- Page 1 Tac-Eye ® (Standard Mobile Monitor) Six15 encourages customers to read this manual before operating this device.
-
Page 2: Table Of Contents
SMM Module ..........................4 SMM Connectors ...........................4 ACCESSORIES ......................... 5 Standard Cable Set .........................5 SIR Cable Set (use with L-3 CSW SIR device) ..................5 Tac-Eye Battery Pack ........................5 USER INTERFACE ........................6 Keypad ............................6 MOUNTING ........................... 7 Velcro Option ..........................7 Loop Option ...........................7 CLEANING AND CARE ...................... -
Page 3: Product Summary
PRODUCT SUMMARY The Tac-Eye SMM is a low power, portable direct view display system with RCA and USB connectivity providing a simple interface to other standard equipment. Developed to support ISR applications, the SMM allows the user to view incoming video on a 5”... -
Page 4: Product Configurations
SMM, which shows the location of these connectors within the recess. The USB connector is on the left and the RCA connector is on the right. Figure 3: USB Mini-B and RCA Receptacles Tac-Eye SMM User Manual Page 4... -
Page 5: Accessories
Figure 7: SIR Cable Set Tac-Eye Battery Pack The Tac-Eye battery pack (Figure 8) is a rugged power source that provides a regulated 5V output from two independently selectable banks of CR123 batteries (2 per bank). Power is provided from a female USB Type-A connector and will power an SMM for over 14 hours. -
Page 6: User Interface
When in this mode the video frame is outlined by a blue hashed border as visual feedback that this mode is active. Releasing this button from ‘Freeze Frame’ returns the display to the incoming video stream without decreasing display brightness. Tac-Eye SMM User Manual Page 6... -
Page 7: Mounting
SMM in the intended location. Straps less than 1” wide and less than 3mm thick can also be used to mount the SMM to a MOLLE Figure 11: Mounting Loops interface. Tac-Eye SMM User Manual Page 7... -
Page 8: Cleaning And Care
CLEANING AND CARE The Tac-Eye SMM is durable and easy to maintain. It is recommended as with any device that a better user experience is tied to product maintenance. To ensure the SMM remains at its functional peak, take afforded opportunities to clean the device using the following instructions. -
Page 9: Troubleshooting
Technologies for further resolution. Technical Support If there is trouble using the SMM you are encouraged to contact Six15 Technologies to investigate and report the problem (contact information on back page). To ensure expedient resolution of any issue be prepared to provide: ... -
Page 10: System Specifications
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Tac-Eye SMM User Manual Page 10... -
Page 11: Warranty Information
Some states or countries do not allow certain exclusions of warranties or limitations of certain types of damages. Accordingly, certain exclusions or limitations might not apply to you. Consult your applicable laws to determine the full scope of your legal rights. Tac-Eye SMM User Manual Page 11... -
Page 12: Contact Information
Six15 Technologies Customer Service Department 336 Summit Point Drive Henrietta, NY 14467 CAGE Code: 1X0E0 (855) 844 - 4655 (Toll Free U.S. and International) info@six-15.com TAC-EYE IS A REGISTERED TRADEMARK IN THE U.S. 404PB0001-01 Tac-Eye SMM User Manual Page 12...
