Page 1: Table Of Contents
INSTRUCTION MANUAL 2 DOORS NO FROST REFRIGERATOR MODEL: HRF422TW1 HRF422TS1 HRF503TW1 HRF503TS1 HRF502TS1 INDEX FEATURES INSTALLATION OPERATION DIGITAL DISPLAY OPERATION CLEANING CAUTION TROUBLE SHOOTING 0060520803 Printed : 22 Jun.’15... -
Page 2: Features
Packing Model compartment compartment (W x H x D (mm.)) (W x H x D (mm.)) (Gross storage) (Gross storage) HRF422TW1, 254 Liter 110 Liter 723 x 694 x 1724 774 x 748 x 1816 HRF422TS1 HRF503TW1, 336 Liter 127 Liter... -
Page 3: Installation
INSTALLATION Select a place with strong, level floor. If the floor is not quite level, adjust the height of the feet accordingly. Allow sufficient clearance between the refrigerator s ’ back, also the side wall, so the door can open fully and to minimize noise. Avoid direct sunlight and heat. -
Page 4: Digital Display Operation
Digital Display Operation ( HRF502TS1) A : Fuzzy Mode Indicator B : Power Freezer Indicator C : Energy Saving Indicator D : Lock Indicator E : Mode Selector F : Freezer Temperature Display G : Freezer Temperature Adjustment Key H : Refrigerator Temperature Display I : Refrigerator Temperature Adjustment Key J : Ambient Temperature Display Fuzzy Mode... -
Page 5: Open Door Warning
Freezer temperature adjustment Press key G, upon which indicator F will flash. Each time key G is pressed, the temperature setting is decreased by 1 C. Once the maximum of -24 C ํ ํ is reached, the temperature will return to -14 C ํ Refrigerator temperature adjustment Press key I, upon which indicator H will flash, Each time key I is pressed, the temperature setting is decreased by 1 C. -
Page 6: Making Ice Cubes
Temperature Control (HRF422TW1 , HRF422TS1 , HRF503TW1) The refrigerator is equipped with 2 independent controls to control the degree of cooling of the refrigerator and freezer compartment. Freezer Compartment MIN. : Minimum Setting for fairly cold in freezer compartment. MAX. : Maximum Setting for the coldest in freezer compartment. -
Page 7: Food Storage
Food Storage Refrigerated air goes down at the rear of the fresh food compartment and rises up at the front. Then, store the foodstuffs such as fish and meats which require quick refrigeration to the rear of the compartment. Leave spaces among foodstuffs to help air circulation. Foodstuffs which are easily dried should be well wrapped with waxed paper, aluminum foil or plastic film. -
Page 8: Cleaning
CLEANING Before cleaning the refrigerator, you should always unplug it from the electrical outlet and remove all food. 2. Both exterior and interior of refrigerator, wipe with damp and warming water until dry. 3. Cleaning internal accessories using a warm water and dry it with a soft clean cloth. -
Page 9: Caution
CAUTION Do not insert the power plug for many products at the same time or do not share other product to the same power supply socket with refrigerator the power plug free o the back side of the refrigerator. Damaged power fr m plug may cause fire due to overheating. - Page 10 Children should be supervised to ensure that they do not play with the appliance. When not using refrigerator for long period, should disconnect the power plug remove all the foods off from compartment, defrosting and clean interior and exterior parts then open the door until the unit dry and properly close the door.
-
Page 11: Trouble Shooting
TROUBLE SHOOTING Before you call for service please check the table below. Your problems could be easily rectified . If you still need service, please contact the store where you purchased or the nearest service center. When Check if ... Power supply cord is unplugged.
