Summary of Contents for Messoa POE008
-
Page 1: User Manual
8-Port 10M/100M + 2-Port Giga (1GT+1G SFP) Web Managed PoE Switch User Manual 201309.008. A1... -
Page 2: Fcc Warning
FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. -
Page 3: Table Of Contents
Content 1. Introduction ....................1 1.1 Product Overview .....................1 1.2 Key Features .....................1 1.3 Package ......................4 2. Hardware Description ..................5 2.1 Product Outlook: ....................5 2.2 LED Indicators....................6 2.3 Hardware Installation ..................6 2.4 Hardware Restore Button (For Web Managed Switch only)......7 3 Preparation for Web Configuration..............8 4. - Page 4 4.7.1 MAC Address Binding.................35 4.7.2 TCP/UDP Filter ....................36 4.8 Spanning Tree ....................38 4.8.1 STP Bridge Settings..................38 4.8.2 STP Port Settings..................39 4.8.3 Loopback Detection Settings..............40 4.9 Trunking......................42 4.10 Backup/Recovery ..................44 4.11 Miscellaneous....................45 4.12 Logout ......................48 4.13 Q&A ........................49 ...
-
Page 5: Introduction
1. Introduction 1.1 Product Overview The switch is 8-port 10M/100M + 2 port Giga uplink (1*TP+1*SFP) Desktop Web Smart PoE Switch, the switch supports IEEE 802.3at Power over Ethernet standard, up to 30W per port, maximum 130W power consumption per system and no special network cable required for your PD devices. - Page 6 Interface Number of Port: 10 Fast Ethernet: 8-port 10/10 Base-TX with IEEE 802.3at PoE+ Gigabit Ethernet: 1-port 10/100/1000 Base-T, 1-port Gigabit SFP Performance MAC Address: Up to 4K Buffer Memory: 2.75Mb Transmission Method: Store and Forward Mechanism Software Feature Description ...
- Page 7 port TCP/UDP Filtering: Protocol Port Filter for secure WAN Port Spanning Tree Protocol Version: Support Legacy Spanning Tree Protocol & Rapid Spanning Tree Protocol Loopback Detection: Loopback detection to avoid network loop. Trunking Trunking Type: Static Trunk or LACP ...
-
Page 8: Package
1.3 Package Before you start to install this switch, please verify your package that contains the following items: One Switch One Power Cord One User Manual CD Optional Accessory: 11” to 19” Rack-mount kit ... -
Page 9: Hardware Description
2. Hardware Description This section mainly describes the hardware of the Web-Smart Management PoE Switch and gives a physical and functional overview on the certain switch. 2.1 Product Outlook: Front Ethernet Ports: The front panel of the web smart switch consists of 8 10/100Base-TX RJ-45 ports,1 10/100/1000M RJ-45 and 1 Gigabit SFP uplink ports. -
Page 10: Led Indicators
2.2 LED Indicators The LED Indicators present real-time information of systematic operation status. The following table provides description of LED status and their meaning. Color/Status Description Power Amber On Power on 10/100M Green On Link Up Link/ ACT Green Blinking Data activating Amber On Port is linked to Power Device... -
Page 11: Hardware Restore Button (For Web Managed Switch Only)
PoE: To delivery power without problem, the Cat 5/5e and Cat 6 cable is suggested. The high quality Ethernet cable reduces the lost while power transmission. SFP Installation While install the SFP transceiver, make sure the SFP type of the 2 ends is the same and the transmission distance, wavelength, fiber cable can meet your request. -
Page 12: Preparation For Web Configuration
3 Preparation for Web Configuration The web management page allows you to use a standard web-browser such as Microsoft Internet Explorer, Google Chrome or Mozila Firefox, to configure and interrogate the switch from anywhere on the network. Before you attempt to use the web user interface to manage switch operation, verify that your Switch is properly installed on your network and that every PC on this network can access the switch via the web browser. - Page 13 Launch the web browser and Login. Launch the web browser (Internet Explorer or Mozila Firefox) on the PC. Type http://192.168.2.1 (or the IP address of the switch). And then press Enter. 3. The login screen will appear next. 4. Key in the password. Default user name and password are both admin. If you can’t login the switch, the following steps can help you to identify the problem.
-
Page 14: Web Management Guide
4. Web Management Guide 4.1 User Log In This part instructs user how to set up and manage the switch through the web user interface. Please follow the description to understand the procedure. At the first, open the web browser, and go to 192.168.2.1 site then the user will see the login screen. -
Page 15: Main Page
Main Page Figure 1-3 ... -
Page 16: Administrator
4.2 Administrator 4.2.1 Authentication Configuration This page shows authentication configuration information. User can set new Username and Password in this page. Figure 2-1 System IP Configuration 12.13.3 This page shows system configuration including the current IP address, Subnet Mask and Gateway. Figure 2-2 User can configure the IP settings, Subnet Mask, Gateway as below: ... - Page 17 Subnet Mask: Assign the subnet mask to the IP address. Gateway: Assign the network gateway for industrial switch. IP Configure: Select the Static or DHCP. The default setting is Static, you can manually configure the IP Address settings.
-
Page 18: System Status
System Status 12.13.3 This page displays the information about the switch of MAC address, how many Physical Ports it has, System Version and Idle Time Security. Besides, users can also fill in up to 15 characters in the Comment, Contact and Location field for note. -
Page 19: Load Default Setting
Load Default Setting 12.13.3 Clicking the Load button will make the switch being set to the original configuration. Figure 2-4 ※ Note: It exclude to change user name, password and IP configuration. If you want to restore default setting including IP and user name password, then you can press the reset button for hardware base reset. -
Page 20: Firmware Update
Firmware Update 12.13.3 Before the firmware update procedure is executed, you should enter the password twice and then press Update button. Figure 2-5 The popup warning window appears for making sure you want to proceed the firmware upgrading process. Notice that the code of flash memory will be erased. - Page 21 page. After pressing Update button, the old web code will be erased. Then you can click “Browse” to select the image file. Figure 2-7 After selected the image file. The place right of the Browse command will display the file name you selected. Press “Update” to continue the firmware upgrading process.
-
Page 22: Port Management
Port Management Port Management includes Port Configuration, Port Mirroring, Bandwidth Control, Broadcast Storm Control and PoE Port Configuration 12.13.3 In Port Configuration, you can set and view the operation mode for each port. Figure 3-1 Port Configuration Function: ... - Page 23 Speed: When the Auto-Negotiation column is set as Disable, users have to set the connection speed to the ports ticked. Duplex: When the Auto-Negotiation column is set as Disable, users have to set the connection mode in Half/Full to the ports ticked. ...
-
Page 24: Port Mirroring
Port Mirroring 12.13.3 The Port mirroring is a method for monitoring traffic in switched networks. That Traffic through ports can be monitored by any of the ports means traffic goes in or out monitored (source) ports will be duplicated into mirroring (destination) port. -
Page 25: Broadcast Storm Control
Figure 3-3 Port No.: Select the port number you want to configure. Tx Rate: Type the Tx Rate value. The value is range from 0-255. Rx Rate: Type the Rx Rate value. The value is range from 0-255. ... -
Page 26: Poe
check boxes. Figure 3-5 The broadcast packet is only checked at the selected port and the number of broadcast packets is counted in every time unit. The one time unit indicates the number of broadcast packet which is allowed to enter each port in one time unit. - Page 27 Figure 3-6 Port: The port number. Enable: Enable PoE feature of the specific ports. PSE Current: The PSE Current Range. Minimum Output Power: The minimum output power of the port. PoE Class: The PoE class of the connected port. ...
-
Page 28: Vlan Setting
VLAN Setting 12.13 A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain, which would allow you to isolate network traffic, so only the members of the same VLAN will receive traffic from the ones of the same VLAN. Basically, creating a VLAN from a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch. -
Page 29: Vlan Member
Figure 4-2 VLAN Mode : Displays VLAN mode : port based/Tag based VLAN. Here you can also switch back to Port Based VLAN Mode Tag Mode: AddTag means the outgoing packet of the selected port will be inserted a 802.1Q tag. - Page 30 Figure 4-3 In Port Based Mode you see a matrix of your 10 Ports. Simply select the port on top screen you want to configure, click on Read, and then select or deselect the ports that are on the same VLAN group. In this configuration mode you do not need to worry about defining VLAN groups and VLAN IDs.
- Page 31 VLAN ID (VID): Since you want the handover to other switches take place smoothly, the VLAN IDs (Numbers) need to be like on the rest of your network. (On other switches you may have the chance to configure names. These are just for your reference.
-
Page 32: Configuration Steps
VID Source Port : This table allows you to configure PVID of the port. Select the port number while you add VLAN and select VLAN member ports, the selected ports’ PVID will be the VID you typed. Please noted that one port only can have one PVID. While one port joins multiple VLAN groups, the PVID is important to identify where the incoming traffic will be forwarded to. -
Page 33: Multi To 1 Setting
the VID Source Port allows you to define the PVID. After configured and selected. Then click on Add to create the table and related port mapping. The new group with its setting will be displayed at the bottom of the screen. Multi to 1 Setting 12.13.3 Multi to 1 VLAN is used in CPE side of Ethernet-to-the-Home and is exclusive to... -
Page 34: Per Port Counter
4.5 Per Port Counter 4.5.1 Port Counter This page provides port counter of each port. There are 4 categories: Receive Packet & Transmit Packet/ Transmit & Collision / Receive Packet & Drop /Receive & CRC error. Once you change the counter category, the counter will be cleared automatically. - Page 35 Clear: Press “clear” will clear all counters. Refresh: Press “Refresh” button will aggregate the number of the counter for all ports. ...
-
Page 36: Qos Setting
QoS Setting 12.13 Here you can configure QoS policy priority mode and CoS (Class of Service) configuration. QoS (Quality of Service) refers to mechanisms in the network software that make the actual determination of which packets have priority. CoS refers to feature sets, or groups of services, that are assigned to users based on company policy. -
Page 37: Port, 802.1P, Ip/Ds Based
Port, 802.1p, IP/DS based 12.13.3 The page allows you to enable Port Based, VLAN Tag or IP/DS mode of COS. Figure 6-2 Class of Service Configuration =Enable High Priority. After Enabled High Priority, the following enabled Port Based parameter will become High Priority. - Page 38 Figure 6-3 The pre-defined Protocols Figure 6-4 The User-defined Protocols The Class of Service for TCP/UDP port number allows the network administrator to assign the specific application to a priority queue. F-I-F-O: The incoming packet will be forwarded in first-in-first-out scheme. Discard: The incoming packet will be discarded at the source port.
-
Page 39: Security
Security 12.13 The Security feature allows you to enable Port Security (MAC Address Binding) and TCP_UDP Filter feature. MAC Address Binding 12.13.3 This is also known as Port Security funciton of some other switch. The feature allows you to bind 1-3 MAC address to one physical port. After the port and MAC address is binded, only the allowed MAC Address can access the switch. -
Page 40: Tcp/Udp Filter
Figure 7-2 This table shows the binding status of the port 1 is enabled. TCP/UDP Filter 12.13.3 This page allows user to configure the TCP/DUP limit. Figure 7-3 Function Enable: To Enable or Disable the function. Port Filtering Rule: The outgoing packet with selec ted protocol will be ... - Page 41 Click Update to have the configuration take effect. ...
-
Page 42: Spanning Tree
Spanning Tree 12.13 The switch supports IEEE 802.1D-2004 RSTP protocol, the RSTP protocol can backward compatible to legacy Spanning Tree Protocol (STP) and 802.1w Rapid Spanning Tree Protocol (RSTP). STP Bridge Settings 12.13.3 The Table allows you to configure STP Mode and the system time settings. ... -
Page 43: Stp Port Settings
also means the maximum life time for a BPDU frame. Number between 6-40 (default is 20). Forward Delay: The maximum time (in seconds) the root device will wait before changing states (i.e., discarding to learning to forwarding). Number between 4 – 30 (default is 15) Click Update to have the configuration take effect. -
Page 44: Loopback Detection Settings
Click “Submit” to apply the settings. Figure 8-2 Port No: The port ID. It cannot be changed. Aggregations mean any configured trunk group. Root Path Cost: This parameter is used by the STP to determine the best ... - Page 45 Figure 8-3 Loopback Detection Function: This column allows you to enable or disable Loopback Detection function. Auto Wake Up: Once the Loopback Detection function is running, the ports maybe be disabled to avoid the loop. The Auto Wake Up allows you to activate the port after Time Interval passed.
-
Page 46: Trunking
Trunking 12.13 Port trunk allows multiple links to be bundled together and act as a single physical link for increased throughput. It provides load balancing, and redundancy of links in a switched inter-network. Actually, the link does not have an inherent total bandwidth equal to the sum of its component physical links. Traffic in a trunk is distributed across an individual link within the trunk in a deterministic method that called a hash algorithm. - Page 47 Figure 9-2 Member: This column allows you to select the member Ports. Status: This column allows you to Enable/Disable the Trunk Group. Type: This column allows you to choose Static Trunking or Dynamic LACP Trunking. After Select the LACP Trunk type, the following parameters can be configured. Please noted that the parameters of the both ends of the LACP should be the same.
-
Page 48: Backup/Recovery
Backup/Recovery 12.13 This function provides the user with a method to Backup/Recovery the switch configuration. The user can save configuration file to a specified file. If the user wants to recover the original configuration, which is saved at the specified path, just enter the password and then press the “upload”... -
Page 49: Miscellaneous
Miscellaneous 12.13 Miscellaneous setting is used to configure output queue aging time, VLAN stride and IGMP snooping. Figure 11-1 Output Queue Aging Time: Purpose: This function is used to avoid the traffic jam on one port will not cause the congestion of other ports. - Page 50 VLAN Striding: Purpose: For some network environment, the network administrator probably want to filter undesired broadcast or multicast packet to enhance the network bandwidth utilization and forward meaningful unicast to a specific destination. VLAN is a good mechanism to block broadcast packet, but it can also block the unicast packet communication between VLANs.
- Page 51 Ethernet switch cannot build the separate MAC address table for different VLANs, there will be a conflict of MAC address table. To solve this problem, the switch controller utilizes the VLAN Uplink port to emulate the usage of Independent VLAN MAC Address Table. VLAN Uplink Setting: If VLAN uplink function is enabled and the ...
-
Page 52: Logout
Logout 12.13 After finished configuring the switch, you can click Logout to leave the configuration page. The administrator has write access for all parameters governing the onboard agent. User should therefore assign a new administrator password as soon as possible, and store it in a safe place. ... -
Page 53: Q&A
4.13 Q&A 1. When you forgot your IP or password, please use the reset button for the factory default setting? Please take the following steps to reset the Web Smart Switch back to the original default: Step 1: Turn on the Web Smart Switch Step 2: Press and hold the reset button continuously for 5 seconds and release the... - Page 54 Appendix 1: Revision History: Version Revision History Date V1.0 First Release Nov. 15, 2012 V1.1 Update latest product specification. Jan. 9, 2013 Update latest figure of web UI. Add information of the Miscellaneous setting. V1.2 updated: Feb. 8, 2013 Optional Accessory: 11” to 19” Rack mount Kit.
