Wall hung, fanflue, roomsealed, high efficiency gas boiler
Service manual
Riva Plus HE
Models
M296.24SM/C
M296.28SM/C
leave this manual adjacent to the gas meter
Warning:
Service / repairs must be carried out, only by a qualified Gas Safety
Registered Engineer, who will be responsible for the current Regulations for
gas appliances.
Note:
After servicing, complete the relevant Service interval Record section of the
benchmark Checklist of the user and installation manual.
G.C. Appl. No.
47-583-24
47-583-25
CoMbi boilER
CoMbi boilER
