Summary of Contents for Vivid HDSW0301M
- Page 1 U S E R M A N U A L 3x1 HDMI Switcher Model No：HDSW0301M Enjoy the vivid world !
- Page 2 INTRODUCTION Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of HDMI converters. switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient ,more comfortable, more productive and more cost-efficient.
- Page 3 The accessories with the machines lists as picture： 1、5V Power Adaptor 2、Remote 3、one pc of Manual Power Adaptor Remote Physical Connection Showing Picture： Figure 1.0 Front Panel Showing Picture Power： Power Led Status Light Source Selection ：Input Signal Switch Button IR：IR Receiver...
- Page 4 Output： HDMI output led status light Input 1- Input 3: HDMI input led status light Figure 1.1 the rear and side board showing picture Input 1- Input 3: HDMI input interface Output : HDMI output interface +DC 5V： 5V DC-DC Power Interface Operating and Connecting：...
- Page 5 SPECIFICATIONS: HDSW0301M HDMI resolution ………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i Support video color format …………………………..…………….24bit/deep color 30bit,36bit Support audio format……………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD Max bandwidth……………………………………………………………………………250MHz Max baud rate…………………….………………….……………………………………7.5Gbps Input/Output TMDS signal ………….…………………………..………...0.5~1.5Volts p-p(TTL) Input/Output DDC signal ……………………………………………..………… 5Volts p-p (TTL) Input cable distance..…... ……………………….……≤15m AWG26 HDMI standard cable Output cable distance…………………………….…...≤25m AWG26 HDMI standard cable...
- Page 6 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
- Page 7 Before power on, pls check the connection line carefully. And make sure that all interfaces are normally connected. The common trouble shooting way shows below: Trouble Serial NO Cause and Ways to deal with Description 1 、 Check if the power adaptor head is truly and Non-Power- correctly inserted the power socket.
