ESTEAM CLEANING SYSTEMS
OWNER'S MANUAL
Congratulations on your selection of a new E1700 Series soil extractor
built in Canada by "Esteam Cleaning Systems." Our goal has been to
produce the best high performance line of carpet cleaning equipment on the
market today. Reading your owners manual will help to achieve maximum
benefit from your purchase.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E1700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Esteam E1700

  • Page 1 ESTEAM CLEANING SYSTEMS OWNER’S MANUAL Congratulations on your selection of a new E1700 Series soil extractor built in Canada by “Esteam Cleaning Systems.” Our goal has been to produce the best high performance line of carpet cleaning equipment on the market today.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page No. Introduction on the E1700 Series Specifications Maintenance Safety Information Operating Instructions Trouble Shooting Schematic Diagram Warranty Registration Warranty...
  • Page 3: Introduction On The E1700 Series

    INTRODUCTION Be it a small residential job or a large commercial contract, Esteam industrial carpet cleaning extractors are right for your needs. The E1715 is an economical, compact, portable soil extractor with the power and capabilities required by professional cleaning technicians.
  • Page 4: Maintenance

    MAINTENANCE 1. After each job, disconnect the vacuum hose and run the vacuums for 3 to 5 minutes to eliminate moisture build up in the components. This prolongs vacuum life and reduces the servicing the vacuums will require. If excess water enters the vacuums due to failure of the float ball shut-off system, run the vacuums for at least 15 minutes, and spray a small amount of penetrating oil (i.e.
  • Page 5: Safety Information

    SAFETY INFORMATION 1. Prior to inspection or repair of this machine, disconnect all electrical cords rendering the machine powerless. Failure to do so could result in serious or fatal injury. 2. Inspect unit daily for worn or damaged components. E.g. frayed cord, loose plug, or a plug with missing ground pin, etc.
  • Page 6: Operating Instructions

    2. We recommend the use of a liquid defoamer, to prevent the machine from prematurely shutting off due to excess foam in the recovery tank. Turn on vacuum and pour approximately ¼ cup of Esteam Liquid Defoamer into the end of the vacuum hose.
  • Page 7 OPERATING INSTRUCTIONS (CONTINUED) 4. Connect the vacuum and solution hoses to the carpet cleaning wand. 5. Proceed to clean the carpets. 6. 6When the recovery tank becomes full, vacuum will automatically stop extracting. When the vacuum stops extracting it will make a distinctive high pitched noise as all air flow will be cut off.
  • Page 9: Troubleshooting

    TROUBLESHOOTING WARNING: Prior to inspection or repair of this machine, disconnect all electrical cords rendering the machine powerless. Failure to do so could result in serious or fatal injury. PROBLEM CAUSE SOLUTION 1. Entire unit will not 1. Unit not plugged in 1.
  • Page 10 TROUBLE SHOOTING (CONTINUED) PROBLEM CAUSE SOLUTION 4. Pump runs but 1. Out of solution 1. Fill with solution does not pump solution 2. Pump inlet screen 2. Clean inlet screen plugged 3. Pump air locked 3. Press trigger to open valve on cleaning wand to relieve air 4.
  • Page 11 TROUBLESHOOTING (CONTINUED) PROBLEM CAUSE SOLUTION 6. Vacuums operate 1. Recovery tank full 1. Drain recovery tank but have poor or no suction 2. Vacuum hose plugged 2. Remove blockage 3. Wand plugged 3. Remove blockage 4. Exhaust port blocked 4. Remove blockage 5.
  • Page 12 TROUBLESHOOTING (CONTINUED) PROBLEM CAUSE SOLUTION 9. Machine blowing 1. Damaged (leaking) 1. Immediately shut unit excessive amounts of recovery tank fittings down. Bring unit to a water out of exhaust dealer for service ports. 10. Water accumulating 1. Inside solution line 1.
  • Page 13: Schematic Diagram

    E1700 150 PSI...
  • Page 14 Handle, Cross M 455-075 Caster, 4” Swivel 455-052 Wheel Cap Dome 455-057 Wheel, 8” Grey/Black Hub 465-050 BRKT, E1700 Pump 465-080 Brace, D/B Tank 470-016 Axel, D/B Set V2 475-035 Gasket Vac 5 3/4 475-125 Gasket 6” Access Cover Clear...
  • Page 15 495-225 Sol Tank 498-055 Plug, 1/2 Nylon 498-065 Plug, 7/8 Button 510-090 Shurflo Elbow, 90 511-105 Pump, 150 PSI, 112v E1715 511-305 Pump, 150 PSI, 220v E1715-20 545-100 Dump Valve, 1 1/2” 555-184 Elbow 45, Street 1/4 555-208 Elbow 90, 1/4 Street Extruded 555-254 Ferrule 3/8 Hose 555-326...
  • Page 16 1700 150PSI DUAL 3 STAGE VAC...
  • Page 17 Handle, Cross M 455-075 Caster, 4” Swivel 455-052 Wheel Cap Dome 455-057 Wheel, 8” Grey/Black Hub 465-050 BRKT, E1700 Pump 465-080 Brace, D/B Tank 470-016 Axel, D/B Set V2 475-035 Gasket Vac 5 3/4 475-125 Gasket 6” Access Cover Clear...
  • Page 18 545-100 Dump Valve, 1 1/2” 555-024 Bushing 3/8 M x 1/4 F 555-184 Elbow 45, Street 1/4 555-208 Elbow 90, 1/4 Street Extruded 555-364 Hose Barb, 3/8 Barb x 1/4 MPT 555-512 Reducing ADPT, 3/8 FPT x 1/4 MPT 560-030 Screen, Acorn 560-330 Guard, Finger 6”...
  • Page 19 E1700 150PSI HEATER MATE...
  • Page 20 Handle, Cross M 455-075 Caster, 4” Swivel 455-052 Wheel Cap Dome 455-057 Wheel, 8” Grey/Black Hub 465-050 BRKT, E1700 Pump 465-080 Brace, D/B Tank 470-016 Axel, D/B Set V2 475-035 Gasket Vac 5 3/4 475-125 Gasket 6” Access Cover Clear...
  • Page 21 495-220 Rec Tank 495-225 Sol Tank 498-055 Plug, 1/2 Nylon 510-090 Shurflo Elbow, 90 511-105 Pump, 150 PSI, 110v E1715-10 511-305 Pump, 150 PSI, 220v E1715-20-10 545-100 Dump Valve, 1 1/2” 550-035 Check Valve 1/4 555-024 Bushing 3/8 M x 1/4 F 555-184 Elbow 45, Street 1/4 555-208...
  • Page 23 8000 PUMP TROUBLE SHOOTING GUIDE TROUBLE PROBABLE CAUSE TO CORRECT Pump starts but 1. Not enough volt 1. Provide correct volt no prime 2. No liquid 2. Fill liquid 3. Leak in inlet line 3. Correct leak 4. Air lock 4.
  • Page 24 8000 PUMP TROUBLE SHOOTING GUIDE TROUBLE PROBABLE CAUSE TO CORRECT Pump will not 1. Bad motor 1. Replace start 2. Bad rectifier 2. Replace motor 3. Bad wire connection 3. Correct connection 4. Bad micro switch 4. Replace 5. Bad brushes 5.
  • Page 25 E1715 WIRING...
  • Page 26 E1715 DUAL STAGE VAC WIRING...
  • Page 27 E1715 HEATER MATE WIRING P. 1...
  • Page 28 E1715 HEATER MATE WIRING P. 2...
  • Page 30: Warranty

    In the event a defect occurs in a E-Series Housing Unit within five years of receipt by the original customer, Esteam will, if satisfied on its examination that the failure is due to defective material or workmanship, repair or replace the E-Series Housing Unit, at no cost to the original customer, other than as maybe provided for in this warranty.
  • Page 31 Notwithstanding any other term or covenant of Esteam contained herein, the following provisions shall apply: No warranty is provided for any Esteam product which has failed as a result of freezing, fire, misuse, alteration, improper amps or voltage, accidental damage,...
  • Page 32 F.O.B. factory within 30 days including a letter providing the machine's serial number, date of purchase, material return authorization number, and customer name. If applicable, credit will be issued after the item has been evaluated by Esteam. Failure to comply with return policy will void the warranty on that item.
  • Page 33 (e.g. winterizing), replacement of worn parts and all regular scheduled or unscheduled maintenance. (ii) Any claim for warranty must be presented to Esteam or its authorized dealer, prior to the expiration of the time limitations specified and not thereafter, otherwise any warranty is void.

This manual is also suitable for:

E1715E1715-20E1715-05E1715-20-05E1715-10E1715-20-10
