Summary of Contents for Rockhood TouchWin TH465-M

  • Page 1 Touch Screen User’s manual Rockhood Automation Co.,Ltd...

  • Page 3: Preface

    Preface Thank you for buying TH series touch screen made by Rockhood Automation Co., Ltd, this manual should be read and understood before doing relative operation. Purpose This manual will guide readers in the correct operating and maintaining TH series touch screen.

  • Page 4: Safety Caution

    Safety caution Please read the manual carefully before using. Make sure your operation is correct and safety. The following contents are only aimed at TH series products. Please keep the manual properly, put in the location easy to get and read, hand the manual to the end users.

  • Page 5: Table Of Contents

    Catalog Preface ..............................3 Safety caution............................4 Summarize ..........................6 Performance characteristics ..................6 1.2 Work flow..........................7 2. General specification........................8 2.1 TH465-M ..........................9 2.2 TH765-M ..........................10 2.3 TH865-M ..........................11 2.4 THA61-M..........................12 3. Hardware.............................13 3.1 Hardware structure......................13 3.2 Dimension .........................14 3.3 Installation and using environment ...................16 4.

  • Page 6: Summarize

    1. Summarize Rockhood new touch screen TH series are based on RT/TP series products. It not only has the language, characters editing, data display, monitor and alarm functions but also has 65536 true color LCD which can bring you brand-new vision enjoyment. It has the advantage of large capability for data duplication and friendly user interface.

  • Page 7: Work Flow

    Communication Two ports communication independently, can connect two different devices at the same time Drive the panel printer directly, economical and flexible Support free format communication, user edits the driver program 1.2 Work flow The work flow of using TH: Install edit software TouchWin Edit your project Connect PC and TH, power on...

  • Page 8: General Specification

    2. General specification This chapter will introduce the specification of TH series touch screen. TH series touch screen contains TH465-M, TH765-M, TH856-M and THA61-M. Series Types TH465-M TH765-M TH865-M THA61-M...

  • Page 9: Th465-M

    2.1 TH465-M Item TH465-M Input voltage DC20-DC28V Consumption current 130mA Momentary power off Less than 10ms Electrical allowance Withstand voltage AC1000V-10mA 1 minute ( signal and time ) Insulated impedance DC500V- about 10MΩ ( signal and time ) COM1 Support RS-232/RS-485 COM2 Support RS-232/RS422/RS485 USB1...

  • Page 10: Th765-M

    2.2 TH765-M Item TH765-M Input voltage DC20-DC28V Consumption current 250mA Momentary power off Less than 10ms Electrical allowance Withstand voltage AC1000V-10mA 1 minute ( signal and time ) Insulated impedance DC500V- about 10MΩ ( signal and time ) COM1 Support RS-232/RS-485 COM2 Support RS-232/RS422/RS485 USB1...

  • Page 11: Th865-M

    2.3 TH865-M Item TH865-M Input voltage DC20-DC28V Consumption current 260mA Momentary power off Less than 10ms Electrical allowance Withstand voltage AC1000V-10mA 1 minute ( signal and time ) Insulated impedance DC500V- about 10MΩ ( signal and time ) COM1 Support RS-232/RS-485 COM2 Support RS-232/RS422/RS485 USB1...

  • Page 12: Tha61-M

    2.4 THA61-M Item THA61-M Input voltage DC20-DC28V Consumption current 630mA Momentary power off Less than 10ms Electrical allowance Withstand voltage AC1000V-10mA 1 minute ( signal and time ) Insulated impedance DC500V- about 10MΩ ( signal and time ) COM1 Support RS-232/RS-485 COM2 Support RS-232/RS422/RS485 USB1...

  • Page 13: Hardware

    3. Hardware 3.1 Hardware structure The hardware structure of TH series touch screen includes front and back side. Take TH465-M as an example to explain the structure. USB-A port Touch area Power LED USB-A port Label USB-B port Power Plug COM1 port COM2 port DIP switch...

  • Page 14: Dimension

    3.2 Dimension TH465-M exterio dimension:150.0mm×100.0mm×41.0mm, mounting dimension: 144.0mm×94.0mm. 142.0 24V 0V FG 1 2 3 4 COM1 COM2 144.0 41.0 150.0 TH765-M exterior dimension:205.0mm×151.5mm×48.9mm, mounting dimension: 192.0mm×138.5mm. 48.9 12.0 190.0 24V 0V FG COM1 COM2 1 2 3 4 1 2 3 4 205.0 192.0...
  • Page 15 (3) TH865-M exterior dimension: 224.4mm×170.8mm×45.5mm, mounting dimension: 211.4mm×157.8mm. 45.5 38.0 209.4 1 2 3 4 24V 0V FG 1 2 3 4 Download 211.4 224.4 (4) THA61-M exterior dimension: 311.0mm×234.0mm×48.0mm, mounting dimension: 02.0mm×225.0mm. 311.0 48.0 302.0 300.0 43.1 COM1 COM2 +24V 0V FG...

  • Page 16: Installation And Using Environment

    3.3 Installation and using environment (1) Install requirements: TH has four ferric mounting racks when out of factory, there are two square holes on the up, down side of TH, use mounting rack to fix the TH with control cabinet. In order to avoid TH temperature too high after long time working, please keep 10cm space on the up/down and 5cm on the left/right side of the TH when installing.
  • Page 17 (4) Power supply requirements: TH series touch screen use DC +24V power supply only. The permitted voltage range is 20V~28V. The connection is as below: +24V 0 V +DC- Besi des, if connect high voltage or AC power supply with TH, the TH may be damaged and cause elec tric shock to human body.
  • Page 18 Disposal Caution Please dispose the TH as industry waste.

  • Page 19: Interface And Switch

    4. Interface and switch 4.1 Introduction TH series touch screen has 1 group of DIP switch and 5 communication ports. 1: DIP switch 4: USB-A port1 2: COM1 port 5: USB-A port2 3:COM2 port 6: USB-B port3 4.2 DIP switch TH has one group of DIP switch at the back side, they can set the function of COM1 port.
  • Page 20 Step: (1) Turn on switch2 when TH power supply is cut off (2) Power on TH, connect TH with PC via Rockhood download cable to download project (3) After the download process is over, cut off the power of TH, then turn off the...
  • Page 21 Figure: Download cable connection Forced download After the download is completed, if the TH can not display the screen normally, you can try forced download mode to update the system. 1 2 3 4 Step: (1) Cut the power of TH, turn on switch2 (2) Power on the TH, connect the cable then download the project (3) After the download is completed, turn off switch2 then...

  • Page 22: Com2 Port

    correct communication parameters and device COM1 port communication parameter COM1 port communication device 4.4 COM2 port CO 2 port has below functions: Communicate with industry devices, such as PLC, inverter, meters… COM2 port pins definition pins Name Meaning RS422 send + RS232 receive RS232 sen RS485 +...

  • Page 23: Usb-A Port

    Please refer to “TP connect with PLC” for the details of TH communicate with PLC. Communicate with frequency inverter TH can communicate with various brands of frequency inverters. For the brands which are not in the list, user can select Modbus protocol or user-defined protocol. Mitsubishi FR series inverter Inovance MD series inverter Bosch Rexroth Indracontrol...

  • Page 24: Usb-B Port

    Connect U-disk and other USB port devices TH front side TH back side USB-A port USB-A TH front side USB cable mobile harddisk USB-A 4.6 USB-B port TH has one USB-B port ( accord with USB2.0 ), located in the back side of TH, the functions are shown as below: To download the data, the speed can up to 480Mbps.
  • Page 25 TH back side USB cable...

  • Page 26: Touchwin Software

    5. TouchWin software 5.1 Preparation 1. Software version: V2.B and later versions. 2. Software source: visit Rockhood website www.rockhood.com to obtain the software or get from the products CD. 3. OS requirements: Windows98/2000/XP/ME 4. Install steps: Open setup.exe Click “next” until show below window Enter the information in the space: serial number is ThingetTouchWin.

  • Page 27: The Construction Of Touchwin

    5.2 The construction of Touchwin 5.2.1 Screen Double click the Touchwin software, build a new project, then you can see the following screen:...

  • Page 28: Application

    7. Application 7.1 Adjust the touch area The touch area adjustment function can make the component touch more precise. The adjustment steps: Step 1: turn on the DIP switch 3, then power on the TH again, it will show the following screen: Adjust cross ●...

  • Page 29: Photo Application

    This result means adjustment This result means the adjustment is failed. successful. You can set the DIP switch to You should click the cross center again to working mode, then restart the TH again. redo the adjust steps. Then you can use TH as normal. 7.2 Photo application TH series LCD are 65536 true colors, it can make your photo display more vividly.
  • Page 30 Select the photo you want, then click “open” button, the photo will be added on the screen. Step2: design the motion track Click the button in the tool bar, drag your mouse to draw the motion track, double click the mouse to finish the drawing.
  • Page 31 Step4: Simulate offline Click to simulate offline your project. You can see the photo motion track. Step5: Change the animation property Right click the photo, then select “animal prop”. The animation property includes coordinate and control. (1) Coordinate X: the position on X axis Y: the position on Y axis Escape time: the time that the photo moves from (X1,Y1) to (X2,Y2) Key point X,Y: the coordinate of every motion position...
  • Page 32 Enable: control the animation by bit signal. When the rising edge of the signal is coming, the animation will be activated. Reset: control the end of the animation by bit signal. When the rising edge of the signal is coming, the animation will end.

  • Page 33: Debug And Download

    7.3 Debug and download TH series touch screen support debug download function. This function can be used when you are debugging your project in order to save your time. Compared with normal download function, this function has the following advantages: (1) This function only can be used when debugging the project.

  • Page 34: Data Duplication

    7.4 Data duplication...

  • Page 35: Th Series Touch Screen Interior Objects

    8. TH series touch screen interior objects This chapter will introduce the interior objects of the TH. The interior objects contain PSB(bit register), PSW(word register), PFW(word register). NOTICE 1. Only when the advanced function is opened, the special interior objects can be used. 2.
  • Page 36 Word register PSW Register Function Remark PSW0 Start screen No. PSW1 Current screen No. PSW20 Screen width ( read only ) PSW21 Screen height ( read only ) PSW26 PSB amounts ( read only ) PSW27 PSW amounts ( read only ) PSW28 PFW amounts Occupy PSW28、PSW29 ( read only )
  • Page 37 PFW66 占用 PFW66、PFW67 四级密码 PFW68 占用 PFW68、PFW69 五级密码 PFW70 六级密码 占用 PFW70、PFW71 PFW72 占用 PFW72、PFW73 七级密码 PFW74 占用 PFW74、PFW75 八级密码 PFW76 九级密码 占用 PFW76、PFW77...
