Analog EDID
______________________________________________________________________
______________________________________________________________________
EDID Version # 1, Revision # 3

DDCTest For: ViewSonic VG1930wm

______________________________________________________________________
______________________________________________________________________
EDID Block 0, Bytes 0-127
128 BYTES OF EDID CODE:
0 1 2
________________________________________
0 | 00 FF FF FF FF FF FF 00 5A 63
10 | 1E 9D 01 01 01 01 01 10 01 03
20 | 0E 29 1A 78 2E E5 B5 A3 55 49
30 | 99 27 13 50 54 BF EF 80 95 00
40 | 95 0F 81 80 81 40 71 4F 01 01
50 | 01 01 01 01 9A 29 A0 D0 51 84
60 | 22 30 50 98 36 00 9A 00 11 00
70 | 00 1C 00 00 00 FF 00 51 43 36
80 | 30 36 30 31 30 30 30 30 31 0A
90 | 00 00 00 FD 00 32 4B 1E 52 0E
100 | 00 0A 20 20 20 20 20 20 00 00
110 | 00 FC 00 56 47 31 39 33 30 77
120 | 6D 0A 20 20 20 20 00 DD
(08-09) ID Manufacturer Name ________________ = VSC
(11-10) Product ID Code _____________________ = 9D1E
(12-15) Last 5 Digits of Serial Number ______ = Not Used
(16) Week of Manufacture _________________ = 01
(17) Year of Manufacture _________________ = 2006
(10-17) Complete Serial Number ______________ = See Descriptor Block
(18) EDID Version Number _________________ = 1
(19) EDID Revision Number ________________ = 3
(20) VIDEO INPUT DEFINITION:
Analog Signal
0.700, 0.300 (1.000 Vp-p)
Separate Syncs, Composite Sync, Sync on Green
(21) Maximum Horizontal Image Size ________________
(22) Maximum Vertical Image Size __________________
ViewSonic Corporation
Time: 15:51:56
Date: Mon Oct 23, 2006
VIEWSONIC CORPORATION
3 4 5 6 7 8 9
22
Confidential - Do Not Copy
= 410 mm
= 260 mm
VG1930wm-3
