Contents Function Description…………………………………………………………………………………………3 Notice for Use……………………………………………………………………………………………..3 System Requirements……………………………………………………………………………………….5 Start to use……………………………………………………………………………………………………..6 ArcSoft PhotoImpression, VideoImpression and MediaImpression……………………………….13 Product Specifications……………………………………………………………………………………..28 Supplied Accessories………………………………………………………………………………………29...
300,000 pixels of still photos. With the playback function you can play back the taken video or photos with this digital video camera. In addition, you can download the videos and photos from the DV-2100 to your PC. The illustrations in this user manual are to visually detail the operation of the DV-2100.
Page 5
Maintenance and care: 1. To clean the lens, blow away the dust on its surface, then use proper cloth or tissue for optical devices to clean the lens. If necessary, use lens cleanser. 2. Never touch the lens with fingers. 3.
Above 128 MB Sound card and display card DirectX8 or above CD-ROM 4× speed or above Hard Disk 300 MB or more useable space Other One standard USB 1.1 or USB 2.0 port * The DV-2100 is compatible with all Mac OS.
Power Key USB Connector TV Out Port Microphone Resolution Switch Lens LED Light USB Switch Speaker Card Slot Battery Cover Strap Holder Tripod...
Page 8
Shutter/Record Up(+) Key Mode Delete Key Left Key Right Key Down(-) key...
Page 9
2. Basic operation 2.1 Battery Installation Slide down the Battery Cover and insert two new AA alkaline batteries. Align with correct polarity of battery terminals. Close Battery Cover. 2.2 Use SD card Insert the SD memory card into the SD card slot. Push it down until the card stays latched. Do not force –...
Page 10
In power-on state, when battery level is very low, the red icon on the bottom left of the screen will flash and the camera will turn off after one second. You must replace the batteries. Change mode After powering on, the camera will always enter video record mode, press mode key to change mode between video record and capture.
Page 11
Take a Picture In capture mode, press the shutter key to take a photo. Play back videos and photos In playback mode, press left or right key to select a file. Press Shutter key to begin/stop play video, and press up key or down key to on a photo. When the inserted memory card is full, the LCD will display "Memory Full,"...
Page 12
Press the delete key once to display “Delete File?” Press the delete key again to carry out deletion. Press any other keys to cancel the deletion. 2.11 Connect to PC and t Slide the USB Switch UP to extend the USB connector urn the camcorder ON.
Page 13
▲ Open USB port ▲Connect camera to PC (1) ▲ Connect camera to PC (2)
Application Attached ArcSoft PhotoImpression, VideoImpression MediaImpression: There are three software applications provided on the CD for image processing: PhotoImpression, VideoImpression, and MediaImpression. Introduction interface for software installation Put the CD into the CD-ROM of the computer, then the following menu will occur: If the CD driver does not automatically carry out or close such function, please click autorun.exe program under...
Page 15
PhotoImpression 6 Installation and Use: Install PhotoImpression6: Click “Install PhotoImpression” button, complete the installation as instructed.
Page 16
After installation, please restart the computer. Run PhotoImpression6: Double click icon on the desktop, or open PhotoImpression 6 via “Start→ Programs”.
Page 17
When PhotoImpression6 is opened, you’ll see the following window. Click the center of the window with the left key of the mouse to shut the window. After the window is off, you can open PhotoImpression. After PhotoImpression is open, the “Get Photo”...
Page 18
After choosing and opening photos in the “Get Photo” window, the chosen photos will be displayed in the center area of the screen. Then you can edit the chosen photos.
Page 19
For the detailed instructions of PhotoImpression, please refer to the Help menu in the program (as shown in the following figure).
Page 20
VideoImpression 2 Installation and Use: Install VideoImpression 2: Click “Install VideoImpression” button and complete the installation as instructed.
Page 21
After installation, please restart the computer. Run VideoImpression 2: Double click the icon on the Desktop or follow “Start → Programs” to open VideoImpression 2.
Page 22
After starting VideoImpression2, choose to create new video short. Choose to find the desired video short.
Page 23
Choose and insert the desired video short into VideoImpression2.
Page 24
In VideoImpression, you can edit the video short. For other detailed operation, press F1 Help menu (as indicated below) to understand more functions of this software.
Page 25
MediaImpression Installation and Use: Install MediaImpression: Click “Install MediaImpression” button and complete the installation as instructed.
Page 26
un MediaImpression: Double click the icon on the Desktop or follow “Start → Programs” to open MediaI mpression.
Page 27
Click on the media files that you would like to organize.
Page 28
ArcSoft MediaImpression® enables users to easily, creatively, and productively manage their multimedia with simple workflow and powerful tools. Organize your media easily and create simple projects with editing tools. There are endless ways to present and share; worry-free media file backup & restore. For other detailed operation, press the F1 Help menu to understand more functions of this software.
Product specifications: 300,000pixels Image sensor Record, playback, mobile disk, deletion Function mode F2.4 f=3.6mm Lens 120cm~infinity Focus range 4× Digital focusing Electronic Shutter 2.0 inch TFT Display LCD display VGA 640×480, QVGA 320×240 Resolution Automatic White balance Automatic Exposure File format TV out Video out SD card (max.
