Instructions for use

KVA 2500/1
Bauknecht AG, Industriestrasse 36, 5600 Lenzburg, www.bauknecht.ch
Verkauf
Telefon 0848 801 002
Kundendienst
Telefon 0848 801 001
Ersatzteile
Telefon 0848 801 005
Fax 0848 801 017
Fax 0848 801 003
Fax 0848 801 004
verkauf@bauknecht.ch
service@bauknecht.ch
ersatzteilverkauf@bauknecht.ch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KVA 2500/1 and is the answer not in the manual?

Questions and answers

Related Manuals for Bauknecht KVA 2500/1

Summary of Contents for Bauknecht KVA 2500/1

  • Page 1: Instructions For Use

    Instructions for use KVA 2500/1 Bauknecht AG, Industriestrasse 36, 5600 Lenzburg, www.bauknecht.ch Verkauf Telefon 0848 801 002 Fax 0848 801 017 verkauf@bauknecht.ch Kundendienst Telefon 0848 801 001 Fax 0848 801 003 service@bauknecht.ch Ersatzteile Telefon 0848 801 005 Fax 0848 801 004...
  • Page 2 PRODUCT SHEET Refrigerator compartment Low temperature compartment Ice cube tray (inside the compartment) 1. Crisper drawer 10. Freezer compartment inner door 2. Shelves / Shelf area 3. Thermostat control knob/light 4. Upper door tray 5. Door trays 6. Bottle rack 7.
  • Page 3 Refrigerator compartment controls A.Light switch cam B.Thermostat control reference C.Thermostat knob D.Switch (if provided) E.Light bulb (max 15 W) Thermostat set to 1/MIN: minimum refrigeration. Thermostat set to 2-3/MED: medium refrigeration. Thermostat set to 7/MAX: maximum refrigeration. Thermostat set to no refrigeration, no light.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS BEFORE USING THE APPLIANCE PAGE SAFEGUARDING THE ENVIRONMENT PAGE PRECAUTIONS AND GENERAL HINTS PAGE HOW TO OPERATE THE REFRIGERATOR COMPARTMENT PAGE HOW TO OPERATE THE LOW TEMPERATURE COMPARTMENT PAGE HOW TO DEFROST AND CLEAN THE APPLIANCE PAGE CARE AND MAINTENANCE PAGE TROUBLESHOOTING GUIDE...

  • Page 6: Before Using The Appliance

    BEFORE USING THE APPLIANCE Your new appliance is exclusively for Keep this handbook for future consultation. domestic use. The low temperature compartment, if present, 1. After unpacking the appliance, make sure can be used for making ice cubes, storing frozen that the door shuts properly.

  • Page 7: Precautions And General Hints

    PRECAUTIONS AND GENERAL HINTS • Use the refrigerator compartment only for storing fresh foods and the low temperature compartment only for making ice cubes, storing frozen food and freezing fresh food ( compartment only). • Do not cover or obstruct the air vents of the appliance.

  • Page 8: How To Operate The Refrigerator Compartment

    HOW TO OPERATE THE REFRIGERATOR COMPARTMENT Switching on the appliance Switching on the appliance Depending on the model, your appliance is fitted with external controls (A) or internal controls (B). Plug in the appliance. If your appliance is equipped with external controls (A): •...

  • Page 9: How To Operate The Low Temperature Compartment

    HOW TO OPERATE THE LOW TEMPERATURE COMPARTMENT The low temperature compartment is at Making ice cubes or at • Fill the ice cube tray 2/3 full of water and In compartments at frozen place it in the low temperature compartment. foods can be stored for the period indicated •...

  • Page 10: How To Defrost And Clean The Appliance

    HOW TO DEFROST AND CLEAN THE APPLIANCE Before servicing or cleaning the appliance, unplug it from the mains or disconnect the electricity supply. Defrosting of the refrigerator compartment is completely automatic. Droplets of water on the rear wall of the refrigerator compartment indicate that the periodic automatic defrost cycle is in progress.

  • Page 11: Care And Maintenance

    CARE AND MAINTENANCE • Periodically clean air vents and the condenser at the rear of the appliance with a vacuum cleaner or a brush. • Clean the outside using a soft cloth. Prolonged disuse 1. Empty the refrigerator. 2. Disconnect the appliance from the mains. 3.

  • Page 12: After Sales Service

    AFTER SALES SERVICE Before calling After Sales Service: 1. See if you can solve the problem yourself with the help of the Trouble-shooting guide. 2. Switch the appliance on again to see if the problem persists. If it does, switch off and wait for about an hour before switching on.

  • Page 13: Electrical Connection

    ELECTRICAL CONNECTION For Great Britain only The wires in the mains lead are coloured in accordance with the following code: BLUE - “NEUTRAL” (“N”) BROWN - “LIVE” (“L”) GREEN AND YELLOW - “EARTH” (“E”) 1. The GREEN AND YELLOW wire must be connected to the terminal in the plug which is marked with the letter “E”...
