Heartland Appliances The Artisan Installation And Operating Instructions Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Business (519) 650-5775 Fax (519) 650-3773 Toll Free Phone: 1-877-650-5775 Toll Free Fax: 1-800-327-5609

Installation and Operating Instructions

SAVE THESE

INSTRUCTIONS FOR

FUTURE USE.

Note: Please read this entire

manual before you install

and use your new room

heater. Failure to follow

instructions may result in

property damage, bodily

injury or even death.

SAFETY NOTICE: If this stove is not properly installed, a

house fire may result, for your safety, follow the

installation directions, contact local building or fire officials

about restrictions and installation inspection requirements

in your area.

IMPORTANT: Check around oven chamber on a weekly

basis for soot and creosote accumulation. Clean the

chamber thoroughly from the top, side and bottom with

the rake provided. Burn the stove hot daily to reduce

creosote accumulation. Use only dry wood aged for one

year. Failure to do so could result in chimney fire and

void the warranty.

ATTENTION INSTALLER: Leave this manual with the appliance.

PLEASE NOTE: Specifications contained in this manual are subject to change without notice

1050 Fountain St N. Cambridge, Ontario, Canada N3H-4R7

The Artisan

The Artisan is listed to

ULC Standard S-627 &

UL 1482 in Intertek

Testing Services NA

Ltd.

WOODSTOVES

The temperature registered by the oven door

thermometer may not necessarily correspond with the

reading taken with a thermometer inside the oven.

OVERFIRING CAUTION

Repeated or extended overfiring

will void warranty on this

appliance. See page 18 for

details.

06/09 EINS 515000

Table of Contents

Summary of Contents for Heartland Appliances The Artisan

Page 1 1050 Fountain St N. Cambridge, Ontario, Canada N3H-4R7 Business (519) 650-5775 Fax (519) 650-3773 Toll Free Phone: 1-877-650-5775 Toll Free Fax: 1-800-327-5609 The Artisan Installation and Operating Instructions The Artisan is listed to ULC Standard S-627 & UL 1482 in Intertek Testing Services NA Ltd.
Page 2 FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPOURS OR LIQUIDS IN THE VICINITY OF THIS STOVE. Stove Location - If the stove must be located near a window, avoid using long curtains which could blow over the stove top, causing a fire hazard.
Page 3 ENTIRE PRODUCT –LIMITED ONE YEAR WARRANTY HEARTLAND warrants the replacement or repair of all parts of the Artisan which prove to be defective in material or workmanship. Painted porcelain enamel finish or plated surfaces have a 90 day warranty from the date of original purchase.
Page 4: Table Of Contents
TABLE OF CONTENTS 1) Welcome ........................... Pg 5 2) Installation ......................... Pg 6 3) Installation Requirements ....................Pg 7 4) Clearances Single Wall Connector .................. Pg 8 5) Clearances Listed Double Wall Connector ..............Pg 9 6) Installing the Chimney Connector ..................Pg 10 7) Wall Pass-Through ......................
Page 5: Welcome
The test standards are ULC S-627 for Canada and UL 1482 for U.S. The Artisan is listed for burning wood only. Do not burn other materials or garbage. The Artisan is not listed for installation in mobile homes. Do not install the stove in...
Page 6: Installation
Installation Place the stove in the intended position and lift out the using to the clearance specified. Failure to do so will result hotplate, checking that the joint between the underside of in an unsafe condition. the hob and the top of the stove is intact. Any joints which Unit must be placed on a continuous non-combustible pad have opened shoud be made good with the fire cement (floor tile with grouting or sheet metal pad) extending...
Page 7: Installation Requirements
Heartland Appliances Inc. 1050 Fountain St North, Cambridge, ON N3H 4R7 Installation Requirements Model Heartland Artisan Ensure these specifications apply to the model you have purchased. Changes may occur in product specification from time to time. Please contact Heartland for the most up-to-date, as it...
Page 8: Clearances Single Wall Connector
Heartland Appliances Inc. 1050 Fountain St North, Cambridge, ON N3H 4R7 Installation Requirements Model Heartland Artisan Ensure these specifications apply to the model you have purchased. Changes may occur in product specification from time to time. Please contact Heartland for the most up-to-date, as it...
Page 9: Clearances Listed Double Wall Connector
Heartland Appliances Inc. 1050 Fountain St North, Cambridge, ON N3H 4R7 Installation Requirements Model Heartland Artisan Ensure these specifications apply to the model you have purchased. Changes may occur in product specification from time to time. Please contact Heartland for the most up-to-date, as it...
Page 10: Installing The Chimney Connector
Guidelines for Installing the Chimney Connector The chimney connector is a single-wall pipe or a listed and 3. The crimped ends of pipe sections should point approved double-wall pipe that connects the stove to the downward towards the stove so that any soot or chimney.
Page 11: Wall Pass-Through
Wall Pass-Through Factory Built Chimney Design your installation so that your connector does not Chimneys manufactured in a factory must be tested and pass through a combustible wall. If you must pass listed to ULC S629 (Can.) or Type HT chimneys in the through, check with a local building inspector before you Standard for Chimneys, Factory-Built Residential Type begin.
Page 12: Chimney And Draft
Chimney and draft Chimney Maintenance The chimney is the most important element of a Chimneys serving woodburning appliances must be successful stove operation. The chimney ‘drives’ the checked for creosote build-up. Until you are familiar with system by producing the draft that draws in combustion air the rate of creosote build-up in the system, check it often and exhausts smoke and gases to outdoors.
Page 13: Users Instructions
Users Instructions General Fuelling with Wood WARNING: HOT SURFACES, use the tool supplied to Woodburning operate this appliance. When raising the dome lids, it The firewood used will make an important contribution to is recommended that the heatproof glove supplied successful operation.
Page 14: Door Operation
Door Operation To open the doors. Use the utensil provided to turn the door release screw 1/4 turn counter-clockwise. OVEN DOOR OPERATION - The screw will back off enough to open the door. It is not possible to open the lower door without first opening the To open the doors.
Page 15: Refuelling
Refuelling Cleaning of the Bottom Grate The firebox should be filled to the recommended level at Due to an accumulation of ash and other material, it may the middle of the firebox door opening. not be possible to pass through the grate. Allow the fire to burn out and then open the ashpit door.
Page 16: Break-In Fire
Break-In Fire Flue Chamber Damper SMOKE/SMELL EMITTED DURING INITIAL USAGE. The adjustable flue chamber damper is for chimney draft. Some parts of the stove have been coated with a light The more it is closed, the easier it is to control the heat. covering of protective oil.
Page 17: Flueway Cleaning
Flueway Cleaning WARNING: HOT SURFACES, use the tool supplied to operate this appliance. It is recommended to use the heatproof glove supplied when raising the dome lids to use the hotplate. Following a prolonged shutdown of the appliance, perhaps after the summer break, ensure the flueway is free from obstruction prior to re-lighting.
Page 18: Fresh Air Kit
Spares List Understanding Combustion Water: Up to half the weight of freshly cut logs is water. Part Number Description No Rep’d After proper seasoning only about 20% of the weight is 1/16182 T Bottomgrate bars top water. As the wood is heated in the firebox, this water boils 1/16182 B Bottomgrate bars bottom off, consuming heat energy in the wood, the more heat...
Page 19: Over Firing
Overfiring - Caution! Overfiring of your woodburning appliance represents a serious fire hazard Overfiring can also warp your stove, break welds, permanently discolour the enamel and cause premature burnout of your stove. Repeated overfirings will void the warranty of the appliance. To prevent overfiring: If the air intake has little effect on dampering the fire, excessive chimney draft is the probable cause (especially on chimneys in excess of 20’).
Page 20: Trouble Shooting
Trouble Shooting Chimneys and Draft Chimney Height Taller chimneys tend to produce stronger draft. We The performance of your woodburning system depends recommend that the top of the chimney should be at least more on the chimney than on any other single component. 36”...
Page 21: Cooking Instruction
Masonry chimneys should be checked for deterioration Safety Practices including damaged bricks, crumbling and missing mortar, cracks in the drip cap at the top of the chimney, and loose What to do if you have a chimney fire flashings at the roof line. The liner should be checked for cracks and mis-alignment.
Page 25 1050 Fountain St N. Cambridge, Ontario, Canada N3H-4R7 Business (519) 650-5775 Fax (519) 650-3773 Toll Free Phone: 1-877-650-5775 Toll Free Fax: 1-800-327-5609 The Artisan Cooking Instructions The temperature registered by the oven door thermometer may not necessarily correspond with the...
Page 26 Be sure to read it entirely, including the terms of reference and function. The Artisan is listed for burning wood only. Do not burn other materials or garbage. Successful stove top and oven cooking will result from using a heated stove and baking the fire to retain the heat required.
Page 27 Top Oven Cooking Bottom Oven Cooking It is not possible to control this oven, but during the course The oven door thermometer registers the temperature at of roasting, sufficient heat input allows the simmering of the door only. Oven temperatures vary from top to bottom dishes that have been taken from the roasting oven.
Page 28 519-650-5775. Our office hours are from 8:30 am to 5.00 pm. est. For our complete line of kitchen appliances, visit our website at www.heartlandapp.com or phone 1-877-650-5775 and ask to speak to a sales representative For pricing please call your dealer, or call Heartland Appliances (519) 650-5775 or Fax (519) 650-3773...
