Summary of Contents for UDP Technology IPN1202HD
-
Page 1: Installation Guide
IPN1202HD Installation Guide 01A.03 UDP Technology Ltd. -
Page 2: Information To User
IPN Series IPN1202HD-5241 Installation Guide INFORMATION TO USER CAUTION RISK OF ELECTRIC SHOCK, DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE DEVICE COVER (OR BACK). CONTACT QUALIFIED SERVICE PERSONNEL FOR INTERNAL PART SERVICES. -
Page 3: Table Of Contents
IPN Series IPN1202HD-5241 Installation Guide Table of Contents 1. FEATURES ......................4 2. PACKAGE CONTENTS..................... 5 3. PART NAMES ......................6 3.1. Rear View ........................... 6 3.2. Side View ..........................6 3.3. Front View .......................... 6 4. INSTALLATION ...................... 8 4.1. -
Page 4: Features
IPN Series IPN1202HD-5241 Installation Guide 1. FEATURES Camera • Box type full-HD IP camera • 1/2.7” 1080p CMOS Image Sensor • 3.1~8 mm, F1.2, F1.2 DC auto iris lens, CS mount Streaming • Dual streaming mode • Burnt-in text support •... -
Page 5: Package Contents
IPN Series IPN1202HD-5241 Installation Guide 2. PACKAGE CONTENTS The package contains main camera, DC power adaptor, DC jack cable, camera lens, terminal block, power adaptor jack, screws, mounting adaptor, clamping core, and quick installation guide. Unpack carefully and handle the equipment with care. -
Page 6: Part Names
IPN Series IPN1202HD-5241 Installation Guide 3. PART NAMES 3.1. Rear View ③ ○ 4 ○ 5 ○ 2 ○ 6 ○ 1 ○ 7 ⑧ ○ 3.2. Side View ⑩ 3.3. Front View ○ 01A.03 UDP Technology Ltd. - Page 7 IPN Series IPN1202HD-5241 Installation Guide ① Power Adaptor Connect The camera requires DC 12V for power supply. Refer to the section “4.3. Connecting Cables” for more specific information ② PAL/NTSC button Press the PAL/NTSC button to set video output as PAL or NTSC. The default is no video output.
-
Page 8: Installation
IPN Series IPN1202HD-5241 Installation Guide 4. INSTALLATION 4.1. Installing a Lens High definition (HD) lenses are recommended on the camera to utilize the full resolution of a megapixel camera. Installing a standard definition (SD) lens to a megapixel camera may exacerbate camera noises and possibly introduce traditional edge effects. -
Page 9: Installing The Mounting Adaptor
IPN Series IPN1202HD-5241 Installation Guide 4.2. Installing the Mounting Adaptor The provided mounting adaptor is designed for installing an IP camera device on a bracket or tripod. Tripod screw holes are available on both top and bottom of the camera. Refer to the following image for instruction. - Page 10 IPN Series IPN1202HD-5241 Installation Guide Power Connection The camera can be powered from either 12VDC or PoE. If the camera is powered via PoE, refer to Appendix (B). Power over Ethernet for more details. To operate your camera using 12VDC, make sure the polarity is correct before connecting the power cable.
- Page 11 IPN Series IPN1202HD-5241 Installation Guide AUDIO Amp Speaker Sensor Input (D/I) The camera provides 1 channel D/I. It can be connected to either a voltage type sensor or relay type sensor as the following figures. Settings can be done through the camera’s configuration webpage.
-
Page 12: Setting The Image Attribute
IPN Series IPN1202HD-5241 Installation Guide Do not exceed the maximum relay rating. Caution Internal Device Relay Type RS-485 Connection The RS-485 serial port consists of TRX+(RX+) and TRX-(RX-) as following. <RS-485 Application> TRX+(RX+) TRX-(RX-) RS-485 Device PTZ Device 4.4. Setting the Image Attribute Through the camera’s webpage, users can configure image settings. -
Page 13: Configuration
IPN Series IPN1202HD-5241 Installation Guide 5. CONFIGURATION 5.1. Set up network environment The default IP address of the device is 192.168.XXX.XXX. Users can identify the IP address of the device from converting the MAC address’s hexadecimal numbers, which is attached to the device. -
Page 14: View Video On Web Page
IPN Series IPN1202HD-5241 Installation Guide To modify the device’s default IP address for customized network area; 1. Find the device from the IPAdminTool’s list and highlight the device’s name. 2. Right-click the mouse and select “IP Address”; IP Setup window appears. - Page 15 IPN Series IPN1202HD-5241 Installation Guide The browser asks to install the ActiveX. Click Allow. Setup.exe installation link or pop-up window appears, depends on Microsoft® Internet Explorer version. Proceed with rest of setup installation. Follow the instructions of the dialog boxes and complete the installation. Once the installation is complete, start the web browser again and check if video stream is displayed in the main view frame.
-
Page 16: View Video Using Ipadmin Tool
IPN Series IPN1202HD-5241 Installation Guide If “This software requires the Microsoft XML Parser V6 or higher. Please download MSXML6 from the Microsoft website to continue. Error code: Cannot create XMLDOMDocument.” message appears, download and install the Caution Microsoft Core XML Services (MSXML) 6.0. -
Page 17: Reset
IPN Series IPN1202HD-5241 Installation Guide 5.3. Reset To reboot the device, follow the steps below Using a pointed object, press the reset button for 2~3 seconds. Wait for the system to reboot. 5.4. Factory Default To reset the device to the factory default settings, follow the steps below;... -
Page 18: Appendix (A): Specifications
IPN Series IPN1202HD-5241 Installation Guide APPENDIX (A): SPECIFICATIONS Summary Camera Module Image Sensor 1/2.7” 1080p CMOS Effective Pixels 1920 x 1080 (HD 1080p, 2M) Scanning system Progressive Scan Lens (Optional) 3.1~8 mm, F1.2, Auto Iris Day & Night Removable IR Cut Filter... -
Page 19: Electrical Characteristics
IPN Series IPN1202HD-5241 Installation Guide Electrical Characteristics Power Source DC 12V / PoE IEEE802.3af compliant(Class 0) Video Output 1 Vp-p, 75Ω, Composite Audio Input Linein, 1.43Vp-p(Min 1.35Vp-p, max 1.49 Vp-p), 39 KΩ Audio Output Lineout, 46mW Power, 16 Ω Max 50mA@5VDC, 1.5V threshold Max 500mA@24VAC or 1A@12VDC On-state resistance: 50 Ω... -
Page 20: Appendix (B): Power Over Ethernet
IPN Series IPN1202HD-5241 Installation Guide APPENDIX (B): POWER OVER ETHERNET The Power over Ethernet (PoE) is designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3af Power-over-Ethernet (PoE) standard. The IEEE 802.3af-2003 standard allows up to 15.4 W power to device. However, 12.95W is the maximum available power, as some power gets lost in the cable. -
Page 21: Appendix (C): Dimensions
IPN Series IPN1202HD-5241 Installation Guide APPENDIX (C): DIMENSIONS UNIT: mm 01A.03 UDP Technology Ltd. -
Page 22: Appendix (D): Hexadecimal-Decimal Conversion Table
IPN Series IPN1202HD-5241 Installation Guide APPENDIX (D): HEXADECIMAL-DECIMAL CONVERSION TABLE Refer to the following table when converting the MAC address of the device to the IP address. 01A.03 UDP Technology Ltd. -
Page 23: Revision History
IPN Series IPN1202HD-5241 Installation Guide REVISION HISTORY MAN# DATE(M/D/Y) Comments 01A.01 03/30/2012 Created 01A.02 04/24/2012 Overall modification and device function verification 01A.03 05/03/2012 Configuration update 01A.03 UDP Technology Ltd.
