Page 1: Table Of Contents
SUMMARY LEGEND INSTRUMENT BOARD AND CONTROLS LEGEND MACHINE TECHNICAL DESCRIPTION INTRODUCTORY COMMENT GENERAL RULES OF SECURITY SYMBOLOGY BEFORE USE Handling of the packed machine Unpacking of the machine Movements of the handle bar Batteries Batteries recharging (standard version with AGM batteries) Batteries recharging (plus version with XFC batteries) Batteries disposal... -
Page 2: Legend Instrument Board And Controls
LEGEND INSTRUMENT BOARD AND CONTROLS GENERAL SWITCH AND RESPECTIVE SIGNAL LAMP LEVER SQUEEGEE LIFTING SWITCH BRUSH MOTOR AND RESPECTIVE SIGNAL LAMP HANDLE BARS SWITCH SUCTION MOTOR AND RESPECTIVE SIGNAL LAMP LEVERS PRESENCE SWITCH SOLENOID VALVE AND RESPECTIVE SIGNAL LAMP LEVER HANDLE BAR RELEASE LEGEND MACHINE RECOVERY TANK WHEELS... -
Page 3: Technical Description
TECHNICAL DESCRIPTION with batteries AGM with batteries XFC Cleaning width Squeegee width Tension batteries Capacity of the batteries Power installed Working capacity, up to sqm/h 1240 1240 Brush diameter Brush rpm Brush pressure (max) Suction vacuum mbar Type of drive semi automatic semi automatic Maximum gradient... -
Page 4: Introductory Comment
INTRODUCTORY COMMENT procedures. Otherwise, ask for technical advice Symbol that Indicates the Thank you for having chosen our machine. to an authorized assistance centre. position of the outlet plug This floor cleaning machine is used for the - Where parts are required, ask for ORIGINAL of the solution tank. -
Page 5: Before Use
BEFORE USE In fact, an extended series of charging cycles carried out when the batteries still have a HANDLING OF THE PACKED MACHINE residual charge, causes a battery deterioration The machine is supplied with suitable packing. and a consequent charge and the battery itself. The total weight is 75 kg. -
Page 6: Batteries Disposal
NOTE: Never leave batteries completely discharged even if the machine is not used. Connect the mains cable supplied with the machine both to the machine and to the mains socket as indicated in the figure. Insert the plug into a single-phase socket type CEE 7/7, with tension 230V, frequency 50Hz, nominal current 10A. -
Page 7: Security Device Brush Lifting
EMPTYING AND CLEANING OF THE DETERGENT SOLUTION TANK To empty the detergent solution remained in the solution tank: 1. Bring the machine to an appropriate place for tanks draining. 2. Switch off the machine pressing the general switch. 3. Unscrew the loading plug (15) of the solution tank. -
Page 8: Brush Cleaning
6. Holding the handle bar firmly, lift the front part of the machine making it rotate on the REAR SQUEEGEE RUBBER REPLACEMENT rear wheels bringing it into the vertical position Check squeegee rubber wear as shown in the figure. eventually turn or replace it. For the replacement it is necessary to: 1. -
Page 9: Front Squeegee Rubber Replacement
3. Check the level in the recovery tank (see under “OVERFLOW DEVICE”) necessary, empty the tank. If the problem persists, please contact the authorized technical assistance. FRONT SQUEEGEE RUBBER REPLACEMENT THE MACHINE DOES NOT CLEAN PROPERLY Check the wear of the squeegee rubber and 1. -
Page 10: Programmed Maintenance
PROGRAMMED MAINTENANCE INTERVENTION DAILY ORDINARY RECOVERY TANK CLEANING • SUCTION FILTER CLEANING • BRUSH CLEANING • BRUSH DISASSEMBLY • SQUEEGEE CLEANING • FRONT SQUEEGEE RUBBER REPLACEMENT • REAR SQUEEGEE RUBBER REPLACEMENT • SQUEEGEE HOSE CLEANING • SOLUTION TANK CLEANING • RECOMMENDED BRUSHES Brushes must be chosen depending on type of floor and dirt to be removed.
