  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Infor- mation contained herein is for reference only and does not constitute a commitment on the part of the man- ufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be dam- aged.
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifi- Warning cations, consult your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the com- puter. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshoot- ing, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 15: Table Of Contents

    Preface Contents Notice ................I System Map: Right View ........1-11 FCC Statement ...........II System Map: Bottom View ........1-12 Windows XP Start Menu & Control Panel .... 1-13 Instructions for Care and Operation ....IV Video Features ............1-14 Power Safety ............. VI Video Driver Controls ........
  • Page 16 Preface Audio “DJ” CD Player ...........2-14 Battery FAQ ............3-12 Adding a Printer .............2-16 Drivers & Utilities USB Printer ............2-16 Install Instructions: ..........2-16 What to Install ............4-1 Parallel Printer ............2-16 Module Driver Installation ........4-1 Service Packs ............4-3 Power Management Authorized Driver Message ........
  • Page 17 Preface Modem (WinXP) ..........4-13 Installed memory (Main Menu) ....... 5-7 LAN (WinXP) .............4-14 Advanced Menu ............5-8 Video (WinXP) ...........4-14 System Information (Advanced Menu) ....5-8 AP-Key Buttons (WinXP) ........4-14 I/O Device Configuration (Advanced Menu) ..5-9 TouchPad (WinXP) ..........4-14 Reset Configuration Data (Advanced Menu) ..
  • Page 18 Preface Modules PC Camera Audio Setup ........7-14 BisonCap ............. 7-16 Overview ..............7-1 ATA Mode Configuration ........7-18 The Wireless LAN & Bluetooth Modules ....7-2 ATA Mode Setup ..........7-19 Mini-PCI Wireless LAN Module ......7-3 RAID Mode Configuration ........7-22 IPN2220 (802.11g) Wireless LAN RAID Mode Setup ..........
  • Page 19 Preface DC-In Jack ...............A-2 ATI Video Driver Controls Serial Port ..............A-2 ATI Video Driver Installation ........C-1 Parallel Port .............A-2 ATI Mobility Radeon X800 Properties ....C-2 DVI-Out Port ............A-2 Display Devices ............C-4 PS/2 Port ..............A-3 Attaching Other Displays .........C-5 RJ-11 Phone Jack ............A-3 Display Modes ............C-6 RJ-45 LAN Jack ............A-3 Enabling TV Display ..........C-11...
  • Page 20 Preface Power ............... D-6 Environmental Spec ..........D-6 Physical Dimensions & Weight ......D-6 Optional ..............D-6 XVIII...

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 23: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the following oper- ating systems: •...

  • Page 24: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC adapter.

  • Page 25: System Map: Top View With Lcd Panel Open

    Quick Start Guide System Map: Top View with LCD Panel Open Optional Built-In PC Camera Wireless Device Operation Aboard LED Power & Aircraft Communication Indicators The use of any portable Speakers electronic transmission LED Status Indicators devices aboard aircraft usually prohibited.

  • Page 26: Led Indicators

    Quick Start Guide LED Indicators Table 1 - 2 - LED Power & Communication Indicators The two sets of LED indicators (LED Status Indica- Icon Color Description tors and LED Power & Communication Indicators) on the computer display helpful information about the Orange DC Power is Plugged In current status of the computer.

  • Page 27: Ap-Key Buttons

    Quick Start Guide AP-Key Buttons Function Keys & Numeric Keypad These buttons access the internet, e-mail or a user-de- The keyboard has an embedded numerical keypad for fined application with one quick button press. Make easy numeric data input (see Figure 1 - sure you install the driver to enable the AP-Key Button functions (refer to...
  • Page 28 Quick Start Guide Table 1 - 4 - Function Keys Figure 1 - 3 - Keyboard Keys Description Function Key Fn + F3 Mute Toggle Function Keys Fn + F4 Sleep Toggle Num Lk & Scr Lk Keys Fn + F5 Decrease Audio Volume Numeric Keypad Fn + F6...

  • Page 29: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front & Rear Views LCD Latches Audio "DJ" Player Controls Consumer Infrared Transceiver Audio "DJ" Player Speakers The built-in standalone audio CD player gives you direct hardware control for audio CDs (MP3 Vent/Fan Intake compatible) when the computer is shut down, but has a working power source.

  • Page 30: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 5 Left View S-Video-Out Jack 4 * USB 2.0 Ports 2 * Mini-IEEE 1394a Port Line-In Jack S/PDIF-Out Jack Microphone-In Jack 10-in-1 Card Reader Formats Headphone-Out Jack The card reader allows you to use the most popular digital storage card formats: 10-in-1 Card Reader PC Card Slot •...

  • Page 31: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 6 - Right View Primary Optical Device Drive Bay (for CD/DVD Device) Secondary Optical Device Drive Bay (for CD/DVD Device) Security Lock Slot Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives.

  • Page 32: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 7 - Bottom View Battery Vent/Fan Intake Memory (RAM) Cover The CPU is not a user Hard Disk Cover serviceable part. Sub Woofer Opening this compart- Video Card Cover ment, or accessing the CPU Cover CPU in any way, may violate your warranty.

  • Page 33: Windows Xp Start Menu & Control Panel

    Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 34: Video Features

    Quick Start Guide Video Features Video Driver Controls This computer features three different (NVIDIA NV41M, NVIDIA NV41GLM or ATI M28) PCI Express vid- eo card options (see “Video Card Options” on page D - 3). If you are unsure which video card your model fea- tures, then go to the BIOS and check “VGA Card:”...
  • Page 35 Quick Start Guide NVIDIA Display Properties ATI Display Properties Figure 1 - 9 - Display Properties Desktop Video Features 1 - 15...

  • Page 36: Display Devices & Options

    Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the DVI-Out port, a TV to the S- Video-Out jack.

  • Page 37: Power Management Features

    Quick Start Guide Power Management Features The Power Options control panel in Windows (see page 13) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Standby or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel as pictured in Figure 1 - 10).
  • Page 38 Concise User’s Guide 1 - 18...

  • Page 39: Storage Devices, Mail Program, Mouse, Audio & Printer

    Storage Devices, Mail Program, Mouse, Audio & Printer Chapter 2: Storage Devices, Mail Program, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and compo- nents of the computer: • The Hard Disk Drive •...

  • Page 40: Hard Disk Drive

    Storage Devices, Mail Program, Mouse, Audio & Printer Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk Power Safety can be taken out to accommodate other 2.5" hard disk drives with a height of 9.5 mm.

  • Page 41: Optical Device

    Storage Devices, Mail Program, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The ac- Sound Volume tual device will depend on the model you purchased (see “Storage Options” Adjustment on page D - 4).

  • Page 42: Handling Cds Or Dvds

    Storage Devices, Mail Program, Mouse, Audio & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/ CD Emergency Eject DVDs can be accessed.

  • Page 43: Dvd Regional Codes

    Storage Devices, Mail Program, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Geographical Location Region DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 44: 10-In-1 Card Reader

    Storage Devices, Mail Program, Mouse, Audio & Printer 10-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push Operating System the card into the slot and it will appear as a removable device. Installation Warning •...

  • Page 45: Pc Card Slot

    Storage Devices, Mail Program, Mouse, Audio & Printer PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC Card. Inserting and Removing PC Cards • Align the PC Card with the slot and push it in until it locks into place. •...

  • Page 46: Check Mail Program

    Storage Devices, Mail Program, Mouse, Audio & Printer Check Mail Program After you have installed the driver for the Check Mail program (see “What to Install” on page 4 - 1) you may then configure it to give notification when new mail is received. You must be online to receive this notification (note that this program only supports the POP3 protocol), and your default mail program does not need to be open.
  • Page 47 Storage Devices, Mail Program, Mouse, Audio & Printer Clicking on Check Mail will bring up the following options menu. Note Check with your Inter- net Service Provider, network administrator or Mail Service provid- er for details on what to put on these pages. Figure 2 - 7 You may then configure the options for your mail server, user name, and Check Mail...
  • Page 48 Storage Devices, Mail Program, Mouse, Audio & Printer Figure 2 - 8 Check Mail Enabled You may enable an audible warning for received mail by clicking on Set Mail Wave, and browsing to a .WAV sound file to use for mail notifica- tion.

  • Page 49: Touchpad And Buttons/Mouse

    Storage Devices, Mail Program, Mouse, Audio & Printer TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The TouchPad buttons Mouse Driver function in much the same way as a two-button mouse.

  • Page 50: Configuring The Infrared Settings For Fir

    Storage Devices, Mail Program, Mouse, Audio & Printer Configuring the Infrared Settings for FIR To configure your computer for Fast Infrared (FIR) communication follow these steps: Infrared Communication Click Start, point to Settings and click Control Panel (or just click Start > The infrared transceiv- Control Panel).

  • Page 51: Audio Features

    Storage Devices, Mail Program, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sounds and Sound Volume Audio Devices /Sounds and Multimedia Windows control panel (see Adjustment Figure 1 - 8 on page 1 - 13), or from the Sound Effect Manager icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration...

  • Page 52: Audio "Dj" Cd Player

    Storage Devices, Mail Program, Mouse, Audio & Printer Audio “DJ” CD Player The built-in standalone audio CD player gives you direct hardware control for Disk Eject Warning audio CDs/DVDs when the computer is shut down, but has a working power source.
  • Page 53 Storage Devices, Mail Program, Mouse, Audio & Printer TV Tuner Option If you have included the optional TV Tuner in your purchase con- figuration, you can use Audio "DJ" Power Button the supplied remote Previous Track control unit to control Next Track the Audio “DJ”.

  • Page 54: Adding A Printer

    Storage Devices, Mail Program, Mouse, Audio & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions Parallel Printer will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options.

  • Page 55: Power Management

    Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer uses the functions will vary ACPI power management system. Power management conserves power by slightly depending on controlling individual components of the computer (the monitor and hard disk your operating system.

  • Page 56: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC adapter or a battery pack. Power Button as Standby or Hibernate AC Adapter Button Use only the AC adapter that comes with your computer. The wrong type of If you are using a fully AC adapter will damage the computer and its components.

  • Page 57: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel. Shutdown Note that you should When the computer is on, you can use the power button as a Standby/Hiber- always shut your com- nate/Shutdown hot-key button when it is pressed for less than 4 seconds puter down by choos-...

  • Page 58: Power Schemes

    Power Management Power Schemes You can set your computer to conserve power through individual components Resuming Operation by means of Power Schemes. You can also adjust the settings for each scheme to set the monitor to turn off after a specified time, and the computer's The system can re- hard disk motor to turn off if the hard disk drive has not been accessed for a sume from Monitor or...
  • Page 59 Power Management Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 60: System Power Options

    Power Management System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - Figure 3 - 2 on page 3 -...

  • Page 61: Standby

    Power Management Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is System Resume made to idle at its slowest speed. All open applications are retained in memo- The system can resume ry.

  • Page 62: Configuring The Power Button

    Power Management Configuring the Power Button The power button may be set to send the computer in to either Standby or Hi- bernate mode (Figure 3 - 3). In Standby mode, the LED will flash green. In Hibernate mode the LED will be off. If you are in a power saving mode set to save power through individual components (e.g.

  • Page 63: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning New Battery When the battery is Always completely discharge, then fully charge, a new battery (see “Battery critically low, immedi- FAQ”...

  • Page 64: Recharging The Battery With The Ac Adapter

    Power Management Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery”...

  • Page 65: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 66: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Caution Don’t turn off the computer by yourself even when you see a message that in- Danger of explosion if dicates the battery is critically low, just let the computer use up all of the bat- battery is incorrectly...

  • Page 67: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utilities essential to the operation or improvement The Device Drivers & Utilities + User’s Manual of some of the computer’s subsystems. The system CD-ROM contains the drivers and utilities neces- takes advantage of some newer hardware compo- sary for the proper operation of the computer.
  • Page 68 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.

  • Page 69: Service Packs

    Drivers & Utilities Service Packs Check the warnings on the following pages regard- ing installation of the appropriate Service Pack for Windows 2000 with Service Pack 4 your Windows OS. If you are unsure of the Service Make sure that your Windows 2000 version in- Pack currently installed see below.
  • Page 70 Drivers & Utilities Windows XP Service Pack 1 Make sure you install Windows XP Service Pack 1(or a Windows XP version which includes Service Pack 1) before installing any drivers. Service Pack 1 includes support for USB 2.0. If you have upgraded the system by installing Service Pack 1 (i.e. your Windows XP version does not include Service Pack 1) then follow these instructions: 1.If you can see the My Computer icon on your desktop (if you cannot see the My Computer icon go to step 2) click on it once to select it, then right-click it to make the sub-menu appear and scroll down to Properties and...

  • Page 71: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message do this go to the Control Panel in the Windows OS and double-click the Add/Remove Programs If you receive a message telling you that the driver item. If you see the individual driver listed (if not you are installing is not authorized (Digital Signa- see below), uninstall it, following the on screen ture Not Found), just click Yes or Continue Any-...

  • Page 72: Driver Installation

    Drivers & Utilities Driver Installation Windows 2000 Insert the Device Drivers & Utilities + User’s Man- ual CD-ROM and the Notebook Driver Installa- tion application will run automatically. If you want to install the driver manually see “Manual Driver Installation” on page 4 - Check the driver installation order from Table 4 - 1, on page 4 - 7...
  • Page 73 Drivers & Utilities Windows 2000 Order Windows 2000 (SP4) Windows XP (SP1) Windows XP Order Chipset page 4 - 9 page 4 - 12 Chipset NVDIA - see page B - 1 page 4 - 13 Video Audio ATI - see page C - 1 Audio page 4 - 10...

  • Page 74: Manual Driver Installation

    Drivers & Utilities Manual Driver Installation If you wish to install the drivers manually, click the Exit button to quit the Notebook Driver Installation application, then follow the manual installation procedure for each driver. The manual installation proce- dure begins with instructions on how to browse to the executable file; “Click Start (menu) > Run ..”. Hard Disk Setup (RAID or ATA Modes) If you need to setup your hard disk(s) in RAID mode see “RAID Mode Configuration”...

  • Page 75: Windows 2000 Professional

    Drivers & Utilities Windows 2000 Professional Chipset (Win2000) This section covers driver and utility installation in- structions for Windows 2000 Professional. 1. Double-click CHIPSET from the Notebook Driver Installation menu . New Hardware Found Click Start (menu) > Run ... and navigate If you see the message “New Hardware Found”...

  • Page 76: Audio & Modem (Win2000)

    Drivers & Utilities Audio & Modem (Win2000) 1. Double-click AUDIO from the Notebook Driver Installation menu . Modem Country Selection Click Start (menu) > Run ... and navigate Be sure to check if the modem country selection is ap- (Browse..) to D:\Drivers\AUDIO\Setup.exe propriate for you (Control Panel >...

  • Page 77: Ap-Key Buttons (Win2000)

    Drivers & Utilities AP-Key Buttons (Win2000) Auto Mail Checker (Win2000) 1. Double-click AP-KEY from the Notebook 1. Double-click AUTOMAIL from the Notebook Driver Installation menu . Driver Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\AP-Key\SETUP.exe (Browse..) to D:\Drivers\AUTO- and click OK.

  • Page 78: Windows Xp

    Drivers & Utilities Windows XP This section covers driver and utility installation in- structions for Windows XP (Professional & Home). Windows XP Service Pack 1 New Hardware Found Make sure you install Windows XP Service Pack 1 If you see the message “New Hardware Found” (or a Windows XP version which includes Service (Found New Hardware Wizard) during the in- Pack 1) before installing any drivers.

  • Page 79: Audio (Winxp)

    Drivers & Utilities Audio (WinXP) Modem (WinXP) 1. Double-click AUDIO from the Notebook 1. Double-click MODEM from the Notebook Driver Installation menu . Driver Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\AUDIO\Setup.exe (Browse..) to D:\Driv- and click OK.

  • Page 80: Lan (Winxp)

    Drivers & Utilities LAN (WinXP) AP-Key Buttons (WinXP) 1. Double-click LAN from the Notebook Driver 1. Double-click AP-KEY from the Notebook Installation menu . Driver Installation menu . Click Start (menu) > Run ... and navigate Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\LAN\Setup.exe and (Browse..) to D:\Drivers\AP-Key\SETUP.exe click OK.

  • Page 81: Auto Mail Checker (Winxp)

    Drivers & Utilities Auto Mail Checker (WinXP) 1. Double-click AUTOMAIL from the Notebook Driver Installation menu . Click Start (menu) > Run ... and navigate (Browse..) to D:\Drivers\AUTO- MAIL\SETUP.EXE and click OK. 2. To continue click Next > Next > Finish. 3.

  • Page 82: Module Drivers

    Drivers & Utilities Module Drivers TV Tuner (WinXP & Win2000) See the following pages for the driver installation See the install procedure in “Installing the AverTV procedures for any modules included in your pur- Utility Software” on page 7 - “Installing chase option.

  • Page 83: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return Setup and restore the Configuration: The Setup utility Setup Defaults with If your computer has never been set up, or you are making important changes...

  • Page 84: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to con- POST Screen duct a POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. 2.CPU type If there is a problem that prevents the system from booting, it will display a 3.Memory status...

  • Page 85: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 86: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 is usually present for a...

  • Page 87: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When Setup menus you select a heading, a new screen appears. Scroll through the features listed shown in this section on each screen to make changes to Setup.

  • Page 88: Main Menu

    BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:11:05] System Date: [09/22/2004] <Tab>, <Shift Tab>, or <Enter> selects field. IDE 0 [CD-ROM] IDE 1 [None] Installed memory 256 MB...

  • Page 89: Ide 0/1 (Main Menu)

    BIOS Utilities IDE 0/1 (Main Menu) Pressing Enter under opens the sub-menu to show the configuration of the ei- ther a CD Device or HDD that on the computer’s IDE Channels 0 or 1. Use the Auto (Type:) setting to have the items configured automatically for you. Installed memory (Main Menu) This item contain information on the system memory, and is not user config- urable.

  • Page 90: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Power Boot Exit Item Specific Help Setup Warning Setting items on this menu to incorrect values may cause your system to malfunction. System Information I/O Device Configuration Reset Configuration Data: [No]...

  • Page 91: I/O Device Configuration (Advanced Menu)

    BIOS Utilities I/O Device Configuration (Advanced Menu) The sub-menus under this item include options to configure the Serial port A (Serial Mouse), Serial port B (Infrared) and Parallel (Printer) port. These can be left to the default settings, however you may wish to use certain devices that require settings to be adjusted accordingly.

  • Page 92: Power On Beep (Advanced Menu)

    BIOS Utilities Power On Beep (Advanced Menu) Use this menu to enable/disable the single beep sound at the end of the POST. This item is “Disabled” by default. Card Reader: (Advanced Menu) This option allows you to enable/disable support for the 10-in-1 Card Read- er.

  • Page 93: Security Menu

    BIOS Utilities Security Menu Figure 5 - 4 PhoenixBIOS Setup Utility Security Menu Main Advanced Security Security Boot Exit Item Specific Help Supervisor Password Is: Clear Set Supervisor Password [E E nter] Supervisor Password controls access to the Password on boot: [Disabled] setup utility.

  • Page 94: Password On Boot: (Security Menu)

    BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password (supervisor or user password) should be entered to boot the computer. If “Enabled” is selected, only users who enter a Password Warning correct password can boot the system (see the warning in the sidebar). The default setting is “Disabled”.

  • Page 95: Boot Menu

    BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 5 Main Advanced Security Exit Boot Boot Menu Item Specific Help Boot priority order: USB FDC: Y-E DATA USB-FDU-(USB) Keys used to view or IDE 0: TOSHIBA DVD-ROM SD-C2612- configure devices: Up and Down arrows PCI SCSI: FT TX Ary 1...
  • Page 96 BIOS Utilities Boot devices usually are hard drives, floppy drives, and CD-ROMs. When you specify a device as a boot device on the Boot Menu, it requires the availability of an operating system on that device. Most home computers come with an operating system already installed on “Drive C:”. If you wish to boot from a CD-ROM you will need to add it to the boot order.

  • Page 97: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...
  • Page 98 BIOS Utilities 5 - 16...

  • Page 99: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or prob- Warranty Warning lems you can contact your service representative for further help. Before you Please check with your begin you will need: service representative...

  • Page 100: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 101: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. Warranty Warning Turn the computer off, and turn it over. Please check with your Loosen screws service representative before undertaking any Release the battery, and lift the battery...

  • Page 102: Upgrading The Hard Disk Drive(S)

    Upgrading The Computer Upgrading the Hard Disk Drive(s) The hard disk drive(s) can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h) (see “Storage Options” on page D - HDD System Warning 4).
  • Page 103 Upgrading The Computer Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and remove screws Remove the bay cover Figure 6 - 2 HDD Bay Cover Removal Upgrading the Hard Disk Drive(s) 6 - 5...
  • Page 104 Upgrading The Computer Release the cable and lift the hard disk assembly up out off the computer. Remove screws in order to separate the bracket from the hard disk(s), and disconnect the cable Reverse the process to install a new hard disk(s). Figure 6 - 3 HDD Assembly Removal...

  • Page 105: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has four memory sockets for 200 pin Small Outline Dual In- line (SO-DIMM) - DDR-II (DDR2) - type memory modules (see “Memory” Contact Warning on page D - 2). The total memory size is automatically detected by the POST Be careful not to touch routine once you turn on your computer.
  • Page 106 Upgrading The Computer Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the arrows in Figure 6 - Figure 6 - 5 RAM Module Removal The RAM module will pop-up, and you can remove it. Pull the latches to release the second module if necessary.

  • Page 107: Upgrading The Optical (Cd/Dvd) Device(S)

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device(s) Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and remove screws , and remove the bay cover. Remove screw and use the screwdriver to push the optical device(s) out of the computer at point Figure 6 - 6 Removing the CD/...

  • Page 108: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a faster/new one you will need to contact your customer service representa- Warranty tive. We recommend that you do not do this yourself, since if it is done incor- The CPU is not a user rectly you may damage the processor or mainboard.

  • Page 109: Overview

    Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the config- uration purchased. If you are unsure please contact your service representa- tive.

  • Page 110: The Wireless Lan & Bluetooth Modules

    Modules The Wireless LAN & Bluetooth Modules If your purchase option includes the any of the Wireless LAN modules and/or Wireless Device Bluetooth and Wireless LAN combination module, follow the information on Operation Aboard the following pages for instructions on installing the driver. Pay careful atten- Aircraft tion to the warnings concerning the use of wireless modules aboard aircraft, The use of any porta-...

  • Page 111: Mini-Pci Wireless Lan Module

    Modules Mini-PCI Wireless LAN Module Before installing the Wireless LAN driver, make sure that the optional Wireless Device WLAN module is on (the LED will be green). Operation Aboard Aircraft Use the WLAN module key combination Fn + F11 to toggle power to the The use of any porta- WLAN module.

  • Page 112: Ipn2220 (802.11G) Wireless Lan Driver Installation

    Modules IPN2220 (802.11g) Wireless LAN Driver Installation (WinXP & Win2000) 1. Insert the Wireless LAN CD-ROM into the CD/DVD drive. Network Connection 2. Click Start (menu) > Run ... Windows 3. Navigate (Browse..) to D:\setup.exe and click OK. Network Connec- 4.

  • Page 113: Mp54G3 (802.11G) Wlan Module Driver Installation

    Modules MP54G3 (802.11g) WLAN Module Driver Installation (WinXP & Win2000) 1. Insert the WLAN CD-ROM into the CD/DVD drive. Network Connection 2. The program will run automatically. 3. Click Install Software and click Next. Windows 4. Click the button to accept the license agreement, then click Next. Network Connec- tions control panel to...

  • Page 114: Bluetooth/Wlan Combo Module

    Modules Bluetooth/WLAN Combo Module Before installing the Bluetooth/WLAN driver, make sure that the optional Wireless Device Bluetooth module/WLAN is on. Use the Bluetooth module key combina- Operation Aboard tion Fn + F12 to toggle power to the Bluetooth module. Use the WLAN Aircraft module key combination Fn + F11 to toggle power to the WLAN module The use of any porta-...

  • Page 115: Combo Module Bluetooth Driver Installation (Winxp)

    Modules Combo Module Bluetooth Driver Installation (WinXP) 1. Insert the Bluetooth/WLAN Combo CD-ROM into the CD/DVD drive. 2. The program will run automatically. 3. Click Install Bluetooth Driver and click Next. 4. Click the button to accept the license agreement, then click Next. 5.

  • Page 116: Combo Module Wlan Driver Installation (Winxp & Win2000)

    Modules Combo Module WLAN Driver Installation (WinXP & Win2000) 1. Insert the Bluetooth/WLAN Combo CD-ROM into the CD/DVD drive. 2. The program will run automatically. Network Connection 3. Click Install WLAN Driver and click Next. 4. Click the button to accept the license agreement, then click Next. Windows 5.

  • Page 117: Tv Tuner

    Modules TV Tuner The optional TV Tuner allows you to watch TV, play music CDs, video con- ference and capture still images and video on your PC. TV Tuner Remote You may have one of two possible optional TV Tuner modules supplied with The remote control unit provided with the op- your computer, depending on your purchase configuration.

  • Page 118: Installing The Avertv Utility Software

    Modules Installing the AverTV Utility Software (Win2000) 1. Insert the AverTV Utility CD-ROM into the CD/DVD drive. PC Camera & TV 2. Click TV Utility Software. Tuner 3. Click Yes > Next > Next (click Continue Anyway/Yes if asked to con- If you have the optional tinue at any time).

  • Page 119: Installing The Intervideo Windvd 4 Software

    Modules Installing the AverTV Utility Software (WinXP) 1. Insert the AverTV Utility CD-ROM into the CD/DVD drive. 2. Click TV Utility Software. 3. Click Yes > Next > Next (click Continue Anyway/Yes if asked to con- tinue at any time). 4.

  • Page 120: Installing The Lifeview Driver

    Modules Installing the LifeView Driver (WinXP & Win2000) 1. Insert the LifeView CD-ROM into the CD/DVD drive. PC Camera & TV 2. Click LifeView Driver. Tuner 3. Click Next > Finish. If you have the optional 4. Click Yes to restart the computer. (WinXP Only). TV Tuner included in your purchase, make Installing the LifeView TVR Software...

  • Page 121: Pc Camera

    Modules PC Camera If your purchase includes the optional PC Camera you will need to install the PC Camera & TV device driver for it as indicated on the following pages (make sure you install Tuner the drivers in the order indicated in Table 4 - 1, on page 4 - If you have the optional TV Tuner included in...

  • Page 122: Pc Camera Audio Setup

    Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Taking Still Pictures (WinXP) You may take still pic- tures in the Windows Go to the Start menu and point to Settings (or click Control Panel) and XP operating system click Control Panel, then double-click the Sounds &...
  • Page 123 Modules Figure 7 - 5 Audio Setup (Windows XP) PC Camera 7 - 15...

  • Page 124: Bisoncap

    Modules BisonCap BisonCap is a video viewer useful for general purpose video viewing and test- ing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > You may pre-allocate Bs350u2 menu (it is recommended that you set the capture file before the the file size for the cap- capture process - see Set Capture File below).
  • Page 125 Modules Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the option from the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select “Video Capture Filter...”. Click either 50Hz or 60Hz under Frequency in Property Page (tab).

  • Page 126: Ata Mode Configuration

    Modules ATA Mode Configuration If you wish to configure your hard disk(s) in ATA mode, then follow the in- structions on the next page. You will need an external floppy drive attached when installing the driver when setting up Windows. Jumper Settings for Two Parallel ATA Hard Disks If you are using Parallel ATA (PATA) hard disk drives.

  • Page 127: Ata Mode Setup

    Modules ATA Mode Setup Prepare a formatted blank 3.5" 1.44MB floppy diskette, and an external USB floppy disk drive. Create an ATA Driver Diskette by using an operable computer to copy the Drivers\RAID\ATA folder from the Device Drivers & Utilities + User’s Manual CD-ROM (Navigate/Browse..
  • Page 128 Modules Select the CD-ROM/DVD-ROM as the first device in the "Boot priority order" by pressing the <Shift> and <+> keys to move the CD-ROM/DVD- ROM to the top of the order. Figure 7 - 8 PhoenixBIOS Setup Utility BIOS Boot Menu Main Advanced Security...
  • Page 129 Modules 13. Select the appropriate controller for your Windows 2000 or Windows XP operating system, and press Enter (see below). Figure 7 - 9 Serial ATA WinXP Promise SATA378 (tm) Controller Controller OS Win2000 Promise SATA378(tm) Controller Select 14. The system will now read from the floppy disk drive and then return to the Windows Setup menu.

  • Page 130: Raid Mode Configuration

    Modules RAID Mode Configuration If you wish to configure your hard disk(s) in RAID (Redundant Array of In- dependent Disks) mode, then follow the instructions on the following pages. This will allow you to use your hard disks in combination with Striping (RAID 0) or Mirroring (RAID 1) for fault tolerance and performance.

  • Page 131: Raid Mode Setup

    Modules RAID Mode Setup Install two identical hard disk drives (see the note below for Parallel ATA Hard Disks). Jumper Settings for Two Parallel ATA Hard Disks If you are using Parallel ATA (PATA) hard disk drives. then set the jumper on the Slave hard disk to the Cable Select option in order for the system to recognize the disks (see your hard disk manual or the information printed on the hard disk itself for details on the jumper settings).
  • Page 132 Modules Prepare a formatted blank 3.5" 1.44MB floppy diskette, and an external USB floppy disk drive. Create a RAID Driver Diskette by using an operable computer to copy the Drivers\RAID\FASTTRAK folder from the Device Drivers & Utilities + User’s Manual CD-ROM (Navigate/Browse.. to D:Drivers\RAID\FASTTRAK) to the blank floppy diskette.
  • Page 133 Modules Select the CD-ROM/DVD-ROM as the first device in the "Boot priority order" by pressing the <Shift> and <+> keys to move the CD-ROM/DVD- ROM to the top of the order. Figure 7 - 12 PhoenixBIOS Setup Utility Main Advanced Security Exit Boot...
  • Page 134 Modules 11. If a disk array is defined the screen will appear as follows (press the Ctrl + F key combination to enter the utility). Figure 7 - 14 FastTrak 378(tm) BIOS Version 1.00.1.35 FastTrak BIOS (C) 2002-2005 Promise Technology, Inc. All rights reserved. (Array Defined) MODE SIZE...
  • Page 135 Modules 13. Press <4> to enter the Delete Array Menu in order to delete existing arrays (press <Esc> to return to the Main Menu). 14. Press <1> to enter the Auto Setup Menu (recommended) as this is the easiest and fastest way to setup your first array. Use <Spacebar> to cycle through the “Optimize Array for”...
  • Page 136 Modules FastBuild (tm) Utility 2.01 (c) 2002-2005 Promise Technology, Inc. [ Define Array Menu ] Figure 7 - 17 Array 1 FastBuild Utility Array 2 ---- ---- ---- ---- Array 3 ---- ---- ---- ---- Array 4 ---- ---- ---- ---- (Define Array Menu) [ Keys Available ]...
  • Page 137 Modules Gigabyte Boundary The Gigabyte Boundary feature is designed for fault tolerant arrays RAID 1 (Mirror) in which a drive has failed, and the user cannot replace the drive with a drive of the same capacity or larger. This feature permits the installation of a replacement drive that is slightly smaller than any remaining working drive (e.g.
  • Page 138 Modules 19. Press a key when you see the message "Press any key to start up from the CD/Press any key to boot from CD". 20. Press the F6 key when you see the message “Press F6 if you need to install third party SCSI or RAID driver”.

  • Page 139: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 140: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer appears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 141: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g.

  • Page 142: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 143: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 144 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 145: Power

    Troubleshooting Power Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is but it doesn’t work. present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 146 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If hot. this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...

  • Page 147: Display

    Troubleshooting Display Problem Possible Cause - Solution Nothing appears The system is in a power saving mode. Toggle the sleep/resume key combination, Fn + F4 screen. (see “Sleep Button” on page 3 - The screen controls need to be adjusted. Toggle the screen control key combinations Fn + F8/F9 (see “Opening the LCD”...

  • Page 148: Boot Password

    Troubleshooting Boot Password Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact password. your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.

  • Page 149: Audio & Cd Device

    Troubleshooting Audio & CD Device Problem Possible Cause - Solution The sound cannot be The volume might be set too low. Check the volume control in the Volume Control Panel heard or the volume is in the Windows taskbar, or use the key combination Fn + F5 and F6 (see “Audio very low.

  • Page 150: Keyboard

    Troubleshooting Keyboard Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON (see “LED Indicators” on page 1 - appear when typing. Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.

  • Page 151: Operation

    Troubleshooting Operation Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC adapter, press a key on the screen goes dark. the keyboard, or press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.

  • Page 152: Modules

    Troubleshooting Modules Problem Possible Cause - Solution Wireless LAN/ The modules are off. Check the LED indicator to see if the modules are on or off Bluetooth/ modules (see “LED Indicators” on page 1 - 6). If the LED indicator is off, then press the cannot be detected.

  • Page 153: Interface (Ports & Jacks) Overview

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your com- puter to communicate with external devices, connect to the internet etc. A - 1...

  • Page 154: Ports And Jacks

    Interface (Ports & Jacks) Ports and Jacks Item Description Built-In Microphone The built-in microphone allows you to record on your computer DC-In Jack Plug the supplied AC adapter into this jack to power your computer. Serial Port Connect a serial type mouse to this port. Parallel Port Connect a parallel type printer to this port.

  • Page 155: Rj-45 Lan Jack

    Interface (Ports & Jacks) Item Description PS/2 Port Connect an external PS/2 type mouse or keyboard to this port. You can use a “Y” splitter if you want to attach both. RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection.

  • Page 156: Usb 2.0/1.1 Ports

    Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which comes with the device).

  • Page 157: Microphone-In Jack

    Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot.
  • Page 158 Interface (Ports & Jacks) A - 6...

  • Page 159: Nvidia Video Driver Controls

    NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Video Card Options NVIDIA Video Driver Installation This computer features three different (NVID- Make sure you install the drivers in the order indicated in Table 4 - 1, on IA NV41M, NVIDIA page 4 -...

  • Page 160: B - 2 Nvidia Display Properties

    NVIDIA Video Driver Controls NVIDIA Display Properties More advanced video configuration options are provided in the NVIDIA Dis- NVIDIA Taskbar Icon play Properties control panel tab. NVIDIA NV41M video cards will dis- play the title NVIDIA GeForce Go 6800 Properties, NVIDIA NV41GLM Click the NVIDIA icon video cards will display the title Quadro FX Go 1400 Properties: in the taskbar to bring up...

  • Page 161: Additional Properties

    NVIDIA Video Driver Controls Additional Properties The items listed in the Additional Properties window allow you to configure your display(s). If the items do not display you can either click the Additional Screenshots Properties button, or click the icon . All screenshots in this chapter are from the GeForce Go 6800 in...
  • Page 162 NVIDIA Video Driver Controls You may make changes to the Display Settings, Color Correction, Video Overlay, Resolutions, Refresh Rates and Screen Rotation by clicking the ap- propriate tab and adjusting the setting. Figure B - 2 Screen Examples Right-click on a control panel item to bring up a Help menu Help Menus (see sidebar).

  • Page 163: Nvidia Nview Desktop Manager

    NVIDIA Video Driver Controls NVIDIA nView Desktop Manager The nView Desktop Manager allows quick access to control panels for fea- tures such as Desktop Management, Profiles, Hot Keys etc. The Control panel nView Desktop may be accessed as follows. Manger from Additional Properties Click Start, point to Settings and click Control Panel (or just click Control Panel).

  • Page 164: Display Devices

    NVIDIA Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel dis- Display Wizard play or TV/HDTV as your display device. The following are the display op- tions: Use the Display Wiz- ard in the Desktop Management window The built-in LCD.

  • Page 165: Attaching Other Displays

    NVIDIA Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the DVI-Out Function Key Port at the rear of the computer. Combination Attach your external monitor to the DVI-Out Port (or TV/HDTV to the S- You can use the Fn + Video-Out jack), and turn it on.
  • Page 166 NVIDIA Video Driver Controls Select the display option from the Primary Display/ Secondary Display dropbox. If you have a TV and external monitor/flat panel display attached you will have a number of available options (see sidebar). Select and Apply nView Display Mode the appropriate option.

  • Page 167: Display Modes

    NVIDIA Video Driver Controls Display Modes Single Display Mode Display Wizard Only one of your displays is used. Use the Display Wiz- Clone Mode ard in the Desktop Management window Clone Mode simply shows an exact copy of the Primary display desktop on to quickly setup and the other display(s).

  • Page 168: Enabling Tv Display

    NVIDIA Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an S-Video cable from the TV to the S-Video-Out jack on the left side of the computer (see “System Map: Left View”...
  • Page 169 NVIDIA Video Driver Controls Set the TV format from the Select TV Format menu. The Advanced option (in Dualview mode) at the bottom of the Select TV Format menu allows you to select TV format by country if you are unsure of your TV format. Figure B - 7 TV Settings and Adjustments...
  • Page 170 NVIDIA Video Driver Controls B - 12...

  • Page 171: Ati Video Driver Controls

    ATI Video Driver Controls Appendix C: ATI Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Video Card Options ATI Video Driver Installation This computer features Make sure you install the drivers in the order indicated in Table 4 - 1, on three different (NVID- IA NV41M, NVIDIA...

  • Page 172: Ati Mobility Radeon X800 Properties

    ATI Video Driver Controls ATI Mobility Radeon X800 Properties More advanced video configuration options are provided in the ATI Mobility ATI Taskbar Icon Radeon X800 control panel tab: You can also access Open the Display Properties (see “Video Features” on page 1 - 14) con- ATI Mobility Radeon trol panel.
  • Page 173 ATI Video Driver Controls Figure C - 2 ATI Mobility Radeon X800 Properties Tabs Help Menus Right-click on almost any item in the tabs to bring up the “What’s This?” button. Click to Configure Theater Mode Help Menu Click “What’s (Not Supported with TV Tuner) This?”...

  • Page 174: Display Devices

    ATI Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel dis- play or TV/HDTV as your display device. The following are the display op- Theater Mode tions: Theater Mode can be enabled clicking The built-in LCD.

  • Page 175: Attaching Other Displays

    ATI Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the DVI-Out Function Key Port at the rear of the computer. Combination Attach your external monitor to the DVI-Out port (or TV/HDTV to the S- You can use the Fn + Video Out port), and turn it on.

  • Page 176: Display Modes

    ATI Video Driver Controls Display Modes Single Display Data Channel Primary & Clone Only one of your displays is used. Information Displays Click the “Use DCC In- Multiple - Clone Mode The Primary display in formation” button to an Extended Desktop Clone Mode simply shows an exact copy of the Primary display desktop on disable/enable DCC.

  • Page 177: Clone Mode

    ATI Video Driver Controls Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same con- tent. Use this feature to display the screen through a projector for a presenta- tion.

  • Page 178: Extended Desktop Mode

    ATI Video Driver Controls Extended Desktop Mode The system supports Extended Desktop in multiple display environments in WindowsXP, but this mode is NOT supported in Windows2000 . An Extend- ed Desktop creates a desktop spanning multiple displays and acts as a large workspace.
  • Page 179 ATI Video Driver Controls 10. In the example shown in Figure C - 6 the primary monitor is on the left, the other display is on the right. Help Click either the Display Further help is avail- pop-up menu, or click able through the icon for the appro-...
  • Page 180 ATI Video Driver Controls 12. One display will be set to 1 (Primary). The displays may be switched as long as one as set to Primary. Figure C - 7 Displays Tab In this picture the notebook (Extended Desktop LCD panel is the primary dis- Mode) play, and the desktop may be extended to any attached dis-...

  • Page 181: Enabling Tv Display

    ATI Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an S-Video cable from the TV to the S-Video-Out jack on the left side of the computer (see “System Map: Left View”...
  • Page 182 ATI Video Driver Controls C - 12...

  • Page 183: Specifications

    Specifications Appendix D: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly proces- sor types/speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release sched- ule.

  • Page 184: Processor Types

    Specifications Feature Specification Processor Types Intel® Pentium® 4 520/ 530/ 540/ 550/ 560 Processor with HT Technology LGA775 Package (775-pin) (90nm) 90 Nanometer Process Technology, 1024KB On-Die L2 Cache & 800MHz Front Side Bus - 2.8/ 3.0/ 3.2/ 3.4/ 3.6 GHz Core Logic Intel 915P + ICH6 Security...

  • Page 185: Lcd

    Specifications Feature Specification 17" WXGA (1440 * 900) / WSXGA+ (1680 * 1050) TFT LCD Video Card NVIDIA Options: ATI Option: Options NVIDIA NV41M High Performance Chip ATI M28 High Performance Chip 256MB DDR-I (DDR1) OR DDR-III (DDR3) 256MB DDR-III (DDR3) Video RAM On Board Video RAM On Board 256 bit Memory Interface 256 bit Memory Interface...

  • Page 186: Storage Options

    Specifications Feature Specification Storage Options One External USB 1.44Mb Floppy Disk Drive One Changeable Primary 2.5" 9.5mm (h) Hard Disk Drive One Changeable Secondary 2.5" 9.5mm (h) Hard Disk Drive Option) Supports Serial ATA HDD RAID 0, RAID 1, HDD Fault Tolerance System One Changeable Primary Optical Device Bay - 12.7 mm (h) for Optical CD/DVD Device Drive Options (see “Optional”...

  • Page 187: I/O Ports

    Specifications Feature Specification I/O Ports Four USB 2.0/1.1 Ports One S/PDIF Out Jack Two Mini-IEEE1394a Ports One RJ-11 Jack (Modem) One S-Video-Out Jack for TV & HDTV Output One RJ-45 Jack (Local Area Network) One Serial Port One DC-In Jack One Parallel Port (LPT1) Supporting ECP/EPP One Line-In Jack for Audio Input One Infrared Transceiver (IrDA 1.1/FIR/SIR/...

  • Page 188: Power Management

    Specifications Feature Specification Power Supports ACPI 2.0 Supports Resume from Alarm Management Supports Hibernate/Standby Modes Supports Resume from Modem Ring Supports Battery Low Sleep Power Full Range AC Adapter - AC-In 100~240V, 47~63Hz, DC Output 20V, 9A Easy Changeable 12-Cell Smart Lithium-Ion 6600mAH Main Battery Environmental Temperature Relative Humidity...

Table of Contents
