Summary of Contents for Itm TES-1316
- Page 1 Instruction Manual TES-1316 Dual Data Logger Thermometer 800.561.8187 information@itm.com www. .com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS / EN TABLE OF CONTENTS TITLE PAGE 1. INTRODUCTION ............1 2. SPECIFICATIONS............2 3. FRONT PANEL DESCRIPTION........4 4. OPERATION INSTRUCTIONS ........7 5. MAINTENANCE ............13 6. RECALIBRATION PROCEDURE ......14 10/15/10 Version No. 00 800.561.8187 information@itm.com www. .com... -
Page 3: Introduction
Environment conditions Altitude up to 2000 meters Relative humidity: 80% max. Operating ambient temperature: 0 to 50°C (32 to 122°F) U.S. Pat. No. 446,135 Safety symbols Complies with EMC Directive 89/336/EEC 10/15/10 Version No. 00 EN-1 800.561.8187 information@itm.com www. .com... -
Page 4: Specifications
R and S type: ±[0.05% of reading +2°C (4°F)] NOTE This basic accuracy specification does not include the error of the temperature probe. Please refer to the temperature probe accuracy specification for additional details. EN-2 10/15/10 Version No. 00 800.561.8187 information@itm.com www. .com... - Page 5 Operating Humidity: Below 80% RH Storage temperature: -10 to 60°C, 14 to 140°F Storage humidity: Below 70% RH Supplied accessories: Qty. 6 AAA Batteries, instruction manual, CD software, and Optical RS-232 to USB cable. 10/15/10 Version No. 00 EN-3 800.561.8187 information@itm.com www. .com...
-
Page 6: Front Panel Description
FRONT PANEL DESCRIPTION / EN 3. FRONT PANEL DESCRIPTION INTERVAL min:sec hour:min TYPE KJTERSN - MN INTERVAL min:sec hour:min TYPE KJTERSN EN-4 10/15/10 Version No. 00 800.561.8187 information@itm.com www. .com... - Page 7 Press again to exit this mode. (7). SET key: Press the "SET" key for 2 seconds then release it to enter to interval time setting for continuous data-logging mode. 10/15/10 Version No. 00 EN-5 800.561.8187 information@itm.com www. .com...
- Page 8 Press backlight key to turn the backlight on and off. The backlight turns off after 13 seconds automatically. (14). T1 input: Thermocouple T1 input. (15). T2 input: Thermocouple T2 input. (16). RS232 to USB optical interface jack. EN-6 10/15/10 Version No. 00 800.561.8187 information@itm.com www. .com...
-
Page 9: Operation Instructions
Read the temperature on the display. The display shows "OL" (overload) when the temperature being measured is outside the valid measurement range of the meter. 10/15/10 Version No. 00 EN-7 800.561.8187 information@itm.com www. .com... - Page 10 T1/T2/T1-T2 will appear on the secondary display. min:sec TYPE T1 present reading + T1 Maximum reading plus elapsed time + T1 Minimum reading plus elapsed time + T1 Averaging reading plus averaging time. EN-8 10/15/10 Version No. 00 800.561.8187 information@itm.com www. .com...
- Page 11 + T1-T2 Minimum reading plus elapsed time + T1-T2 Averaging reading plus averaging time. Press "MX/MN" key for 2 seconds to exit MX/MN mode. In MX/MN mode, the "C/F/K" and "TYPE" keys are not active. 10/15/10 Version No. 00 EN-9 800.561.8187 information@itm.com www. .com...
- Page 12 LCD display will show " READ " and a memory location number. Press " " or " " key to scroll through the logged readings. Press " READ" key again to exit READ mode. EN-10 10/15/10 Version No. 00 800.561.8187 information@itm.com www. .com...
- Page 13 LCD display will show " MEM " and auto power-off function will be disabled. The " MEM " mark will flicker each time a set of data is stored into memory. TYPE 10/15/10 Version No. 00 EN-11 800.561.8187 information@itm.com www. .com...
- Page 14 The time display auto power-off mark " : " will not be visible. Auto power off mode is enabled each time you turn on the meter. It is automatically disabled in " MX/MN " and continuous data logging modes. EN-12 10/15/10 Version No. 00 800.561.8187 information@itm.com www. .com...
-
Page 15: Maintenance
Do not use abrasives or solvents. Clean and dry as required. 5-2 Battery Replacement: When the LCD display shows “ ”, the battery has insufficient power to support an accurate test. Replace the batteries with Qty. 6 AAA cells. 10/15/10 Version No. 00 EN-13 800.561.8187 information@itm.com www. .com... -
Page 16: Recalibration Procedure
The thermometer should be calibrated once a year to ensure its continued accuracy. Contact RS Components for further details of calibration service. The address is given at the end of these instructions. EN-14 10/15/10 Version No. 00 800.561.8187 information@itm.com www. .com...
