Laser Pegs Zippy 004 Assembly Instruction Manual

by
Please read this manual before you begin!
004
Failure to follow this manual's instructions may
result in damage to the Zippy Do® Power Base
and/or the Zippy Do® pieces. Not adhering to
For Boys And Girls
these instructions will void the manufacturer's
Ages 3 And Up
warranty. The packaging must be kept because
12 Models+
it contains important information.
WARNING:
ANY CREATION YOU CAN BUILD
CHOKING HAZARD
- Small parts.
LIGHTED
Not for children under 3 yrs.
Do not submerge in water.
CONSTRUCTION SET INCLUDES:
• 21 Construction Parts
• Zippy Do® Power Base
• Instruction Manual
Requires 3-LR44 Batteries
Construction Compatible
Compatible with other construction kits
Batteries
EN71, RoHS COMPLIANT
Included
This product complies to
all safety requirements
of ASTM F 963
Zippy Do® Parts List
x2
x2
x1
x1
x1
x1
x1
x1
x2
x3
x1
x4
x1
x1
www.LaserPegs.com
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2014 © All Rights Reserved US Patent
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs®Ventures
LLC. 8304 Consumer Ct Sarasota FL. 34240. Contact: Support@LaserPegs.com
Connecting Pegs
®
To construct with Laser Pegs®, slide two pieces together to form
a connection. Slide each piece on and off smoothly. (Laser Pegs®
pieces sold separately).
*To avoid short-circuits, keep metal objects and other
unauthorized materials from obstructing the peg holes.
Slide Power Switch to turn on/off/flash
Slide Power Switch to cycle through different light settings.
Power Switch
underside of Zippy Do® Power Base
This Product contains a button battery. If swallowed, it could
cause severe injury or death in just 2 hours.
Seek medical attention immediately.
Replacing Batteries
1. Remove the Phillips head screw.
2. Remove the Battery Compartment Cover.
3. Place three (3) LR44 batteries in the correct
position. (Batteries are to be inserted with the correct
polarity).
4. Replace the Battery Compartment Cover.
5. Replace the Phillips head screw.
6. Slide Power Switch to turn on!
7. Do not mix old and new batteries.
8. Do not mix alkaline, standard (carbon-
zinc), or rechargeable (nickel-cadmium, NiMH) batteries!
9. Exhausted batteries are to be removed
from the power base.
10. Batteries should be recycled or disposed of as per
state and local guidelines.
11. Non-rechargeable batteries are not to be recharged.
12. Rechargeable batteries are only to be recharged under
adult supervision.
13. Rechargeable batteries are to be removed from the
toy before being recharged.
14. The supply terminals are not to be short-circuited.
15. Do NOT throw batteries into fire!
Remove the Phillips head
screw with a 4mm screw
driver.
Screw
Battery Compartment
Cover
Power Switch
Battery
Compartment
BATTERIES ARE TO BE INSERTED
INTO THE TOY BY AN ADULT ONLY!
ONLY ADULTS SHOULD INSTALL THE BATTERIES
Requires
3-LR44 Button Cell
Batteries
Batteries
WARNING: STROBE LIGHTS
Connects to other
MAY CAUSE SEIZURES
Laser Pegs® pieces
The toy is not to be connected to more than
the recommended number of power supplies
CAR
PLANE
Environmental Phenomena
* The unit may malfunction if subjected to radio-frequency interference. It SHOULD revert to
normal operation when the interference stops. If not, it may become necessary to turn the power
off and back on, or remove and reinstall the batteries.
* In the unlikely event of an electrostatic discharge, the unit may malfunction and lose memory,
requiring the user to reset the devise by removing and reinstalling the batteries.
HELICOPTER
SKI PLANE
