Urban Detour Peninsula User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Car Seat V6 D4 ML
7/4/05
Conforms to
ECE R44.03 Universal
Peninsula Car Seat
Compatible with selected Urban Detour three wheelers.
For infants up to 13 Kg (Group 0+)
Important. keep for future reference
12:05 PM
Page 1
EXTREME HAZARD: Parents should
not under any circumstances use
this child restraint on a passenger
seat equipped with an airbag.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Peninsula and is the answer not in the manual?

Questions and answers

Summary of Contents for Urban Detour Peninsula

  • Page 1 Page 1 Conforms to ECE R44.03 Universal Peninsula Car Seat Compatible with selected Urban Detour three wheelers. EXTREME HAZARD: Parents should not under any circumstances use For infants up to 13 Kg (Group 0+) this child restraint on a passenger Important.

  • Page 2: Safety Warnings

    Car Seat V6 D4 ML 7/4/05 12:05 PM Page 2 safety warnings PLEASE READ THOROUGHLY BEFORE COMMENCING INSTALLATION, AND FOLLOW THE INSTRUCTIONS CLOSELY AS AN INCORRECT INSTALLATION COULD BE HIGHLY DANGEROUS. • Do not use this child seat in passenger seats equipped with airbags. •...

  • Page 3: Get To Know Your Car Seat

    Car Seat V6 D4 ML 7/4/05 12:05 PM Page 3 get to know your car seat This seat is classified as Group 0+ and is suitable for infants from birth to 13kg / 29 lbs (12-15 months approx.) SHOULDER PADS HEAD HUGGER (If supplied) BUCKLE RELEASE BUTTON...

  • Page 4: Legal Requirements

    Car Seat V6 D4 ML 7/4/05 12:05 PM Page 4 the type of seat belt required Your Mothercare child seat can only be installed rearward facing using a 3 point static or retractor seat belt, approved to UN/ECE Regulation No.16, or other equivalent standard. DIAGONAL DO NOT USE THIS CHILD SEAT IN BELT...

  • Page 5: Important Notes

    Car Seat V6 D4 ML 7/4/05 12:05 PM Page 5 important notes • This child seat is for children from birth to 13kg / 29lbs (12-15 months approx) using a 3-point lap and diagonal seat belt in the rearward facing position only. •...
  • Page 6 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 6 the harness (fastening and tension) The buckle is fastened by locating parts (1) and (2) together then pushing into the socket. A positive click should be heard, indicating that the buckle is secure. Check by pulling the straps above and below the buckle.
  • Page 7 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 7 the harness (height selection) Your child seat comes with the shoulder straps through the lowest shoulder slots in the seat back. As your child grows you will need to move the straps to the next slots.
  • Page 8 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 8 the harness (adjusting the height) Before you begin, loosen the harness straps using the ‘one-pull’ adjuster as described at the beginning of this section. Step 1 Remove the ends of the shoulder straps from the metal plate at the rear of the seat.
  • Page 9 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 9 positioning the head hugger (if supplied) A head hugger can be used to provide extra support for your child's head.Position the shoulder straps of the car seat through the slots of the head hugger.
  • Page 10 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 10 using the seat level indicator Your car seat is fitted with a seat level indicator. SEAT LEVEL This is designed to help you ensure that the seat INDICATOR is positioned at the correct angle. The arrow should point directly at the top of the star as shown below.
  • Page 11 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 11 fitting the child seat with standard seat belts However safe a child seat is, however well built • Ensure the harness is adjusted to suit your it is, your child’s safety depends on you. child.
  • Page 12 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 12 fitting the child seat with standard seat belts Step 2 Route the lap belt (1) through BOTH lap belt guides (2). These are marked with light blue arrows on the seat. The lap belt should never be passed through the slots at the front of the seat.
  • Page 13 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 13 fitting the child seat with standard seat belts Step 4 Ensure the seat belt is not twisted. Then, lean on or press down on the handle to push the child seat down into the vehicle seat (1), while pulling on the lap and diagonal sections (2) and (3) of the seat belt to remove any slack.
  • Page 14 Car Seat V6 D4 ML 7/4/05 12:05 PM Page 14 checking the security of the seat When fitted, the security of the child seat can be tested by pressing firmly into the backrest as shown. The seat should feel very firm and move only slightly.

  • Page 15: Customer Care

    Car Seat V6 D4 ML 7/4/05 12:05 PM Page 15 accessories • Your child seat and its cover have been carefully designed, manufactured and tested to the highest safety standards. • Do not put your child’s safety at risk by using without a seat cover.

  • Page 16: Replacement Parts

    Car Seat V6 D4 ML 7/4/05 12:05 PM Page 16 replacement parts The replacement parts listed below are available for your product. In the event that you require any of these parts, please contact your local Mothercare store or contact Customer Care on 08453 30 40 30. Other parts may be repairable by returning the product to your nearest Mothercare store.
