Summary of Contents for Estate Swing EST-64

  • Page 1: User Manual

    User Manual...
  • Page 2 EST-64 GSM Remote Control Device Electronic KIT to convert your gate into a GSM gate EST-64 GSM Remote Control Device Diagram EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 3 It has a White List of numbers who are enabled to open the phone, up to 64. When the EST-64 GSM Remote Control Device receives a call, it will check to see if the calling number is in the list. If it is in the list it will reject the call (so there will be no charge –...
  • Page 4 PUK!! EST-64 PROGRAMMING INSTRUCTIONS You can program the EST-64 with SMS commands using your phone. It is safe to do so because in addition to the fact that other people may not know the number of the SIM inserted in it, we also use a Password that makes it impossible for anybody, who doesn’t...
  • Page 5 Access Mode. This command allows you to open only to people that are in the white list or to anybody calling the SIM number. #PWD123456#ACM0 (it is a zero) • EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 6 #CSQ Check GSM signal quality. This command is useful to see what is the GSM network signal level your EST-64 GSM Remote Control Device is receiving. If you send the command: #PWD123456#CSQ? You should receive an SMS with signal quality in range 0 to 31 (if it is 0 we doubt it will ever answer…).
  • Page 7 ADDITIONAL INPUT & OUTPUT PROGRAMMING INSTRUCTIONS The EST-64 also comes with additional 1 Input and 1 Output. The output is connected to an on-board relay which can be activated by sending an SMS command. The Input can be used to generate alarms when triggered. It also can be programmed to count the input active pulses up to 1ms fast or activate the output relay.
  • Page 8 The Input Alert Message can be edited and programmed up to 100 characters long. You can change the displayed text by sending the following commands by SMS message to the unit. Text Command: EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 9 For example, assume you want it sends a counter alert message each time the input has triggered for 5 times, you would send the following SMS message to the unit. EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 10 Activate the output relay 2 for 1 second • Sends a counter alert message once alarm counter reaches the alert value • Function 5: Sends an alert message once triggered • EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 11 You will receive the sub increment value from the unit by SMS. Note: The sub increment counter value will be reset automatically each time the alarm counter reached the alert value. EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 12 Note: The reply message will be send to the recipients (The Administrators) only when the relay has turned on/off. This is to notify the administrators when someone outside the list activates the relays. EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 13 SMS message to the unit. Text Command: #FTRY=F F stands for function 0 – 2 Function Descriptions Function 0: This function is disabled ~ Normal Mode (Default) • EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 14 Example 1, assume you want output relay number 1 to turn off for 20 seconds on 8.30am, you would send the following SMS message to the unit. #PWD123456#SMW=00,30,08,020,1,1; • EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 15 Setting the Output Relay 2 to Supply Voltage or use Dry Contact when Activated To set the output relay 2 to supply DC voltage when activated, please adjust the jumper according to the below diagram EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 16 XXXXXX stands for 6 digits password based on #PWD and it can be changed anytime with #CAP command Example: To reset the unit (with default password 123456), the syntax of the command is the following: *REST#123456 EST-64– USER MANUAL – Rev.2.4 – Technical Support: 1-800-640-4283 COPYRIGHT ©2008 Estate Swing...
  • Page 17 Estate Swing warranties all EST-64 GSM Remote Control Device against defective parts and workmanship for 1 year. Estate Swing shall, at its option, repair or replace the defective equipment upon the return of such equipment to any Estate Swing branch.
