Page 1 DE – Betriebsanleitung FR – Mode d‘emploi IT – Istruzioni per l’uso EN – Instruction manual Revolution Z-7789...
Page 2 2 Revolution Z-7789...
Page 3: Dear Customer
Dear customer Finally arrived at YA! Take a seat and enjoy the world of YA! You will see: It is a wonderfull place to be. The appliance must only be used for the intended purpose according to these instructions. Keep the instructions carefully and pass them on to further users.
Page 4: Safety Instructions
■ Regularly check if the mains cable / appliance / extension lead is defective. ■ Only trained personnel should repair electrical appliances. Unskilled repairs can cause considerable danger to the user. ■ Do not use attachments not recommended by the manufacturer. ■ Never put the appliance / cable on hot surfaces or near open flames. 4 Revolution Z-7789...
Page 5 ■ Switch the appliance off and pull the plug out of the mains when it is not in use. Don’t wind the cable around the appliance The appliance is only cut from the mains if the plug is pulled out! WARNING: Do not use this appliance near bathtubs, showers, basins or other vessels containing water. 5 Revolution Z-7789...
Page 6 There is a danger of explosion if batteries are exchanged improperly. Only replace batteries with ones of the same type. ■ Do not put any container (f. ex. vases, etc.) containing liquids on or in the surroundings of the appliance. ■ Subject to technical modifications. No liability for typographical errors. 6 Revolution Z-7789...
Page 7: Key To Symbols
NOTE This symbol and the heading NOTE apply to technical requirements that the user must pay attention to during the activities. 7 Revolution Z-7789...
Page 8: Proper Use Of The Appliance
Improper use of the appliance No warranty for any possible damage can be accepted if the appliance is improperly used, incorrectly operated or repaired unprofessionally. In such a case, any warranty claim is void. 8 Revolution Z-7789...
Page 9: Disposal Of Old Electrical Appliances
The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the appliance, it must be separately collected. Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance. 9 Revolution Z-7789...
Page 10: Scope Of Delivery
Scope of delivery 1 x Revolution Z-7789 Audio System 2 x Speaker 2 x Stand (for speakers) 1 x Stand (for audio system) 1 x Docking Station 1 x Mains plug/mains cable 1 x Remote control (incl. battery) 7 x Different adaptors...
Page 11: Technical Data
260 x 229 x 160 mm without stand Docking Station: 86 x 192 x 110 mm Weight Appliance: 1.8 kg Speaker: 2.3 kg Docking station: 0.34 kg Speaker 28 W x 2 + 15 W x 2 Amplifier 10 W x 2 Protection Class 11 Revolution Z-7789...
Page 12: Operation
Connecting the speakers Unpack the speakers and connect the cables to the right-hand side of the unit. 2 connections for left-hand speaker and right-hand speaker. Locate the speakers in the room to give the best sound quality. 12 Revolution Z-7789...
Page 13: Technische Daten
Power consumption is reduced in standby mode. ■ Remote control Carefully remove the transparent plastic foil from the battery compartment and ■ test if the appliance reacts on the remote control with ON / STANDBY 13 Revolution Z-7789 Technische Daten...
Page 14 This unit can be fastened to the wall. ■ Screws: 3.5 x 34 mm (7 screws supplied) ■ WARNUNG The unit may only be mounted on vertical walls. Check before installation whether the wall can bear three times the weight of the unit. Bring in a qualified craftsman if in doubt, and in any case to drill the holes. 14 Revolution Z-7789...
Page 15 15 Revolution Z-7789...
Page 16 Overview Revolution Z-7789 16 Revolution Z-7789...
Page 17: Aux Input
15 VOLUME / JOG MODE 32 Display mains current and audio source 16 ENTER 33 Dock for adaptor 17 MULTI JOG Wheel 34 Stand 18 Sensor remote control 35 Dock for iPod 19 ON / STANDBY 36 iPod docking station 17 Revolution Z-7789...
Page 18 Overview remote control Revolution Z-7789 18 EQ (Equalizer) 1 ON / STANDBY 19 MUTE 2 Numbers button 20 INFO 3 MENU 21 Battery compartment 4 UP 5 FUNC PREV 7 SELECT 8 NEXT 9 SLEEP 10 DOWN 11 REC 12 PLAY/PAUSE / FM Stereo...
Page 19: Set Clock
NEXT Confirm Press SELECT resp. ENTER Set minutes PREV resp. NEXT Confirm Press SELECT resp. ENTER NOTE If no key is pressed for 10 seconds, the appliance automatically returns to its initial function. The programming is not saved. 19 Revolution Z-7789...
Page 20: Set Alarm
Choose display Set TIMER PREV resp. NEXT Confirm Press SELECT resp. ENTER Choose display ( ENABLE PREV resp. NEXT Confirm Press SELECT resp. ENTER PREV resp. NEXT Choose display ( NOTE shows a listing of the most recent alarm messages. 20 Revolution Z-7789...
Page 21 NEXT ENTER Confirm Press SELECT resp. NOTE Follow the steps given above to set a new time at the timer. ENABLE NEW TIMER After the display appears: Choose display ( PREV resp. NEXT Confirm Press SELECT resp. ENTER 21 Revolution Z-7789...
Page 22: Music Equalizer
INFO on the appliance JOG WHEEL This device has a multifunctional JOG WHEEL to regulate the volume and to navigate through the menus. Changing over VOLUME / JOG WHEEL VOLUME / JOG MODE Press on the appliance 22 Revolution Z-7789...
Page 23 It is possible to hear a CLICK during the adjustment. The clicking stops once the desired loudness is achieved. Playback Start playback Interrupt playback STOP Stop playback PREV NEXT Select track resp. Fast forward or reverse within the actual track Press and hold PREV resp. NEXT 23 Revolution Z-7789...
Page 24 There are 10 preset memory slots. The display shows the numbers with Find a saved frequency Press the numbers button on the remote control Overwrite saved positions: save the new frequency on the desired position. 24 Revolution Z-7789...
Page 25: Internet Radio
■ Maximum number of connections of the desired station has been reached. Try again in a few minutes. ■ The lists are constantly updated. It can happen that the station has been taken off the Internet and is no longer available. 25 Revolution Z-7789...
Page 26 Choose display main menu Press PREV Confirm Press SELECT resp. ENTER Choose display System Set up resp. DOWN MULTI JOG WHEEL Confirm Press SELECT resp. ENTER Choose display Internet set up resp. DOWN MULTI JOG WHEEL Confirm Press SELECT resp. ENTER 26 Revolution Z-7789...
Page 27 The device now connects to the network. If the connection fails, the display once again shows the password input menu. ■ If the Internet connection is broken off, the device attempts to restore the connection automatically by itself. 27 Revolution Z-7789...
Page 28 A list of stored connections can be called up under: Choose display Station list PREV Press Confirm Press SELECT resp. ENTER Choose display My added stations resp. DOWN MULTI JOG WHEEL Confirm Press SELECT resp. ENTER 28 Revolution Z-7789...
Page 29 ENTER Choose display Help resp. DOWN MULTI JOG WHEEL Confirm Press SELECT resp. ENTER Choose display get access code resp. DOWN MULTI JOG WHEEL Confirm Press SELECT resp. ENTER Write down the code! Get access code access code lccw52x 29 Revolution Z-7789...
Page 30 ■ Valid E-mail address ■ Password ■ Radio model (Jupiter 6) If you have already registered, have an account and want to add a new device, log into the account and select My Preferences. Choose “Add another Wi-Fi radio”. 30 Revolution Z-7789...
Page 31 DOWN MULTI JOG WHEEL Browse list of stations resp. ENTER Confirm Press SELECT resp. DOWN MULTI JOG WHEEL Change station: resp. ENTER Confirm Press SELECT resp. NOTE To view further information about the stream press INFO on the appliance. 31 Revolution Z-7789...
Page 32 DRC off / DCR Low / drc high ENTER Confirm Press SELECT resp. MENU Display list Press STATION ORDER: PREV resp. NEXT or operate JOG WHEEL ALPHANUMERIC = Alphabetical ENSEMBLE = Transmitter for the same station VALID = Transmitter with the best reception 32 Revolution Z-7789...
Page 33 MULTI JOG WHEEL Choose resp. Confirm Press ENTER Choose function resp. DOWN MULTI JOG WHEEL Valid / Ensemble / Alphanumeric Confirm Press SELECT resp. ENTER Alphanumeric Alphabetical Ensemble Transmitter for the same station Valid Transmitter with the best reception 33 Revolution Z-7789...
Page 34: Network Stream
Assistant to release domain directories The function allows searching through media files in directories on a network drive. This is a good alternative if you cannot use a media release centre. It is also a further option for finding media files, even if you have the media release centre available. The computer must be set such that “Release domain directories” is available. If the computer asks for a password, input it and the user name. 34 Revolution Z-7789...
Page 35: Media Library
Released directories In order to release directories in Windows the computer must be logged in on the network to a workgroup or a domain. Once this has been set up the directories are released in Windows Explorer. 35 Revolution Z-7789...
Page 36: Computer Name
Input a new password 4. Write down the user name and password NOTE Windows Vista: Call up the Guest account via User Accounts (Control Panel). Allow access for ALL or GUEST. A new user can also be set up. 36 Revolution Z-7789...
Page 37 Setting up the device to use domain directories The password and user name must be input to set up the device so that titles on password-protected network drives can be played back from domain directories. Input the keyword with letters on the display and confirm with OK. 37 Revolution Z-7789...
Page 38 REPEAT ALL repeat all titles (entire CD) REPEAT FOLDER repeat current folder playing 10 seconds of the title random playback of the track Switch on appliance Press ON / STANDBY Select Press FUNC repeatedly 38 Revolution Z-7789...
Page 39 Press and hold PREV resp. NEXT MP3 CD DOWN If the MP3 CD has no directories or folders, 10 titles can be skipped by pressing PREV NEXT respectively on the remote control. To change titles: press and. respectively. 39 Revolution Z-7789...
Page 40: Usb And Sd Card
It can take up to 60 seconds. CAUTION Switch off the appliance before removeing the USB Sticks/SD Card. Do not use an USB FLASH DRIVE with this appliance. Always connect the USB without cable. 40 Revolution Z-7789...
Page 41 This saves the title at the desired number and skips automatically to the next number. Repeat these steps until the list is complete. Playback Press Cancel without saving Press and hold STOP End playback and delete memory Press STOP 41 Revolution Z-7789...
Page 42 This saves the title at the desired number and skips automatically to the next number. Repeat these steps until the list is complete. Playback Press Cancel without saving Press and hold STOP End playback and delete memory Press STOP 42 Revolution Z-7789...
Page 43 Switch on appliance and iPod docking station and conect iPod with docking station (Select ipod Press FUNC repeatedly Start playback Interrupt playback Select track PREV resp. NEXT Fast forward or -reverse within the actual track Press and hold PREV resp. NEXT 43 Revolution Z-7789...
Page 44 When connected to the appliance the iPod automatically charges. ■ When connecting an iPhone to the device you can get a message to the effect that this accessory is DISMISS not optimized for the iPhone. If this message appears: Press on the screen to start playback. 44 Revolution Z-7789...
Page 45 STOP NOTE The titles are saved in a new directory. If USB and SD CARD are connected at the same time, the message appears after pressing RECORD Record to USB Record to Card Changing media Press NEXT 45 Revolution Z-7789...
Page 46 Imported by: CECONET AG Hintermättlistrasse 1 CH-5506 Mägenwil...
