Interphone stereo F4 S Quick Manual

EN
QUICK GUIDE
www.interphone.cellularline.com
2 1
1 - Multipurpose button
2 - Multipurpose LED
4
3 - Volume adjustment button +
3
4 - Volume adjustment button -
5 - Recharge / Multipurpose socket and
accessories
6 - Bluetooth® control panel connection guide
7 - Speaker
8 - Microphone
5
6
ASSEMBLY OF THE SLIDE SUPPORT
WITH REMOVABLE CLIP
Take the support and note the best place
to fasten it to the side of the helmet. Insert
the rear part of the clip into the helmet and
couple the other part on the outside.
Insert the screws and tighten gently.
Check position and move
the support if necessa-
ry, by sliding it along.
Tighten the screws with
the screwdriver supplied.
6
ASSEMBLY OF THE ADHESIVE SLIDE
SUPPORT
Take the adhesive support and look for the
best side and place to position it. Clean and
de-grease the part of the helmet where you
are going to stick the support (do not use
any detergents that could damage the hel-
met's finish). Remove the
protective film from the
bi-adhesive, and apply the
support to the helmet.
As the support will not be
able to be moved once
stuck onto the helmet,
take great care with its po-
sitioning, when applying.
for installation of audio kit refer to the help available
www.interphone.cellularline.com
B B
B
A
A A - YELLOW
B - GREEN
www.interphone.cellularline.com - www.cellularline.com
Export Dept. international.interphone@cellularline.com
