Summary of Contents for GECMA Challenger 15i-2-HB-FMO
-
Page 1: Operating Instructions
Operating Instructions CHALLENGER 15i-2-HB-FMO ( High Brightness Display ) GECMA COMPONENTS GMBH WWW.GECMA.COM TEL +49 2237 6996- MANUAL HB-DISPLAY REV C EN.DOC 31.01.07 A.J. -
Page 2: Table Of Contents
Safety instructions................... 7 Introduction The Challenger 15i-2-HB-FMO is an intrinsically safe display for use in Zone 1 / Zone 2. It is used, for instance, for the visualization of process displays in areas prone to explosion. The display is distinguished by its particular luminous intensity of up to 650cd/m². -
Page 3: General Advice
The manufacturer reserves the right to alter technical data according to the latest technical developments without special notice. Repairs, Hazardous materials Devices sent to GeCma Components GmbH for repair should be accompanied by a of description of the fault encountered. -
Page 4: Installation
For the connection of ASDs* Video input UVI * ASD: Application Supporting Device The terminal notation / numbering should be taken from the terminal nameplate which is attached close to the terminal. Details should be taken from the authorisation. GECMA:CMANUAL HB-DISPLAY REV C EN.DOC... -
Page 5: Technical Data
Connection interfaces: Terminal K4, K5, K9 (0.5-2.5)mm² rigid/flexible Terminal strip K4: for the connection of an ASD (application supporting device) for data input/ output e.g. a keyboard Voltage Current Max. external capacitance Max. external inductivity GECMA:CMANUAL HB-DISPLAY REV C EN.DOC... - Page 6 Max. external inductivity for the connection of an intrinsically safe video circuit with the following maximum values: Voltage Current Power effective internal capacitance negligible effective internal inductivity negligible Further details should be taken from the authorisation. GECMA:CMANUAL HB-DISPLAY REV C EN.DOC...
-
Page 7: Safety Instructions
Please only use the device for its authorised purpose. Conversions of and changes to the device are not permitted. The case may be opened solely by the GeCma Components GmbH company. Installation The national installation and erection regulations should be adhered to.
