HEXA STANDALONE DVR HSDVR-3308A Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
\
HEXA DVR Manual
─ HEXA ─
STANDALONE DVR
MODEL: HSDVR-3308A
This document contains preliminary information and subject to change without notice.
1
COPYRIGHT 2009 BY HEXACCTV CO.,Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STANDALONE DVR HSDVR-3308A and is the answer not in the manual?

Questions and answers

Related Manuals for HEXA STANDALONE DVR HSDVR-3308A

Summary of Contents for HEXA STANDALONE DVR HSDVR-3308A

  • Page 1 HEXA DVR Manual ─ HEXA ─ STANDALONE DVR MODEL: HSDVR-3308A This document contains preliminary information and subject to change without notice. COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...
  • Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipment has been tested and found to comply with the limits for a class digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 PACKING DETAIL AND INSTALLATION _____________________ 5 1-1 PACKING ____________________________________________________ 5 1-2 Hard Disk Installation _________________________________________ 5 1-3 DVD-RW Installation __________________________________________ 6 2-1 LIVE Mode___________________________________________________ 9 2-2 PLAYBACK Mode____________________________________________ 11 2-3 PTZ Mode __________________________________________________ 13 CHAPTER 3 SETTING UP THE DVR _________________________________ 15 3-1 RECORD SETUP ____________________________________________ 16 3-1.1 Quality &...
  • Page 4 7-1.2 Mobile Application Operation_____________________________ 43 7-1.2.1 Add New Login DVR _______________________________ 43 7-1.2.2 Logging Onto the DVR _____________________________ 43 7-1.2.3 Modify the Login Information of DVR ________________ 43 7-1.2.4 Delete the Login Information of DVR_________________ 44 7-1.3 Live Monitoring Operation _______________________________ 44 7-1.3.1 Scroll the Image ___________________________________ 44 7-1.3.2 Image Quality Setup _______________________________ 45 7-1.3.3 Single or Quad Channel Display_____________________ 45...

  • Page 5: Chapter 1 Packing Detail And Installation

    CHAPTER 1 PACKING DETAIL AND INSTALLATION 1-1 PACKING 1. DVR 2. Quick Start 3. IR Remote Control 4.Batteries x2 5. CD 6. Hard Disk Mount x2 7. Screws x20 8. Power Adaptor 9. Power Cord 10. SATA Cord x3 11. DB 26 Flat Cables (16ch only) 1-2 Hard Disk Installation Step 1) Fix the HDD to rack mount with the screws as indicated.

  • Page 6: Dvd-Rw Installation

    Step 2) Place the HDD on the HDD plate and screw it as indicated. Step 3) Connect the power and the SATA cables as indicated. 1-3 DVD-RW Installation Step 1) Remove the front cover from DVR. COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...
  • Page 7 Step 2) Put the DVD-RW into the DVR as indicated by the arrow. Step 3) Screw the bottom of the DVR as indicated to fix the DVD-RW. Step 4) Connect the power and the SATA cables. COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...
  • Page 8 COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...

  • Page 9: Live Mode

    CHAPTER 2 LIVE, PLAYBACK AND PTZ OPERATIONS The IR remote control and mouse operate differently under each mode; this chapter describes the functions of them under three different modes: LIVE, PLAYBACK and PTZ. 2-1 LIVE Mode You can monitor all the channels, listen to audio signal and have some related operations under LIVE mode.
  • Page 10 Icon Description Resting the cursor on this icon will bring up the following four menu icons. Main menu. Search menu. Backup menu. PTZ mode. Turn on/off recording. Playback. Resting the cursor on this icon will bring up the following five display icons. FREEZE.

  • Page 11: Playback Mode

    Icon Description Recording is on Live Audio is on Live Audio is off Motion detected on the channel Sensor triggered on the channel Video loss detected on the channel USB device detected DVD burner is detected Remote user currently logging into DVR Timer recording is on Red：Timer is set and recording has been started White：Timer is set but recording has not yet been started...
  • Page 12 will show up on the upper center of the screen and the operation panel ( see below picture) will show up at right lower corner of the screen. You can drag the panel by mouse to place it on any location of your screen. Table 2-2.1 Remote control functions under the PLAYBACK mode Button Description...

  • Page 13: Ptz Mode

    Quad display 9-channel display 16-channel display Note：4CH will show quad display; 8 CH will show quad display and 9-channel display. 2-3 PTZ Mode Switch to the PTZ mode by pressing “PTZ” button under the LIVE mode. The PTZ icon will appear on upper left of the screen but it can be re-located on any place of your screen by dragging the mouse.
  • Page 14 number will appear near the top left corner. Table 2-3.2 Mouse operation under the PTZ mode Icon Description Leave PTZ Mode，back to the LIVE mode Pre-set number N. (1~64) Go to pre-set number N. Set current PTZ location at pre-set number N. 「TOUR」...

  • Page 15: Chapter 3 Setting Up The Dvr

    CHAPTER 3 SETTING UP THE DVR To enter the main menu and set up DVR, log-in account and user password are required. The default password of the administrator is “123456”. Please check the “Account Setup” for related setup of other log-in users. Table 3-0.1 Some definition of virtual keyboard.

  • Page 16: Record Setup

    Table 3-0.2 The operation of remote control under the setting menu Item Description Switch to different options under one item Switch to different items MENU Save setup and back to LIVE mode BK-UP / ESC Back to Upper level of the menu ENTER Enter the menu, or display virtual keyboard 3-1 RECORD SETUP...

  • Page 17: 3-1.1 Quality & Frame Rate Setup

    3-1.1 Quality & Frame Rate Setup ： Note 4CH DVR will display 4 channels and 8CH DVR will display 8 channels. Item Description Resolution Choose record resolution from : CIF / HD1(2CIF) / D1. You can setup quality and FPS separately for record type. Record Type Check/uncheck the box will enable/disable recording of that channel.

  • Page 18: 3-2.1 Motion Setup

    3-2.1 MOTION SETUP Item Description Check the box to Enable/Disable Motion Detection for all Motion Detection channels. Check the box to Enable/Disable popup screen function for all Motion Popup channels. When motion is detected in LIVE mode, the detected channel image will pop up in full screen display. 1~16 You can setup independently for each channel.

  • Page 19: 3-2.2 Sensor Setup

    Item Description LOCK/ZOOM Press LOCK/ZOOM to select entire screen as detection area. MUTE / PIP Press MUTE/PIP to deselect entire screen as detection area. STATUS Switch between “select” and “deselect” for cursor-dragging function ENTER Press to function on the selected area with assigned status Press to save the setup and leave MENU Press to cancel the setup and leave...

  • Page 20: Schedule Setup

    High Polarity：Sensor has been triggered. When connected, sensor status will be turned off.. ：Sensor is deactivated, and will not be turned on/off. ： Note 4CH DVR will display 4 channels and 8CH DVR will display 8 channels. 3-3 SCHEDULE SETUP Except from starting recording manually, you can also setup the recording time by weeks and schedule including normal, motion detect, and sensor detect recording type.

  • Page 21: 3-3.2 Holiday Setup

    3-3.2 Holiday Setup Since holidays are different by different country and region, you can setup the holiday of your location accordingly. 3-4 CAMERA SETUP Item Description You can setup independently for each channel. 1~16 ： Note 4CH DVR will display 4 channels and 8CH DVR will display 8 channels.

  • Page 22: Account Setup

    Select to adjust audio volume for CH1 to CH 4 under LIVE mode and Volume recording mode. ‘3-5 ACCOUNT SETUP The Account Setup menu is used to provide role-based permission independently setting for each user (maximum of 4 users) to access DVR over network. The default admin account is 「admin」and password is “123456”.

  • Page 23: Networking Setup

    Utility, Backup and Mask on specific channels while playing back. Note：4CH DVR will display 4 channels and 8CH DVR will display 8 channels. 3-6 NETWORKING SETUP Item Description Connect type Setup mode for network connection: DHCP、LAN、ADSL. HTTP Setup Enter to set up HTTP for remote access into DVR. DDNS Setup Enter to Enable/Disable DDNS function and set up.

  • Page 24: 3-6.1.2 Lan

    3-6.1.2 LAN Select LAN for network connection, the following information is required. Item Description IP Address Enter IP address provided by ISP Subnet Mask Enter IP address of Subnet Mask provided by ISP Enter IP address of Gate way provided by ISP Gateway Enter DNS address provided by ISP.

  • Page 25: 3-6.2 Http Setup

    3-6.2 HTTP Setup Item Description Enable HTTP Check to enable HTTP server. Users can remotely access into the Server DVR over the network if the HTTP function is activated. Port Enter a valid port value from 1 up to 65000. The default value is 80. 3-6.3 DDNS Setup Item Description...

  • Page 26: Ptz & Rs485 Setup

    E-mail can be used as a form of notification when an event occurs (VLOSS, MOTION, SENSOR). Item Description Enable E-mail Check the box to enable/disable E-mal Notification function. Notification SMTP Server Enter to set up SMTP Serve name. User Name Enter to set up User Name.

  • Page 27: System Setup

    Enable PTZ Click the box to Enable/Disable PTZ function for each channel. Protocol Set up the protocol of PTZ cam. The supported protocol are PELCO-P, PELCO-D, KND, LI-LIN. PTZ ID ◀ ▶ Click or press to set up PTZ ID. The valid ID value is from 1 to 64.

  • Page 28: 3-8.1 Display Setup

    3-8.1 DISPLAY SETUP Item Description Turn On / Off OSD display DVR Status Turn On / Off DVR illustration and record status display Date/Time Turn On / Off date and time display Message Turn On / Off message display Channel Name Turn On / Off channel name display Set up the color of border in LIVE , PLAYBACK mode.

  • Page 29: 3-8.2.1 Change Date & Time

    Internet Time Setup Setup automatic synchronization with internet server 3-8.2.1 CHANGE DATE & TIME Users are allowed to setup date and time of DVR manually according to your local time. 3-8.2.2 TIME ZONE SETUP In time zone setup, users can change your time zone and activate Daylight Saving Time function according to your DVR location.

  • Page 30: 3-8.3 Buzzer & Relay Setup

    3-8.3 BUZZER & RELAY SETUP Item Description KEY TONE Enable/Disable keystrokes. Set relay signal to be Normal Close (N.C.) or Normal Open (N.O.). Relay Switch Connection Buzzer Duration Set up the duration from 1~999 seconds. Enable/Disable buzzer operation when the alarm is triggered for ALARM BUZZER sensor, motion and vloss (Video Loss).

  • Page 31: Utility Setup

    EVENT: Display channels with event occurred. The duration time in seconds for the interval between channels under Interval (Seconds) SPOT mode. Skip Video Loss Whether to skip channels without video signal. Channel 3-9 UTILITY SETUP Item Description Select to enter hard disk initialization menu. Please stop HDD Initialization recording before entering this menu.

  • Page 32: Diagnostic

    3-10 DIAGNOSTIC Item Description Version The current firmware version of DVR The connected IP address of DVR. If disconnected from IP Address network, the screen will display”NETWORK DISCONNECT”. MAC Address MAC Address of DVR HDD Volume The capacity of HDD HDD Used Rate Percentage of space used on HDD.

  • Page 33: Search Setup

    Item Description The start time of backup file From The end time of backup file Device Select USB or CD/RW as the backup device Free Space The available space in your backup device Refresh Recalculate the available space of backup device Calculate the size of backup file Calculate Start backup operation.

  • Page 34: 4-2.1 Event Search

    4-2.1 EVENT SEARCH The DVR automatically records events with type, time and channel information included. If there is recording data for an event, a yellow signal will be shown on the left side of time information. Rest your cursor under the line and press “enter”, or left click your mouse to playback the recording data.

  • Page 35: 4-2.1.1 Criteria Setup For Event Search

    4-2.1.1 CRITERIA SETUP FOR EVENT SEARCH The amount of events can be numerous. Therefore, you can facilitate event sorting by setting up “criteria”. Setup “start time” and “end time” for event search, then the search result will be limited to this specific period of time. Only checked events and channels will be sorted in event search as well.

  • Page 36: Chapter 5 Network Surveillance

    CHAPTER 5 NETWORK SURVEILLANCE AP software:「DVR Remote Desktop」can allow you to remotely access and control the DVR from PC. 5-1 AP Software Installation and Setup Step One：Enter the IP address of DVR in IE browser Step Two: Below windows will be shown up. Please enter the user name and password. Default user name is admin and password is 123456.
  • Page 37 Step Three: Click on the link to start downloading the AP software. Step Four: Run or Save our AP software. COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...
  • Page 38 Step Five: If you choose to run the software, Start window will be shown up. Please enter information of login DVR: IP, Port, Username and Password, or choose “Play Recorded File” to open backup files in your PC. Step Six: You’ve logged into the DVR COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...

  • Page 39: Ap Software Operation

    5-2 AP Software Operation Open the file “DVRemoteDesktop.exe”; enter the information of DVR “IP address”, “Port” “Username” and “Password” and click “OK”. You should be able to login DVR successfully and start to use the software. The default username and password is 「admin/ 123456」 After successful login, the operation and interface are the same as local DVR.

  • Page 40: Chapter 6 Specificaitons

    CHAPTER 6 SPECIFICAITONS 1. VIDEO Input Level 1.0 Vp-p±10% Composite, 75Ω Balanced NTSC 480 fps(16CH), 240fps(8CH), 120fps(4CH) Display Speed 400 fps(16CH), 200fps(8CH) , 100fps(4CH) NTSC 720(H) X 480(V) Display Resolution 720(H) X 576(V) Monitor Output 2Vp-p Composite, 75Ω Balanced 2. RECORDING Compression Method H.264 Recording Speed...
  • Page 41 7. ENVIRONMENTAL Operation Temperature 5℃ ~ + 40℃ Humidity Less than 90% 8. PHYSICAL Dimention 430(W) x 293(D) x 55(H) mm Weight 2.5kg (3.5kg including 1 HDD and CD-RW) 9. BACKUP USB Stick Video Data, Audio BACKUP ±RW CD-RW/DVD Video Data, Audio Network Video Data, Audio 10.

  • Page 42: Chapter 7 Mobile Application Installation And Usage

    CHAPTER 7 MOBILE APPLICATION INSTALLATION AND USAGE You can remotely monitor all channels of DVR through your mobile device. The required mobile application is from DVR manufacturer and it supports mobile OS for both Windows mobile 5.0 above and Symbian. 7-1 Mobile Application Installation and Operation for Symbian System.

  • Page 43: 7-1.2 Mobile Application Operation

    7-1.2 Mobile Application Operation After the installation, enter the Program Files menu in your mobile device to run a file called “DVMIDlet”. Select “Menu” at the right lower corner of your mobile screen, 4 commands, Login Add Modify and Delete, will show up.

  • Page 44: 7-1.2.4 Delete The Login Information Of Dvr

    You can use the “Modify” command to change the login information of DVR. The dialogue is identical to that of the “Add” command. 7-1.2.4 Delete the Login Information of DVR “Delete” command can be used to remove the DVR information if it is no longer useful. Select the DVR on the name list then choose “Delete”...

  • Page 45: 7-1.3.2 Image Quality Setup

    Scroll Left Scroll Right Scroll Down 7-1.3.2 Image Quality Setup Select “Quality” under the “Menu” There will be 5 levels for your to choose: Low、 Normal、Middle、High and Highest. 7-1.3.3 Single or Quad Channel Display You can choose single or quad channel display for live monitoring. Select “Single”...

  • Page 46: 7-1.3.5 Rotate The Image

    really different. You can select “Size” under the “Menu” to choose from “Original” or “Fit Screen” to resize the display image. 7-1.3.5 Rotate the image The Live image can be displayed in normal or rotate to 90 degrees. Select “Rotate” under the “Menu” for this operation.

  • Page 47: 7-2.2 Mobile Application Operation

    Please follow the steps cited below to perform the mobile device surveillance function on your mobile device (mobile phone, PDA ...etc). Step 1: In DVR that you’d like to log onto. Main menu Network Setup Application Setup HTTP Setup Check the “Enable HTTP Server”...

  • Page 48: 7-2.2.1 Add New Login Dvr

    7-2.2.1 Add New Login DVR To log into the DVR, you need to enter the logging-in DVR information. Find “Add” under the “OK” then enter logging-in DVR’s IP address, Port number, account name and password. Press “Add” to save this information after entering. COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...

  • Page 49: 7-2.2.2 Logging Onto The Dvr

    7-2.2.2 Logging Onto the DVR Use the Login command to log onto a DVR and monitor live images. If multiple DVRs have been added to the mobile application, they will be listed by name, you can select one to log onto. Note: The fee rate will depend on the telecom c ompany and package fee you go with.

  • Page 50: 7-2.2.4 Delete The Login Information Of Dvr

    You can use the “Modify” command, under the “OK”, to change the login information of DVR. The dialogue is identical to that of the “Add” command. 7-2.2.4 Delete the Login Information of DVR “Delete” command can be used to remove the DVR information if it is no longer useful. Select the DVR on the name list then choose “Delete”...

  • Page 51: 7-2.3 Live Monitoring Operation

    7-2.3 Live Monitoring Operation After successfully log onto the DVR, an operation list will show up when you press “View” that is at the right lower corner of the screen. You can choose which channel to monitor, weather to activate the status bar, alarm and full screen display under this operation list.

  • Page 52: 7-2.3.2 Status Bar

    7-2.3.2 Status Bar A graphical icon will be shown on the status bar if there is event such as motion detected, sensor triggered and video loss to be detected on any channel. You can also uncheck the “Status Bar” under the “View” to inactivate this function. Icon Description Motion detected...
  • Page 53 4. Select “Browse” to change installation path if needed. To check available space on hard disk, please select “Disk Cost” then please select “Next” to the next step. 5..”Confirm Installation” window shows. Select ‘Next’ then the installation starts. COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...

  • Page 54: Cms Login And Environment

    6. Select ‘Close’ to finish installation when the “Installation Complete” window shows. 8-2 CMS LOGIN AND ENVIRONMENT To enter CMS, the administrator’s user name and password are entered. The defaults are ‘admin’ and ‘123456’. After successful login, the following image shows on your screen: COPYRIGHT 2009 BY HEXACCTV CO.,Ltd...

  • Page 55: Dvrs, Groups & Events

    ③ ① ② ④ ⑤ ① DVRs, Groups & Information about DVRs, groups and events. See “9-3 Informa tion List” for detail. Events ② PC information Information about local PC’s hard disk, volume, recording...etc. See “9-4 PC Information and Control” for more detail. and control ③...

  • Page 56: 8-3.1 View Dvr ／ Group List

    ／ 8-3.1 View DVR Group List Single left click on ‘DVR’ or ‘Group’ will expand/collapse DVRs groups. On the DVR list, double left click on a connected DVR will show its image in the main display. “9-6.2 Administration” for further information. On the Group list, double left click on a group will show live image from the channels of the group in the main display.

  • Page 57: Main Display

    8-5 Main Display The main display area is where the live image of DVR is shown. You can drag to change the location of screen for each channel and turn on/off audio signal with mouse. 8-5.1 Audio Control In live mode, you can turn on/off the audio signal of Ch1~Ch4: 「...

  • Page 58: Operation Bar

    8-6 Operation Bar 10 Operations to be listed as below: Table 9-6.1 description of 10 operations: Description Icon User Administration. Please see “9-6.1 User administration” DVR Administration. Please see “9-6.2 DVR Administration” Group Administration. Please see “9-6.3 Group Administration” eMap Administration. It won’t be supported in x10 series. Remote Playback.

  • Page 59: 8-6.2 Dvr Administration

    8-6.2 DVR Administration DVR connections can be added to or deleted from the CMS and their information can be edited. DVR’s channel names can be entered here or downloaded from the DVR by pressing ‘From DVR’. Select “OK” to save the information. 8-6.3 Group Administration A ‘Group’...

  • Page 60: 8-6.4 Hdd Playback

    4. Click “OK” to return to the previous window. 5. Select a display mode. 6. Drag a channel from the lower left panel into the main display to a preferred location. Or, change the channel location in the main display by mouse dragging. 7.

  • Page 61: 8-6.5 File Playback

    8-6.5 File Playback You can play the recorded .irf files by “File Play” in CMS. It allows you to change the display mode, forward or rewind the file and drag the time bar. Icon Description Start Playback. Pause. Stop playback. Fast forward.

  • Page 62: 8-6.6 Snapshot Data

    8-6.6 Snapshot Data It can display all the snapshots you’ve taken in line in “Snapshot Data”. You can review, delete or save as other files here. 8-6.7 Recording Data It can play all the recording files you’ve recorded in line in “Recording Data”. You can play or delete them here.

  • Page 63: Appendix I I-Dvr.nrt Registration

    APPENDIX I I-DVR.NRT REGISTRATION DDNS Registration on I-DVR.NET In the package of each DVR, you will find a sticker shows account information including username and password that allow users to login I-DVR.NET for registration. To register DDNS on I-DVR.NET, please follow the steps as below. Step 1.

  • Page 64: Appendix Ii Db 26 Difinition

    APPENDIX II DB 26 DIFINITION First pin Read Line 編號 編號 WIRE COLOR WIRE COLOR BLUE SENSOR 4 ORANGE GREEN SENSOR 5 RS 485_B YELLOW SENSOR 6 BROWN RLY1_NO ORANGE SENSOR 7 BLACK RS485_A SENSOR 8 WHITE RLY1_COM BROWN SENSOR 9 GRAY BLACK SENSOR 10...
