing Your Vehicle Belts Manual lap belts are Not all vehicle belts will work with this child restraint. common in the center You must determine if your vehicles belts are compatible rear seat and can allow with this child restraint.

  • Page 13: Locking Clip

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 25 Thread both portions of Locking Clip the vehicle belt onto the locking clip. NOTE: Remove the locking clip when the seat belt is not being used with a child restraint. The locking clip is located on the back of the seat.A locking clip will not fix all types of seat belt problems.

  • Page 14: Rear-Facing Use

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 27 Rear-Facing Use Rear-Facing Installation After deciding whether to use your Vehicle Belts or LATCH, be sure to read the warnings below as they pertain to both systems. To use rear-facing the child restraint MUST fully reclined.

  • Page 15: Vehicle Belt

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 29 Push down firmly on the Rear-Facing Installation with child restraint and pull Vehicle Belt: up on belt to tighten. For a manual belt, refer to “Knowing your Connect and tighten Vehicle Belt” section. harness straps prior to Pull up on shoulder installing in vehicle.

  • Page 16: Latch

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 31 Pull other end of Rear-Facing Installation with LATCH hook in front of LATCH: Install LATCH Belt crotch strap and across seat to other side. NOTE: Do not use the LATCH system along with the adult lap or lap/shoulder belt.
  • Page 17 4358-3775B Scenera OHB 5/30/06 2:09 PM Page 33 With weakest hand at Rear-Facing Installation with belt path, tilt and push LATCH: Install in Vehicle the child restraint forward and back, and Connect and tighten from side to side. If the harness straps prior to LATCH belts do not installing in vehicle.

  • Page 18: Forward-Facing Use

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 35 Forward-Facing Use Forward-Facing Installation After deciding whether to use your Vehicle Belts or LATCH, be sure to read the warnings below as they pertain to both systems. In the forward-facing position, the child restraint can be used in either reclined or upright position.

  • Page 19: Vehicle Belt

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 37 With weakest hand at Forward-Facing Installation with belt path, tilt and push Vehicle Belts: the child restraint forward and back, and Connect and tighten from side to side. If the harness straps prior to seat belts do not installing in vehicle.

  • Page 20: Latch

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 39 Fasten one LATCH belt Forward-Facing Installation with hook to the anchor in LATCH Belt: Install LATCH Belts the vehicle seat located in the vehicle seat bight. Repeat for other side of NOTE: Do not use child restraint.
  • Page 21 4358-3775B Scenera OHB 5/30/06 2:09 PM Page 41 With weakest hand at belt To release LATCH: path, tilt and push the Push in on release button and pull LATCH adjuster child restraint forward away from child restraint and back, and from side to to loosen.

  • Page 22: Adjusting The Top Anchorage (Tether) Strap

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 43 Adjusting the Top Anchorage Removing Seat Pad for Cleaning Strap WARNING The top anchorage strap is used for the forward-facing Do not use this child restraint without the position only. seat pad. Failure to do this can result in Most vehicles made after 9/1/99 already have the anchor serious injury.
  • Page 23 4358-3775B Scenera OHB 5/30/06 2:09 PM Page 45 From under seat, locate Pull pad off the shell. buckle’s metal clip. Clean with warm sudsy water, rinse clean and air dry. Do not use bleach or other harsh cleaners. Spot clean barrier pad and harness straps.

  • Page 24: Reinstall Harness

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 47 Rethread harness into new Reinstall Harness harness guide location. Refasten harness to Fit the buckle strap down splitter plate. Make sure through the slot in the harness does not twist. seat. Make sure buckle faces out.

  • Page 25: Trouble Shooting

    4358-3775B Scenera OHB 5/30/06 2:09 PM Page 49 Trouble Shooting Installation Tips: If your child restraint is not held securely In the rear-facing position, the harness strap must be by the belt: positioned at or below the child’s shoulders. In the Press down firmly on the child restraint and remove all the forward-facing position the harness must be positioned at slack in the belt.

  • Page 26: Warranty

    The warranty and remedies as set forth are exclusive and in lieu of all others, oral or written, expressed or implied. In no event will DJG or the dealer selling this product be liable to Name: ____________________________________________ you for any damages, including incidental or consequential damages, arising out of the use or inability to use this product.
