- Page 1 User’s Manual for ZKSD3 Series PTZ Dome IP Camera Document Version: 1.7 Date: 2012.10 Introduction This document mainly introduces the functional features, installation process and access methods of ZKSD3 series IPC.
-
Page 2: Important Notices
Important Notices Thanks for selecting our company’s IPC. Before use, please read through the user’s guide to avoid any unnecessary damage! All functions depend on the actual product. Since the product is subject to updating, our company is not responsible for any difference from this guide and not liable for any dispute over different technical parameters from this guide. -
Page 3: Table Of Contents
Table of Contents Table of Contents 1 Overview ....................... 1 1.1 Product Description ..................1 1.2 Product Features ..................1 1.3 Technical Parameters ................... 3 1.4 Product Appearance ..................5 1.5 Connecting Terminal ..................8 1.6 Basic Procedure ..................12 2 Installation and Network Configuration ............13 2.1 Hardware Installation ..................13 2.2 Operating Environment ................20 2.3 Network Connection ...................20... -
Page 4: Overview
Overview 1 Overview 1.1 Product Description The ZKSD3 series products are high-speed domel IP cameras with CCD sensors, which are integrated with multiple new technologies in mechanical, electronic and casting fields; they are high-performance integrative cameras with built-in zoom lens and high-end surveillance products combining the platform and digital decoder design, which represent new generation technologies. - Page 5 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 Analog video signal output interface Functions of the system 1/4" Sony high-performance CCD used for sharp images; Driven by precision motor, featuring sensitive response and steady operation;...
-
Page 6: Technical Parameters
Overview Support ratio zoom function; rotation speed can be automatically adjusted according to the zoom multiple. Performance Hi3512 high-performance multimedia processor, supporting H.264 Main Profile video coding The highest resolution of images is to D1 (704 * 576) resolution ... - Page 7 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 Secondary Code Stream: 352x288, 176x144 optional Video Frame Rate 1~25 frames optional Functional Interfaces Audio Interface 1 Mic input and 1 linear output (optional) Alarm Input 1 alarm input (normally opened or normally closed) (optional)
-
Page 8: Product Appearance
Overview Working Environment AC 24V, ≥2A Input Power POE Ethernet power supply: comply with 802.3af regulation (optional) 30W (without heater) Maximum Power Consumption 40W (with heater) -40~+55 °C Working Temperature Working Humidity 10%~85%RH Level of Protection IP66 Installation Mode Wall-mounted / Pending mounted net weight 4.5KG 1.4 Product Appearance... - Page 9 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 Dimensional Drawing (in mm) dimensional drawing of wall mounted bracket (unit: mm) Right Side View...
- Page 10 Overview Front View dimensional drawing of Lifting mounted bracket Right Side View...
-
Page 11: Connecting Terminal
User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 Wiring hole Bottom View 1.5 Connecting Terminal ( 8 ) ( 7 ) ( 6 ) ( 5 ) ( 4 ) ( 3 ) ( 2 ) ( 1 ) Power Interface: used for connecting the power adapter. - Page 12 Overview Reset Button: When the camera fails to function during incorrect operation or accidental failure (e.g. forget IP address or password), or it is used in different scenes, press down the button for above 5s after a delay of 30s from powering on to restore the camera to its factory default.
- Page 13 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 alarm input terminals alarm (IN,GND) switch input device power supply of alarm input device Schematic Diagram of Alarm Input (Normally Closed) Connection Notice: When external alarm input is started, different alarm inputs have different software settings.
- Page 14 Overview alarm alarm output terminals switch output (COM,NO) device power supply of alarm output device Schematic Diagram of Alarm Output (Normally Closed) Connection (5) Reserved Interface: Reserved for other uses. (6) Audio Input Interface: connect to external audio acquisition (e.g. MIC) for sound acquisition as detailed in User Manual –...
-
Page 15: Basic Procedure
User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 1.6 Basic Procedure Unpack and check whether any component is missing; Connect the camera to computer by means of patch cable; If your computer IP is in a network section different from camera IP, please set it to the same network section as camera IP, such as, 192.168.1.87. -
Page 16: Installation And Network Configuration
Installation and Network Configuration 2 Installation and Network Configuration 2.1 Hardware Installation Installation Notices: 1) ...... Read through the guide for installation prior to installation. 2) ...... Check whether any component is missing against the packing list, if yes, please contact your supplier. 3) ...... - Page 17 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 4) ...... Please use the power (voltage 24V AC and rating current no lower than 2A) provided by the factory for the cameras. Much higher or lower voltage and direct current power may cause the camera failure.
- Page 18 Installation and Network Configuration Please use repeater when exceeding 80m 9) ...... Pay attention to provide lightning protection if the camera is mounted outdoor. Do not touch the camera during lightning. 10) ....Use the camera in the working conditions: Ambient temperature: -20 ℃...
- Page 19 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 12) ....Do not let the cameras aim at intense light source for long period of time, in order to avoid the CCD failure, which results in no images or distorted images displayed.
- Page 20 Installation and Network Configuration Installation Diagram Wall Mounted Mode: Make the red buckle and green buckle in dome core match with the red tab and green tab in upper cover. First insert the green buckle to cover, and then insert the red buckle to cover, until a sound DI comes out.
- Page 21 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 installation screws Put the power cable, video cable and control cable through mounting bracket. Tighten the upper cover on the mounting bracket. If the device is installed outside, it is needed to wrap some waterproof tape in screw thread before tightening.
- Page 22 Installation and Network Configuration Fix the bracket in wall by 4 screws. steel M8 expansion bolt Note: The method of Pendant Mounting is the same as Wall Mounting. Paper template for pendant mounting pendant mounting...
-
Page 23: Operating Environment
User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 2.2 Operating Environment Operating System: Windows 98/ Windows2000, 2003, XP, Vista/ Windows 7; CPU: Pentium III 1GHZ or higher; Memory: 256MB or higher, at least 128MB (possibly affect performance and some functions);... - Page 24 Installation and Network Configuration Notice: 1) The default IP address is “192.168.1.88” and the default HTTP port is 80. If needed to change IP address or port, refer toNetwork Setting in User Manual – Using Browser for Video Surveillance. 2) If the device is in a network section different from computer, refer to How to Visit IPC on Internet in User Manual –...
-
Page 25: Accessing Device
User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 3 Accessing device There are 4 methods can be used to access the device: Browser, RTSP Media Player, Mobile Device and Video Surveillance Software (ZKiVision client software). 3.1 Using Browser Open a browser, type in the dynamic domain name or IP address of the device (e.g. -
Page 26: Using Rtsp Media Player
Accessing device Note: When accessing the device via browser for the first time, it is necessary to download the control. More details about how to use browser for video surveillance, please refer to User Manual – Using Browser for Video Surveillance in the supplied CD. - Page 27 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 Type in the network URL in the form of rtsp://<IP address>:<RTSP port>/<stream code>.
-
Page 28: Using Mobile Devices
Accessing device Click “Play” and the media player will play the real-time video of the device. Note: 1) The default RTSP port of device is 554. If it must be modified, please refer to User Manual – Using Browser for Video Surveillance in the supplied CD. - Page 29 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 Install the media player in the supplied CD into the mobile device. Click the icon “HIPlayer” to enter the media player. Click the button at the lower right corner to the setting interface, type in the user name, password, domain name and port of the device, or select a set device from the favorite.
-
Page 30: Using Video Surveillance Software
Accessing device Click “Play” and the medial player will play the real-time video of the device. Note: 1) The operating system of mobile device must be Android, BlackBerry or iOS . 2) As the internet service is required for watching video, please consult with your internet service provider for specific charges. - Page 31 User’s Manual for ZKSD3 Series PTZ Dome IP Camera V1.7 monitoring can be started. If needed to learn about how to use the video surveillance software, refer to ZKiVision Client Software User Manual in the CD.
