- Page 1 Instruction Manual Rack Power Distribution Unit 7M, 7N, 7S, 7T and 7W Series Firmware Version 3.12.7 Revision Date: 06/01/2015...
-
Page 2: Table Of Contents
Contents Contents..........................2 Specifications........................4 Overview Environmental Electrical Receptacle Ratings Networking Data Formats EMC Verification Installation ........................6 Guidelines Mounting Network Overview Default IP Address Initial Setup Web Interface .........................13 Overview Sensors Page Logging Page Display Page Alarms Page Control Page (7S and 7W Only) Configuration Page Unit Configuration ......................27 Network Configuration... -
Page 3: Revision History
Technical Support ......................44 Firmware Version Firmware Updates Resetting PDU Service and Maintenance More Technical Support Table of Figures.......................45 Revision History... -
Page 4: Specifications
The 7M, 7N, 7S, 7T and 7W series units are rack level PDUs with circuit monitoring via a built-in web server. In the 7M series, built-in sensors monitor Voltage, Current, instantaneous and cumulative Power, as well as calculated Power Factor. -
Page 5: Data Formats
Ethernet Link Speed 10 MBit; half-duplex Data Formats HTML, SNMP, CSV/Plain Text, XML EMC Verification This Class A device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Installation
Installation Guidelines If the PDU is installed in a cabinet the ambient temperature of the rack should be no greater than the PDU’s maximum rated operating temperature. Install the PDU such that the amount of airflow required for safe operation of equipment is not compromised. -
Page 7: Mounting
Using the full length bracket, mount PDU to rack as shown Figure 2: Toolless Mounting Hardware Secure toolless mounting buttons to PDU as shown. Use toolless buttons with key-holed slots built into cabinet or with optional Siemon PDU brackets (V-PDU & VP-PDU-002 shown). -
Page 8: Network Overview
Figure 3: Adjustable Mount Brackets Using adjustable mount brackets, attach PDU to rack as shown Network Overview This product comes preconfigured with a default IP address set. Simply connect to the PDU and access the web page with your browser. Default IP Address 7M, 7N, 7S and 7W units have a default IP address for initial setup and access to the unit if the assigned address is lost or forgotten. -
Page 9: Initial Setup
The Configuration page allows you to assign the network properties or use DHCP to connect to your network. Access to the unit requires the IP address to be known, so use of a Static IP or reserved DHCP is recommended. The default address is shown on the front of the unit: ... - Page 10 Windows XP On your computer, go to “Start > Settings > Control Panel > Network and Dial Up Connections” Right click on “Local Area Connection” and select “Properties” Select “Use the following IP address”. Use these settings: IP Address: 192.168.123.1 ...
-
Page 11: Figure 4: Windows Xp Network Settings For Initial Setup
Figure 4: Windows XP network settings for initial setup. MacOS X 10.5 and 10.6 Open System Preferences via the Dock or the Apple menu. Select “Network” under “Internet & Network.” Select “Ethernet” from the list on the left side of the window and enter these settings on the right side of the window: Configure: Manually... -
Page 12: Figure 5: Macos X Network Settings For Initial Setup
Figure 5: MacOS X network settings for initial setup Note: Problems connecting to the local PDUs may be caused by the use of proxy servers. Turn off “Use a proxy server for your LAN” or select “Bypass proxy server for local addresses” under your web browser’s LAN settings. -
Page 13: Web Interface
Web Interface Overview The unit is accessible via a standard, unencrypted HTTP connection as well as an encrypted HTTPS (SSL) connection. The following web pages are available: Sensors Page The front page, Sensors, gives both instantaneous and historical views of the unit’s data. Real time readings are provided for all power strip data, outlet group data (7W only), and sensor data next to historical graphs. -
Page 14: Figure 8: Sensors Page - Delta Configuration
Figure 8: Sensors Page – Delta Configuration... -
Page 15: Figure 9: Sensors Page - Group And Sensor Data
Figure 9: Sensors Page – Group and Sensor Data... -
Page 16: Logging Page
Logging Page The Logging page allows the user to access the historical data by selecting the desired sensors and time range to be logged. The Sensor Measurement Data Graph section contains check boxes which allow the user to select which readings are to be graphed on the Logging page and/or displayed on the internal LCD. -
Page 17: Figure 10: Logging Page
Figure 10: Logging Page... -
Page 18: Display Page
Display Page The Display page allows the user to assign friendly names to attached sensors, change the default unit of measure for all temperature sensors, and change what is scrolling on the LCD display (Measurements or Alarms). The display page also allows the user to select between the default and classic web page layouts. -
Page 19: Alarms Page
Alarms Page The Alarms page allows the user to establish alarm conditions for each sensor reading. Alarm conditions can be established with either high or low trip thresholds. The alarms are displayed in different sections based on the device the alarm is associated with. Alarm options include a local Buzzer, Email and SNMP Trap. -
Page 20: Control Page (7S And 7W Only)
Control Page (7S and 7W Only) The Control page has two sub-tabs; Actions and Settings. See Remote Outlet Switching (page 39) for details. Control Actions Tab The Actions tab on the Control page gives the user control of the outlets. Outlets can be rebooted or turned on/off with or without pre-programmed delays. -
Page 21: Figure 14: Control Settings Tab
Control Settings Tab The Settings tab on the Control page allows the user to name and define a URL for outlets in addition to setting time delays for each outlet action. Boot up status and sequential boot up options are also available. All delay settings are referenced from the trigger event. This tab also allows the user to restore factory default settings for the outlets. -
Page 22: Configuration Page
Configuration Page The Configuration page has five sub-tabs; Network, Monitoring, Diagnostics, Event Log, and Admin. See Unit Configuration (page 27) for details. Configuration Network Tab The user can enter and update the network settings on the Network tab of the Configuration page. -
Page 23: Figure 16: Configuration Monitoring Tab
Configuration Monitoring Tab The user can enter and update the email alert, SNMP, and camera settings on the Monitoring tab of the Configuration page. See Unit Configuration section for details. Figure 16: Configuration Monitoring Tab... -
Page 24: Figure 17: Configuration Diagnostics Tab
Configuration Diagnostics Tab The user can update the Syslog settings on the Diagnostics tab of the Configuration page. Figure 17: Configuration Diagnostics Tab... -
Page 25: Figure 18: Configuration Event Log Tab
Configuration Event Log Tab The user can view the Event Log and update the Memory Syslog settings on the Event Log tab of the Configuration page. Figure 18: Configuration Event Log Tab... -
Page 26: Figure 19: Configuration Admin Tab
Configuration Admin Tab The user can set the system clock and administrative information on this tab. Additionally, the user can set administrator and account passwords. See Unit Configuration section for details. Figure 19: Configuration Admin Tab... -
Page 27: Unit Configuration
Unit Configuration Network Configuration The unit’s network configuration is set on the Network tab of the Configuration page. Settings pertaining to the unit’s network connection are: Figure 20: Network Configuration DHCP: Allows the unit to request a dynamic IP address from a server on the network. ... -
Page 28: Time And Date
Time and Date The system clock is set on the Admin tab of the Configuration page. The unit comes preconfigured with the IP addresses of two NIST time servers and is set to the Central Time Zone (-0500 GMT). Should a local time server be preferred, select “NTP Server” from the “Set Clock method”... -
Page 29: E-Mail/ Business Hours
The time, date, IP address and friendly name of the unit are displayed at the top of each web page. E-Mail/ Business Hours The e-mail and business hours configuration are set on the Monitoring tab of the Configuration page. The unit is capable of sending e-mail to as many as five addresses at once. Most SMTP and ESMTP servers are compatible. -
Page 30: Snmp
unit. In addition, a test email can be sent from the bottom of the Monitoring tab of the Configuration page. Note: The unit cannot receive e-mails. The POP3 server is used strictly for authentication and is not required when the protocol is set to ESMTP or None. Status Reports When enabled, the unit will periodically send a full status report to all “To”... -
Page 31: Telnet
Administrator: Password protects the Display, Alarms and Configuration pages along with protecting the Telnet and Serial access. Control Access: Password protects the Control Actions and Control Settings pages. View-Only: Password protects the Sensors, PDA, WAP and XML pages. Figure 27: Account Configuration User account names may include alphanumeric characters, spaces and underscores. -
Page 32: Camera Configuration
The unit provides a Telnet server for basic monitoring via the command line. The Administrator account must be enabled to use the Telnet interface. Type “help” after logging in to the unit to see a list of available commands. The Telnet service can be disabled under “Web Server” on the Network tab of the Configuration page. -
Page 33: Kilowatt-Hours Reset
Information entered in the “Admin Info” section of the Admin tab of the Configuration page will show up at the bottom of the unit’s web interface. Figure 29: Admin Information Fields Kilowatt-Hours Reset The 7M, 7N, 7S and 7W’s kilowatt-hours measurements are zeroed at the factory and can be reset at any time, should it become necessary. -
Page 34: Ssl Certificate Upload
Figure 31: XML File Upload SSL Certificate Upload The unit will automatically generate a unique SSL Certificate and Private Key. Alternatively, a custom SSL Certificate and Private Key can be uploaded to the unit by pressing the “Upload SSL Files” button on the Admin tab of the Configuration page. The SSL certificate and key file must be in Distinguished Encoding Rules (DER) format. -
Page 35: Alarms
Alarms Alarm Notifications The 7S, 7M, 7N and 7W support three types of alarm notification: E-Mail: The unit can be configured to send alarm e-mails to up to five recipients. SNMP: The unit can be configured to send SNMP traps to up to two trap servers. The unit is capable of any combination of the above alarms at once. - Page 36 alarm thresholds. By allowing the sensors to operate for several hours, the user can better understand what the normal variations are; thereby allowing the user to choose alarm thresholds that will not trigger numerous false alarms. Alarms can be set to only send notification if the alarm is in a tripped state for a certain amount of time.
-
Page 37: Sensors
Sensors Overview All internal sensors are measured every 15 seconds. External sensors are measured every 15 to 30 seconds, depending on the number of devices connected. Sensor data collected by the 7M, 7N, 7S or 7W unit gives useful trend analysis data. While all values are not absolute in relation to a known unit, trend analysis of the data allows users to view changes and draw useful conclusions about what is happening over time in the monitored environment. -
Page 38: Data Logging And Display
Group Volts: Measures instantaneous RMS voltage for a group of outlets. Group Amps: Measures instantaneous RMS current for a group of outlets. Outlet Amps: Measures instantaneous RMS current for each outlet. Outlet Real Power: Average of instantaneous voltage and current over last 1.5 seconds for each outlet. -
Page 39: Remote Outlet Switching (7S And 7W Only)
Remote Outlet Switching (7S and 7W Only) Actions The 7S and 7W Series are equipped with individually switchable outlets. There are seven possible actions for any given outlet, available from the “Action” drop down box on the Actions tab of the Control page: Figure 34: Outlet Actions ... -
Page 40: Configuration
Configuration The 7S and 7W series units list all available outlets under “Configuration” on the Settings tab of the Control page. Each outlet has five fields associated with it: Figure 36: Outlet Configuration Name: A friendly name to easily identify what is plugged into the outlet. For example: “Mail Server”... - Page 41 Note for units with built-in circuit breakers: Should one of the unit’s circuit breakers trip, upon being reset any outlets powered by that breaker will perform their power-on actions.
-
Page 42: Accessories
Accessories Serial Communication (Delta Configured Units Only) The Delta configured units provide an out-of-band, serial line, monitoring interface. The unit provides an RJ-45 port for RS-232 serial communication, giving monitoring via the command line similar to the Telnet service. If the administrator name and password are setup then they must be used to access the serial command line. -
Page 43: Alternate Data Formats
Figure 39: Camera Images Camera model and IP address are entered on the Monitoring tab of the Configuration page. Note: Some cameras require additional software downloads to display live video in a web browser. Alternate Data Formats In addition to the full access, control and configuration available via a desktop web browser, 7M, 7N, 7S and 7W Series products present data in multiple formats for easy integration with other monitoring systems. -
Page 44: Figure 41: Web Page Header
No service or maintenance is required. Do not attempt to open the PDU or you may void the warranty. No serviceable parts inside. It is recommended that power be removed from the unit before installing or removing any equipment. More Technical Support http://www.siemon.com (866) 474-1197 Email: techsupport@siemon.com Or contact your distributor. -
Page 45: Table Of Figures
Table of Figures Figure 1: Full Length Bracket ....................7 Figure 2: Toolless Mounting Hardware ...................7 Figure 3: Adjustable Mount Brackets..................8 Figure 4: Windows XP network settings for initial setup............11 Figure 5: MacOS X network settings for initial setup ............... 12 Figure 6: Internet Explorer's LAN Settings for selecting proxy settings ........
