Summary of Contents for ITOX CT334exa
- Page 1 Auto Cutter CT334exa Operation Guide Before using the CT334exa, read this guide carefully for safe and proper use. Manufactured by: Itox Supply Co., Ltd. World Wide Supplier: BN Technology Corporation...
-
Page 2: Table Of Contents
Introduction CT334exa Thank you for purchasing the CT334exa. This guide provides information about the proper use and pre- cautions for the CT334exa. Before using the CT334exa, read this guide carefully. This guide should be so kept that you can refer to it as needed. -
Page 3: Precautions For Setup And Use
Power must come from a wall outlet with a solid stand. ground securely established. The CT334exa must not be placed near a TV set, The CT334exa must not be set up in a dusty radio, or any other equipment that produces location. -
Page 4: Components
2. Components CT334exa 2. Components Paper Supply Unit Cover Side Cover (Right) Rear Cover Top Cover Paper Supply Unit Card Receiver Operation Panel Side Cover (Left) Margin Receiver Handle Decompression Lever Top Cover Side Cover (Right) Splitter Unit Pickup Roller... -
Page 5: Before Using The Ct334Exa
3. Before Using the CT330exa The product includes the following articles. Article Description CT334exa Main Unit CT334exa Paper Supply Unit Contained in the inner box CT334exa Margin Receiver Incorporated into the main unit CT334exa business card Receiver Contained inside the margin... -
Page 6: Producing Printed Output (Prescribed Imposition)
4. Producing Printed Output CT334exa 4. Producing Printed Output 4-1 The CT334exa is designed to use A4-sized, short-grained paper (297 mm x 210 mm). 4-2 The impositions prescribed for your CT334exa are shown below (magnified figures, see Page 18~20). 51 x 85 mm... - Page 7 Curling or wavy paper is not cut as intended. Flatten the paper as much as possible before it is cut. If paper is excessively curling or wavy, the CT334exa cannot feed or cut the paper properly. This causes skewed paper feeds, inaccurate cutting, and/or paper jams due to a feed error.
-
Page 8: Setting Up The Ct334Exa And Mounting The Components
5. Setting Up the CT334exa and Mounting the Components CT334exa 5-1 Setting up the CT334exa The CT334exa should be placed on a solid, stable stand that adequately supports the weight of the unit. In addition, the unit must be horizontal. Caution When you lift the CT334exa, place your hands under the unit to securely hold it. - Page 9 5-4 Static electricity (1) Every sheet of paper produces static electricity when it is being fed inside the CT334exa. If a ground is not properly established, static electricity has nowhere to go and steadily accumulates inside the unit. This may cause a malfunction of the electric system of the CT334exa.
-
Page 10: Operating The Ct334Exa
6. Operating CT334exa CT334exa 6-1 Turning on the power. Turn on the power. Then, ensure that the operation panel is lit. 6-2 Setting the paper (1) Open the paper supply unit cover. (2) Set paper into the paper supply unit. - Page 11 6. Operating CT334exa CT334exa If a paper jam occurs, the CT334exa immediately stops and the STOP button LED comes on in red. In this case, open the top cover and remove the jammed paper and cut margins. Then, properly place the paper into the paper supply unit, and press the START button to start the CT334exa again.
- Page 12 6-7 Turning off the power When you are finished with the cutting, turn off the power. * If you will not use the CT334exa for a long period of time, disconnect the plug from the outlet. How to Change the Set Values -------------------------------------------------------------------------------------...
- Page 13 6. Operating CT334exa CT334exa (3) When a desired value is reached, release the Settings button. This brings the indication back to the sheet count. *The cutting interval (51, 54, 55 mm) is factory set. ■ Resetting the count of sheets To clear the count, press the Counter Reset button.
- Page 14 Case 1 Paper is not fed from the paper supply unit because it is curling excessively at the edges or curling downward. Uncurl the paper and reset it. Then, restart the CT334exa. Case 2 Paper stops at the primary feed roller.
- Page 15 (product) from the slitter ejection. * After clearing the paper, properly replace the card receiver. Warning Do not touch the blades. Your CT334exa is equipped with two blades: the cutter and slitter blades. They are both extremely sharp and dangerous.
-
Page 16: Maintaining And Repairing The Ct334Exa
However, if they are used to cut solid objects, such as metal and ceramic, they may become nicked. Although the CT334exa is designed not to easily allow substances other than paper to enter the blade portions, exercise added care to... - Page 17 8. If the CT334exa is out of order, see Qs and As on Page 16 of this guide to identify the cause. 9. If the CT334exa is out of order, contact your distributor.
-
Page 18: Troubleshooting (Qs & As)
The pickup roller is excessively worn so that it cannot pick up paper. (See Page 14 to replace the roller.) If none of the possible causes above apply and the paper is not still fed, then your CT334exa is out of order. - Page 19 Turn off the power. Then wait five seconds after the lamps on the operation panel go out and turn the power on again to reset the microcontroller. The voltage dropped momentarily. Many appliances are connected to the outlet. If the microcontroller is reset and the problem is not still solved, then your CT334exa is out of order.
-
Page 20: Cutting Layout
9. Cutting Layout CT334exa 51 x 85 Cutting Layout... - Page 21 9. Cutting Layout CT334exa 54 X 85 Cutting Layout...
- Page 22 9. Cutting Layout CT334exa 55 X 85 Cutting Layout...
