ONEBEE SMART SERVER Installation Guide v.1 1. Getting Started Before you start installing make sure all accessories are packed well. In ONEBEE Smart server comes two different packages .There are ONEBEE Smart Home pack and ONEBEE Commercial pack. Each Pack has different kind of package lists.
1 Set Server Wall Mount Screws 2 Set HDD Screws 1 Set Sensors Batteries 1 Kit Note: The materials in the above check list may differ according to the rules by authorized dealer without any information. ONEBEE TECHNOLOGY PRIVATE LIMITED...
Page 3
1 Set Server Wall Mount Screws 2 Set HDD Screws 1 Set Sensors Batteries 1 Kit Note: The materials in the above check list may differ according to the rules by authorized dealer without any information. ONEBEE TECHNOLOGY PRIVATE LIMITED...
Page 4
3. Connecting point view Picture-2 shows the server ports and connecting the resources Video Input Audio Output HDMI OUT Video Input RJ45 Ethernet Audio Input block USB Port(Mouse/Pen drive/Wi-Fi Dongle) Antenna Port(Sensor) GSM Antenna SIM Tray Picture-2 ONEBEE TECHNOLOGY PRIVATE LIMITED...
Page 5
5. Connecting the Accessories Before you connecting the server accessories we’re highly recommended PLEASE PULL OUT POWER SOCKET FROM POWER SOURCE and DISCONNECT the BATTERY PROBE if it connects. Please refer PICTURE -2 for respective connecting accessories. ONEBEE TECHNOLOGY PRIVATE LIMITED...
Page 6
5.1 Connection for Video Input Recently ONEBEE SMART SERVER panel supports RCA for video input, In this case we have used RCA with female dc pin for power over video cable(1+3). ONEBEE TECHNOLOGY Picture-3 5.2 Connection for Camera Server Side RCA...
Page 7
In this step the wireless transceiver pin should be placed well in panel. And transceiver should be placed in an open air and respective height. Or it may causes coverage issues between the sensors ONEBEE TECHNOLOGY Sensor Antenna Port Picture-5 ONEBEE TECHNOLOGY PRIVATE LIMITED...
Page 8
Carefully insert the SIM. ONEBEE TECHNOLOGY SIM and GSM Antenna Picture-6 5.5 Connection for Hard Disk Picture-7 shows fixing the hard disk in top of the board. Picture-7 ONEBEE TECHNOLOGY PRIVATE LIMITED...
Page 9
This picture shows how to connect battery inside the panel. In this picture the Inverter (refer Picture-1) has two connection probes. Black refers the Negative of battery and Red refers the Positive of Battery. 5.7. Final Connection diagram ONEBEE TECHNOLOGY PRIVATE LIMITED...
