Socket IQsocket DIN/IQSD-GSM User Manual

Intelligent power sockets
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User
Guide
IQSD-GSM
documentation v1.1.1 R5
User guide
Intelligent power
sockets
tm
IQsocket
DIN / IQSD-GSM
...makes your life more comfortable
www.IQsocket.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQsocket DIN/IQSD-GSM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Socket IQsocket DIN/IQSD-GSM

  • Page 1 Intelligent power sockets IQsocket DIN / IQSD-GSM …makes your life more comfortable User Guide IQSD-GSM documentation v1.1.1 R5 User guide www.IQsocket.eu...

  • Page 2: Table Of Contents

    Important information ..............3 1 Introduction ..............4 1.1 Product description ............... 4 2 Installation ..............6 2.1 Wiring the IQSD-GSM ..............6 2.2 Inserting SIM Card ................ 7 2.3 Powering IQSD-GSM On ..............7 3 Managing IQSD-GSM ............8 This chapter guides you through management commands and features of IQSD-GSM.

  • Page 3: Important Information

    ©2009 NETCONS, s.r.o. Important information Every effort has been taken to ensure the accuracy of this document, however we do not accept responsibility for damage, injury, loss or expense resulting from errors and omissions, and we reserve the right of amendment without further notice.

  • Page 4: Introduction

    Need of data communication in companies even in homes is especially visible in this Internet age. Intelligent power socket IQsocket IQSD-GSM is a member of wide product family of intelligent sockets which helps people to do some tasks remotely.
  • Page 5 ©2009 NETCONS, s.r.o.  Remotely reboot appliance by cutting power for a couple seconds (e.g. server restart)  Remotely switch of appliance status (turnon to turnoff or back)  Remotely measuring of temperature  Thermoregulation feature, with custom program definition: o Control outputs based on state of inputs: temperature, digital and voltage input o Notify user by SMS (user defined text or status message) or by making call based on state of inputs...

  • Page 6: Installation

    ©2009 NETCONS, s.r.o. 2 Installation Before starting installation, please read this manual and take into account Important information section at beginning of this manual. 2.1 Wiring the IQSD-GSM Wire connections per following schematic diagram. Page 6 of 27...

  • Page 7: Inserting Sim Card

    IQSD-GSM.  Insert SIM card with inactive PIN code authorization into the SIM socket bay, accessible from bottom side of IQSD-GSM housing.  Push the card into the bay until you feel a click so card is locked inside.

  • Page 8: Managing Iqsd-Gsm

    ©2009 NETCONS, s.r.o.  Once AC power is connected, all three LED indicators will blink shortly and if everything is ok, the Power LED will turn to solid Red.  In case of active PIN authorization on the SIM card, GSM LED starts blinking fast (approx.
  • Page 9 ©2009 NETCONS, s.r.o. Case of commands is ignored; STATUS or sTaTUS is the same command. All incoming SMS messages longer than 30 characters or messages containing space and dot characters are being deleted without any error response. SMS Command Description SMS Response Type TURNOFF...

  • Page 10: Managing By Phone Call

    ©2009 NETCONS, s.r.o. If a power failure occurs during TURNON=123/ TURNOFF=123 commands, time of power failure is not included in the countdown, so e.g. you need to run an appliance for a hour issuing TURNON=60 command, but AC power is lost after 30minutes and restored back say after 2hours, appliance will be running for half an hour after power is restored back.

  • Page 11: Date/Time Setup

    ©2009 NETCONS, s.r.o. RINGONTIME? Get current configuration of RINGONTIME=30 seconds RINGONTIME parameter. 3.4 Date/Time setup IQSD-GSM is equipped with real-time clock, clock is running during a AC power failure until internal backup battery is not empty. There are two ways of date/time setup: ...

  • Page 12: Security Features

    ©2009 NETCONS, s.r.o. Please note commands working with Main switched output, including manual control using the push button, cannot be performed during AC power failure. IQSD-GSM use a bistable relay for Main switched output so its state remains unchanged during a power failure. 3.6 Security features IQSD-GSM is equipped with advanced authorization features to avoid controlling by unauthorized users.

  • Page 13: Response Messages Settings

    ©2009 NETCONS, s.r.o. SECNUMBER- Delete specific number from SECNUMBER- 421233355777 permitted phone numbers list. 421233355777 - OK SECNUMBER-ALL Delete all numbers from permitted SECNUMBER-ALL - OK phone numbers list. SECNUMBER=LIST Get dump of permitted phone LIST numbers list. 421903123456,42190311 1222,421235678235 Or LIST - NO NUMBER! SMSPIN=1234 Configuration of SMS...

  • Page 14: Scheduler Feature

    ©2009 NETCONS, s.r.o. parentheses. ERRORREPLY=YES Sending error SMS messages is ERRORREPLY=YES- OK enabled/active ERRORREPLY=NO Sending error SMS messages is ERRORREPLY=NO- OK disabled/inactive ERRORREPLY? Get configuration of ERRORREPLY ERRORREPLY=NO,(YES) parameter, active setting is in () parentheses. NOTE: When RINGCONFIRM=YES command is used, realized are confirmation back calls only for SIM cards with active CLIP service.

  • Page 15: Counters

    ©2009 NETCONS, s.r.o.  INF, to send STATUS message by SMS to number preconfigured by the ALARMNUMBER command (e.g. ALARMNUMBER+421903123456, see chapter Alarms) Example of SCHEDULER? command output (four actions were recorded): o 11:00,*,ON Turn on Main switched output every day at 11:00 o 14:30,*,OFF Turn off Main switched output every day at 14:30 o 01:30,1,RES Restart Main switched output every Monday at 01:30 o 19:00,5,INF Send Status SMS every Friday at 19:00...

  • Page 16: Defining Phone Numbers For Sms And Ringing Up Alerts

    ©2009 NETCONS, s.r.o. An alarm can generate alert by calling of or sending SMS to up to three predefined phone numbers or in case of alarm invoked by change of inputs, possible alert actions include control of Main switched output and supporting simple scripting allowing IQSD-GSM to act as user-programmable, event- driven controller.

  • Page 17: Ac Mains Power Failure Alarm

    ©2009 NETCONS, s.r.o. thresholds. Once remaining battery charge reach a predefined threshold, IQSD-GSM will send following SMS alert message to the numbers set by ALARMNUMBER command: Battery! 50% 3.10.3 AC mains power failure alarm IQSD-GSM can send you an SMS alert to inform you when there is a temporary failure of AC mains power for time longer than 10 seconds.
  • Page 18 ©2009 NETCONS, s.r.o.  Two independent digital inputs to connect various sensors  Analogue voltage input to connect various analogue sensors State of all inputs can be read by SMS command STATUS, which returns following SMS message: STATUS SMS Response Description Output:OFF/OFF, State of Main and AUX switched outputs...
  • Page 19 ©2009 NETCONS, s.r.o. Syntax of ID commands is: IDNr+E_Var,E_Temp1,E_Temp2,E_VoltageIn,DigIn1,DigIn2,A_Alert,A_SetVar,A_Main,SMStext Where  IDNr means identification of row with order number Nr in range 1 to 6,  + sign indicating to add particular row.  E_Var is a value of system variable, which is being compared with the current value of the system variable - evaluation is true when both values are equal.
  • Page 20 ©2009 NETCONS, s.r.o.  A_SetVar means action to set a new value of the system variable.  A_Main means action with the Main switched output, possible values are: TURNON Turn on Main switched output TURNOFF Turn off Main switched output RESTART Change (negate) status of Main switched output for time preconfigured by command RESTARTTIME.
  • Page 21 ©2009 NETCONS, s.r.o. ALARM+421903123456 Then enter following two program rows: ID1+0, >25.5,*,*,*,*,S,1,Turnon,* ID2+1,<15.1,*,*,*,*,R,0,Turnoff,* And then let‟s start the program issuing SMS command: PROGRAM=START When needed, program can be stopped by command: PROGRAM=STOP Example 2) – Observing a state of a contact sensor, e.g. door contact Once there is a change of state on Digital Input1, send to my phone number SMS message with text “Open”...

  • Page 22: Various Settings

    ©2009 NETCONS, s.r.o. PROGRAM=STOP Example 4) When there is Log.1 level at both digital inputs, restart the Main switched output (cut the power for an appliance for a couple seconds) Enter following two program rows: ID1+0, *,*,*,1,1,*,1,RESTART,* ID2+1, *,*,*,0,*,*,0,*,* ID3+1, *,*,*,*,0,*,0,*,* And then let‟s start the program issuing SMS command: PROGRAM=START When needed, program can be stopped by command:...

  • Page 23: Error Messages

    ©2009 NETCONS, s.r.o. switched output is in TurnedOn state – contacts C and NC connected OUTPUT=NO When device is powered on, Main OUTPUT=NO- OK switched output is in TurnedOff state – contacts C and NO connected OUTPUT? Get configuration of OUTPUT OUTPUT parameter, active setting is in () =(REMEMBER),NC,NO...

  • Page 24: Indication Of Error State

    ©2009 NETCONS, s.r.o. second, 0.5s on/0.1s off) indicates an outgoing call in progress, e.g. a ringing alert in case of alarm or during RINGON command.  RELAY – yellow color, indicates state of Main switched output relay: steady lighting means turned on - connected contacts C and NO; not lighting means turned off –...

  • Page 25: Technical Specification

    ©2009 NETCONS, s.r.o. Parameter Default setting RING NOACTION RESTARTTIME RINGONTIME SMSPIN NOPIN SECNUMBER SMSCONFIRM RINGCONFIRM ERRORREPLY BATALARM 00,00,00 POWERFAULT PROGRAM STOP OUTPUT REMEMBER 6 Technical specification Model IQsocket IQSD-GSM Mains power 230VAC / 50Hz, 15mA Backup battery 4.2V Li-Ion Switched Outputs MAIN 230V, 10A max (resistance load) AUX 230V 100mA (resistance load) Inputs...

  • Page 26: Operation, Maintenance And Safety Recommendations

    ©2009 NETCONS, s.r.o. Features Appliance control over SMS, by call or manually Remote restart of appliances Temperature monitoring Digital sensors monitoring Analogue sensor monitoring Programmable event-driven controller Alarm detection Monitoring of sound using integrated microphone Dimensions 90x53x58mm Weight 0.1kg netto Operating temperature 0 to +50 ˚C Humidity...

  • Page 27: Ordering And Accessories

    IQsocket product family uses following ordering code system: IQSx-y-z Example: IQSD-GSM Product family: W=WALL | R=RACK | D=DIN Product model: GSM | IP | RS232 | HDO | IPGSM Output Socket type: F=Schuko | E=French Optional accessories Code Description SR-TMP-01...
