Summary of Contents for K40 RL360i
- Page 2 K40 Consult Don’t like to read manuals? Call our experienced K40 Consultants. We’ll explain the whole thing. 800.323.5608 K40 ELECTRONICS 600 Tollgate Rd., Suite A Elgin, IL 60123 www.K40.com...
-
Page 3: Table Of Contents
Table of Contents Wake-Up Sequence ....... . .4 Receiving Alerts ........5-6 Radar Alert Sequence . -
Page 4: Wake-Up Sequence
Wake-Up Sequence (using factory default settings) Your K40 RL360i / RL200i will be ready for use following this automatic wake-up sequence: 1. Start your vehicle – The K40 system is designed to turn on automatically every time your vehicle is started. -
Page 5: Receiving Alerts
Each band has its own distinctive tone. Laser Alert Sequence (only for K40 RL360i / RL200i systems that include the Laser Defuser g5) When the K40 RL360i / RL200i detects a laser signal: A voice announces, “Laser.” (This assumes the factory default •... -
Page 6: Laser Settings
Alerts from Non-Police Signals Your K40 RL360i / RL200i is sensitive enough to detect signals gen- erated by non-police equipment, such as automatic doors. To learn how to minimize these signals, please read about FILTER options (page 7), Quiet Ride function (page 8), and Mark to Mute (page 9). -
Page 7: Special Features / Functions
(i.e. signal sensitivity) CITY Press and release on the remote control to change the • setting at any time. The K40 RL360i / RL200i offers three levels of radar sensitivity settings to accommodate various driving situations. Settings Sensitivity Recommended Use 1. -
Page 8: Quiet Ride
Quiet Ride The Quiet Ride function will automatically silence all radar / laser alerts when traveling under a speed setting of your choice between 5 - 75 mph in 5 mph increments or 10-120 kph in 10 kph increments. Visual alerts are unaffected by Quiet Ride settings. The factory default setting for Quiet Ride is “Off.”... -
Page 9: Mark To Mute
Mark to Mute The Mark to Mute function allows you to mute any radar band / laser alert from a non-police source (i.e. an automatic door) in a specific GPS location. Using Mark to Mute Press and release to mute a specific radar band / laser alert.* •... -
Page 10: Mark To Alert
Mark to Alert The Mark to Alert function allows you to add specific GPS locations to your personal database, alerting you to any point of interest you choose (such as school zones, speed traps, or red light cameras). Press and release on the remote control when you want to •... -
Page 11: Customizable Settings
Speed Monitor setting, stop scrolling and voice will announce, “Exit.” When driving and the Speed Monitor speed is exceeded: The K40 RL360i / RL200i will emit a continuous “Bing Bong” tone • and the LED(s) will remain lit. - Page 12 Customizable Settings Default Setting Menu Options (voice confirmations) Description (in sequential order) RL360i RL200i System System 1 Voice Type “Voice Female” “Voice Female” Choose male or female voice for audio alerts. 2 Audible Voice ”Voice On“ “Voice On” For all initial audio alerts: “Voice On”...
- Page 13 Customizable Settings Default Setting Menu Options (voice confirmations) Description (in sequential order) RL360i RL200i System System 11 Front Ka-Band ”Ka-Band On“ “Front Ka-Band Enables the detection of Ka-Band On” radar from front receiver. “Off” disables this detection . 12 Rear Radar “Rear Radar On”...
-
Page 14: Remote Control
Remote Control POWER MENU Turn the K40 RL360i / Press to enter customizable RL200i system on or off. menu settings. (pages 11-13) Adjust LED brightness. (page 7) Press to increase vol- ume. Use to scroll and change menu options. (pages 8 & 11) -
Page 15: Remote Control
OPEN To Use Supplied Visor Clip: To Change Remote Battery: Insert by placing the clip in the Unlock and remove battery back of the remote control as door by turning the cover counterclockwise as shown. shown. Press firmly until it clicks. Insert battery with + symbol side facing the + symbol side of the battery door cover. -
Page 16: Warranty / Guarantees
30 days for a full product credit. Guaranteed from theft If your K40 RL360i / RL200i is ever stolen, we’ll replace the stolen product.** One-year warranty K40 offers a one-year “repair or replace” warranty if your RL360i / RL200i fails to work properly. - Page 17 In addition, any changes or modifications to this product, which are not expressly approved by K40 Electronics in writing, could void the user’s authority to operate this product. Learn more at K40.com...
- Page 18 Our Promise TO EXCEED... Customer expectations through the pride and dedication of our strong team of caring and talented employees by being the “Model of Excellence” in the entire industry on every level — from innovative product design and flawless manufacturing to knowledgeable sales and total customer service.
- Page 19 Letter From the President Thank you very much for your recent purchase of the most progressive radar and laser solution available on the market today. Our ultimate goal is that you, our valued customer, is empowered with peace of mind and unparalleled radar protection. Because we care about you, we’re still the only company that stands behind every product with a comprehensive speeding ticket guarantee.
