Summary of Contents for Homecare LBP30
- Page 1 Model LBP30 Smart Pulsewave Blood Pressure Monitor Model LBP30 Smart Pulsewave Blood Pressure Monitor INSTRUCTION MANUAL Shenzhen RSP Medical Technology Co., Ltd...
- Page 2 Model LBP30 Smart Pulsewave Blood Pressure Monitor Dear Customer, Thank you for purchasing the LBP30 Smart Pulsewave Blood Pressure Monitor. In order to use the device correctly and efficiently, please read this Instruction Manual before use. In addition, please take good care of the manual after your reading to ensure you can find it easily when necessary.
-
Page 3: Table Of Contents
Model LBP30 Smart Pulsewave Blood Pressure Monitor CONTENTS SAFETY PRECAUTIONS..................4 COMPONENTS OF THE PRODUCT................6 RECHARGE THE BATTERY..................7 APPLYING THE CUFF....................8 POSTURES INSTRUCTIONS..................8 SETTING UNITS......................9 TAKING A MEASUREMENT..................10 CARE AND MAINTENANCE..................12 ERROR INDICATORS....................12 TROUBLESHOOTING TIPS..................12 PRODUCT SPECIFICATIONS................... 13 APPENDIX A: PACKING LIST.................. -
Page 4: Safety Precautions
Model LBP30 Smart Pulsewave Blood Pressure Monitor SAFETY PRECAUTIONS The purpose of the symbols used in the Instruction as safety identifying is to enable you use the product safe and properly, and to prevent harm to you and others or damage to property. - Page 5 Model LBP30 Smart Pulsewave Blood Pressure Monitor CAUTION 1. Be sure to use and purchase a dedicated double-bladder cuff, or you cannot get accurate results. 2. Do not use a cellular phone near the device, or it may cause electromagnetic interference, and thus result in an operational failure.
-
Page 6: Components Of The Product
Model LBP30 Smart Pulsewave Blood Pressure Monitor Otherwise the device may reach less than the claimed accuracy. COMPONENTS OF THE PRODUCT Main unit: Display: Diastolic blood pressure Unit Pulse rate Systolic blood pressure Measurement data... -
Page 7: Recharge The Battery
Model LBP30 Smart Pulsewave Blood Pressure Monitor DualCuff: (Applicable arm circumference: 22cm-32cm) Connect to upper bladder Connect to lower bladder The arrow directs down. RECHARGE THE BATTERY 1. When the screen displays “LOP”, it means low battery, please recharge it in time;... -
Page 8: Applying The Cuff
Model LBP30 Smart Pulsewave Blood Pressure Monitor If the product was not operated for 3 months, please store the device with fully charged battery. APPLYING THE CUFF When measuring, take off the thick garments and keep the upper arm bared. Thin clothing does not affect the measurement if it does not take pressure to the arm. -
Page 9: Setting Units
Model LBP30 Smart Pulsewave Blood Pressure Monitor 2. Place your arm on the table so that the cuff is at the same level as your heart. 3. Be relaxed and breathe normally before measurement. NOTE: Your arm cuff and heart should be on the same level; otherwise, measurement accuracy will be affected. -
Page 10: Taking A Measurement
Model LBP30 Smart Pulsewave Blood Pressure Monitor NOTE: If you need to reset the units, you must turn the monitor off, then operate the unit according to the above steps. TAKING A MEASUREMENT This monitor has two different units optional: mmHg and kPa. The default unit is “mmHg”. - Page 11 Model LBP30 Smart Pulsewave Blood Pressure Monitor 6. After inflation stopped, the bladder will deflate with a constant speed, the monitor enters the measuring state and the value on the display goes down. 7. After the measurement finished, the DualCuff deflates quickly, and your blood pressure and pulse rate will show on the display.
-
Page 12: Care And Maintenance
Model LBP30 Smart Pulsewave Blood Pressure Monitor 4. If in the measurement process a system error occurs for some reasons which result in measurement failure or the cuff is excessively inflated, please press the button “ ” to turn off the device and restart it. -
Page 13: Product Specifications
Model LBP30 Smart Pulsewave Blood Pressure Monitor Number Phenomenon of fault Possible reason Solution No display appears Use the AC adaptor to supply No power on the unit power Unable to measure Arm cuff may not Please apply the arm cuff... -
Page 14: Appendix A: Packing List
Model LBP30 Smart Pulsewave Blood Pressure Monitor APPENDIX A: PACKING LIST When the user opens blood pressure monitor’s packaging, please check the following packing list. If objects are not complete or have other questions, please contact RSP Medical or authorized distributors. - Page 15 Model LBP30 Smart Pulsewave Blood Pressure Monitor Table 1: Guidance and manufacturer’s declaration – electromagnetic emission Smart Pulsewave Blood Pressure Monitor is intended for use in the electromagnetic environment specified below. The customer or the user of Smart Pulsewave Blood Pressure Monitor should assure that it is used in such an environment.
- Page 16 Model LBP30 Smart Pulsewave Blood Pressure Monitor ± 2 kV for power ± 2 kV for power Electrostatic Mains power quality should be supply lines supply lines transient / burst that of a typical commercial or hospital ± 1 kV for input/output ±...
- Page 17 Model LBP30 Smart Pulsewave Blood Pressure Monitor Portable and mobile RF communications equipment should be used no closer to any part of the Smart Pulsewave Blood Pressure Monitor, including cables, than the recommended separation distance calculated from the equation applicable to the frequency of the transmitter.
- Page 18 Model LBP30 Smart Pulsewave Blood Pressure Monitor Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3V/m. Table 4: Recommended separation distances between portable and mobile RF communications equipment and the Smart Pulsewave Blood Pressure Monitor...
- Page 19 Model LBP30 Smart Pulsewave Blood Pressure Monitor Product Name: Smart Pulsewave Blood Pressure Monitor Model: LBP30 Shenzhen RSP Medical Technology Co. Ltd 2203, Taibang Technical Building, Gaoxin S. 4 Rd, Nanshan District, Shenzhen, 518000, China. Website: www.lepuhomecare.com Tel: +86 -755-86952278 Email: sales@lepuhomecare.com...
