- Page 2 BUSH - DVD Home Theatre Kit Installation & User Instructions – Please keep for future reference 533/8636 (D) INPUT VOL+ VIRTUAL MODE VOL- VIRTUAL 2.1CH VIRTUAL 5.1CH Important – Please read these instructions fully before installing or using These instructions contain important information which will help you get the best from your appliance and ensure safe and correct installation, use and maintenance.
-
Page 3: Table Of Contents
Electrical connection User Instructions 11-13 Getting started Basic operation 11-13 Speaker level setup AUX input Product Codes AUX sound modes CHT101DVD Advanced Operation 14-15 DVD Program menu CD Program menu 14-15 JPEG Picture disc The Setup Menu 16-18 Language Setup menu... -
Page 4: Safety Information
Safety Information Important – Please read these instructions fully before installation Before Use During Use Dispose of all packaging carefully and responsibly. This appliance is not intended for use by persons (including children) with reduced physical, sensory The appliance is designed for indoor use only and or mental capabilities, or lack of experience and must be protected from rain, moisture and extreme knowledge, unless they have been given supervision... -
Page 5: Safety Precaution
Safety Information Important – Please read these instructions fully before installation Safety Precautions Locations Do not locate the unit in places near heating devices, high temperature (40C or higher), high humidity user to the presence of uninsulated “dangerous (90% or higher), dirty places and avoid direct voltage”... -
Page 6: Warning
Warning Important – Please read these instructions fully before using Disc handling Copyrights Do not touch the playback side of the disc. This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual Do not attach paper or tape to disc. property rights. -
Page 7: Functions & Controls
If you have damaged or missing parts, Functions & Controls call the Customer Helpline: 0870 600 3030 Please familiarize yourself with the parts and accessories listed below Accessories included Sub woofer front Panel Sub woofer rear Panel 6-CH INPUT AUX INPUT INPUT VOL+ VIRTUAL MODE... - Page 8 Functions & Controls DVD control panel DVD rear panel FRONT PANEL REAR PANEL 21. Disc tray 27. SCART output 22. LED Display 28. 2 CH Stereo outputs 23. OPEN/CLOSE button 29. COAXIAL (Digital Audio) output 24. PLAY/PAUSE button 30. COMPOSITE output 25.
-
Page 9: Remote Battery Installation
Functions & Controls Remote control 53. ZOOM button 54. A-B (repeat) button 55. OSD button GOTO 56. SKIP buttons 57. Fast search buttons 58. N/P button (NTSC/PAL) 59. Direction buttons 60. PLAY/PAUSE button 61. VOL + button 62. MUTE button 63. -
Page 10: Installation
Installation Audio connections NOTE: before you make any connections, ensure the DVD player, Sub woofer and any Rear of Sub woofer TV / Monitor you wish to connect to is switched OFF. 6-CH INPUT AUX INPUT (optional) Stereo Input This unit comes supplied with 5.1 audio cables. -
Page 11: Other Connections
Installation Other connections On the rear of the DVD player there are two other outputs. This is a digital output capable of sending the 5.1 signal to an amplifier with a built-in 5.1 decoder 2Ch stereo output: This can be used to send a stereo audio signal to an external amplifier. -
Page 12: Electrical Connection
Installation Electrical connection Plug replacement (UK & Ireland only) Should you need to replace the plug; the wires in Any electrical work that is required to the power cable are coloured in the following way: install this appliance MUST be carried out Blue –... -
Page 13: User Instructions
User Instructions Getting started Basic operation Follow the below steps to get the system up RESUME: The resume function alows you to stop and running. playback of a DVD and resume later. 1. Ensure you have correctly connected all the During playback, pressing the STOP button once wiring and cables. - Page 14 User Instructions Basic operation Basic operation NOTE: This function may not work during the NOTE: Some discs may not allow repeat “Warning” section of a DVD. functions. OSD: Press the OSD button to show various information about the currently playing disc, like REPEAT A-B: This function allows you to set a 1.
-
Page 15: Speaker Level Setup
User Instructions Basic operation Speaker level setup You can press the AUDIO button to cycle through 1. Press the MUTE button, the audio will cease. the available options 2. Press the MUTE button again to resume. SUBTITLES: Many DVD discs contain subtitle Once setup the Home theatre system will more tracks to aid in various ways. -
Page 16: Advanced Operation
Advanced Operation DVD Program menu To program a play order for a DVD or CD Program disc please follow the below procedures. Play Play 1. Press the PROG button, the DVD program menu will appear. Clear program Clear program chapter. 3. -
Page 17: Jpeg Picture Disc
Advanced Operation CD Program menu 5. Highlight the track you wish to play first and press the ENTER button to begin playback in the order you specified. 6. To clear the program settings, navigate to EDIT MODE and activate with the ENTER button. -
Page 18: The Setup Menu
The Setup Menu Language setup menu NOTE: Use the navigation buttons to scroll up and down, left to right and press the ENTER button to select. Press the SETUP button to activate the menu. LANGUAGE: This sets the On Screen Display language. German. -
Page 19: Video Setup Menu
The Setup Menu Video setup menu VIDEO OUT This option designates the video output, depending on what connection you use to connect the DVD player to your TV/Monitor. RESUME This option can enable or disable the resume function, explained on page 10. Audio setup menu AUDIO OUTPUT MODE Choose between Stereo or 5.1 audio output... -
Page 20: Audio Setup Menu
The Setup Menu Audio setup menu CENTRE DELAY 1.7m. M denotes the distance in metres from the front speakers. SURR. DELAY M denotes the distance in metres from the front speakers. DIGITAL OUTPUT Sets the digital output signal for the Coaxial digital output (29). -
Page 21: Care And Maintenance
Care & Maintenance Important: Always unplug the appliance from the power socket during cleaning and maintenance. Never use any sharp instruments or abrasive substances, soap, household cleaner, detergent or wax polish for cleaning. Clean the external surfaces with a damp soft cloth only. Never use abrasive products or solvents as it may damage the appliance. -
Page 22: Disposal Information
DVD player Power 230-240V ~ 50Hz Power Consumption 1W (standby), 10W (maximum) Video Output Composite (1.0V p-p / 75 Ohms) S-Video (Luminance Signal: 1.0 V p-p /75 Ohms) (Chrominance Signal: 0.286 V p-p /75 Ohms) Audio Output Analogue audio output 2V RMS MAX 48KHz sampling: 20Hz-20KHz+0.5/-1.0dB 48KHz sampling: 20Hz-20KHz+0.5/-1.0dB... -
Page 23: Guarantee
Guarantee PRODUCT GUARANTEE This product is guaranteed against manufacturing defects for a period of Year This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to faulty materials or workmanship will either be replaced, refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit.
