Recommended Motors:

A8-3, B4-2, B6-4, C6-5

Please read this entire instruction sheet before you begin, so

that you become familiar with each step in constructing the

Triskelion.

READ FIRST: Congratulations! You are about to build a

quality model rocket kit from FlisKits. If this is your first model

rocket then you are in for a real treat. Even if you have built

other model rocket kits, please read on.

The Triskelion kit is designed as a perfect first rocket kit and

the assembly steps should be easy to follow. That does not

mean that this kit will be a simple project. On the contrary, you

will have to carefully read each instruction step with the

associated figure if you are to properly assembly this kit. Even

if you have built other kits, you may find a surprise or two

because all FlisKits model rocket kits are constructed with

wood fins and balsa nose cones which do not appear in many

other popular kits.

Take your time and use this as a good opportunity to learn how

to work with these new materials. This will serve as a big help

as you get into more complicated FlisKits kits.

To assemble this model rocket kit you will need the following

tools and supplies: Hobby knife, white glue (DO NOT use Hot

Glue!), sand paper, masking tape, pencil, and ruler. To finish

this model you will need sand paper, wood filler/sealer, primer

paint and other paints of your choice. Additional items that can

help with the construction include clear plastic wrap,

cellophane tape, and a hole punch.

Now, on to Step One!

Triskelion Instruction Sheet: FK-INS-SP010 Rev: B

Office of Chief Engineer

SP010

16-Sept-2004

Chief Deployment Engineer

anniversary of the

Flying Model Rocket

Assembly Instructions

Table of Contents

Need help?

Do you have a question about the Triskelion SP010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Flis Kits Triskelion SP010

Page 1 From: Office of Chief Engineer Vehicle(s): SP010 Effective Date: 16-Sept-2004 Chief Ordinance Engineer Chief Deployment Engineer Effective immediately, the attached procedures will be used in the assembly and deployment of Launch Vehicle SP010, known as “Triskelion”, released on the 2 anniversary of the birth of FlisKits, Incorporated.
Page 2 There is one large brown ring in your kit. This is the CRP- Place a bead of glue on the inside of the top of the Engine 50-55. This ring is not a part of your model. Rather it is Tube and insert the Engine Block until it touches the Engine Hook inside the tube, as shown in Figure 3.
Page 3 Your Triskelion model rocket kit comes with Laser-Cut Fins to make assembly easier. In some kits these are loose, in others they are attached to a sheet of balsawood. If your fins are attached, carefully removed them and discard the scrap balsawood. Figure 6 shows you what your fins look like and what they are called.
Page 4 Figure11 12. Referring to Figure 12, apply a bead of glue along the Root Edge of one Fin and attach it to the Body Tube such that it is aligned with one of the fin outlines on the alignment pattern. When properly attached, the fin should be sitting flat on the paper, covering the fin outline on the guide with the root edge of the fin flat against the Body Figure 13...
Page 5 Figure 19 shows you how you can use a hole punch to 16. Locate the three Toothpicks that came with your kit. punch holes in the center of each tape disk. Using the template provided on the Fin Pattern Sheet, cut these to 2 inches long.
Page 6 24. Referring to Figure 24, tie the free end of the Shock Cord Tie the other end of this same Shroud Line to the next to the Screw Eye in the Nose Cone. Also tie the gathered hole, so that ONE Shroud Line is tied to TWO holes. Shroud Lines of the Parachute to the Screw Eye.
Page 7 your model to look exactly like the picture on the cover of your kit! Refer to the following Flight Preparation section for all you will need to know about getting your Triskelion on the launch pad and into the air! FIGURE D Triskelion Flight Preparation! Select a recommend model rocket motor (per kit...
Page 8 First, make sure that your igniter is intact with no wires touching each other. Place igniter into the motor nozzle until it will go no further (when it stops, the tip of the igniter is in contact with the propellant) Take a small square of recovery wadding, roll it into a tight ball and, using a pencil or other pointed object, push this into the nozzle, securing the igniter in place,...
