Summary of Contents for Smartlink IntelPage 5W
- Page 1 IntelPage 5W (POCSAG) Transmitter INSTALLATION MANUAL IntelPage 5W (POCSAG) Transmitter Installation Manual v1.3...
-
Page 2: Table Of Contents
The installation of Multiple Transmitters and Aerials............9 VSWR................................9 7. Types of Antennas..................10 Co-linear..........................10 Monopole..........................10 Side Mounted / Unity Gain Dipole..................10 8. APPENDIX......................11 This Product is Not Field Serviceable................11 Technical Specifications.......................11 Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3... -
Page 3: Equipment List
Small Rubber whip antenna with 90deg adaptor Communications cable (blue 5 metre CAT-5E straight through RJ45 to RJ45) RS232 Type connector set (DB25 Female to RJ45 connector) Installation Manual Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3... -
Page 4: Overview
Transmitter Indicators PTT LED (Yellow) Indicates that the externally connected POCSAG transmitter is currently busy transmitting (“Keyed up”) Data LED (Red) Indicates POCSAG data activity. Carrier Detect LED (Yellow) Indicates channel is busy. Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3... -
Page 5: Rear Panel
ANTENNA Port The antenna port is an opening to allow connection of the antenna to the internal transmitter. The connector is a standard BNC 50 ohm. Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3... -
Page 6: Installation
See the technical information section below for further information. WARNING: The antenna must be placed at least 5 metres away from other electronic equipment to prevent interference. Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3... -
Page 7: Connecting Intelpage To A Paging Terminal
SmartWatch XP Monitoring software must be setup to match and ensure correct operation. 1. Ensure you are logged on as Maintenance User (see SmartWatch XP Help for details). 2. From the SmartWatch XP Main Screen, click Interfaces and then select Ports as shown below. Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3... - Page 8 3. Click New to create a new Port and type eg. Dongle 02644 – Intelpage 5W Tx as the Name. 4. In the Protocol field, select POCSAG from the drop down list. 5. In the Type field, select Direct RS-232 from the drop down list.
- Page 9 10. Click/Highlight Dongle 02644 – Intelpage 5W Tx as shown below. 11. The correct settings for the Intelpage 5 Watt Transmitter are easily achieved by clicking the Presets and selecting Maxon. 12. Ensure that Contains security device, PTT invert, Ignore busy and Ports enabled are ticked.
-
Page 10: Technical Informations
Damage will also occur to the unit if the amplifier is set to transmit if no antenna is connected to the unit. To transmit without an antenna connected to the unit, use a dummy load capable of handling at least 5 watts. Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3... -
Page 11: Types Of Antennas
The general coverage pattern for this type of antenna is shown below. Side Mounted / Unity Gain Dipole Dipole antennas are most suited for installations which require excellent building penetration. The general coverage pattern for this type of antenna is shown below. Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3... -
Page 12: Appendix
To the best of our knowledge, the information contained in this manual is correct at the time of print. SmartLink International reserves the right to make changes to the “A division of NESS CORPORATION PTY LTD” features and specifications at any time without prior notice in the course of product development. Intelpage 5W (POCSAG) Transmitter Installation Manual v1.3...
