Page 1: Table Of Contents
MODEL MDS107CN, MDS107LCN MODEL MDS101CN, MDS101LCN SECURITY INSTRUMENTS, INC. ® IoPhic SMOKE & FIRE ALARM WITH SILENCE FEATURE AND ALARM ORIGINATION FEATURE READ ALL INSTRUCTIONS This smoke alarm uses an extremely small amount of a radioactive element in the ionization chamber. Do not tamper with radioactive sealed source or try to repair the smoke alarm yourself. -
Page 2: Smoke Alarm Limitations And Functions
SMOKE ALARM LIMITATIONS AND FUNCTIONS ® There are three basic smoke alarm types: IoPhic , Ionization and Photoelectric. ® IoPhic is an ionization alarm containing a patent-pending Universal Smoke Sensing Technology. ® IoPhic alarms are very effective at detecting fast flaming fires and also respond very quickly to slow smoldering fires - up to 87% faster than the maximum allowable alarm limit (UL217 Smoldering Smoke Test on 5/26/2010, Underwriters Laboratories Project #09CA38078). -
Page 3: Avoid These Locations
• Locate at least one smoke alarm on every floor level. • Locate a smoke alarm in any area where a smoker sleeps or where electrical appliances are operated in sleeping areas. • Smoke, heat and other combustion products rise to the ceiling and spread horizontally. Mounting the smoke alarm on the ceiling in the center of the room places it closest to all points in the room. -
Page 4: Early Warning
• in extremely dusty, dirty or insect-infested areas. Loose particles interfere with smoke alarm operation. • in areas where temperature may fall below 40 F (4.4 C) or rise above 100 F (37.8 • closer than 1 foot (0.3m) from fluorescent lights, electrical "noise" and flickering may affect the alarm's operation. -
Page 5: Wiring Instructions
This alarm can be interconnected with the following models: 2995CN, 5304CN, MI100CN, MI106CN, MDS211CN, MDS201CN, 2985CN, 5303CN, MI200CN, MI210CN, MDS101CN, MDS107CN, 3885CN, 3895CN, MP118CN, MP117CN, 3303CN, 3304CN, MP202CN, MP212CN, MDSCN111CN, MDSCN103CN, MICN109CN, MICN102CN, MCN108CN, MCN105CN, SS-785-CAN, SS-790-CAN, SS-795-CAN, USI-1103-CAN, USI-7795-CAN, USI- 7385, USI-7390, USI-7485, USI-7490, CD-9385, CD-9390, CD-9485, CD-9490, CD-9795-CAN, CD-9785-CAN, and USI-960, RM-100 Relay. -
Page 6: Operation, Testing & Maintenance
Interconnected CO alarms or CO alarm circuit of combination smoke and CO alarms will only respond if a CO alarm / event initiates the alarm. All other alarms remain silent. Interconnected smoke alarms, heat alarms and relay modules will only respond if a smoke alarm / event or heat alarm / event initiates the alarm. -
Page 7: Quick Find Alarm Originating Feature & Reset
ALARM ORIGINATION: QUICK FIND Alarm Origination - In an interconnected system consisting of any of these models: 5304CN, MI106CN, MDS107CN, MCN108CN, MICN109CN, MDSCN111CN, MP117CN, it may be difficult to determine which alarm initiated the alarms to sound during an alarm ®... -
Page 8: Backup Battery Replacement
Before using the alarm Silence Feature, identify the source of smoke and be certain that safe conditions exist. Clean the smoke alarm at least once a month to remove dust, dirt, insects or debris. Always turn off power to smoke alarm before cleaning. Using a soft brush or wand attachment to a vacuum cleaner, vacuum all sides and cover of smoke alarm. -
Page 9: Operational Summary
OPERATIONAL SUMMARY HORN RED LED GREEN LED CONDITION / RECOMMENDATION Silent Blinks On once Stays On Condition: AC Power is present. DC Power is present. approx every Recommendation: None, alarm is operating properly. 40-45 seconds Blinks On once Silent Condition: AC Power is not present and alarm is receiving DC Power. approx every Recommendation: Check the breaker or fuse box for power. -
Page 10: Warranty
MODELS MDS107CN, MDS101CN MODELS MDS107LCN, MDS101LCN USI ELECTRIC, INC. / UNIVERSAL SECURITY INSTRUMENTS, INC. (“USI”) warrants your product to be free from defects in material and workmanship for a period of ten (10) years from the date of purchase. This warranty shall not apply to any batteries used in the product or to any damage which may be caused by such batteries.
