Summary of Contents for Domar HYBRID
- Page 1 H.264 Digital Video Recorder Quick Star Guide Easy to Set your surveillance system Ver.1.1...
- Page 2 Digital Video Recorder User Manual Caution Please read this User manual carefully to ensure that you can use the device correctly and safely This manual is suitable for 4 channel, 8 channel, 16 channel and 32 channel series DVR. In this book, we take 200fps 8 channel DVR as a sample.
-
Page 3: Table Of Contents
Digital Video Recorder User Manual Contents CHAPTER 1- INTRODUCTION ............................4 1.1DVR INTRODUCTION ............................. 4 1.2 MAIN FEATURES ..............................4 1.3 DVR REMOTE CONTROLLER ..........................5 CHAPTER2-DVR INSTALLATION ........................... 6 2.1 INSTALL THE HARD DISK DRIVE .......................... 6 2.2 CONNECT THE CAMERAS AND MONITORS ....................... 7 2.3 CONNECT THE POWER ............................ -
Page 4: Chapter 1- Introduction
Digital Video Recorder User Manual Chapter 1- Introduction 1.1 DVR Introduction This DVR (Digital Video Recorder) is designed especially for CCTV system. It adopts high performance video processing chips and embedded Linux system. Meanwhile, it utilizes many most advanced technologies, such as standard H.264 with low bit rate, Dual stream, SATA interface, VGA output mouse supported, IE browser supported with full remote control, mobile view(by phones), etc., which ensure its powerful functions and high stability. -
Page 5: Dvr Remote Controller
Digital Video Recorder User Manual Feature： H.264 High profile Video compression format G.711 Audio compression format Windows Style GUI, embedded real-time Linux operating system Combines the function of DVR/NVR/HVR together, support pure analog input, pure network HD video input, and analog + network HD video input. -
Page 6: Chapter2-Dvr Installation
Digital Video Recorder User Manual Serial Name Function number Same as POWER button on the POWER Button front panel SEARCH Button Enter playback mode Code input/number input/channel Numeric button switch “10+”(press 0 and 1-6 to switch from channel 11 to 16 ) Same function as QUAD button on QUAD the front panel... -
Page 7: Connect The Cameras And Monitors
Digital Video Recorder User Manual 2.2 Connect the cameras and monitors 2.2.1 Connect the camera signal to the DVR video input via BNC cable, and then connect the DVR video output to the monitor via VGA. If the camera supports PTZ control, connect the camera cable to the DVR video input via RS-485 interface. -
Page 8: Power Off Your Dvr
Digital Video Recorder User Manual 3.1.2 Power off your DVR There are two ways to shut down your DVR: Option 1: Standard Shutdown (soft switch): Enter the main menu, click on Menu→Shutdown. 2: Manual Shutdown (hard switch): Pressing the power supply switch, plug off the power supply. 3.2 Login DVR When the DVR boots up, the user must login and the system will provide the corresponding function according to the user authority. - Page 9 Digital Video Recorder User Manual menu→record function→record configuration to set. Notice: There is at least one read-write hard disk in DVR. Pic.3.2 Record configuration Record configuration set the record plan for each channel. 【Channel】: Choose the corresponding channel number to set the channel. Choose “all” option to set all channels.
-
Page 10: Playback
Digital Video Recorder User Manual 【Alarm】 ：Trigger the external alarm signal in the set time section. The above alarm function is set as follows: when starting recording, the “detection recording” state is on. The video file type is “A”. 3.5 Playback Playback: Access playback mode, Set recording search, recording play, video file storage Pic.3. -
Page 11: Backup
Digital Video Recorder User Manual Previous file Next file Repeat Play Full screen Edit Record backup 3.6 Backup You can back up the video files to external storage through setup Notice: You need to install storage device before backup. If the backup is terminated, the files already backup can playback individually. -
Page 12: Motion Detection
Digital Video Recorder User Manual Pic3.6 Backup2 【Remove】: Clear the file information. 【Add】 ：Show the file information satisfying the set file attributes. 【Backup format】: Choose the backup files format, there are two options: H.264 and AVI. 【Start/Stop】 ：Click Start button to start backup, Click stop button to stop the backup Notice: During backup you can exit this page to carry out other functions. - Page 13 【Enable】: Tick enable means the motion detect function is on. 【Sensitivity】: Choose from the six levels (Lowest, Lower, Middle, High, Higher, Highest) to set the sensitivity. Notice: Only the motion detect under Hybrid mode/Full analog mode have can set the sensitivity, and only the analog channel can set region.
-
Page 14: Ptz Control
Digital Video Recorder User Manual Pic.3.9 Set motion detection time 【Interval】: Only one alarm signal is triggered even there are several motion detect signals in the set interval 【Alarm Output】: Start the external equipment of corresponding linkage alarm when the motion detect alarm is turned on 【Delay】: Alarm lasts a few seconds when the alarm state is turned off. -
Page 15: Network Setting
Digital Video Recorder User Manual Pic.3.10 PTZ control interface 【Speed】: Set the PTZ rotation range, Default range 1-8. 【Zoom】: Click－/＋ button to adjust the zoom of cameras. 【Focus】: Click－/＋ button to adjust the focus of cameras. 【Iris】: Click－/＋ button to adjust the Iris of cameras. 【Hide】: Current interface will be temporarily hidden after click it. -
Page 16: Chapter 4-Network Access Settings And Cloud Technology Introduction
Digital Video Recorder User Manual 【DHCP Enable】:Obtain IP address automatically (not suggested). Notice: DHCP server is preinstalled. 【IP address】:Set the IP address. Default: 192.168.1.10. 【Subnet mask】:Set the subnet mask code. Default: 255.255.255.0. 【Gateway】:Set the default gateway. Default: 192.168.1.1. 【DNS setup】: Domain Name Server. It translates the domain name into IP address. The IP address is offered by network provider. -
Page 17: Cloud Technology Functions And Using Introduction
Digital Video Recorder User Manual Pic.4.1 WEB Login interface Step 2: Login. Enter the user name and password, the administrator user name of factory default is admin, password is blank. After login, please promptly modify the administrator password. Login is successful, display the interface as shown below. Pic.4.2 WEB control interface 4.2 Cloud technology functions and using introduction Cloud technology is the latest network remote access technology;... - Page 18 Digital Video Recorder User Manual Pic.4.3 Connect failed interface Pic.4.4 Connect successfully interface Open web browser, enter cloud access website: www.dvrcenter.net . Login interface as picture 4.5: Pic.4.5 login There are two ways to remote control the device with cloud technology: (1) By device serial No. (2) By user.
-
Page 19: Login By Device Serial No
Digital Video Recorder User Manual 4.2.1. Login by Device serial no. Input Serial No. of DVR and verify code can do remote access (way to get Serial No: “main menu” “info” “version”) 4.2.2. Login by User Customers use their registered user name and password to log in (first time use need to register). After login, needs to add the device (enter “device management”... - Page 20 Digital Video Recorder User Manual After enter into CMS interface, shown in Picture 4.8: Pic.4.8 CMS control interface Click the right corner of “System” settings, switch to the control of management options as below: Pic.4.9 manage First click to add a domain, region name are free to take, after determining the list of selected regional areas to create a domain name, select add device as shown below:...
-
Page 21: Mobile Phone Monitoring
Digital Video Recorder User Manual Pic.4.10 edit As the follow prompts to input required information of the DVR device, confirmed and added successful, repeat the above operation, can add multiple DVR equipments, management and monitoring operations. If you want to modify the equipments which have been added before, selected the needed DVR at first, then click icon to modify the parameters, but also can delete the DVRs which have been added on the regional list through click deletion. - Page 22 Digital Video Recorder User Manual Step 1: DVR settings. The “main menu”“record”, enable extra stream; Step 2: Install the matching mobile phone monitoring software. Obtain corresponding client software from the optical disc (the client software of Android smart phone is vMEyeCloud.apk) and install it on the phone； Step 3: After successful installation, find and run the corresponding client software from “start”“program”...
- Page 23 Digital Video Recorder User Manual Device Name: Set by user; User name: Input user name to login DVR; Password: Input password to login DVR; Serial No.: DVR device No.; Port: default port is 34567; Click OK after finish adding, shown below. Choose the channel which needs to be monitored, preview screen will display properly.
-
Page 24: Chapter 5-Faq And Maintenance
Digital Video Recorder User Manual Chapter 5-FAQ and Maintenance 5.1 FAQ 1. System cannot detect hard disk Possible reasons are as follows: (1)The hard disk power supply line is not well connected. (2)The cables of the hard disk are damaged. (3)The hard disk is damaged. - Page 25 Digital Video Recorder User Manual 7. There is audio signal in the surveillance window but mo audio signal in the playback state. Possible reasons are as follows: (1)Setting issues: the audio option is not chosen. (2)The according channel is not connected with the video. 8.
-
Page 26: Maintenance
Digital Video Recorder User Manual (1)Network is not stable. (2)IP address is conflicted. (3)MAC address is conflicted. (4)The network card of the computer or the hard disk recording machine is bad. 14 There is something wrong with the USB backup or writing a CD. Possible reasons are as follows: (1)The rewritable machine and the hard disk are shared the same data lines.
