Summary of Contents for SUNRUY SR-P-01
- Page 1 SR-P-01 3D SCANNER USER MANUAL V 0.0.1 SUNRUY TECHNOLOGIES CO.,LTD.
- Page 2 1. Introduction 1.1 What includes 3D scanner: 1pc Drive and software disk: 1pc 1.2 Features VGA(640*480): 30fps, QVGA(320*240): 60fps USB 2.0 Size: about 18*3.5*5cm Output color models available Visual angel: horizontal 58º,vertical 45º，across corners 70º ...
-
Page 3: Software Installation
2. Software installation 2.1 Installation 1、Install 3D scanning driver Install the right drivers based on your computer: Win 32 or Win64. 2. Install software A. Double click “Skanect-1.5.0-win64.exe” to install original program. And tick all plug-in units to install in your computer. Please do not run the program after installation finished. -
Page 4: Scanning Operation
3 Operation 3.1 Scanning operation 1、Connect Scanner to your computer by USB, run Skanect.exe, then show as below: Prepare: settings before scan Record: Start and stop scanning Reconstruct: reconstruction and repair after scanning Process: processing after scanning and reconstruction Share: export scanning file and share to other equipments In the right up corner: OpenNI 2 Sensor : the small icon in green means scanner connected normally. - Page 5 Setting: Recording feedback: Choose GPU if available. If not, choose CPU. Feedback Quality: select the one you need. Offline Recording: recommend choose Key Frames Track Loss Detection: recommend choose On Log File: Open Log File Remember to click “Save” after setting.
- Page 6 3.2. Start scanning preparation a. Click it to start scanning. b. Count down time before start scanning. c. If choose None, you need to stop scan manually. Or you can set the time for scanning. d. Real scene window e. Recognize object scene window f.
-
Page 7: Starting Scanning
3.3 Starting scanning Stop Scanning Green part: scan and rendering finished. Red part: scan finished, but render not finished Tips: 1. How to get a good scan model? The best way is to use rotating table and lifting table. Put the target object or person standing on the rotating table, while the scanner fixed on the lifting table. - Page 8 2. Do not wearing glasses during scanning. 3. You can scan more times until get the satisfied model. 4. Keep the circumstance clean, without other small articles 3.4 Reconstruct You can start reconstruct when you get the satisfied model. Select the right processor and fidelity, then click “ Run” . It will start reconstruct the model. You can click “...
- Page 9 3.5 Process Click “Process” after reconstruct is finished. 1. Mesh Reset : Revoke the mesh process. (e.g. When over watertight make the model not real, you can click Reset to clear)
- Page 10 Watertight: Normally choose Low for smoothing. Then click “Run” 2. Geometry Simplify: It will reduce the faces of model, make the file smaller but down the precision.
- Page 11 Fill Holes: Fill holes and repair surfaces. Select the right one for Strategy, and Low for Smoothing. After fill holes, the scanned models became a solid model. Move and Crop: Rotate and translate. Rotate the model centered on every axises.
- Page 12 Remove Parts: Remove parts smaller than a percentage of the biggest model part. You can set the parameter according to your needs. Color: Colorize: The model will show in color if you click “On” in “Inpaint Colorless. Remove Color: remove the parts with color. Remove Colorless: remove the parts without color.
- Page 13 3.6 Share You can export the model when the process finish. Lcocal: save to the computer in Skn file. Export Model: Export model in Ply, Obj or STL file. (Recommend to export in OBJ file, thus the model can be edit in other softwares.) Web and 3D print: seldom use.
