  • Page 1 INSTRUCTION MANUAL INSTRUCTION MANUAL...

  • Page 2: Safety Precautions And Warnings

    The 4XS is a High Competition, High Quality, 10th scale Electric Off Road Buggy Race Car for persons age 14 or order. THIS IS NOT A TOY. It is a precision racing chassis kit. Adult supervision is required at all times during assembly and operating. If in doubt, ask your fellow RC racers for advice or contact your local supports for assistant.
  • Page 3 Front & Rear Gear Di Assembly STEP 1 - 7 BAG A / BEUTEL A BORSA A / バッグ A MAKE TWO Di Case O-Ring Grease Shim 10.1 x 12 x 0.1mm 2 or 3 pcs may be O-Ring required for proper 5 x 3 x 1mm fitment Di Case...
  • Page 4 STEP 8 - 12 BAG A / BEUTEL A BORSA A / バッグ A ADD ABOUT 5g For Front Use 7K cst. Gear 21T For Rear Use 3.5K cst. Snap Ring Fill up about SPC-G00009 BE CAREFUL this level x 2pcs USE PLIERS Fill up about Flat Head Screw...
  • Page 5 Mid-Slipper Assembly STEP 1 - 4 BAG B1 / BEUTEL B1 BORSA B1 / バッグ B1 Slipper Plate C 2.5 x 11.8mm TWSM00046 x 1pc Pin 2.5 x 11.8mm 2.5 x 10mm TWSM00045 x 1pc Ball Bearing 2.5 x 8.8mm 8 x 12 x 3.5mm TWSM00047 x 1pc...
  • Page 6 Mid-Slipper Assembly STEP 5 - 6 BAG B / BEUTEL B BORSA B / バッグ B Thread-lock Set Screw M3x3 TWSSW00013 Set Screw x 1pc 2.5-3mm M3 x 3 Completed Threadlock CHM-G00059 Slipper (BAG R) Assembled ROTATE THE PRELOAD NUT TO APPLY PRESSURE TO THE SLIPPER PLATES.
  • Page 7 Mid-Gear Di Assembly STEP 6 BAG B2 / BEUTEL B2 USE 0.05” HEX DRIVER BORSA B2 / バッ グ B2 Flat Head Screw M2 x 10mm Flat Head Screw M2 x 10mm Mid Di Spur Gear Plate B Mid Di Spur Gear Plate B TWSM00039 x 1pc...
  • Page 8 Main Drive Shaft Assembly STEP 2 BAG C / BEUTEL C BORSA C / バッグ C Shim 4.2 x 6.4 x 0.1mm Mid Di Shaft MASM2544A Bushing Mid Di Shaft B x 2pcs Input Bearing CVD Grease Crush Spacer TWSM00018 x 1pc Input Drive Shaft Shim...
  • Page 9 Chassis Plate Assembly STEP 1 - 3 BAG E / BEUTEL E BORSA E / バッグ E Chassis Plate Flat Head Screw M3 x 10mm Thread-lock Thread-lock Chassis Plate TWCBF00005 Suspension Mount FR. x 1pc Flat Head Screw M3 x 10mm Gear Box Lower GTB40202 Gear Box...
  • Page 10 Chassis Plate Assembly STEP 4 - 6 BAG E / BEUTEL E BORSA E / バッグ E Flat Head Screw Flat Head Screw M3 x 10mm M3 x 10mm Gear Box Rear Lower GTB4P0204 x 1pc Thread-lock Thread-lock Thread-lock Suspension Mount TWSM00083 x 1pc Suspension Mount...

  • Page 11: Steering Bell Crank Assembly

    Button Head Screw Steering Bell Crank Assembly STEP 1 - 2 M3 x 8mm BAG F / BEUTEL F Bell Crank Plate BORSA F / バッグ F Thread-lock Bell Crank Post Shim Button Head Screw M3 x 8 mm Ball Bearing 5 x 10 x 4mm TWSSW00005 Bell Crank Post Shim x 2pcs...
  • Page 12 Front And Rear Shock Towers Assembly STEP 1 - 2 BAG G / BEUTEL G Front Shock Tower Assembly BORSA G / バッグ G Button Head M3 x 8mm Thread-lock Button Head M3 x 8mm Shock Mount Shock Mount Shock Tower Front TWCBF00010 Thread-lock x 1pc...
  • Page 13 Front & Rear Sway Bar Assembly STEP 1-3 BAG H / BEUTEL H Front Sway Bar Assembly BORSA H / バッグ H Set Screw Set Screw M3 x 3mm M3 x 3mm TWSSW00013 Thread-lock x 8pcs Set Screw Pivot Ball Sway Bar M3 x 3mm Pivot Ball Sway Bar TWSM00051...
  • Page 14 Battery Plate Saddle Pack Layout Assembly STEP 1 - 2 Thumb Nut BAG I1 / BEUTEL I1 • If You Choose SHORTY PACK layout, Please Go To Page 17 BORSA I1 / バッグ I1 Battery Holder Battery Plate Plate Saddle Pack Battery Holder Thumb Nut Plate Saddle Pack...
  • Page 15 Button Head Screw Saddle Pack Layout Assembly STEP 3 - 4 M3 x 10mm Steel Tube BAG I1 / BEUTEL I1 4 x 3 x 20.4mm BORSA I1 / バッグ I1 Gear Box Upper Main Drive Shaft (1) Gear Box Front NOTE POSITION Assembled Upper...
  • Page 16 Saddle Pack Layout Assembly STEP 5 - 6 BAG I1 / BEUTEL I1 BORSA I1 / バッグ I1 Rear Shock Tower Assembled (BAG G) Button Head Screw M3x12mm TWSSW00002 x 8pcs Button Head Screw M3 x 12mm Front Shock Tower Assembled (BAG G) Button Head...
  • Page 17 Shorty Pack Layout Assembly STEP 1 - 2 BAG I2 / BEUTEL I2 BORSA I2 / バッグ I2 Battery Plate Thumb Nut Battery Holder Plate Shorty Pack Battery Holder Shorty Pack Set Screw GTB4P0702 M3 x 20mm Battery Plate x 1pc Thumb Nut FROM BAG I1 Set Screw...
  • Page 18 Button Head Screw M3 x 10mm Shorty Pack Layout Assembly STEP 3 - 4 Steel Tube 4 x 3 x 20.4mm BAG I2 / BEUTEL I2 BORSA I2 / バッグ I2 Gear Box Upper FROM BAG I1 Gear Box Front Steel Tube NOTE POSITION Main Drive...
  • Page 19 Shorty Pack Layout Assembly STEP 5 - 6 BAG I2 / BEUTEL I2 BORSA I2 / バッグ I2 Rear Shock Tower Assembled (BAG G) FROM BAG I1 Button Head Screw M3x12mm TWSSW00002 Button Head Screw x 8pcs M3 x 12mm Front Shock Tower Assembled (BAG G)
  • Page 20 Turnbuckles Assembly STEP 2 - 4 STEP 1 - 3 BAG J / BEUTEL J Camber / Steering Link Assembly BORSA J / バッグ J Ball End Ball End GTB4P0501 Turnbuckle x 14pcs 48mm Front Camber Link Rear Camber Link Set Screw M3 x 16mm TWSSW00011...
  • Page 21 Front Steering Knuckle Assembly STEP 2 - 4 BAG K / BEUTEL K Left Steering Assembly BORSA K / バッグ K Mid Drive Shaft Pin B Ball Bearing 2.5 x 8.5mm 5 x 11 x 4mm TWSM00092 x 4pcs Thread-lock Mid Di Shaft Front Drive Pin B...
  • Page 22 Rear Hub Assembly STEP 1 - 3 BAG L / BEUTEL L Ball Stud BORSA L / バッグ L 4.8 x 6mm Rear Knuckle Plate Rear Knuckle Left Rear Knuckle Plate TWCBF00012 x 2pcs Locknut Button Head Screw M3 x 8mm TWSSW00005 Ball Stud x 4pcs...
  • Page 23 Assemble the Front Shocks STEP 1 - 8 BAG M / BEUTEL M Assemble 2 Front Oil Shocs BORSA M / バッグ M E-Clips Shock Body Front MASM053A x 4pcs Shim Shock Piston 3.1 x 6 x 1mm 5 x 1.4mm E-Clip 2.3 TWSM00059 x 4pcs...
  • Page 24 Assemble the Rear Shocks STEP 9 - 16 BAG M / BEUTEL M Assemble 2 Rear Oil Shocks BORSA M / バッグ M E-Clips MASM053A Shock Body Rear x 4pcs Shim Shock Piston 3.1 x 6 x 1mm 5 x 1.4mm E-Clip 2.3 TWSM00059 x 8pcs...

  • Page 25: Rear Shock Installation

    Front Shock Installation STEP 1 - 2 BAG N / BEUTEL N BORSA N / バッグ N O-Ring 5 x 3 x 1mm Button Head Screw M3 x 8 mm TWSSW00005 Front Oil Shock Thread-lock x 4pcs Assembled O-Ring (BAG M) 5 x 3 x 1mm Button Head Screw O-Ring...
  • Page 26 Installing the Brushless Motor(NOT INCLUDED) STEP 1-3 BAG O / BEUTEL O BORSA O / バッグ O Button Head Screw M3 x 8 mm TWSSW00005 Button Head x 4pcs Screw M3 x 8mm Set Screw (NOT INCLUDED) Brushless Motor (NOT INCLUDED) Motor Plate Motor Plate TWSM00044...
  • Page 27 Servo & ESC Assembly STEP 1 - 3 BAG P / BEUTEL P Servo Horn Assembly BORSA P / バッグ P Ball Stud 4.8 x 6mm M3 Locknut Servo Arm 23T: JR / KO / SANWA / Spektrum Servo Arm 24T : Hitec Servo Arm 23T GBT4P0305 x 1pc...
  • Page 28 Mounting the ESC and Receiver STEP 4 - 6 BAG P / BEUTEL P Shorty Pack Layout BORSA P / バッグ P Flat Head Screw M3 x 8mm TWSSW00010 x 1pc 7.4V 2S LiPo Receiver (NOT INCLUDED) Shorty Battery Pack (NOT INCLUDED) (NOT INCLUDED) Antenna Mount...
  • Page 29 Body & Wing Assembly STEP 1 BAG I1 / BEUTEL I1 BORSA I1 / バッグ I1 Please Cut and Trim Along the Body Line. Body Clip MASM032A Flat Head Screw M3 x 6mm x 2pcs Wing Plate Wing Plate Flat Head Screw M3 x 6mm TWSSW00009 x 4pcs...
  • Page 30 Front And Rear Wheel Assembly STEP 1 BAG S / BEUTEL S BORSA S / バッグ S 23301W 1:10 Buggy 4WD Front White (KYO) Wheel RTA-G00003 x 2pcs 1:10 Buggy Rear White (KYO-AE-TLR) Wheel Rear Tyre (NOT INCLUDED) Stop Nut M4 23101W 1:10 Buggy 4WD Flanged Front White (KYO-AE-TLR)

  • Page 31: Spare Part List

    Carisma Racing Shock Oil 35wt 15611 4XS M3 Locknut Set 15531 Carisma Racing Shock Oil 45wt 15612 4XS Ø4.8 x 6mm & Ø4.8 x 8mm Ball Stud Set 15532 Carisma Racing Di Grease 3.5k 15613 4XS Alum Rear Knuckle Left 15533...

  • Page 32: Setup Sheet

    SETUP SHEET SHORTY PACK SADDLE PACK DRIVER: DATE: AIR TEMP.: HUMIDITY: TRACK: TRACK CONDITION: TRACK TEMP.: FRONT WIDTH: REAR WIDTH: WHEELBASE: MOTOR: RECEIVER: SPUR GEAR: PINION GEAR: SERVO: WING: BATTERY: FRONT TIRE INSERT: REAR TIRE INSERT: FRONT ANTI ROLL BAR: REAR ANTI ROLL BAR: BEST LAP: FRONT...
  • Page 33 SHORTY PACK SADDLE PACK SETUP SHEET DRIVER: DATE: AIR TEMP.: HUMIDITY: TRACK: TRACK CONDITION: TRACK TEMP.: FRONT WIDTH: REAR WIDTH: WHEELBASE: MOTOR: RECEIVER: SPUR GEAR: PINION GEAR: SERVO: WING: BATTERY: FRONT TIRE INSERT: REAR TIRE INSERT: FRONT ANTI ROLL BAR: REAR ANTI ROLL BAR: BEST LAP: FRONT...
  • Page 34 SHORTY PACK SADDLE PACK SETUP SHEET DRIVER: DATE: AIR TEMP.: HUMIDITY: TRACK: TRACK CONDITION: TRACK TEMP.: FRONT WIDTH: REAR WIDTH: WHEELBASE: MOTOR: RECEIVER: SPUR GEAR: PINION GEAR: SERVO: WING: BATTERY: FRONT TIRE INSERT: REAR TIRE INSERT: FRONT ANTI ROLL BAR: REAR ANTI ROLL BAR: BEST LAP: FRONT...
  • Page 35 Note...
  • Page 36 www.carisma.com.hk Visit Us on www.carisma-shop.com Also avaliable at ©2015 Carisma. All Rights Reserved. Product specifications are subject to change. Printed in China Some models shown are prototypes which may vary slightly from what is inside. MAN-G00627...
