SWIMMING POOL HEAT PUMP
"C" SERIES
MODELS: ELITE 55, 65, 85, 100, 115, & 130
INSTALLATION AND OPERATION MANUAL
It is important to register your product with us on our web
site. This will help us find your warranty when you place a
service call. If we cannot find your warranty registration, a
proof of purchase will be necessary.
www.PoolHeatPump.ca/warranty.php
IMPORTANT
1
Advertisement
Table of Contents
Summary of Contents for TTI Elite 55
- Page 1 SWIMMING POOL HEAT PUMP “C” SERIES MODELS: ELITE 55, 65, 85, 100, 115, & 130 INSTALLATION AND OPERATION MANUAL IMPORTANT It is important to register your product with us on our web site. This will help us find your warranty when you place a service call.
- Page 2 FAILURE TO FOLLOW THESE INSTRUCTIONS WILL VOID YOUR WARRANTY MANDATORY SAFETY MEASURES Congratulations for your purchase of a Elite heat pump. Your new Elite heat pump will extend your pool season and bring you years of comfort and enjoyment. This document will help to answer any questions you may have, will provide technical support and will allow you to take full advantage of your new Elite heat pump safely.
- Page 3 WATER PRESSURE EQUIPMENT HAZARDS Your water filtration system works under pressure, and water pressure may go off prior to work beginning. Please refer to the water filtration system instruction manual for more information. PREVENTING INJURIES AND DROWNING To reduce the risk of injury, do not authorize children to operate this device. ...
-
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION…….…………………………………..P.5 A source of savings How does it work? Minimal maintenance POSITIONING…………………………………………….P.6 Ventilation and accessibility Other recommendations III) WATER SUPPLY AND BACKFLOW………….……….P.7 Plumbing connections Minimum and maximum water flows CHLORINATORS, BROMINATORS AND OTHERS………………………………………….…...….P.8-9 Basic connections, inline chlorinator or brominator Salt chlorinator Pressurized chlorinator or brominator Parallel connection... -
Page 5: Introduction
INTRODUCTION A SOURCE OF SAVINGS Your heat pump will allow you to realize substantial savings compared to other means of heating your pool. Even if it has a lower heating capacity (BTU / h), which forces it to operate up to 24 hours a day in some cases, the heat pump remains the most inexpensive way to heat your pool, thanks to the use of advanced techniques in thermodynamics. -
Page 6: Minimal Maintenance
MINIMAL MAINTENANCE Your new heat pump has been designed to necessitate minimal maintenance. However, if you want your pool to be heated as efficiently as possible, you should abide by the installation and maintenance advice contained in this document. POSITIONING Choosing the area where your heat pump will be installed is extremely important. -
Page 7: Iii) Water Supply And Backflow
WATER SUPPLY AND BACKFLOW PLUMBING CONNECTIONS All Elite model connections have a 1 ½’ diameter. MINIMUM AND MAXIMUM WATER FLOWS For maximum efficiency, your heat pump must operate with water flows between 57 litres per minute (15 U.S. gallons per minute) and 170 litres per minute (45 U.S. gallons per minute). With a water flow of less than 57 lpm (15 U.S. -
Page 8: Chlorinators, Brominators And
CHLORINATORS, BROMINATORS AND OTHER AUTOMATIC SYSTEMS BASIC CONNECTIONS, INLINE CHLORINATOR OR BROMINATOR This connection is mandatory to ensure the long working life of your pool heat pump. Any automatic distribution system for chemicals, chlorine, bromine or other, must be installed so that the distribution system’s water output is located after the pool’s heat pump. -
Page 9: Connection To Electrical Power
For certain larger pools, it may be necessary to connect two parallel units. Keep the evaporator from one unit away from the evaporator in the other, fans away from fans and evaporators away from fans. 1, 2 and 3: optional valves 4: filter 5: water pump When you shut off the water to one of the heat pumps, the water flow that previously... -
Page 10: Cleaning
MAINTENANCE Before any storage or cleaning operation, turn off all electrical circuit WARNING breakers. CLEANING To prolong the working life of the device, you must: Clean the pool filter regularly to ensure adequate water flow inside the heat pump. Keep the surface of the coil (evaporator) clean and free from obstructions: paper, leaves or other. - Page 11 THE REGULATOR SF-501 The regulator features 1 display screen, 3 keys and 3 indicator lights. KEYBOARD DESCRIPTION DOWN KEY: Lower the displayed value UP KEY: Increase the displayed value POOL HEATING MODE INDICATOR: (green) indicates that the heat pump is heating the pool. SPA HEATING MODE INDICATOR: (green) indicates that the heat pump is heating the spa.
- Page 12 OPERATION 1) HOW TO START YOUR HEAT PUMP The heat pump starts as soon as the water temperature falls below the preset temperature for the pool or the spa. Temperature can be set using the UP and DOWN keys. 2) MANUAL ACTIVATION OF SWIMMING POOL MODE Press and hold set key (3 times) until P-S is displayed.
- Page 13 CODES CODE DESCRIPTION POSSIBLE CAUSES ACTION Water temperature sensor Water temperature sensor is not Call a certified technician working or has been improperly Heat pump shuts off connected Evaporator temperature sensor Evaporator temperature sensor is Call a certified technician not working or has been Heat pump shuts off improperly connected LP &...
-
Page 14: Regulator
TROUBLESHOOTING PROBLEMS POSSIBLE CAUSES SOLUTIONS The device won’t start. No power Make sure circuit breaker No need for heat is on Compressor protection Check desired delay activated (Power light is temperature and adjust if necessary flashing) When the device stops, the regulator imposes a 3-minute delay before restarting compressor to allow for pressure balancing. -
Page 15: Questions And Answers
QUESTIONS AND ANSWERS 1) Is it possible that my pool has been losing water since my heat pump was installed? Your pool is not leaking water, but because of the higher temperature of the pool water, water evaporates more than before. Indeed, the greater the temperature difference between pool water and air, the more evaporation occurs. - Page 16 6) The TTI heat pump is designed for use with in-ground or above-ground pools only. If the device is used for any other purpose than its intended and prescribed use, the device’s owner discharges the manufacturer from any and all responsibility.
- Page 17 The individual who purchased this device from a retailer is the only individual habilitated to submit a claim under the terms of this limited warranty. Any and all claims against TTI Fabrication will be limited to defects, improper functioning or deterioration of this TTI product, in accordance with the provisions of this limited warranty.
